Summary of Contents for Scanvest AlphaCom 30696902
- Page 1 AlphaCom Flush mount station with front foil FUPT Model 30696902 Scanvest Deutschland GmbH, Berliner Allee 2-4, 30855 Langenhagen www.scanvest.de...
-
Page 2: Table Of Contents
Table Of Contents General Description Features Back box for wall mounting 4 Technical Data Installation Operation Activate Private mode Set Volume Programmierung General Station Programming Programming Direct Access Keys (DAK) Enable Open / Private Selection Enable feature codes for Open / Private feature and volume setting 10 External Connections Overview Settings and Connections Seite 2... -
Page 3: General Description
1 General Description The model 30696902 is a ush mount master station with front foil. It is designed for use in hospital operating rooms or other clean rooms applications with extremely high requirements to hygiene and cleanness. It will be mounted with a specially designed back box for wall mounting (model 32696700). This box can also be used for cavity wall mounting. -
Page 4: Back Box For Wall Mounting
1.2 Back box for wall mounting The back box for wall mounting (model 32696700) was specially designed for use with the FUPT station. This box can also be used for cavity wall mounting. The box is equipped with a snapping mechanism consisting of two spring clips which t into corresponding clips at the front plate. -
Page 5: Technical Data
1.3 Technical Data Item no.: 30696902 Temperature range: 0 o C to +40 o C Humidity range: 10 % - 85 % RH non-condensing Size font plate (WxHxD): 130mm x 280mm x 3 mm Protection class: IP 65 (surface front plate) Performance front foil: Front foil on aluminium plate 3 mm Type of foil:... -
Page 6: Installation
2 Installation • Connect the installation cable coming from an ASLT port of the exchange to the screw terminals marked with a, b, c, d. • If the station shall be permanently in Private mode, make the strap “Open / Private”. Alternatively, one can set the Private mode by dialling a code. -
Page 7: Operation
3 Operation The standard operation of the station is described in the “AlphaCom E user guide” 3.1 Activate Private mode If the station has been enabled in the exchange for this feature: • Dial function code 7887 to switch the station to Private mode •... -
Page 8: General Station Programming
4 Programming The exchange can be programmed with the programming tool AlphaPro to alter and extend factory defaults. The displayed programming windows may di er from versions of the programming tool AlphaPro. 4.1 General Station Programming In this window one can change e. g. directory no. and display text. Seite 8 10.9.2019 This documentation may be updated without notice... -
Page 9: Programming Direct Access Keys (Dak)
4.2 Programming Direct Access Keys (DAK) The FUT station has got 3 DAKs (F1, F2, F3). In add ition two DAK features can be accessed by external keys. The relation between DAK key and DAK programming is as following: DAK line in programming window DAK key External DAK1 External DAK2... -
Page 10: Enable Open / Private Selection 1
4.3 Enable Open / Private Selection In order to use the Open / Private feature from the station it has to be enabled. Enable ag for Open / Private selection 4.4 Enable feature codes for Open / Private feature and volume setting In addition to the previous programming these features must be enabled in the Class of Service this station belongs to, as factory default it is Class of Service COS1. -
Page 11: External Connections
5 External Connections The FUPT station provides connections for external keys. Subscriber connection (a,b,c,d) Terminals for Terminals for DAK1 and DAK2 C and M key Seite 11 10.9.2019 This documentation may be updated without notice... -
Page 12: Overview Settings And Connections
6 Overview Settings and Connections Subscriber connection a, b, c, d Open / Private strap a b c d Terminals for DAK1 and DAK2 Ex.C Terminals for M and C key Ex.M Alternative subscriber Vol.LSP connection with RJ45 socket Vol.MIC Loudspeaker Electret microphone Mic –...
