Summary of Contents for QEI 7RSP1
- Page 1 UG-1010 INSTALLATION/OPERATION MANUAL MODEL 7RSP1 Radio Synthesizer Panel Manual No. 906 November 2018...
- Page 2 Furthermore, QEI reserves the right to make changes to any products herein described to improve reliability, function or design. QEI does not assume liability arising to the application or use of any product or circuit described herein; neither does it convey any license under its patent rights nor the rights of others.
- Page 3 UG-1010 Radio Synthesizer Panel Revisions Revision Description Date Release to Production February 1990 Formatting Update June 2013 Formatting Update February 2016 Updated QEI Address November 2018 Copyright © 2016 QEI Contents...
-
Page 5: Table Of Contents
Equipment Location ............. 5 2.3.1 Environment ............5 Interconnecting Wiring ............5 2.4.1 External Wiring............5 2.4.2 Radio Control Lines ..........5 2.4.3 Terminal block Connections ........ 10 3 Operating Instructions ............10 Operation ................10 Copyright © 2016 QEI Contents... -
Page 7: Introduction
Request to Send (RTS) signal from the ASCII/external modem port on the Central Processing Panel is set, data is transmitted to the 7RSP1 Radio Synthesizer Panel. The data is processed and converted to the protocol used by the radio receiver. Once the radio has been keyed, the data is then sent to the radio transmitter in the form of Frequency Shift Keying (FSK). - Page 8 +5 V dc when off or sink 300 rnA when on. These are controlled by a command byte from the RTU. One application for these outputs is to key one or two RF transmitters. Specifications Copyright © 2016 QEI...
- Page 9 -8 V to +8V. The output offset can be adjusted over the same range . Baseband Bit Rate: Programmable from 10 to 300 bps with accuracy of 0.1% or 0.1 bps, whichever is greater. Copyright © 2016 QEI Specifications...
-
Page 10: Installation
2.1.2 Missing Items Each 7RSP1 Radio Synthesizer Panel includes a parts list at the end of the manual. Check all hardware against the parts list and immediately report any shortage to QEI Compare instruction manuals and drawings to the Documentation List and/or packing list and report any shortage to QEI. -
Page 11: Equipment Location
(equipment may be safely stored from -55°C to +85°C). Interconnecting Wiring The 7RSP1 Radio Synthesizer Panel which is normally part of the Model RCU-5500 Radio Communication Unit is wired and connected at the factory. Connectors Jl and J2 are plug in connectors to other electronic subassemblies. When replacing a 7RSP1 Radio Synthesizer Panel, these connectors are simply inserted into the Panel connectors. - Page 12 4990 ohms - series 1 82-3 100 ohms - parallel 1 S2-4 S2-5 Direct Output XMT 2 499 ohms - series 2 S2-6 4990 ohms - series 2 S2-7 100 ohms – parallel 2 S2-8 Interconnecting Wiring Copyright © 2016 QEI...
- Page 13 UG-1010 Radio Synthesizer Panel Figure 2-1. Dip Switch S2 Settings Copyright © 2016 QEI Interconnecting Wiring...
- Page 14 Figure 2-2 illustrates the basic circuit configuration. TABLE 2-4. OUTPUT ATTENTUATION TABLE SWITCH STATE FUNCTION S1-1 S1-2 Attenuate Output 14db S1-2 S1-1 Boost Output ldB S1-1 Attenuate Output 4db S1-4 S1-3 Select De-emphasis S1-3 S1-4 Select Flat Response Interconnecting Wiring Copyright © 2016 QEI...
- Page 15 OBSERVE ALL SAFETY RULES WHEN WORKING WITH AC POWER LINES Power Power for the 7RSP1 Radio Synthesizer Panel is applied to connector J1, pins 1 and 2. Pin 1 requires +12 V dc, pin 2 is common. Copyright © 2016 QEI...
-
Page 16: Terminal Block Connections
Aux Key 1 Operating Instructions Operation The 7RSP1 Radio Synthesizer Panel does not contain any operating controls which require a user's interface. The panel, when installed in a system, operates unattended. Turn on and turn off procedures usually involve controls associated with a power supply which is part of the system.
