Technologic Systems TS-ETH100 Getting Started

OVERVIEW
The TS-ETH100
Ethernet port. The TS-ETH100 is compatible with both Technologic Systems x86 and ARM
single board computers.
10/100 Ethernet Port
✔
Jumper selectable I/O and IRQ
✔
PC/104 Dimensions 3.6 x 3.8 inches
✔
Wake-on-LAN
✔
Linux driver and utilities available
✔
RoHS compliant (Restriction of Certain Hazardous Substances)
✔
The TS-ETH100
embedded MAC with on-chip PHY. It interfaces with the PC/104 connector via 16-bit data
bus and the register map is NE2000 compatible. The ASIX solution features Wake-on-LAN
functionality, enabling the Ethernet chip to enter in sleep mode with programmed wake-up on
the recepetion of a magic network package.
PRODUCT VIEW
HARDWARE CONFIGURATION
The TS-ETH100
Also, it is possible to do PC/104 16-bit access using only the 64-pin PC/104 connector in
ARM mode if the ARM jumper is ON. Jumpers IRQ5, IRQ6 and IRQ7 (ARM IRQs 22, 33 and
40, respectively) selects the desired ISA IRQ line for the TS-ETH100 MAC.
There are two on-board LEDs for the MAC, indicating speed of the link and network activity
on the cable.
I/O ADDRESS
The PLD and MAC I/O address locations can be configured using jumpers Add1 and Add2
according to the table below:
© Nov, 2007
GETTING STARTED WITH TS-ETH100
is a PC/104 peripheral board (standard format) that provides a 10/100
TS-ETH100 features include:
provides an integrated 10/100 ethernet port through the ASIX AX88796B
jumpers select one-of-three IRQ lines and one-of-four I/O address regions.
www.embeddedARM.com
10/100 ETHERNET PERIPHERAL BOARD
