Summary of Contents for APART DIWAC
- Page 1 DIWAC Instruction manual...
- Page 3 DIWAC Instruction manual DIWAC manual...
- Page 4 Thanks for purchasing our DIWAC Digital Wallmount Audio Controller. Affordable, versatile, but by no means a compromise...
-
Page 5: Safety Precautions
DIWAC Instruction manual Safety precautions • Keep this manual for future reference. • Take care of your connection wires, they should be free of damage. Damaged wires may result in poor performance or malfunctions and can cause damage to installations. - Page 6 AUDIO CONTROLLER damaged, please contact your dealer before opening it. • Please note that this unit must be protected from moisture and is meant for indoor use only. Features and benefits • Inconspicuous and elegant design • Easy and foolproof 2-wire system • Polarity-independent wiring system • Phantom powered over the communication wire • Industry standard in wall chassis dimensions...
- Page 7 DIWAC Instruction manual • Hardwired addressing • 2 x 12 characters white backlit LCD display • Automatic power save function • Preconfigured for immediate plug & play use on supported systems • Functionality is reprogrammable via the master unit’s graphical user interface...
-
Page 8: Connecting And Installing The Unit
Connecting and installing the unit Please power off your master unit before connecting the DIWAC. It is possible to use standard low voltage approved wires or cables such as standard CAT5 cables. The controller will be hardwired to a specific zone. The polarity of the wires does not matter. - Page 9 DIWAC Instruction manual The connector is not permanently fixed and can be easily disconnected from the controller. This makes installation a breeze. Connect the wires here.
- Page 10 AUDIO CONTROLLER The controller is equiped with 4 mm pins that fit the metal mounting plate for easy installation. the 4mm pins fit here.
- Page 11 Selection of audio volume using the “VOLUME” up and down buttons. In the graphic interface of your main unit, you are able to configure new functions. Consult the manual of your main unit for more details. DIWAC will only work with supported main units.
- Page 12 AUDIO CONTROLLER...
- Page 13 DIWAC Instruction manual...
-
Page 14: Specifications
AUDIO CONTROLLER Specifications Dimensions 83 x 83 x 9 mm Cut-out dimensions approx. 51 mm diameter or 51 x 51 mm minimally Mounting depth minimally 20 mm Connectors 2-pole connectors up to 2.5 mm Fits in E-MODIN and N-MODIN Weight 72 g including wall mount chassis Power supply... - Page 16 Audioprof nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
