- Page 1 ZIPSCREEN-SKYLIGHT ASSEMBLY MANUAL November 2018...
-
Page 2: Table Of Contents
Information is supplied upon the condition that the persons receiving the information will make their own determination as to its suitability for their purposes prior to use. Rollease Acmeda assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the information included herein. -
Page 3: Section A: | Overview
28� Crown Wheel | S60 9� Zip Tube Reducer | Long 19� Skylight Tape Spool 29� Drive Wheel Set | S60 10� RB10 Booster 20� Lift Tape Page� 01 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 4: Bill Of Materials
Not Supplied Somfy M50 Motors (Round Head / Star Head) mm [in] W - 61 [2.40] MT01-1145-06900x AUTOMATE | ARC FT SLIM Motor mm [in] Page� 02 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 5: Deductions
PROPRIETARY & CONFIDENTIAL www.rolleaseacmeda.com THE INFORMATION CONTAINED IN THIS DRAWING I ITEM CODE: ROLLEASE ACMEDA. ANY REPRODUCTION IN PART WRITTEN PERMISSION OF ROLLEASE ACMEDA IS PRO Page� 03 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 6: Section B: | Preparation
PROPRIETARY & CONFIDENTIAL DIMENSIONS www.rolleaseacmeda.com THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF IN "MM" ROLLEASE ACMEDA. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE REV. WRITTEN PERMISSION OF ROLLEASE ACMEDA IS PROHIBITED. FABRIC PREPARATION CUT FABRIC TO SIZE Refer to ‘BOM’... -
Page 7: Weld Specifications
SECTION B: | PREPARATION WELD SPECIFICATIONS To achieve a quality weld, Rollease Acmeda recommend using an Impulse Welding Machine. Ultrasonic, Wedge and Hot Air Welding Machines can be used at the manufacturer’s discretion. Dedicated Welding Jig & Impulse Welding Machines available through Rollease Acmeda WELDING TIPS Ensure welding area and fabric is clean and free from dust and dirt�... -
Page 8: Fabric Specifications
NOTE: Melt zip at either end to prevent fraying WELD ZIP/SPLINE TO TOP OF FABRIC & SPLINE/POCKET TO BOTTOM NOTE: Trim zip/splines to cutout size Page� 06 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 9: Section C: | Assembly
STEP 3� SWING BOX COVER ON & SNAP ON END PLATE COVERS NOTE: If cover wont snap in bend snap feature on cover extrusion where it meets the end plate tabs Page� 07 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 10: Motor/Spool Box Assembly
BOX BACK (& ‘BOX TOP’ FOR BOX100) END PLATE COVERS NOTE: If cover wont snap in bend snap feature on cover extrusion where it meets the end plate tabs Page� 08 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 11: Fabric Tube Assembly
STEP 2� ASSEMBLE BOOSTER COMPONENTS, PRESS SPLIT PIN TO CONNECT IDLER TO BOOSTER STEP 3� ASSEMBLE IDLER SIDE COMPONENTS STEP 4� INSERT IDLER ASSEMBLIES INTO TUBE Page� 09 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... - Page 12 NOTE: Neatly wrap up ribbon and tie up to avoid damage and tangles Page� 10 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda...
-
Page 13: Motor/Spool Tube Assembly
STEP 1� ATTACH MOTOR HEAD PLATE TO MOTOR AS REQUIRED AU/EU *No assembly required at this stage STEP 2� ASSEMBLE MOTOR COMPONENTS, CROWN & DRIVE STEP 3� ASSEMBLE MOTOR ASSEMBLY, SPOOLS & IDLER Page� 11 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 14: Side Channels
STEP 1� INSERT AND FIX FUNNELS INTO INNER RAILS NOTE: Pre-drill holes in the extrusion prior to assembly STEP 2� INSERT AND FIX BOTTOM CAP INTO INNER RAILS Page� 12 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda... -
Page 15: Section D: | Installation Preparation
PREPARE & PACK ASSEMBLED PARTS 1� Spring/Fabric Box 2� Motor/Spool Box 3� Spring/Fabric Tube 4� Motor/Spool Tube 5� U Channel 6� Inner Rails w/ Funnel End Caps Page� 13 Zipscreen Skylight Assembly Manual | November 2018 2018 ©Copyright All Rights Reserved Rollease Acmeda...
