Delta Five D5r6 Pest Monitoring System

Account Setup & Installation User Guide

PACKAGE CONTENTS ................................................................................................................................... 1

STEP 1: Create an Account ........................................................................................................................... 3

STEP 2: Adding a Property ............................................................................................................................ 4

STEP 3: Adding Devices to the Dashboard ...................................................................................................... 4

STEP 4: Pairing your Device with a Wireless Network ...................................................................................... 6

STEP 5: Mounting the D5r6 Device ................................................................................................................ 8

STEP 6: Block & Guide Installation ................................................................................................................. 9

STEP 7: WRAPPING THE BEDFRAME LEGS .................................................................................................... 10

Monitoring the System .............................................................................................................................. 10

Appendix A .............................................................................................................................................. 13

Appendix B ............................................................................................................................................... 13

Appendix C ............................................................................................................................................... 14

PACKAGE CONTENTS

Single Device Purchase Contents

Table of Contents

Need help?

Do you have a question about the D5r6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Delta Five D5r6

Page 1: Table Of Contents
STEP 3: Adding Devices to the Dashboard ...................... 4 STEP 4: Pairing your Device with a Wireless Network ..................6 STEP 5: Mounting the D5r6 Device ........................ 8 STEP 6: Block & Guide Installation ......................... 9 STEP 7: WRAPPING THE BEDFRAME LEGS ....................10 Monitoring the System ..........................
Page 2 Tweezers may be useful for assisting with the removal of the Blue masking tape on the back of the device. Before installing the D5r6 Device and Block & Guide onto wall be sure to dust entire area with damp cloth and allow time to fully dry to ensure proper adhesion.
Page 3: Step 1: Create An Account
Delta Five devices via MAC addresses to the Wireless Network. If your property employs a Captive Portal/Terms & Conditions portal, it will be necessary to have your Delta Five devices whitelisted to your network. This can be completed by whitelisting the individual MAC addresses or whitelisting the 2 URLs below to allow the devices to pass through the captive portal.
Page 4: Step 2: Adding A Property
If you are not re-directed you may also click the Dashboard icon on the left of the screen and select your property. STEP 3: Adding Devices to the Dashboard A. Once viewing the Property Dashboard, you may add your D5r6 Device(s) by selecting the Add Device Button P a g e...
Page 5 Delta Five D5r6 Account Setup & Installation Guide updated 2.26.18 B. Once on the Add Devices menu, ensure the correct property is selected and enter the Serial Number (located below the barcode on the front of the device) & Nickname...
Page 6: Step 4: Pairing Your Device With A Wireless Network
STEP 4: Pairing your Device with a Wireless Network When you first power on your D5r6 device, it will be in setup mode awaiting network credentials. This mode is denoted by the Red LED blinking one short blink every 1-2 seconds. The LED is located on the front side of the device, the opposite side of the wire.
Page 7 After loading the network credentials and after any power on, the D5r6 device will run through an initialization phase where it tests the network connection and attempts to sync with the D5 Server. The Red LED will indicate any issues the device encounters by the sequence and number of blinks.
Page 8: Step 5: Mounting The D5R6 Device
Choosing a Location Your D5r6 device should be placed on the wall beneath the headboard in the center of the bed approx. 15” from the floor (may vary depending on bed height, mattress thickness, etc.).
Page 9: Step 6: Block & Guide Installation
Prior to Placement wipe down the wall with a damp cloth and allow to dry fully before placing the device. Each Delta Five device comes with a strip of foam tape attached to its perimeter. Remove the light blue cover on all four edges to reveal the foam’s adhesive (tweezers may assist with this step).
Page 10: Step 7: Wrapping The Bedframe Legs
* If you have a platform or solid bed frame type please disregard this step Delta Five D5r6 will provide the earliest detection if pests are prevented from being able to climb from the floor directly onto the bed. This can be accomplished by simply wrapping each of the bed legs with an overlapping pass of double-sided tape, which will deter most pests from attempting to pass.
Page 11 Delta Five D5r6 Account Setup & Installation Guide The 1 pie chart will display your devices that are: • Alerted - need attention and inspected for pest • Resetting – have been reset remotely via the dashboard and will reset the next sync with the server •...
Page 12 If you have disconnected devices usually a power cycle of the device will correct the issue. Simply unplug wait 10 seconds and plug back in. If this does not correct the issue, please refer to the diagnostics table or call Delta Five support.
Page 13: Appendix A
No Network Credentials This will happen the first time you turn on your D5r6 device, after a factory reset, or after the button has been held for 5 or more seconds. Simply search for and connect to the wireless network names ` D5 [Serial- Number]`. Then use a web browser to navigate to `192.168.0.1`.
Page 14: Appendix C
Factory Reset If the D5r6 device is malfunctioning or not responding to any button presses, alerts, etc., a factory reset may be required. Unplug the AIM device, hold the button, and plug it back in. Continue to hold the button as long as the LED is blinking rapidly –...
