Operating Instructions for the EmulsiFlex -C5
G
F
E
AVESTIN, Inc.
2450 Don Reid Drive, Ottawa, ON, Canada, K1H 1E1, e-mail:avestin@avestin.com, website:www.avestin.com
Tel: -613-736-0019, Fax: -613-736-8086, US & CDN customers call toll free: 1-888-AVESTIN (283-7846)
No voice mail: a qualified person will answer your call in the language of your choice: English, Deutsch, Français
High Pressure Homogenizer
JACKETED
CONTAINER
A
B
C
D
www.avestin.com
EmulsiFlex Principle of Operation:
A high pressure pump (C) pushes the product
through an adjustable homogenizing valve (D).
The product can also be passed through a
membrane (E). It can be collected (G) or
recycled to the reservoir (A) via tubing/pipes
or heat exchanger (F).
EmulsiFlex equipment can be delivered as:
1-High pressure homogenizer (A,C,D,F,G)
2-High pressure filter/extruder (A,C,E,G)
3-Homogenizer/filter/extruder combination
(A,C,D,E,G)
4-Two-phase homogenizer/filter/extruder with precision
metering pumps, or as shown to the left (A,B,C,D,E,F,G).
Advertisement
Table of Contents
Related Manuals for Avestin EmulsiFlex-C5
Summary of Contents for Avestin EmulsiFlex-C5
- Page 1 2450 Don Reid Drive, Ottawa, ON, Canada, K1H 1E1, e-mail:avestin@avestin.com, website:www.avestin.com Tel: -613-736-0019, Fax: -613-736-8086, US & CDN customers call toll free: 1-888-AVESTIN (283-7846) No voice mail: a qualified person will answer your call in the language of your choice: English, Deutsch, Français...
- Page 2 This is due to 1.2 Do not run the instrument dry for more than a few improvements or technical advancements. The changes do cycles. If the instrument is not lubricated by a liquid, the not alter any of the functions described below. www.avestin.com...
- Page 3 EmulsiFlex- C5 was delivered. This container should the product is 30000psi/207MPa despite the fact that on be used if you need to return the instrument to AVESTIN some EmulsiFlex the maximum is given as 25000psi/172MPa. For most applications an incoming for updating or servicing (see Figure 20).
- Page 4 Connect (5) to pressurize the sample. After the pump is Figure 3). primed the cap can be removed after first removing the Quick Connect from the cap. If the sample is viscous (e.g. yoghurt), the sample cylinder must be kept under pressure to help the pumping process. www.avestin.com...
- Page 5 Figure 6: Homogenizing pressure can be measured using 145psi/1.0MPa. When processing volumes greater than a pressure transducer (16) attached to an electronic meter 1L it is less costly to run the EmulsiFlex-C5 with an air (21). Filtration/extrusion pressure can be measured using compressor than with bottled gas.
- Page 6 3.2.3 The pressure of the filtration/extrusion process can be monitored by a gauge (19) as shown in Figure 6. This AVESTIN also supplies simple cooling coils where less gauge is supplied with all filter/extruder units. If using the stringent cooling is required (see Figure 8). The...
- Page 7 AVESTIN under catalogue number C5CYLPLU1 (shown in Figure 9). Figure 10: The EmulsiFlex-C5 can be submerged in a temperature controlled water bath to the level shown 3.7.2 Let the entire sample pass through the instrument, then return it to the sample cylinder and repeat.
- Page 8 4. Specific Applications: Extruder @ 500psi, 100nm pores Homogenizer @ 20kpsi Homogenizer @ 20kpsi, Extruder The EmulsiFlex-C5 is capable of handling an extremely @ 500psi, 100nm pores wide range of applications. Only a few of the most Homogenizer @ 20kpsi, Extruder common applications are outlined below.
- Page 9 Almost any type of cleaning EmulsiFlex check valve and homogenizing valve manual. agent can be used. Contact AVESTIN directly if you do not have this manual; please have your serial number available. 5.1.3 Put the sample cylinder back in place and tighten the nut gently.
- Page 10 7.1 Seal Removal: available. 7.1.1 Place the EmulsiFlex-C5 on a stable, flat surface. Remove the air motor (Figure 16, 1) by turning counter- 6.1.2 The check valves are not closing properly. See 6.3.2.
- Page 11 7.2.9 Reattach any hoses/fittings necessary to run the 7.2.3 Position the white, high pressure seal (Figure 17, 4) EmulsiFlex-C5. Check the operation of the new seal by with the spring down, in the hole in the centre of the running water through the system. Briefly run the insertion tool (Figure 17, 6).
- Page 12 8.2.1 LiposoFast-Basic: This hand-powered unit is the smallest extruder system made by AVESTIN (0.1mL to 1.0mL). The instrument is made up of two, gas-tight, glass syringes (0.25, 0.5 or 1.0mL) mounted in a housing that holds a polycarbonate membrane.
