MULTIFUNCTION GENERATOR

WF1967/WF1968

Instruction Manual (Operations)

NF Corporation

nbn Austria GmbH

Table of Contents

Need help?

Do you have a question about the WAVE FACTORY WF1968 and is the answer not in the manual?

Questions and answers

Summary of Contents for NF WAVE FACTORY WF1968

Page 1 MULTIFUNCTION GENERATOR WF1967/WF1968 Instruction Manual (Operations) NF Corporation nbn Austria GmbH...
Page 3 DA00048287-002 MULTIFUNCTION GENERATOR WF1967/WF1968 Instruction Manual (Operations)
Page 5: Preface
 Preface  Thank you very much for purchasing our "Multifunction Generator WF1967/WF1968". To use the instrument in a safe and correct manner, please first read the next section titled "Safety Precautions".  Caution symbols used in this manual The following caution symbols are used in this manual. Be sure to observe these caution symbols and their contents to ensure the safety of the user and avoid damage to the equipment.
Page 6 7. Creating Arbitrary Waveforms This chapter describes how to input and edit arbitrary waveforms from the panel control. 8. Convenient Use of 2-channel Equipment (WF1968 Only) This chapter describes how to coordinate the settings of two channels. 9. Synchronizing Multiple Units This chapter describes how to configure a multi-phase oscillator by connecting multiple units of this product.
Page 7: Safety Precautions
 Safety Precautions  To ensure safe use, be sure to observe the following warnings and cautions. NF Corporation shall not be held liable for damages that arise from a failure to observe these warnings and cautions. This product is a Class I instrument (with protective conductor terminal) that conforms to the JIS and IEC insulation standards.
Page 8: Other Symbols
 Do not modify the product. Do not modify the instrument under any circumstances. Modification of the instrument could cause unexpected accidents or failures. NF Corporation has the right to refuse to repair any instruments modified by unauthorized persons.  Safety-related symbols The general definitions of the safety-related symbols used on this product and in the instruction manual are provided below.
Page 9 potential is restricted to 42Vpk or less (since this product is grounded when being used, the potential of the enclosure equals the grounding potential).  Requesting waste disposal To protect the environment, ensure that this device is disposed of by an appropriate industrial waste processor.
Page 10 WF1967/WF1968...
Page 11: Table Of Contents
Table of Contents Page  Preface  ....................... i 1. Overview .......................... 1-1 Features ........................1-2 Operating Principles ....................1-4 2. Preparations Before Use ....................2-1 Checking Before Use ....................2-2 Installation ....................... 2-3 Grounding and Power Supply Connection ............... 2-5 Firmware Update .....................
Page 12 4.3.2 To Change Waveforms ................... 4-15 4.3.3 Shortcut Keys for Changing Basic Parameters ..........4-16 4.3.4 Functions of ENTER/CANCEL/UNDO Key ............. 4-17 4.3.5 Change Display Unit ..................4-18 4.3.6 CH1/CH2 Switching Key and Active Channel (WF1968 Only) ......4-20 4.3.7 Operations Available on Utility ................
Page 13 4.7.11 Setting PWM ....................4-70 Setting and Operation of Sweep ................4-71 4.8.1 Sweep type (Sweep type) ................4-71 4.8.2 Screen for Setting and Operation of Sweep ............ 4-71 4.8.3 Common Setting and Operation of Sweep ............4-74 4.8.4 Setting Frequency Sweep ................4-82 4.8.5 Setting Phase Sweep ..................
Page 14 7. Creating Arbitrary Waveforms ................... 7-1 Basics ........................7-2 Display Procedure and Overview of Screen for Creating/Editing Arbitrary Waveforms7-3 Creating New Arbitrary Waveform ................7-5 Simple Arbitrary Waveform Creating Example ............7-6 Outputting Created Arbitrary Waveform ..............7-7 Saving Created Arbitrary Waveform ................. 7-7 7.6.1 Saving to Internal Memory ................
Page 15 11.6.2 Recalling from the USB Flash Memory ............11-19 11.7 Deleting the Saved Sequence................11-20 11.7.1 Deleting from the Built-In Memory ..............11-20 11.7.2 Deleting from the USB Flash Memory ............11-20 11.8 Outline of Screen ....................11-21 11.9 Individual Description of Step Control Parameters ..........11-23 11.10 Tips for Sequence Creation .................
Page 16 17.1 Oscillation Mode ....................17-2 17.2 Waveform ......................17-2 17.2.1 Standard Waveform ..................17-2 17.2.2 Arbitrary Waveform ..................17-2 17.3 Frequency, Phase ....................17-3 17.3.1 Frequency....................... 17-3 17.3.2 Phase ......................17-4 17.4 Output Characteristics ................... 17-4 17.4.1 Amplitude ....................... 17-4 17.4.2 DC Offset ......................
Page 17 17.14 Synchronization of Multiple Units ................. 17-25 17.15 User-defined Unit ....................17-26 17.16 Other Functions ....................17-26 17.17 Options ........................ 17-27 17.18 General Characteristics ..................17-27 WF1967/WF1968 xiii...
Page 18 Figures and Tables Page Figure 1-1 WF1967 Block Diagram ..................1-4 Figure 1-2 WF1968 Block Diagram ..................1-5 Figure 3-1 Front Panel of WF1967 ..................3-2 Figure 3-2 Rear Panel of WF1967 ..................3-3 Figure 3-3 Front Panel of WF1968 ..................3-4 Figure 3-4 Rear Panel of WF1968 ..................
Page 19: Overview
Overview Features ........................1-2 Operating Principles ....................1-4 WF1967/WF1968...
Page 20: Features
1.1 Features Features The WAVE FACTORY "WF1967 Multifunction Generator" and "WF1968 Multifunction Generator" are multifunctional oscillators based on DDS (Direct Digital Synthesizer). The WF1967 features one channel and the WF1968 features two channels.  Maximum Frequency: 200MHz (Sine wave), 70MHz (Square wave, Pulse) ...
Page 21 1.1 Features  Two-channel ganged function with 2 phases, constant frequency difference, constant frequency ratio, etc. (only WF1968).  Each channel uses a floating ground with the enclosure to reduce the effects of ground loops.  Supports the synchronization of multiple units to configure a multiphase oscillator. ...
Page 22: Operating Principles
1.2 Operating Principles Operating Principles  WF1967 Block Diagram Analog section 400kHz BW ±1V 約2.2MS/s Approx. 2.2 MS/s MOD/ADD Waveform 波形メモリ memory 16Mbit ANALOG CONT. 外部変調/ External modulation/ 外部加算 SSRAM 100MHz BW External 切換え addition switching ± 10V Vref PG AMP CONT FCTN 840MS/s...
Page 23: Figure 1-2 Wf1968 Block Diagram
1.2 Operating Principles  The maximum output voltage of this product is 20Vp-p, 4Vp-p or 800mVp-p depending on whether or not the 1/5x ATT or the 5x amp is used. Correspondingly, the external addition gain changes to 10x, 2x or 0.4x. ...
Page 24 1.2 Operating Principles  In order to synchronize multiple units by a signal to REF OUT (frequency reference output), it sends a channel synchronization (WF1968 only) signal to the Analog section of each channel.  Power Supply  Continuously supplies power from the AC/DC source directly connected to the power input. ...
Page 25: Preparations Before Use
2. Preparations Before Use Checking Before Use ....................2-2 Installation ....................... 2-3 Grounding and Power Supply Connection ............... 2-5 Firmware Update ..................... 2-6 Calibration ....................... 2-6 WF1967/WF1968...
Page 26: Checking Before Use
Please confirm the contents after take out them from the container. If there are any signs of damage to the exterior of the product or if any of the accessories are missing, please contact NF Corporation or dealer. • Checking the Exterior Please check that equipment has any damages on the panel, knobs and connectors.
Page 27: Installation
2.2 Installation Installation a) Installation location Do not place the instrument with the rear side down. It may damage the connectors and hinder ventilation. Place the equipment on the flat surface such as a desk so that the four rubber feet and stands rest on that surface.
Page 28 2.2 Installation the instrument surface. Otherwise, the surface treatment might be altered and/or its paint might be damaged. d) Rack mounting method This product can be mounted in a 19-inch IEC, EIA standard rack, or a JIS standard rack using a rack mounting kit (optional). In a rack, you can mount just one unit, or two units side by side.
Page 29: Grounding And Power Supply Connection
2.3 Grounding and Power Supply Connection Grounding and Power Supply Connection Be sure to ground the product. WARNING This product uses a line filter, which may cause electric shock if the product is not grounded. To prevent electric shock accidents, connect the product to ground. This product is automatically grounded when its three-pole power supply plug is connected to a three-pole power outlet with a protective conductor terminal.
Page 30: Firmware Update
2.4 Firmware Update Firmware Update How to check the version of the product of the firmware, refer to Section 13.6.  P. 13-3 Specific steps of the latest version and update the firmware, will be provided at the support page of our Web page (http://www.nfcorp.co.jp/index.html).
Page 31: Panels And I/O Terminals
3. Panels and I/O Terminals Panel Component Names and Functions ..............3-2 I/O Terminals ......................3-6 Cautions on Floating Ground Connection .............. 3-18 WF1967/WF1968...
Page 32: Panel Component Names And Functions
3.1 Panel Component Names and Functions Panel Component Names and Functions This section describes the names and functions of the components on the front panel and rear panel. 3.1.1 Front Panel of WF1967 MENU key MODE key Numeric keypad Basic parameters Displays the top menu Changes the oscillation mode Used for numerical input and waveform setting...
Page 33: Rear Panel Of Wf1967
3.1 Panel Component Names and Functions 3.1.2 Rear Panel of WF1967 Power supply input P.2-5 Air outlet P.2-3 GPIB connector USB connector Multi I/O connector Used for sweeps, sequence control and output of synchronization codes. P.3-15 Frequency reference output terminal P.3-13 External 10 MHz frequency reference input terminal P.3-12...
Page 34: Front Panel Of Wf1968
3.1 Panel Component Names and Functions 3.1.3 Front Panel of WF1968 MENU key MODE key Numeric keypad Basic parameters Displays the top menu Changes the oscillation mode Used for numerical input and waveform Allows waveform, frequency, P.4-11 P.4-27, P.4-58, setting amplitude and DC offset to be P.4-14, P.4-15 P.4-71, P.4-88...
Page 35: Rear Panel Of Wf1968
3.1 Panel Component Names and Functions 3.1.4 Rear Panel of WF1968 CH2 External trigger input terminal P.3-11 CH1 External trigger input terminal P.3-11 Power supply inputP.2-5 Air outletP.2-3 GPIB connector USB connector Multi I/O connector Used for sweeps, sequence control and output of synchronization codes.
Page 36: I/O Terminals
3.2 I/O Terminals I/O Terminals WARNING To prevent electric shocks, do not apply a voltage exceeding 42Vpk (DC + AC peak) between the ground of the BNC connectors insulated from the enclosure and the enclosure. Also, do not apply a voltage exceeding 42Vpk (DC + AC peak) between the grounds of the BNC connector groups insulated from the enclosure.
Page 37: Waveform Output (Fctn Out)
3.2 I/O Terminals 3.2.1 Waveform Output (FCTN OUT) WF1967 WF1968 CH1 FCTN OUT CH2 FCTN OUT FCTN OUT [Insulated from [Insulated from [Insulated from enclosure] enclosure] enclosure] This is the main output. As a mechanical switch is used to turn the waveform output on or off, chattering may occur when turning the output on/off, and this may cause unintended waveforms to be output.
Page 38: Synchronization/Sub-Output (Sync/Sub Out)
3.2 I/O Terminals 3.2.2 Synchronization/Sub-output (SYNC/SUB OUT) WF1967 WF1968 SYNC/SUB OUT SYNC/SUB OUT [Insulated from SYNC/SUB OUT [Insulated from enclosure] enclosure] [Insulated from enclosure] A synchronization signal is output according to the secondary waveform/internal modulation signal, waveform or oscillation status. This signal can be used as the synchronization signal for oscilloscope. As shown in the following table, the output signal can be selected according to the oscillation mode.
Page 39 3.2 I/O Terminals WF1968 are separate. Reference phase for the modulation source is an internal modulation, there is in addition to the main output, signal that the value set in the modulation phase [ModPhs] has been added will be used in actual modulation.
Page 40: External Modulation/Addition Input (Mod/Add In)
3.2 I/O Terminals 3.2.3 External Modulation/Addition Input (MOD/ADD IN) WF1967 WF1968 MOD/ADD IN [Insulated from MOD/ADD IN MOD/ADD IN enclosure] [Insulated from [Insulated from enclosure] enclosure] When the modulation source is external in the modulation mode except FSK and PSK, an external modulation signal is input.
Page 41: External Trigger Input (Trig In)
3.2 I/O Terminals 3.2.4 External Trigger Input (TRIG IN) WF1967 WF1968 CH2 TRIG IN CH1 TRIG IN TRIG IN This terminal can be used as external trigger input in the following cases. The polarity setting can be changed.  Start trigger of single sweep  P.4-77 ...
Page 42: External 10Mhz Frequency Reference Input (10Mhz Ref In)
3.2 I/O Terminals 3.2.5 External 10MHz Frequency Reference Input (10MHz REF IN) WF1967 WF1968 10MHz REF IN 10MHz REF IN [Insulated from [Insulated from enclosure] enclosure] This terminal can be used for the following purposes.  When frequency accuracy higher than the frequency accuracy specification of this product is required, or when you want to use the same frequency reference as a different signal generator Input the 10MHz reference signal from an external frequency standard.
Page 43: Frequency Reference Output (Ref Out)
3.2 I/O Terminals  Input Characteristics Input voltage 0.5Vp-p to 5V p-p Maximum allowable input 10Vp-p 1kΩ, AC coupling Input impedance Input frequency 10MHz (±5ppm(±50Hz)) Input waveform Sine or square wave (50±5% duty) Signal GND Insulated from the enclosure and each channel waveform output (maximum 42Vpk) Check Do not input any signal to External 10MHz Frequency Reference Input to prevent...
Page 44 Check Do not connect any equipment other than WF1967, WF1968, and the equipment specified by NF Corporation to the frequency reference output. The special signal that is output from this terminal during synchronization may make the operation of such connected equipment unstable.
Page 45: Multi-I/O (Multi I/O)
3.2 I/O Terminals 3.2.7 Multi-I/O (MULTI I/O) WF1967 WF1968 MULTI I/O MULTI I/O This feature can be used for sweep and sequence control. It outputs the step synchronization code for the sequence.  Control Input for sweep oscillation mode Sweep oscillation can be controlled as follows using 3 bit logic input.  P.4-81 Start Starts sweep from beginning with falling input.
Page 46: Figure 3-5 Multi-I/O Connector Pin Configuration Diagram
3.2 I/O Terminals Check To prevent malfunction due to exogenous noise when not using the multi-I/O connector, it is recommended that the control input be set to prohibited.  P.4-81 Figure 3-5 Multi-I/O connector pin configuration diagram Table 3-2 Multi-I/O connector pin assign Sweep Oscillation Optional cable color Pin No.
Page 47 10kΩ, pull up to +5V Input impedance Output voltage TTL level (low: 0.4V or lower, high: 2.7V or higher) Signal GND Same potential as the enclosure Connector Mini-Dsub 15pin The connection cable is optional. Please contact NF Corporation or dealer for details. WF1967/WF1968 3-17...
Page 48: Cautions On Floating Ground Connection
3.3 Cautions on Floating Ground Connection Cautions on Floating Ground Connection The signal ground of the BNC terminals for FCTN OUT, SYNC/SUB OUT, and MOD/ADD IN is shared, but since it is insulated from the enclosure (ground potential), it can be connected to the equipment that has a different potential.
Page 49: Figure 3-6 Cautions On Floating Ground Connection For Wf1967
3.3 Cautions on Floating Ground Connection  Cautions on floating ground connection for WF1967 Use with potential Use with potential difference of 42Vpk or difference of 42Vpk less! or less! Enclosure ground Use with potential difference of 42Vpk or less! Enclosure ground Figure 3-6 Cautions on floating ground connection for WF1967 ...
Page 50 3.3 Cautions on Floating Ground Connection MEMO WF1967/WF1968 3-20...
Page 51: Basic Operations
4. Basic Operations Power On/Off and Restoration of Settings ..............4-2 Screen Configuration and Operation ................4-6 Basic Settings and Operations ..................4-12 Setting for Main Items ....................4-26 Using Variable Parameter Waveforms ................ 4-52 Using Arbitrary Waveforms ..................4-53 Setting and Operation of Modulation................
Page 52: Power On/Off And Restoration Of Settings
4.1 Power On/Off and Restoration of Settings Power On/Off and Restoration of Settings 4.1.1 How to Turn Power On/Off  Power-on operation The start screen is displayed Press the power switch The power is turned on Power off state (standby state) Once the power is turned on, a self test is executed, and then the equipment becomes operable.
Page 53: Restoration Of Settings At Power-On
4.1 Power On/Off and Restoration of Settings 4.1.2 Restoration of Settings at Power-on When the power is on with the power switch, the settings before the previous time the power was switched off are restored. The output on/off at power on can be set on the Utility.  P.4-24 However, if the power is directly cut off while the power is on, the settings are set to the contents of the setting memory number 1 when the power supply is resumed.
Page 54 4.1 Power On/Off and Restoration of Settings the power is turned on again. • The settings before the previous power-off are restored. • The output on/off setting at power on can be changed on the Utility.  P.4-21 • The Sequence Oscillation mode and Sequence state (restarts from beginning in Run/Hold) are also restored.
Page 55 4.1 Power On/Off and Restoration of Settings b) Restoration of settings at power supply on/off This is the case when you collectively turn on/off the power supply for this product and other devices which are mounted in a rack. When the power supply is cut off while the power is on, the power is automatically turned on the next time the power supply is resumed.
Page 56: Screen Configuration And Operation
• Uncalibrated status UCal Displayed when the calibration information of the product is lost due to a problem, and the prescribed performance cannot be maintained. As this indicates a failure, please contact NF Corporation or Dealer. • Overheating status Temp Displayed when the internal temperature of the product is abnormally high.
Page 57 4.2 Screen Configuration and Operation  Mode display section Displays the oscillation mode and the channel mode (WF1968 only) of this product. • Oscillation mode The current oscillation mode is displayed. CONT (continuous oscillation)/MODU (modulated oscillation)/ SWEEP (sweep oscillation)/BURST (burst oscillation) Oscillation Mode For details on the oscillation mode setting see ...
Page 58: Switching Display Format With Tabs (To Display Waveform Graph)
4.2 Screen Configuration and Operation 4.2.2 Switching Display Format with Tabs (To Display Waveform Graph) When multiple display formats can be selected, the display format switching tabs are displayed on the left side of the screen. For example, if the [Graph] tab screen is displayed, you can set the parameters while checking the image of the output waveform.
Page 59 4.2 Screen Configuration and Operation b) To switch the display format The Single tab screen In the left example, the Single tab screen is displayed is displayed. On this screen, the settings are displayed in text format. The Graph tab is Use the arrow keys or the modify knob to selected select the Graph tab.
Page 60: To Use Usb Flash Memory(Switching With Tab)
4.2 Screen Configuration and Operation 4.2.3 To use USB flash memory(Switching with tab) In the store / recall screen of setting, arbitrary waveform, and sequence settings, switch the operation target by tab selection to internal memory or USB flash memory. a) To switch the storage and reading destination When USB interface is not used, it will appear as "DISK"...
Page 61: Top Menu
4.2 Screen Configuration and Operation 4.2.4 Top Menu Arbitrary waveform editing, various system settings, saving and recalling settings and others can be done by selecting the desired item from the top menu. a) To display the top menu Pressing the MENU key displays the following top menu window. The menu items are displayed Select the desired item with the arrow keys or the modify knob and then press ENTER key.
Page 62: Basic Settings And Operations
4.3 Basic Settings and Operations Basic Settings and Operations 4.3.1 To Change Frequency, Amplitude, and Other Values a) To change a value with the up/down arrow keys (or the modify knob) Select the desired item with the arrow keys or the modify knob. In the left example, the [Frequency] field is selected.
Page 63 4.3 Basic Settings and Operations Increment or decrement the value of the digit using the up/down arrow keys or the modify knob. In the left example, the value is changed to 2 kHz. The value of the digit is The change is immediately reflected to now 2.
Page 64 4.3 Basic Settings and Operations b) To change a value with the numeric keypad [0]...[9] Select the desired item with the arrow keys or the modify knob. In the left example, the [Frequency] field is selected. The frequency Item is selected. selection The current frequency...
Page 65: To Change Waveforms
4.3 Basic Settings and Operations 4.3.2 To Change Waveforms When the FCTN key is pressed, waveforms which can be selected will lit on the numeric keypad. Current waveform is flashing. At the same time, a selection list of waveforms will open.
Page 66: Shortcut Keys For Changing Basic Parameters
4.3 Basic Settings and Operations 4.3.3 Shortcut Keys for Changing Basic Parameters The selection list or input field for waveform, frequency, amplitude, DC offset, and oscillation mode can be immediately opened by using the corresponding basic parameter shortcut key.  Frequency The frequency input field is opened ...
Page 67: Functions Of Enter/Cancel/Undo Key
4.3 Basic Settings and Operations 4.3.4 Functions of ENTER/CANCEL/UNDO Key  Functions of ENTER key The ENTER key can be used to perform the following actions. • Open the input field or selection list for the selected item. • Set the value input from the numeric keypad. •...
Page 68: Change Display Unit
4.3 Basic Settings and Operations 4.3.5 Change Display Unit a) To change the unit prefix (k, m, M, etc.) Frequency is used as an example here. For amplitude and pulse width, you can use a similar way. Select frequency and then press the ENTER key to open the input field.
Page 69 4.3 Basic Settings and Operations b) Change Vp-p, Vrms, user-defined unit, etc. Amplitude is used as an example here. For frequency and pulse width, you can use a similar way. Select amplitude and then press the ENTER key to open the input field. Press the [Unit] soft-key to move the cursor to "Vp-p".
Page 70: Ch1/Ch2 Switching Key And Active Channel (Wf1968 Only)
4.3 Basic Settings and Operations 4.3.6 CH1/CH2 Switching Key and Active Channel (WF1968 Only) Each time the CH1/CH2 switching key is pressed, the channel to be set is switched alternately. This key is disabled on the setting screens that are not dependent on the channel.
Page 71: Operations Available On Utility
4.3 Basic Settings and Operations 4.3.7 Operations Available on Utility a) Displaying the Utility menu When the MENU key is pressed, the top menu opens. Then, select Utility. This opens the Utility menu. b) Utility menu External 10MHz frequency Initialization reference ON/OFF External addition External 10MHz...
Page 72 4.3 Basic Settings and Operations sequence start on/off settings for when the power is restored after being cut off.  P.4-24 • REMOTE I/F select [Remote] Selects GPIB and USB and set the GPIB address. Also displays the USB ID.  P.13-2 •...
Page 73: To Restore Initial Settings
4.3 Basic Settings and Operations 4.3.8 To Restore Initial Settings Restore the initial settings from the Utility. Restoring the settings to the initial state will turn off the output for continuous oscillation, sine wave, 1kHz, and 0.1Vp-p/open. For a list of the initial settings refer to  P.16-2. When you press the MENU key, the top menu is displayed.
Page 74 4.3 Basic Settings and Operations b) Power-on settings Specifies the waveform output on/off state and/or sequence state when the power is turned on. The following are the 3 available. • Off[Off] Output is always off. Oscillator mode(not sequence mode). • On[On] Output is always on.
Page 75 4.3 Basic Settings and Operations When the power-on output setting is completed, select [OK], and then press the ENTER key. The change of the power-on output setting is applied, and the window is closed. When you do not want to apply the change of the power-on output setting, select [Cancel] and press the ENTER key, or press the CANCEL key.
Page 76: Setting For Main Items
4.4 Setting for Main Items Setting for Main Items This section describes how to set the main items that are set in the Oscillator. When you press the MENU key while another screen is displayed, the Top menu is displayed. Select [Oscillator].
Page 77: To Set Oscillation Mode
4.4 Setting for Main Items 4.4.2 To Set Oscillation Mode MODE key Press the MODE key or use the arrow keys and modify knob to select the MODE item. Pressing the ENTER key will open the oscillation mode selection list. Current Oscillation mode list Oscillation...
Page 78: To Set Waveforms
4.4 Setting for Main Items 4.4.3 To Set Waveforms Pressing the FCTN key or using the arrow keys and modify knob to select [Fctn] will cause the selectable waveforms above the numeric keypad to light. At the same time, a selection list of waveforms will open.
Page 79: To Set Period
4.4 Setting for Main Items 4.4.5 To Set Period Period can be set instead of Frequency. The following two methods are available to change from the frequency display to the period display:  Use the soft-key [Freq] / [Period] The input field of Frequency opens. When the current Frequency is displayed, the soft-key [Period] is displayed.
Page 80: To Set Phase
4.4 Setting for Main Items 4.4.6 To Set Phase a) Setting procedure Select the [Phase] field and then press the ENTER key to open the phase input field. [Phase] is displayed at first page. Select the digit to be changed by using the right or left arrow key, and then use the up or down arrow key or the modify knob to increment the value.
Page 81 4.4 Setting for Main Items  The phase difference between channels can be changed in synchronous oscillation and 2 phase oscillation (WF1968 only) The difference between the phase settings of each channel is the phase difference between the channels. CH1 waveform output When [Phase setting of CH1 minus Phase setting of CH2] is negative, the...
Page 82: To Set The Synclator Function
4.4 Setting for Main Items 4.4.7 To Set the Synclator Function Select [Synclator] and press the ENTER key to turn the Synclator function on or off. Frequency of waveform output and external signal added to TRIG IN will synchronize when the Synclator function is on. In this case, the phase difference between the added external signal and the output signal can be freely adjusted in the [Phase] settings.
Page 83: To Set Amplitude
4.4 Setting for Main Items 4.4.8 To Set Amplitude a) Setting procedure Press the shortcut-key AMPTD to open the amplitude input field. Or select the [Amplitude] field and then press the Amplitude ENTER key. input field [Amplitude] is displayed at the first page. If [High] is displayed in the [Amplitude] field, press the AMPTD key again.
Page 84 4.4 Setting for Main Items d) Restriction on AC + DC The maximum total value of AC amplitude and DC offset is restricted to ±10V/open (110MHz or less) or ±2V /open. For example, when the AC amplitude is 5Vp-p/open, DC offset is restricted to the range from -7.5V/open to +7.5V/open.
Page 85: To Set Dc Offset
4.4 Setting for Main Items 4.4.9 To Set DC Offset a) Setting procedure Press the shortcut-key OFFSET to open the DC offset input field. Or select the [Offset] field and then press the ENTER DC offset key to open the DC offset input field. input field [Offset] is displayed at the top left on the first page.
Page 86: To Set Output Level With High/Low Level
4.4 Setting for Main Items 4.4.10 To Set Output Level with High/Low Level The output level can be set with the top end value (high level) and the bottom end value (low level) of a waveform instead of amplitude and DC offset. a) To change Amplitude/DC offset display to High/Low display There are the following three methods to change the amplitude/DC offset display to high/low display:...
Page 87 4.4 Setting for Main Items b) Restriction on AC + DC Depending on the oscillation frequency, high level and low level are restricted to a range of -10V to +10V/open (110MHz or less) or -2V to +2V/open. The maximum range also differs depending on the range setting of output voltage or Ext Add setting.
Page 88: To Set Waveform Polarity And Amplitude Range
4.4 Setting for Main Items 4.4.11 To Set Waveform Polarity and Amplitude Range a) Setting procedure Selecting the Polarity/Amplitude Range icon to the right of the waveform name display will show the current polarity and amplitude range settings. Press the ENTER key to open the selection list for the polarity/amplitude range.
Page 89 4.4 Setting for Main Items c) How to determine amplitude range Waveform is changed as follows when Amplitude is changed. Pay attention how the waveform changes as the Amplitude is changed, and decide the amplitude range. By default, waveforms which oscillate to both polarities are set to ± FS while unipolar waveforms are set to 0/+FS.
Page 90: How To Use Auto Range/Range Hold For Output Voltage
4.4 Setting for Main Items 4.4.12 How to Use Auto Range/Range Hold for Output Voltage Auto-range is selected by default. The optimum range is automatically selected according to the amplitude and DC offset (including high/low level settings) settings. When the range is changed, a transitional voltage is generated.
Page 91: To Set Load Impedance
4.4 Setting for Main Items 4.4.13 To Set Load Impedance By matching the setting value of the load impedance to an actual loading condition, the amplitude and the DC offset (including the setting according to high level and low level) can be set with the voltage that appears to the load end.
Page 92: To Add External Signal
4.4 Setting for Main Items 4.4.14 To Add External Signal It is possible to output by adding an external signal to a waveform output. a) To Connect addition signal Connect an addition signal to the external modulation/addition input (MOD/ADD IN) BNC terminal on the front panel of the WF1967 or on the rear panel of the WF1968.
Page 93 4.4 Setting for Main Items External addition setting window When the external addition settings is opened window opens, select the desired output setting and press the ENTER key. When the selection list opens, select the desired setting and then press the Set the external ENTER key.
Page 94: To Set Duty Of Square Wave
4.4 Setting for Main Items 4.4.15 To Set Duty of Square Wave The waveform is assumed to be set as square wave [Square]. For how to set the waveform,  P.4-15. The setting unit for duty is % only, and it is not possible to set or display with time. a) How to set the duty When the [Duty] field is selected and the ENTER key is pressed, the duty input...
Page 95 4.4 Setting for Main Items c) Difference between standard and enhanced duty variable range Variable range Features Setting range: 0.0100% to 99.9900% Standard • Duty can be changed within the range where jitter is low and the pulse does not disappear. •...
Page 96: To Set Pulse Width And Rising/Falling Time Of Pulse Wave
4.4 Setting for Main Items 4.4.16 To Set Pulse Width and Rising/Falling Time of Pulse Wave The waveform is assumed to be set as pulse wave [Pulse]. For how to set the waveform,  P.4-15. The pulse width can be set with either time or duty. The rising time and the falling time can be set with time only.
Page 97 4.4 Setting for Main Items c) To toggle pulse width time and pulse width duty  Pulse width time → Pulse width duty The input field of pulse width time opens. When the current pulse width time is displayed, the soft-key [Duty] is displayed. Press the key opens the input field of Pulse width duty, and the display changes from [Width] to [Duty].
Page 98 4.4 Setting for Main Items f) Definition and restriction of pulse width, leading time and trailing time The definitions of pulse width, leading time and trailing time are shown in the following figure. Pulse width Rising time Falling time Cycle However, the setting range is restricted mutually as for pulse width, leading time, trailing time, and frequency as shown below.
Page 99: To Set Ramp Wave Symmetry
4.4 Setting for Main Items 4.4.17 To Set Ramp Wave Symmetry The waveform is assumed to be set to ramp wave [Ramp]. For how to set the waveform,  P.4-15. The setting unit for symmetry is % only, and it is not possible to set or display in units of time. a) How to Set Symmetry When the [Symm] field is selected and the ENTER key is pressed, the input field...
Page 100: To Use Sub Waveforms
4.4 Setting for Main Items Outputs the main signal's waveform reference phase synchronization signal (50% duty square wave which rises at the main signal's 0° point).  Sub Waveform [SubFctn] Outputs the sub waveforms common to the only frequency of main signal. ...
Page 101 4.4 Setting for Main Items • Up ramp wave [UpRamp] A selection button will appear when choosing an arbitrary waveform. This button will open a screen to select a arbitrary waveform. A selection item for the bandwidth will also appear when selecting noise. c) To Set the Sub Waveform Frequency When the condition 1 of the above it will be forced to the same frequency as the main waveform.
Page 102: Using Variable Parameter Waveforms
4.5 Using Variable Parameter Waveforms Using Variable Parameter Waveforms a) Outputting Variable Parameter Waveforms(PWF) Press the FCTN key to display the waveforms above the numeric keypad and select the key ([5] key) corresponding to the PWF. The waveform which is currently set as the PWF is output. Similar to other waveforms, the waveform's polarity and amplitude range may also be changed.
Page 103: Using Arbitrary Waveforms
4.6 Using Arbitrary Waveforms Using Arbitrary Waveforms a) Outputting Arbitrary Waveforms(ARB) Press the [8] key Press the FCTN key to display the on the numeric waveforms above the numeric keypad and keypad to output select the key ([8] key) corresponding to an arbitrary waveform (ARB).
Page 104: Setting And Operation Of Modulation
4.7 Setting and Operation of Modulation Setting and Operation of Modulation 4.7.1 Modulation Types The following 8 types of modulations are available. • FM: Frequency Modulation  P.4-61 • FSK: Frequency Shift Keying Binary Frequency Shift Keying.  P.4-62 • PM: Phase Modulation  P.4-63 •...
Page 105: Screen For Setting And Operation Of Modulation
4.7 Setting and Operation of Modulation 4.7.2 Screen for Setting and Operation of Modulation The following explains the common screen configuration of the modulated oscillation mode and modulation function (in other modes). Settings and operations are performed in the Oscillator setting screen. When you press the MENU key while another screen is displayed, the Top menu is displayed.
Page 106 4.7 Setting and Operation of Modulation  Modulation type [ModType] Select from FM, FSK, PM, PSK, AM, AM (DSB-SC), DC offset modulation, and PWM.  P.4-58 Off (modulation function not used) is also available as a selection in sweep oscillation mode and burst oscillation mode.
Page 107 4.7 Setting and Operation of Modulation  Internal modulation phase [ModPhs] /Sub waveform phase [SubPhs] This is the phase of the internal modulation source when the modulation function is turned on and set to internal modulation. Changes the phase difference between the reference phase of the internal modulation source and the waveform output.
Page 108: Common Settings And Operation Of Modulation
4.7 Setting and Operation of Modulation 4.7.3 Common Settings and Operation of Modulation The following explains the common settings and operation independent of the modulation type. a) To set the oscillation mode modulation Press the MODE key to open the oscillation mode selection list.
Page 109 4.7 Setting and Operation of Modulation waveforms where [RAW] is displayed in the [Type] field of the selection screen of arbitrary waveforms are in array format. On the other hand, arbitrary waveform where [Point] is displayed in the [Type] field are in control point format. In arbitrary waveforms in this format, the entire waveform is developed with 8192 points so that the features of the waveform may remain as much as possible.
Page 110 4.7 Setting and Operation of Modulation Modulation function on and Modulation function off or internal modulation external modulation Waveform reference phase Waveform reference phase synchronization[Sync] synchronization[Sync] Internal modulation synchronization [ModSync] Internal modulation waveform Sub waveform [SubFctn] [ModFctn] Output disabled [Off] Output disabled [Off] *1: Cannot be selected in FSK or PSK.
Page 111: Setting Fm
4.7 Setting and Operation of Modulation 4.7.4 Setting FM The output frequency changes according to the instantaneous value of modulation signal. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) Example of FM When the modulating signal swings to a positive side, the frequency shift of the output signal increases.
Page 112: Setting Fsk
4.7 Setting and Operation of Modulation 4.7.5 Setting FSK A binary frequency deviation modulation that output frequency is switched between the carrier frequency and the hop frequency according to the modulating signal. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) Example of FSK The phase continuity of output signals is maintained though the frequency changes abruptly.
Page 113: Setting Pm
4.7 Setting and Operation of Modulation frequency is output for high-level input. When the polarity is set as negative [Low], that is reversed. 4.7.6 Setting PM The output phase changes according to the instantaneous value of modulation signal. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) Example of PM When the modulating signal swings to a positive side, the phase shift of the output signal increases.
Page 114: Setting Psk
4.7 Setting and Operation of Modulation external modulation/addition input terminal. It reaches the specified peak phase deviation at ±1V input. 4.7.7 Setting PSK A binary frequency deviation modulation that the output phase offsets according to the modulation signal. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) Example of PSK Because the phase changes abruptly, the output signal waveform is discontinuous.
Page 115 4.7 Setting and Operation of Modulation and modulation phase [ModPhs]. Internal [Int] cannot be selected during sweep oscillation mode. Set the polarity of the trigger when the modulation source [Source] is external [Ext], and then enter the modulation signal (TTL level) to the external trigger input terminal. When the polarity is set as positive [High], the phase deviation of zero is output for low-level input, and the specified phase deviation is output for high-level input.
Page 116: Setting Am
4.7 Setting and Operation of Modulation 4.7.8 Setting AM The output amplitude changes according to the instantaneous value of modulation signal. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) Example of AM When the modulating signal swings to a positive side, the amplitude of the output signal increases.
Page 117 4.7 Setting and Operation of Modulation When the modulation source [Source] is internal [Int], set the modulation waveform [ModFctn], modulation frequency [ModFreq], and modulation phase [ModPhs]. Internal [Int] cannot be selected during sweep oscillation mode. When the modulation source [Source] is external [Ext], enter the modulating signal to the external modulation/addition input terminal.
Page 118: Setting Am (Dsb-Sc)
4.7 Setting and Operation of Modulation 4.7.9 Setting AM (DSB-SC) The output amplitude changes according to the instantaneous value of modulation signal. AM without carrier frequency element. DSB-SC is abbreviation of Double Side Band - Suppressed Carrier. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) AM (DSB-SC) example The amplitude of output signal increases when the absolute value of the amplitude of modulation signal is large.
Page 119: Setting Dc Offset Modulation
4.7 Setting and Operation of Modulation 4.7.10 Setting DC Offset Modulation The DC offset changes according to the instantaneous value of modulation signal. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) DC offset modulation example When the modulating signal swings to the positive side, the DC offset of the output signal increases in the positive direction.
Page 120: Setting Pwm
4.7 Setting and Operation of Modulation 4.7.11 Setting PWM The duty of the square wave and the pulse wave is changed depending on instantaneous value of the modulation signal. For the modulation setting screen and the common operation method, please refer to P.4-55, P.4-58 a) Example of PWM When the modulating signal swings to a positive side, the duty of the output signal increases.
Page 121: Setting And Operation Of Sweep
4.8 Setting and Operation of Sweep Setting and Operation of Sweep 4.8.1 Sweep type (Sweep type) Sweep can be done for the following five types: • Frequency sweep  P.4-82 • Phase sweep  P.4-83 • Amplitude sweep  P.4-84 •...
Page 122 4.8 Setting and Operation of Sweep c) Second page of the setting screen: Screen for Setting the Sweep The following figure is an example of selecting the frequency as a sweep type. Indicates that the second page is displayed Sweep type Sweep function Sweep start value Sweep Mode...
Page 123 4.8 Setting and Operation of Sweep d) Third page of the setting screen: screen for setting the modulation function and synchronization/sub output terminal Indicates that the third page is displayed Modulation Modulation width Modulation frequency Modulation source Pressing the NEXT key switches the Synchronization display to the first...
Page 124: Common Setting And Operation Of Sweep
4.8 Setting and Operation of Sweep 4.8.3 Common Setting and Operation of Sweep This section describes the common settings and operations regardless of the items to sweep all together. a) To sweep oscillation mode Press the MODE key to open the oscillation mode selection list.
Page 125 4.8 Setting and Operation of Sweep e) To sweep as sawtooth wave Set the sweep function [SwpFctn] on the second page of the setting screen One-way sweep as One-way [OneWay]. For frequency sweep, linear Sweep value [Lin-OneWay] or log [Log-OneWay] is available for the slope.
Page 126 4.8 Setting and Operation of Sweep To start sweep with trigger Set the sweep mode [SwpMode] on the second page of the setting screen as single [Single]. Because a trigger signal is necessary, set a trigger source in trigger [Trig] on the same 2nd page. For trigger setting, ...
Page 127 4.8 Setting and Operation of Sweep  Oscillation stop unit (usually set as 1 cycle [Cycle]) When you want to stop the oscillation every half cycle, set the oscillation stop unit [OscStop] to half cycle [HalfCycle] on the second page of the setting screen. When it is set as 1 cycle [Cycle], it is oscillation with integer cycle.
Page 128 4.8 Setting and Operation of Sweep The soft-key [Start] and TRIG key can be used for manual trigger operation. However, in the case of WF1968, the TRIG key only works on the channel side where the display is active. For the channel where the display is active,  P.4-20 When only manual trigger operation and remote trigger operation are used for a trigger, set the trigger source as external [Ext].
Page 129 4.8 Setting and Operation of Sweep p) To output sweep stop value When the soft-key [StpState] is pressed, it enters into the status to output the sweep stop value. You can check the status of tested equipment with sweep stop value. The soft-key [StpState] is displayed when the output is not at the sweep stop value.
Page 130 4.8 Setting and Operation of Sweep  When [X-Drive] is selected A signal with the value of -3V to +3V/open corresponding to the sweep is output from the synchronization/sub-output terminal. The voltage changes linearly in proportion to sweep elapsed time. The voltage also changes linearly in proportion to sweep elapsed time, even if logarithmic sweep [Log-OneWay] and [Log-Shuttle] is selected as the sweep function in frequency sweep.
Page 131 4.8 Setting and Operation of Sweep Continuous sweep One way Shuttle Stop value Stop value Marker value Marker value Sweep value Start value Start value Sweep Low at Low from sync signal first start to stop SwpSync half (marker disabled) Sweep sync signal Low from...
Page 132: Setting Frequency Sweep
4.8 Setting and Operation of Sweep stopped, the sweep (out-going or return for shuttle) will start from the beginning. 4.8.4 Setting Frequency Sweep For the sweep setting screen and the common operation method, please refer to P.4-71, P.4-74 a) Frequency sweep example Examples of a continuous sweep and linear shuttle.
Page 133: Setting Phase Sweep
4.8 Setting and Operation of Sweep • Marker frequency [Marker] (second page of the setting screen) P.4-79 • Stop level [StpLvl] (second page of the setting screen) P.4-76 The setting used for gated single sweep only. • Oscillation stop unit of the gated single sweep [OscStop] (second page of the setting screen)  P.4-76 The setting used for gated single sweep only.
Page 134: Setting Amplitude Sweep
4.8 Setting and Operation of Sweep Select from continuous, single, or gated single.  P.4-75 • Sweep function [SwpFctn] Select from one-way, shuttle.  P.4-75 It is possible to set with center phase [Center], and span phase [Span], instead of start phase, and stop phase.
Page 135: Setting Dc Offset Sweep
4.8 Setting and Operation of Sweep • Stop amplitude [Stop] • Sweep time [Time] Time to change from the starting amplitude to the stop amplitude.  P.4-74 • Sweep Mode [SwpMode] Select from continuous, single, or gated single.  P.4-75 •...
Page 136: Setting Duty Sweep
4.8 Setting and Operation of Sweep DC offset modulation is canceled (modulation function turned off) when DC offset sweep is specified. d) Items necessary for DC offset sweep Set the following items on the second page of the setting screen. The DC offset setting on first page of the setting screen becomes invalid, and the current DC offset is displayed.
Page 137 4.8 Setting and Operation of Sweep b) To select duty sweep When the oscillation mode [Mode] is set to sweep oscillation mode [SWEEP], select the sweep type [SwpType] on the second page of the setting screen to display the selection list. When [Duty] is pressed, duty sweep is set.
Page 138: Setting And Operation Of Burst
4.9 Setting and Operation of Burst Setting and Operation of Burst 4.9.1 Burst Oscillation Types(Burst mode) The following 4 types of burst oscillations are available. • Auto burst Repeat oscillation and stop automatically at the specified by waveform respectively. A trigger signal is not necessary.
Page 139 4.9 Setting and Operation of Burst d) Third page of the setting screen: screen for setting the modulation function and synchronization/sub output terminal The following figure is an example of selecting FM as a modulation type. Indicates that the third page Modulation type is displayed Modulation width...
Page 140: Auto Burst
4.9 Setting and Operation of Burst Selects the output signal from the synchronization/sub output terminal. Choose from the selection list.  P.4-59  Sub output amplitude [SubAmp] Sets the output amplitude when the internal modulation waveform and sub waveform are selected as the output signal from the synchronization/sub output terminal.
Page 141 4.9 Setting and Operation of Burst The wave number to stop oscillation. 0.5 This can be set in cycle unit. Usually, set to 1 cycle unit.  Stop level [StpLvl] The signal level while oscillation is stopped. Set the level by specifying Off or On.  P.4-92 d) Waveform that auto is unavailable Noise and DC cannot perform auto burst.
Page 142 4.9 Setting and Operation of Burst  When [Sync] is selected Signals with TTL level that are rising at the reference phase of waveform are output from the synchronization/sub-output terminal. Burst sync signal Output signal  When [BrstSync] is selected Signals with TTL level that synchronize with the burst oscillation are output from the synchronization/sub-output terminal.
Page 143: Trigger Burst
4.9 Setting and Operation of Burst 4.9.4 Trigger burst Every time a trigger is accepted, perform oscillation with the specified cycle(s). a) Trigger burst example Mark wave number (oscillation wave number): 4 waves, start oscillation/stop phase: 30 degrees, stop level: In case of Off. Oscillation start/stop phase 30 degrees Trigger signal...
Page 144 4.9 Setting and Operation of Burst c) Screen for trigger burst setting(second page) Indicates that the second Set the burst mode to [Trigger] page is displayed Mark wave number Trigger delay Pressing the NEXT key Trigger switches the display to the first page Stop level ...
Page 145 4.9 Setting and Operation of Burst Trigger setting for trigger burst Internal trigger oscillator, external signal, manual trigger key operation, and remote trigger can be used as a trigger. When a trigger is received, the TRIG'D lamp on the TRIG key lights up. Set the trigger source in the trigger [Trig] on the second page of the setting screen ...
Page 146 4.9 Setting and Operation of Burst h) To output a burst synchronous signal → In the synchronous output setting Set synchronization output [SyncOut] on the third page of the setting screen. Select from following table. Modulation function on and internal modulation Modulation function off or external modulation Waveform reference phase synchronization[Sync] Waveform reference phase synchronization[Sync]...
Page 147 4.9 Setting and Operation of Burst How to use stop level The level while oscillation is stopped is usually set by oscillation start/stop phase. It is also possible to set by the ratio to the full scale of the amplitude independently. Set the stop level [StpLvl] as On [On] on the second page of the setting screen, and set the level with % value.
Page 148: Gate Oscillation
4.9 Setting and Operation of Burst 4.9.5 Gate Oscillation While the gate is On, performs an oscillation with an integer cycle or half-cycle unit. a) Gate oscillation example Start oscillation/stop phase: 30 degrees, Oscillation stop unit: 1 cycle, Stop level: In case of Off. The oscillation is stopped when reaching the start oscillation/stop phase after the gate signal is Off.
Page 149 4.9 Setting and Operation of Burst d) Waveform that gate oscillation is unavailable DC cannot perform gate oscillation. Noise can perform gate oscillation, however, the action differs from other waveforms.  P.4-101 e) Setting items necessary for gate oscillation Set the oscillation start/stop phase [Phase] on the first page of the setting screen. The stop level [StpLvl] on the second page of the setting screen is usually set as Off [Off].
Page 150 4.9 Setting and Operation of Burst g) To start gate oscillation → Trigger (gate signal) When gate signal On is accepted, oscillation starts. Internal trigger oscillator, external signal, manual trigger operation, and remote trigger can be used as a trigger. h) To output a burst synchronous signal →...
Page 151 4.9 Setting and Operation of Burst In the case of 1 cycle unit, the oscillation is stopped when reaching the start oscillation/stop phase after gate is Off. In the case of a half cycle unit, the oscillation is stopped when reaching the start oscillation/stop phase or the start oscillation/stop phase + 180 degrees (or -180 degrees) after gate is Off, and then it transits to the start oscillation/stop phase.
Page 152: Triggered Gate Oscillation
4.9 Setting and Operation of Burst 4.9.6 Triggered Gate Oscillation Gate oscillation that turns the gate On/Off every time a trigger is accepted. a) Triggered gate oscillation example Start oscillation/stop phase: 30 degrees, Oscillation stop unit: 1 cycle, Stop level: In case of Off. The oscillation is stopped when reaching the start oscillation/stop phase after the gate signal is Off.
Page 153 4.9 Setting and Operation of Burst c) Screen for triggered gate oscillation setting (second page) Indicates that the second page is displayed Set the burst mode to [Trigger] Oscillation stop unit Pressing the NEXT Trigger key switches the Stop level display to the first page ...
Page 154 4.9 Setting and Operation of Burst The TRIG key can be used for manual trigger operation. However, in the case of WF1968, the TRIG key only works on the channel side where the display is active. For the channel where the display is active,  P.4-20 When only manual trigger operation and remote trigger operation are used for a trigger, set the trigger source as external [Ext].
Page 155 4.9 Setting and Operation of Burst How to use stop level The level while oscillation is stopped is usually set by oscillation start/stop phase. It is also possible to set by the ratio to the full scale of the amplitude independently. Set the stop level [StpLvl] as On [On] on the second page of the setting screen, and set the level with % value.
Page 156 4.9 Setting and Operation of Burst MEMO WF1967/WF1968 4-106...
Page 157: Saving And Recalling Settings
5. Saving and Recalling Settings Procedure to Save Settings ..................5-2 Procedure to Recall Settings ..................5-4 Restoring Saved Contents to Initial Settings ..............5-6 Changing Setting Memory Name .................. 5-6 USB Flash Memory Operations ..................5-7 WF1967/WF1968...
Page 158: Procedure To Save Settings
5.1 Procedure to Save Settings You can save the current setting condition in the setting memory, and call it to use later. Settings are saved on the Store Settings screen and recalled on the Recall Settings screen. When the power is resumed after a power failure, WF1967 or WF1968 will load the contents of the configuration memory 1.
Page 159: To Save To Usb Flash Memory
5.1 Procedure to Save Settings 5.1.2 To save to USB flash memory When USB interface is used, USB memory is not available. When the MENU key is pressed, the top menu opens. Then, select [Store Settings]. This opens the Store Settings screen. In the top menu, Select [Store Settings].
Page 160: Procedure To Recall Settings
5.2 Procedure to Recall Settings Procedure to Recall Settings 5.2.1 To recall from build on memory When the MENU key is pressed, the top menu opens. Then, select [Recall Settings]. This opens the Recall Settings screen. In the top menu, Select [Recall Settings].
Page 161: To Recall From Usb Flash Memory
5.2 Procedure to Recall Settings 5.2.2 To recall from USB flash memory When the MENU key is pressed, the top menu opens. Then, select [Recall Settings]. This opens the Recall Settings screen. In the top menu, Select [Recall Settings]. Select [Internal Memory No.] on the top right of the screen, and then press the ENTER key to To recall settings saved to USB, first open the input field of the setting memory...
Page 162: Restoring Saved Contents To Initial Settings
5.3 Restoring Saved Contents to Initial Settings Restoring Saved Contents to Initial Settings As with the save operation, press the [Clear] soft-key after setting the setting memory number. The dialog box to confirm the initialization operation is opened. If you wish to initialize the setting, select [OK], and then press the ENTER key.
Page 163: Usb Flash Memory Operations
5.5 USB Flash Memory Operations USB Flash Memory Operations This section explains the unique operations when working with USB flash memory. 5.5.1 File List When working with USB flash memory, the file list for the current folder will appear on the operation screen for saving or recalling settings.
Page 164 5.5 USB Flash Memory Operations that made the adjustment of the instrument is obtained by adding energizing time. It is not possible to change the date and time for the time stamp. WF1967/WF1968...
Page 165: Variable Parameter Waveforms
6. Variable Parameter Waveforms Categories ........................6-2 Meaning of Each Parameter and Waveform Examples ..........6-3 WF1967/WF1968...
Page 166: Categories
6.1 Categories Categories The variable parameter waveforms are categorized into six groups due to their large number. Selecting a waveform group on the variable parameter waveform selection screen (☞4-52) allows you to select a waveform to output from the waveforms contained in the group. Waveform Polarity/Amplitud Variable Parameter Waveform...
Page 167: Meaning Of Each Parameter And Waveform Examples
6.2 Meaning of Each Parameter and Waveform Examples Meaning of Each Parameter and Waveform Examples 6.2.1 Outline The following provides an overview, explains the meaning of each parameter and gives examples for each waveform. The waveform examples display one cycle of the waveform drawn in the waveform memory. The polarity of the waveform is normal.
Page 168: Steady Sine Group
6.2 Meaning of Each Parameter and Waveform Examples 6.2.2 Steady Sine Group a) Unbalanced Sine Overview Sine wave in which the amplitudes of the first half and the latter half of the cycle are independent and can be changed. Application examples •Simulation of an output waveform where the gain of the plus side differs from the minus side •Simulation of full-wave rectification and half-wave rectification waveforms Meaning of each parameter...
Page 169 6.2 Meaning of Each Parameter and Waveform Examples b) Clipped Sine Overview This waveform is a sine wave with the top and bottom clipped. Application examples •Simulates a waveform clipped by an input clamp circuit •Simulates an amp output waveform saturated by the power supply voltage Meaning of each parameter The example shows the case where the amplitude range is...
Page 170 6.2 Meaning of Each Parameter and Waveform Examples c) CF Ctrl Sine Overview This is a waveform which removes and extends the area around 90° and 270° in a sine wave. Application examples •Simulates the current waveform of a condenser input rectifier circuit Meaning of each parameter The example shows the case where the amplitude range is ±FS.
Page 171 6.2 Meaning of Each Parameter and Waveform Examples d) Angle Ctrl Sine Overview This is a sine waveform with either the front or back portion of each half cycle removed. Application examples •Simulates a thyristor controlled waveform Meaning of each parameter The example shows the case where the amplitude range is ±FS.
Page 172 6.2 Meaning of Each Parameter and Waveform Examples e) Staircase Sine Overview This is a sine wave in a staircase pattern. Application examples •Simulates the pseudo sine wave output of a UPS (uninterruptible power supply), etc. Meaning of each parameter The example shows the case where the amplitude range is ±FS.
Page 173 6.2 Meaning of Each Parameter and Waveform Examples Multi-Cycle Sine Overview This is a waveform consisting of multiple, continuous cycles of a sine wave. Application examples •Burst wave substitution Meaning of each parameter The example shows the case where the amplitude range is ±FS. •Cycles The number of cycles included in one basic cycle.
Page 174: Transient Sine Group
6.2 Meaning of Each Parameter and Waveform Examples 6.2.3 Transient Sine Group a) On-Ph Ctrl Sine Overview Sine wave which follows a slope during the starting state. Application examples •Simulates the output waveform of an AC power supply with a restricted rising and falling time Meaning of each parameter The example shows the case where the amplitude range is ±FS.
Page 175 6.2 Meaning of Each Parameter and Waveform Examples b) Off-Ph Ctrl Sine Overview Sine wave which follows a slope during shut off. Application examples •Simulates the output waveform of an AC power supply with a restricted rising and falling time Meaning of each parameter The example shows the case where the amplitude range is ±FS.
Page 176 6.2 Meaning of Each Parameter and Waveform Examples c) Chattering-On Sine Overview Sine wave which have a chattering pattern during the starting state. Application examples •Simulates an AC power supply output waveform which follows the chattering pattern of a switch or relay during the start of output.
Page 177 6.2 Meaning of Each Parameter and Waveform Examples d) Chattering-Off Sine Overview Sine wave which have a chattering pattern during the shut off state. Application examples •Simulates an AC power supply output waveform which follows the chattering pattern of a switch or relay during output shut off.
Page 178: Pulse Group
6.2 Meaning of Each Parameter and Waveform Examples 6.2.4 Pulse Group a) Gaussian Pulse Overview Waveform with a Gaussian distribution. Meaning of each parameter The example shows the case where the amplitude range is 0/+FS. • Standard deviation (Sigma) Gaussian sigma function. Variable range: 0.01% to 100.00% of basic cycle standard Peak value is fixed at +FS at the center of the horizontal axis.
Page 179 6.2 Meaning of Each Parameter and Waveform Examples b) Lorentz Pulse Overview A Lorentz waveform. Meaning of each parameter The example shows the case where the amplitude range is 0/+FS. • Half Width The half value width of the Lorentz function. Variable range: 0.01% to 100.00% of basic cycle Peak value is fixed at +FS at the center of the horizontal axis.
Page 180 6.2 Meaning of Each Parameter and Waveform Examples c) Haversine Overview pulse. Sine wave with an added offset from the -90° to 270° range. Meaning of each parameter The example shows the case where the amplitude range is 0/+FS. •Width The width of one cycle of the sine wave over the -90°...
Page 181 6.2 Meaning of Each Parameter and Waveform Examples d) Half-Sine Pulse Overview A sine wave half cycle pulse. A half cycle waveform of a sine wave from the 0° to 180° range. Meaning of each parameter The example shows the case where the amplitude range is 0/+FS. •Width The width of a sine wave from the 0°...
Page 182 6.2 Meaning of Each Parameter and Waveform Examples e) Trapezoid Pulse Overview A trapezoid waveform pulse. Meaning of each parameter The example shows the case where the amplitude range is 0/+FS. • Slope width (RiseFall) The width of each oblique side. Variable range: 0.00% to 50.00% of basic cycle •Upper base width (UpperBase) The width of the upper base.
Page 183 6.2 Meaning of Each Parameter and Waveform Examples Sin(x)/x Overview Sin(x)/x waveform. This is called the sinc function. Meaning of each parameter The example shows the case where the amplitude range is ±FS. •Number of zero crossings (ZeroCross) The number of zero crossings on one side. Variable range: 1 to 50 Peak value is fixed at +FS at the center of the horizontal axis.
Page 184: Transient Response Group
6.2 Meaning of Each Parameter and Waveform Examples 6.2.5 Transient Response Group a) Exponential Rise Overview A first order LPF step response waveform. Application examples •Simulates a first order system's step output waveform Meaning of each parameter The example shows the case where the amplitude range is 0/+FS.
Page 185 6.2 Meaning of Each Parameter and Waveform Examples b) Exponential Fall Overview A first order HPF step response waveform. Application examples •Simulates a first order system's step output waveform Meaning of each parameter The example shows the case where the amplitude range is 0/+FS.
Page 186 6.2 Meaning of Each Parameter and Waveform Examples c) 2nd Order LPF Step Response Overview A second order LPF step response waveform. Application examples • Simulates the step output waveform of a transmission system accompanied by ringing and over shooting Meaning of each parameter The example shows the case where the amplitude range is 0/+FS.
Page 187 6.2 Meaning of Each Parameter and Waveform Examples d) Damped Oscillation Overview An oscillation waveform where the oscillation attenuates in the exponential fall. An oscillation waveform where the oscillation increases in the exponential rise can also be created. Application examples •...
Page 188: Surge Group
6.2 Meaning of Each Parameter and Waveform Examples 6.2.6 Surge Group a) Oscillation Surge Overview Simulates a surge waveform accompanying a damped oscillation. The step response waveform of a cascade connection circuit with a first order HPF and a second order LPF.
Page 189 6.2 Meaning of Each Parameter and Waveform Examples b) Pulse Surge Overview Simulates a surge waveform. Does not have an oscillation component. Application examples • Simulates the transient voltage waveform of a car battery Meaning of each parameter The example shows the case where the amplitude range is 0/+FS.
Page 190: Other Waveforms Group (Others Group)
6.2 Meaning of Each Parameter and Waveform Examples 6.2.7 Other Waveforms Group (Others Group) a) Trapezoid with Offset Overview A trapezoid wave with an offset in the amplitude direction. Application examples • Simulates the various voltages and current waveforms of a switching power supply circuit Meaning of each parameter The example shows the case where the amplitude range is 0/+FS.
Page 191 6.2 Meaning of Each Parameter and Waveform Examples b) Half-Sine Edge Pulse Overview Pulse wave with variable rising time, falling time and pulse width duty. The rising and falling shapes have the same half sine (half cycle of a sine wave) shape as a standard pulse wave.
Page 192 6.2 Meaning of Each Parameter and Waveform Examples c) Bottom Referenced Ramp Overview Ramp wave referenced to the bottom level. Meaning of each parameter The example shows the case where the amplitude range is 0/+FS. • Symmetry (Symm) The ratio of the rising portion. Variable range: 0.00% to 100.00% Peak value is fixed at ＋FS.
Page 193: Creating Arbitrary Waveforms
7. Creating Arbitrary Waveforms Basics ........................... 7-2 Display Procedure and Overview of Screen for Creating/Editing Arbitrary Waveforms . 7-3 Creating New Arbitrary Waveform ................. 7-5 Simple Arbitrary Waveform Creating Example .............. 7-6 Outputting Created Arbitrary Waveform ................ 7-7 Saving Created Arbitrary Waveform ................7-7 To Use the Saved Arbitrary Waveform ................
Page 194: Basics
7.1 Basics Basics There are the following two types of methods to create arbitrary waveforms: • Enter waveform data from the panel. • Use the accompanying arbitrary waveform editing software to create arbitrary waveforms on a personal computer. This section describes the method to create arbitrary waveforms using operations on the panel of the main unit.
Page 195: Display Procedure And Overview Of Screen For Creating/Editing Arbitrary Waveforms7-3
7.2 Display Procedure and Overview of Screen for Creating/Editing Arbitrary Waveforms Display Procedure and Overview of Screen for Creating/Editing Arbitrary Waveforms An arbitrary waveform is created or edited in the ARB Edit screen. Select [ARB Pressing the MENU key opens the top Edit] menu.
Page 196 7.2 Display Procedure and Overview of Screen for Creating/Editing Arbitrary Waveforms  Graph display For the graph display, a waveform in process of creation is enlarged. X and Y values of the one selected control point are displayed. As with the list display, the shape of the waveform is created by setting the X and Y values for each control point.
Page 197: Creating New Arbitrary Waveform
7.3 Creating New Arbitrary Waveform Creating New Arbitrary Waveform There are the following three types of methods to newly create an arbitrary waveform: • Create a new arbitrary waveform thoroughly First, press the [New] soft-key to clear the edit memory. Then, enter control points. The next section describes the example of creation.
Page 198: Simple Arbitrary Waveform Creating Example
7.4 Simple Arbitrary Waveform Creating Example Simple Arbitrary Waveform Creating Example This section creates a simple arbitrary waveform actually. Use the list display to explain the example. Arbitrary waveform to create is a triangular wave as shown below. The number of control points of this waveform is three, but in this section, it begins with two points and then changes to three points on the way.
Page 199: Outputting Created Arbitrary Waveform
7.5 Outputting Created Arbitrary Waveform Outputting Created Arbitrary Waveform Select the [Apply] button (per CH for WF1968) on the screen, and then press the ENTER key. The waveform in process of creation is in the output. When you press the Apply button, waveform in process of creation is output .
Page 200: Saving To Internal Memory
7.6 Saving Created Arbitrary Waveform 7.6.1 Saving to Internal Memory Select the memory number of destination. In order to select the save source, display the first page. When USB is selected, press the ENTER key to select Internal. Select an arbitrary memory number between 1 and 128 and select the [OK] soft-key.
Page 201: To Use The Saved Arbitrary Waveform
7.7 To Use the Saved Arbitrary Waveform b) Selecting the save destination, rename, delete This screen allows you to change the save destination folder, create a folder, delete files and folders, and rename items. Folders are displayed "/" at the end. Press the [OK] soft-key when not selecting the folder to display the dialog for specifying the file name.
Page 202: To Retrieve From Internal Memory
7.7 To Use the Saved Arbitrary Waveform this screen. Select the [Internal] or [USB] tab on the far left of the screen and press the ENTER key to switch sources. Selection of either read from USB memory or internal memory. 7.7.1 To Retrieve From Internal Memory Select an arbitrary memory number between 1 and 128 and select the [OK] soft-key.
Page 203: To Retrieve From Usb Flash Memory
7.7 To Use the Saved Arbitrary Waveform 7.7.2 To Retrieve From USB Flash Memory The screens for retrieving from USB flash memory are split into two pages. One screen specifies the retrieval source (files in USB flash memory) and the other the retrieval destination (edit memory or internal arbitrary waveform memory).
Page 204: To Delete The Saved Arbitrary Waveform
7.8 To Delete the Saved Arbitrary Waveform To Delete the Saved Arbitrary Waveform The upper limit of the storage capacity for the internal arbitrary waveform memory cannot be exceeded. In this case, unnecessary arbitrary waveforms must be deleted. Select the [Store] soft-key on the ARB Edit screen to change to the save screen and delete any arbitrary waveforms.
Page 205: Identifying Memory Space Required For Saving Arbitrary Waveforms
7.9 Identifying Memory Space Required for Saving Arbitrary Waveforms Identifying Memory Space Required for Saving Arbitrary Waveforms The non-volatile memory can save arbitrary waveforms up to 128-waveforms or 4 Mi-words (8Mi bytes). The memory capacity (K-byte) required when saving an arbitrary waveform in the array format and control point format, respectively is calculated by the following formula.
Page 206 7.9 Identifying Memory Space Required for Saving Arbitrary Waveforms MEMO WF1967/WF1968 7-14...
Page 207: Convenient Use Of 2-Channel Equipment
8. Convenient Use of 2-channel Equipment (WF1968 Only) Outline .......................... 8-2 Copying Setting between Channels ................8-3 Unifying Settings of 2 Channels ..................8-5 Phase Synchronization between Channels ..............8-6 Maintaining to Same Frequency (2-Channel Coordination, 2-Phase) ......8-7 Keeping Frequency Difference Constant (2-Channel Coordination, 2-Tone) ....8-9 Keeping Frequency Ratio Constant (2-Channel Coordination, Ratio) ......
Page 208: Outline
8.1 Outline Outline You can use 2-channel equipment, WF1968, not only as the two independent oscillators but also as the 2-channel coordination setting and operation. Functions specific to 2-channel equipment are as follows: • Parameter copy function One's channel setting can be copied to another's channel setting. Channel settings can be changed each other.☞...
Page 209: Copying Setting Between Channels
8.2 Copying Setting between Channels Copying Setting between Channels Copying the settings between channels can be done on the Utility screen. In the Utility screen, select In the Utility screen, select [Parameter [Parameter Copy], Copy] and then press the ENTER key. and then press the ENTER key A fter the Parameter copy window is...
Page 210 8.2 Copying Setting between Channels When the above setting is completed, select [OK] at the bottom of the window, and then press the ENTER key. The copy operation is performed. When you do not want to copy, select [Cancel] at the bottom of the window and press the ENTER key, or press the CANCEL key.
Page 211: Unifying Settings Of 2 Channels
8.3 Unifying Settings of 2 Channels Unifying Settings of 2 Channels  Procedure and operation First, set the 2-channel equivalence setting function to on in the Utility screen. Next, set items to which you want to set the same setting. When you set setting for one channel, the same settings are set to the same items for another channel.
Page 212: Phase Synchronization Between Channels
8.4 Phase Synchronization between Channels Phase Synchronization between Channels Even if you set the frequency and phase to the same values using the 2-channel equivalence setting function, the phase relationship between the output waveforms from the 2 channels is changed accordingly.
Page 213: Maintaining To Same Frequency (2-Channel Coordination, 2-Phase)
8.5 Maintaining to Same Frequency (2-Channel Coordination, 2-Phase) Maintaining to Same Frequency (2-Channel Coordination, 2-Phase) If the channel mode is [2Phase], you can change the frequency with the frequencies for both channels kept the same value while the synchronization relationship is kept. In coordination with the change of frequency of the channel 1, the frequency of the channel 2 is automatically changed.
Page 214 8.5 Maintaining to Same Frequency (2-Channel Coordination, 2-Phase)  Operational restrictions There are restrictions shown in the following table to keep the synchronization relationship with the same frequency: Item Restriction Waveform Disabled for noise and DC. Modulated Both CHs are FM. Peak deviation is common. oscillation Modulation source is internal only.
Page 215: Keeping Frequency Difference Constant (2-Channel Coordination, 2-Tone)
8.6 Keeping Frequency Difference Constant (2-Channel Coordination, 2-Tone) Keeping Frequency Difference Constant (2-Channel Coordination, 2-Tone) If the channel mode is [2Tone], you can change the frequency with the frequency difference between both channels kept constant. In coordination with the change of frequency of the channel 1, the frequency of the channel 2 is automatically changed.
Page 216 8.6 Keeping Frequency Difference Constant (2-Channel Coordination, 2-Tone)  Operational restrictions There are restrictions shown in the following table to keep the frequency difference: Item Restriction Waveform Disabled for noise and DC Modulated Both CHs are FM. Peak deviation is common. oscillation Modulation source is internal only.
Page 217: Keeping Frequency Ratio Constant (2-Channel Coordination, Ratio)
8.7 Keeping Frequency Ratio Constant (2-Channel Coordination, Ratio) Keeping Frequency Ratio Constant (2-Channel Coordination, Ratio) If the channel mode is [Ratio], you can change the frequency with the frequency ratio between both channels kept constant. In coordination with the change of frequency of the channel 1, the frequency of the channel 2 is automatically changed.
Page 218 8.7 Keeping Frequency Ratio Constant (2-Channel Coordination, Ratio)  Operational restrictions There are restrictions shown in the following table to keep the frequency ratio: Item Restriction Waveform Disabled for noise and DC Modulated Both CHs are FM. Peak deviation follows the frequency ratio. oscillation Modulation source is internal only.
Page 219: Obtaining Differential Output (2-Channel Coordination, Differential)
8.8 Obtaining Differential Output (2-Channel Coordination, Differential) Obtaining Differential Output (2-Channel Coordination, Differential) If the channel mode is [Diff], you can change the setting with the differential output of both channels being kept. In this 2-channels coordination mode, the DC offset setting is the same for channel 1 and channel 2.
Page 220: Obtaining Double Output Voltage(2-Channel Coordination, Differential 2)
8.9 Obtaining Double Output Voltage(2-Channel Coordination, Differential 2) Obtaining Double Output Voltage(2-Channel Coordination, Differential 2) If the channel mode is [Diff2], you can change the setting with the differential output of both channels being kept. In this 2-channels coordination mode, the DC offset setting for channel 2 is the set value with the reversed sign.
Page 221: Synchronizing Multiple Units
9. Synchronizing Multiple Units Connection Procedure ....................9-2 Performing Synchronization ..................9-4 WF1967/WF1968...
Page 222: Connection Procedure
9.1 Connection Procedure Synchronizing multiple units of WF1967 or WF1968 can configure up to 12-phase oscillators (for 6 units of WF1968) without using sub waveform. You can change a phase and amplitude for each phase independently. Set the same frequency for all units and channels. Connection Procedure WF1967 or WF1968 as the synchronous reference is called a "master unit."...
Page 223 9.1 Connection Procedure • Connection method 2 Connect the reference output for the master unit or slave unit to the reference input for the next slave unit. Time difference between slave units varies depending on the delay within units (approximately 25ns) and connection cable length (approximately 5ns/m).
Page 224: Performing Synchronization
9.2 Performing Synchronization Performing Synchronization  Before synchronization After connection among the master unit and slave units is finished, perform the setting as follows: Set [Channel Mode] to [Indep] Set 10MHz Ref Out Master unit or [2Phase] (WF1968 only) to [Enable] •...
Page 225 9.2 Performing Synchronization  Performing synchronization Synchronous operation is performed in the master unit. Synchronous operation is performed in the Utility screen of the master unit. Select [φ Sync] in the Utility screen, and then press the ENTER key. This runs the phase synchronization. At this time, the phase will be discontinuous temporarily because all channels stop the oscillation once.
Page 226 9.2 Performing Synchronization MEMO WF1967/WF1968...
Page 227: Using External Frequency Reference
10. Using External Frequency Reference 10.1 Purpose of Using External Frequency Reference ............10-2 10.2 Connection and Usage Procedure of External Frequency Reference ......10-2 WF1967/WF1968 10-1...
Page 228: Purpose Of Using External Frequency Reference
10.1 Purpose of Using External Frequency Reference 10.1 Purpose of Using External Frequency Reference This product uses a built-in crystal oscillator as the frequency reference, but you can also use the external 10 MHz clock as the frequency reference. Generally, the external frequency reference is used for the following purposes: •...
Page 229 10.2 Connection and Usage Procedure of External Frequency Reference WARNING To prevent electric shocks, do not apply a voltage exceeding 42Vpk (DC + AC peak) between the ground of the BNC connectors insulated from the enclosure and the enclosure. Also, do not apply a voltage exceeding 42Vpk (DC + AC peak) between the grounds of the BNC connector groups insulated from the enclosure.
Page 230 10.2 Connection and Usage Procedure of External Frequency Reference  Enabling external frequency reference You can switch the enabled/disabled for the external frequency reference in the Utility screen. In the Utility screen, select [Ext Reference], and then press the ENTER key to switch an indicator to [Enable] from [Disable].
Page 231: Using The Sequence Oscillation
11. Using the Sequence Oscillation 11.1 Sequence Oscillation Example ................... 11-2 11.2 Basics ......................... 11-4 11.3 In-Step Processing Flow ................... 11-12 11.4 Setting and Operation Procedure ................11-13 11.5 Saving Created Sequence ..................11-17 11.6 Using the Saved Sequence ..................11-19 11.7 Deleting the Saved Sequence ..................
Page 232: Sequence Oscillation Example
11.1 Sequence Oscillation Example 11.1 Sequence Oscillation Example As a simple example of sequence oscillation, this section describes how to change DC voltage in stages as shown in the following figure. (First, restore the initial setting in the Utility screen.) Output voltage Time...
Page 233 11.1 Sequence Oscillation Example After that, when stop operation is performed, the sequence moves to Step 0. Since [StepTerm] is set to [End], the sequence moves to Step 0 even if resume operation is performed. Note that if the [StepTerm] is set to [Continue], the sequence moves to Step 4 when resume operation is performed.
Page 234: Basics
11.2 Basics 11.2 Basics This section describes the necessary information you should know when using the sequence oscillation. a) Difference between sequence oscillation and normal oscillation During sequence oscillation, the unit operates on individual waveform, frequency, and amplitude settings, which are independent from normal oscillation (continuous, modulated, sweep, and burst). In another word, the sequence oscillation and the normal oscillation operate as a separate oscillator independent from each other.
Page 235 11.2 Basics c) Intra-step parameter change pattern Intra-change parameters, except for the waveform, have the following three patterns of value changes within the step. These are called action settings. In case of waveform parameters, there is no action setting. Instead, the setting is always done in that step. •...
Page 236 11.2 Basics e) Phase at step end [StopPhs] Normally, when the prescribed step time has elapsed, the sequence moves on to the next step regardless of the reference phase. However, if you wish to set the sequence to move on to the next step after the completion of one cycle of waveform, it is possible to specify the end phase (stop phase).
Page 237 11.2 Basics When a stop phase is not specified in the previous step When a stop phase is specified in the previous step Previous step Previous step Next step Next step End of step time End of step time Waiting for the stop phase Check •...
Page 238 11.2 Basics f) Phase at step start If the waveform of the previous step is DC or noise, oscillation in the next step starts from reference phase 0°. Phase 0° here is the phase value based on the reference phase as in the case of the phase at step end (stop phase). The start phase that appears in the actual output is the phase setting value of that step.
Page 239 11.2 Basics h) Two types of branches The control flow can be changed by the panel operation or by the external signals. This is called branching. For example, branching can be used to set the sequence to move to a different step in response to a status change of the equipment under test.
Page 240 11.2 Basics j) Limitation of available waveform The waveforms that can be used for sequence oscillation are limited to sine wave, square wave (both standard and extended duty variable range), noise, DC, and arbitrary waveform. When you wish to use a ramp wave or parameter-variable waveform, copy the desired waveform to the arbitrary waveform and save it as an arbitrary waveform in advance in the ARB Edit screen.
Page 241 11.2 Basics l) Channel coordination (WF1968 only) The step control parameters are common to both channels. The sequence makes the same step transition for both channels. However, since the stop phase can be controlled only by the channel 1 side, the stop phase of channel 2 does not necessarily match the desired value. On the other hand, the intra-step channel parameters can be set independently for each channel.
Page 242: In-Step Processing Flow
11.3 In-Step Processing Flow 11.3 In-Step Processing Flow The following figure shows the flow of processing within one step. Start Output is performed according to the action setting during the specified step time. If hold operation is performed during this time, the sequence goes to standby, while keeping the current output status, and waits until resume operation is performed.
Page 243: Setting And Operation Procedure
11.4 Setting and Operation Procedure 11.4 Setting and Operation Procedure a) Switching to sequence oscillation mode Press the MENU key to open the top menu window. Then select [Sequence] and press the ENTER key. The dialog box to confirm the move to the sequence oscillation mode is displayed.
Page 244 11.4 Setting and Operation Procedure active channel. Second row (Graph screen) The input field corresponding to the step number can be opened by [Step]. Use [AutoScale] to adjust the vertical axis scale of the graph displayed so that the scale does not become saturated.
Page 245 11.4 Setting and Operation Procedure When the sequence begins it will be displayed with the Run Soft keys in [Run] status e) Pausing sequence execution Press the [Hold] soft key in the [Run] status to pause the sequence. The sequence goes into the standby, while keeping the output condition as it is.
Page 246 11.4 Setting and Operation Procedure j) Returning to normal oscillation mode Select other than [Sequence] (such as [Oscillator]) in the top menu and then press the ENTER key. The dialog to confirm the exit from the sequence oscillation mode is displayed. Select [OK] and then press the ENTER key.
Page 247: Saving Created Sequence
11.5 Saving Created Sequence 11.5 Saving Created Sequence 11.5.1 Saving to the Built-In Memory of Main Body Press the [Store] soft-key in the [Edit] status to switch to the screen for saving. Screen is displayed for the save by pressing the "Store" soft key Select sequence number...
Page 248: Saving To The Usb Flash Memory
11.5 Saving Created Sequence 11.5.2 Saving to the USB Flash Memory USB interface in use, USB memory cannot be used. Press the [Store] soft-key in the [Edit] status to switch to the screen for saving. Screen is displayed for the save by pressing the "Store"...
Page 249: Using The Saved Sequence
11.6 Using the Saved Sequence 11.6 Using the Saved Sequence 11.6.1 Recalling from the Built-In Memory Select memory number Press the [Recall] soft-key in the [Edit] status to switch to the screen for recalling the saved sequence. Select Internal tab at the left bottom side of the screen and press the ENTER key to switch the recalling source.
Page 250: Deleting The Saved Sequence
11.7 Deleting the Saved Sequence 11.7 Deleting the Saved Sequence To delete the sequence is done in the save screen. Therefore, operation of up to save is the same. 11.7.1 Deleting from the Built-In Memory The sequence which was stored in the specified built-in memory is deleted and restored to the initial state. Sequence names are also initialized to "seq01"...
Page 251: Outline Of Screen
11.8 Outline of Screen 11.8 Outline of Screen  Text display [Text] (WF1967) or [Single] (WF1968) The step control parameters of one step and the intra-step channel parameters of one channel are displayed simultaneously. Step time Common setting Step number Step control parameters Intra-step...
Page 252 11.8 Outline of Screen  Graph display [Graph] Graph display shows the trends along the step progress for four intra-step channel parameters. However, the trend shown is only for the case where the step progresses according to the step number from Step 0.
Page 253: Individual Description Of Step Control Parameters
11.9 Individual Description of Step Control Parameters 11.9 Individual Description of Step Control Parameters Step time [Time] This parameter sets the step duration. Auto hold [AutoHold] Usually, set to Off. Set this parameter on when the sequence goes into standby without moving on to the next step after the lapse of the specified step time.
Page 254: Tips For Sequence Creation
11.10 Tips for Sequence Creation 11.10 Tips for Sequence Creation Repeating the same pattern for more than 10 000 times The maximum value for setting the jump count is 9 999; therefore, up to 10 000 times of step patterns can be repeated.
Page 255: Using User-Defined Units
12. Using User-defined Units 12.1 About User-defined Unit ....................12-2 12.2 Display and Setting in User-defined Unit ..............12-2 12.3 Defining User-defined Units ..................12-3 WF1967/WF1968 12-1...
Page 256: About User-Defined Unit
12.1 About User-defined Unit 12.1 About User-defined Unit For example, you can set the frequency in units of rpm (number of rotations per minute) instead of Hz. You can set a value converted to the mechanical deviation quantity or a value converted to the output voltage after the power amplifier output instead of voltage.
Page 257: Defining User-Defined Units
12.3 Defining User-defined Units 12.3 Defining User-defined Units ■ Setting screen The setting is done on the Utility screen. In the Utility screen, select the [User Unit] field and press the ENTER key. In the Utility screen, select the [User Unit] and press the ENTER key The user-defined unit setting window opens.
Page 258 12.3 Defining User-defined Units log is a common logarithm whose base is 10. You need to pay attention to when you use a log formula for a value that can be negative such as the DC offset and phase. If a value before changing to the user-defined unit is zero (0), "-Inf"...
Page 259: Other Utility Settings
13. Other Utility Settings 13.1 Selecting Remote Interface [Remote] ................. 13-2 13.2 Display Setting [Display] ..................... 13-2 13.3 Modify Knob and Modify Direction Setting [Modify Direction] ........13-2 13.4 Operation Sound Setting [Sound] ................13-3 13.5 Self-Diagnosis [Self Check] ..................13-3 13.6 Product Information Display [Information] ..............
Page 260: Selecting Remote Interface [Remote]
13.1 Selecting Remote Interface [Remote] 13.1 Selecting Remote Interface [Remote] Select the external control interface from USB, GPIB or LAN(option). When you select USB, USB ID is displayed. When you select GPIB, set GPIB address within the range of 0 to 30. When you select LAN, MAC address and port address are displayed.
Page 261: Operation Sound Setting [Sound]
In rare Self-Diagnosis cases, an error may occur due to the effect of noise. If you encounter repetitive errors, please contact NF Corporation or one of our representatives. 13.6 Product Information Display [Information] The model name, firmware version, etc. of Model this product are displayed.
Page 262 13.6 Product Information Display [Information] MEMO WF1967/WF1968 13-4...
Page 263: Troubleshooting
14. Troubleshooting 14.1 Error Messages at Power-on ..................14-2 14.2 Error Messages during Operation ................14-3 14.3 Conflict Messages for Modulation ................14-7 14.4 Conflict Message for Sweep ..................14-8 14.5 Conflict Message for Burst ..................14-9 14.6 Sequence Compiler Message ................... 14-10 14.7 Suspected Failure .....................
Page 264: Error Messages At Power-On
At power-on, self-diagnosis is performed and an error message is displayed if there are any problems. If you encounter any failure, please contact NF Corporation or one of our representatives. When a message that tells you machine is shut down due to overheat, check installation environment if the environment is not in hot so that the product become over heat.
Page 265: Error Messages During Operation
14.2 Error Messages during Operation 14.2 Error Messages during Operation Often run-time error messages are displayed when the setting exceeds the allowable output range. For example, when a square wave is output and you try to set the frequency to 100MHz, an error is displayed and the frequency is set to the maximum frequency of square wave.
Page 266 14.2 Error Messages during Operation 22029: Edge time changed due to Width A given pulse width time cannot be achieved with the current edge time (LE, TE). The edge time becomes shorter. The pulse width time takes precedence over the edge time. 22030: Edge time changed due to Duty A given pulse width duty cannot be achieved with the current edge time (LE, TE).
Page 267 14.2 Error Messages during Operation 22045: Frequency changed due to Function The frequency is changed based on the upper frequency of waveform when the channel mode is RATIO. 22046: Frequency of CH1 changed due to Ratio The frequency of CH1 is changed to maintain the frequency ratio when the channel mode is RATIO. The frequency ratio takes precedence over the frequency of CH1.
Page 268 14.2 Error Messages during Operation 61057: Data beyond upper limit; Value clipped to upper limit You are trying to set the value beyond upper limit. The value is set to the upper limit. 61058: Zero data not allowed Zero cannot be set in this parameter. 61059: Invalid operation This operation is invalid.
Page 269: Conflict Messages For Modulation
14.3 Conflict Messages for Modulation 14.3 Conflict Messages for Modulation These messages are displayed when the [?] soft key is pressed when the specified modulation cannot be executed due to an inappropriate setting (conflict state). They describe the improper settings. HopFreq beyond upper limit for current Function The hop frequency is beyond the allowable range of the current waveform to output in FSK.
Page 270: Conflict Message For Sweep
14.4 Conflict Message for Sweep 14.4 Conflict Message for Sweep These messages are displayed when the [?] soft key is pressed when the specified sweep cannot be executed due to an inappropriate setting (conflict state). They explain about the improper settings. Frequency beyond upper limit for Gated sweep The frequency is beyond the upper frequency of gated sweep.
Page 271: Conflict Message For Burst
14.5 Conflict Message for Burst 14.5 Conflict Message for Burst These messages are displayed when the [?] soft key is pressed when the specified burst cannot be executed due to an inappropriate setting (conflict state). They describe the improper settings. BrstMode not compatible with current Function The burst oscillation mode is not adequate for the current waveform.
Page 272: Sequence Compiler Message
14.6 Sequence Compiler Message 14.6 Sequence Compiler Message These messages are displayed when unexecutable setting is found as a result of sequence compilation. Amptd -Offset conflict CH:N Step:M Amptd (Step K) - Offset (Step L) The amplitude and offset do not satisfy mutual restriction in step M of channel N. The amplitude is set at step K and the offset is set at step L.
Page 273: Suspected Failure
14.7 Suspected Failure 14.7 Suspected Failure When the device appears to be abnormal, try following steps. If the operations cannot be recovered after the measures taken, contact NF Electronic Instruments or one of its representatives. Problem Possible cause Action Reference page...
Page 274 14.7 Suspected Failure MEMO WF1967/WF1968 14-12...
Page 275: Maintenance
15. Maintenance 15.1 Outline ........................15-2 15.2 Operation Inspection ....................15-4 15.3 Performance Test ......................15-5 WF1967/WF1968 15-1...
Page 276: Outline
This Instruction Manual describes the operation inspection and the performance testing method that can be easily performed. For more accurate inspections, adjustments, calibration or repairs, contact NF Corporation or one of our representatives. WARNING High voltages appear inside of the instrument.
Page 277 15.1 Outline  Equipment To perform the operation inspection and performance test, following instruments. Requirement Sample Model Intended Purpose Digital AC Voltage Agilent 3458A Measurement of AC voltage Multi-meter TrueRMS less than 100kHz, and DC Accuracy: ±0.1% voltage. (1kHz to 100kHz) DC voltage Accuracy: ±0.1% Power meter...
Page 278: Operation Inspection
15.2 Operation Inspection 15.2 Operation Inspection  Check Before Operation inspection Check followings before the operation inspection.  The power supply voltage is within the rated range.  Ambient temperature is within the range of 0 to +40°C.  Ambient relative humidity is within the range of 5 to 85%RH (furthermore, the absolute humidity is within the range of 1 to 25g/m ...
Page 279: Performance Test
After the performance test, when the product does not meet the specification, it needs to be repaired. Contact NF Corporation or one of our representatives.  Check before the performance test Check followings before the performance test.
Page 280: Sine Wave Amplitude Accuracy Test
15.3 Performance Test 15.3.2 Sine Wave Amplitude Accuracy Test FCTN OUT → Digital multi-meter (AC voltage TrueRMS measurement) Connection: Use a coaxial cable. Setting: The following table shows the amplitude after setting initialization. (Frequency is set to 1kHz). Measurement: Measure the output voltage for each waveform as the effective value. Judgment: It is normal when the value falls within the following table.
Page 281: Sine Wave Amplitude/Frequency Characteristics Test
15.3 Performance Test 15.3.4 Sine Wave Amplitude/Frequency Characteristics Test  100kHz or lower FCTN OUT → Digital multi-meter (AC voltage TrueRMS measurement, and 50Ω Connection: termination) Use a coaxial cable. Setting: The following table shows the amplitude and frequency after setting initialization. Measurement: Measure the output voltage for each frequency as the effective value.
Page 282 15.3 Performance Test  More than 100kHz FCTN OUT → Power meter (Power sensor) Connection: Use a coaxial cable. Measure a signal up to approx. 24dBm. Use a coaxial attenuator separately not to exceed the allowable input of the power sensor. Setting: The following table shows the amplitude and frequency after setting initialization.
Page 283: Sine Wave Total Harmonic Distortion Test
15.3 Performance Test 15.3.5 Sine Wave Total Harmonic Distortion Test FCTN OUT → Audio analyzer (50Ω termination) Connection: Use a coaxial cable. If the audio analyzer does not have a 50Ω termination, install a 50Ω terminator (feed through terminator) at the input of the instrument. Setting: Set frequency to 20kHz after setting initialization.
Page 284: Sine Wave Non-Harmonic Spurious Test
15.3 Performance Test 15.3.7 Sine Wave Non-harmonic Spurious Test FCTN OUT → Spectrum analyzer Connection: Use a coaxial cable. Measure a signal up to approx. 24dBm. Use a coaxial attenuator separately not to exceed the allowable input of the spectrum analyzer. Setting: The following table shows the amplitude and frequency after setting initialization.
Page 285: Square Wave Leading/Trailing Time Test
15.3 Performance Test 15.3.9 Square Wave Leading/Trailing Time Test FCTN OUT → Oscilloscope (50Ω termination) Connection: Use a coaxial cable. Setting: Set the waveform to square, the frequency to 5MHz, and the amplitude to 4Vp-p/open after setting initialization. The following table shows the duty variable range. Measurement: Observe the waveform and measure the leading and trailing time.
Page 286 15.3 Performance Test MEMO WF1967/WF1968 15-12...
Page 287: List Of Initial Settings
16. List of Initial Settings WF1967/WF1968 16-1...
Page 288 16 List of Initial Settings When initialization([Reset]) is performed on the Utility screen , settings are initialized as follows. These items are also stored in the setting memory (except for output on/off setting). The arbitration memory, the setting memory, the user-defined unit setting, the output setting at power-on, the remote setting, and the panel operation settings are not initialized.
Page 289 16 List of Initial Settings  Sweep Sweep type Frequency Frequency sweep range 1kHz to 10kHz Phase sweep range -90° to 90° Amplitude sweep range 0.1Vp-p to 0.2Vp-p DC offset sweep range -0.1V to 0.1V Duty sweep range 40% to 60% Sweep time 0.1sec Sweep mode...
Page 290 16 List of Initial Settings  Others Use of user-defined unit Cancel External 10MHz frequency reference input Disable External 10MHz frequency reference output Disable External addition Followings are shipping settings that are not changed with initialization.  Definition of user-defined unit Unit name usr1 to usr6 Formula...
Page 291: Specifications
17. Specifications 17.1 Oscillation Mode ......................17-2 17.2 Waveform ........................17-2 17.3 Frequency, Phase ....................... 17-3 17.4 Output Characteristics ....................17-4 17.5 Signal Characteristics ....................17-7 17.6 Modulated Oscillation Mode ..................17-11 17.7 Sweep Oscillation Mode ................... 17-14 17.8 Burst Oscillation Mode ....................17-18 17.9 Synclator Function ....................
Page 292: Oscillation Mode
17.1 Oscillation Mode Numeric values marked as *1 are guaranteed values. The other numeric values are not guaranteed values but nominal values or typical values (marked as typ.). If not specified, the condition is that oscillation is continuous, the load is 50Ω, the amplitude setting is 10Vp-p/50Ω, the DC offset setting is 0V, the auto range, the amplitude range of waveform is ±FS, the external addition is off, and AC voltage is effective value measurement.
Page 293: Frequency, Phase
17.3 Frequency, Phase 17.3 Frequency, Phase Targets are signals output to the main-output (FCTN OUT) and signals output to the sub-output (SYNC/SUB OUT), when the sub-waveform is selected. 17.3.1 Frequency Frequency setting range Limited to the range determined by the waveform output from the main-output or from the sub-output when the sub-waveform is selected, whichever is smaller.
Page 294: Phase
17.4 Output Characteristics 17.3.2 Phase Phase represents the phase of waveform output to the reference phase synchronization output waveform. This does not include noise and DC. Setting range of the phase (main-output) -1800.000° to +1800.000°(resolution 0.001°) Common to the oscillation start/end phase of the gated single sweep and burst Setting range of the phase (sub-output/sub-waveform) -180.000°...
Page 295: Dc Offset
17.4 Output Characteristics Vrms, dBV, and dBm are applied to sine wave and noise only. 0dBV shall be 1Vrms. Regarding dBm, voltage that is 1mW at the specified load impedance (excluding High-Z) shall be 0dBm. Range Auto, hold (switch) Maximum output voltage range: 20Vp-p, 4Vp-p, 0.8Vp-p Amplitude attenuator range: 0dB, -10dB, -20dB, -30dB Resolution of waveform amplitude Approx.
Page 296: Waveform Output
17.4 Output Characteristics output terminal voltage under the specified load condition. 1Ω to 10kΩ (resolution 1Ω), 50Ω, High-Z (load open) Setting range 17.4.4 Waveform Output Output on/off control On, off (switch) (output terminal is in a released condition when off) 50Ω, unbalanced Output impedance Short-circuit protection...
Page 297: Signal Characteristics
17.5 Signal Characteristics 50Ω or higher recommended Load impedance Output connector Front panel, BNC receptacle (SYNC/SUB OUT) Signal GND Insulated from enclosure, same potential as the waveform output. 17.5 Signal Characteristics It specified only to the main-output. 17.5.1 Sine Wave Amplitude frequency characteristics Up to 100kHz ±0.1dB...
Page 298: Square Wave
17.5 Signal Characteristics 8MHz to 80MHz -55dBc+20 dB/dec or less 80MHz to 200MHz -35dBc or less Conditions: Continuous oscillation, 50Ω load, amplitude setting 2Vp-p/50Ω, DC offset setting 0V, measured at 500MHz bandwidth. 17.5.2 Square Wave Duty Variable Range (switch) Standard, Extended (switch) Standard range: Duty can be changed within the range where jitter is low and a pulse does not disappear.
Page 299: Pulse Wave
17.5 Signal Characteristics Conditions: 50Ω load, amplitude setting 2Vp-p/50Ω, DC offset setting 0V Overshoot 5% or less typ. Jitter Duty variable range standard 85ps rms or less typ. (100Hz or more) Duty variable range extended 700ps rms or less typ. Conditions: Continuous oscillation, 50Ω...
Page 300: Parameter-Variable Waveform
17.5 Signal Characteristics 17.5.6 Parameter-Variable Waveform For each of the following waveforms, a waveform with multiple parameters which are arbitrary varied can be generated. a) Steady sine group Unbalance sine Clipped sine CF controlled sine Conduction angle controlled sine Staircase sine Multiple-cycle sine b) Transient sine group On-phase controlled sine...
Page 301: Modulated Oscillation Mode
17.6 Modulated Oscillation Mode 17.6 Modulated Oscillation Mode 17.6.1 General Operation in other oscillation mode Partly possible in the burst and sweep oscillation mode. Modulation type FM, FSK, PM, PSK, AM, DC offset modulation and PWM When the sweep function is used simultaneously the modulation type which overlaps with that of the sweep type cannot be selected.
Page 302 17.6 Modulated Oscillation Mode Output connector Shared with synchronization/sub-output connector (SYNC/SUB OUT). External modulation input (except for FSK and PSK) Input voltage range ±1V full scale Maximum allowable input ±2V 10kΩ, unbalanced Input impedance Input frequency DC to 400 kHz (-3 dB) Input connector Front panel (WF1967)/rear panel (WF1968), BNC receptacle (MOD/ADD IN)
Page 303: Fsk
17.6 Modulated Oscillation Mode Carrier frequency ± peak deviation is limited within the allowable range of frequency for each carrier waveform. Sub-output is turned off when the peak frequency exceeds 160MHz. With the peak frequency exceeding 110MHz, the value combining waveform amplitude and DC offset is limited to ±2V/open.
Page 304: Dc Offset Modulation
17.7 Sweep Oscillation Mode b) DSB-SC(Double Side Band - Suppressed Carrier) Carrier waveform Standard waveforms except for DC, and arbitrary waveforms Modulation depth setting range 0.0% to 100.0% (resolution 0.1%) Remarks When the modulation depth is 100%, maximum amplitude becomes equal to setting. The component of the carrier frequency is zero during DSB-SC.
Page 305 17.7 Sweep Oscillation Mode Common regardless of sweep type. However, logarithmic can use only frequency sweep. Sweep range setting Specify starting value and stop value, or center value and span value However, the center value is also a simple average of starting value and stop value during frequency logarithmic sweep.
Page 306 17.7 Sweep Oscillation Mode Sweep synchronization/marker output Marker off at one-way Low level is used from sweep staring value to half of sweep time. High level, otherwise Marker off at shuffle Low level is used from sweep staring value to sweep stop value.
Page 307: Frequency Sweep
17.7 Sweep Oscillation Mode 17.7.2 Frequency Sweep Waveform Standard waveforms except for noise, pulse wave and DC, and arbitrary waveforms Setting range of start and stop frequency 0.01µHz to 200MHz Resolution: 0.01µHz (< 50MHz), 0.1µHz (50MHz ≦) Limited within the allowed setting range of frequency for each waveform.
Page 308: Duty Sweep
17.8 Burst Oscillation Mode ±0.5V or more 5 digits or 1mV Remarks When the waveform is DC, gated single sweep is not available 17.7.6 Duty Sweep Waveform Square wave and pulse wave Setting range of start and stop duty Square wave Duty variable range standard 0.0100% to 99.9900% (resolution 0.0001%) Duty variable range extend 0.0000% to 100.0000%(resolution 0.0001%)
Page 309: Synclator Function
17.9 Synclator Function Remarks: The same setting value as the phase setting in Section 17.3.2 Stop level setting range Function Specifies the signal level when oscillation is stopped. Setting range -100.00% to +100.00% (amplitude full-scale reference and resolution 0.01%) or off When stop level is set to off, stops by set oscillation start/stop phases.
Page 310: Trigger
17.10 Trigger input from the synchronization source and the signal output to the main output. The frequency of the input signal is displayed on the screen. Frequency range 20Hz to 10MHz Synchronization target Only external trigger input terminal is available. In addition, CH2 can select the same trigger source as CH1.
Page 311: Sequences
17.11 Sequences 10kΩ (pull up to +3.3V), unbalanced Input impedance Input connector Front panel (WF1967)/rear panel (WF1968), BNC receptacle (TRIG IN) Manual trigger Panel key operation Usage For single sweep, gated single sweep, trigger burst, gate and trigger gate (Not available for synclator) Internal trigger oscillator Independent for sweep and burst, and Independent for each channel...
Page 312: Other I/Os
17.12 Other I/Os connector (SYNCOUT/SUB OUT). Available waveforms Sine wave, square wave, noise, and arbitrary waveform Ramp wave and variable parameter waveforms are available by saving them as arbitrary waveforms Maximum number of waveforms Phase at step start The next step of DC or noise starts oscillation from each channel reference phase 0°...
Page 313: 2-Channel Coordination (Wf1968 Only)
17.13 2-Channel Coordination (WF1968 only) Input voltage range -1V to +1V Maximum allowable input ±2V Input frequency DC to 100MHz (-3dB) 10kΩ, unbalanced Input impedance Input connector Front panel (WF1967)/rear panel (WF1968), BNC receptacle (MOD/ADD IN) Shared with external modulation input. Used with the external modulation and addition operation is not available.
Page 314 17.13 2-Channel Coordination (WF1968 only) Constant Keep the ratio of frequency constant. Oscillation in the same oscillation frequency ratio mode (the same modulation type for modulation oscillation and the same sweep type for sweep oscillation). Apply to the standard waveform except for noise and DC, and arbitrary waveform.
Page 315: Synchronization Of Multiple Units
17.14 Synchronization of Multiple Units 17.14 Synchronization of Multiple Units Connection Connect the frequency reference output of the master unit to the frequency reference input of the slave unit Connect the frequency reference output of the slave unit to the frequency reference input of the other slave unit Connection method 1 Master unit Slave unit...
Page 316: User-Defined Unit
17.15 User-defined Unit 17.15 User-defined Unit Function Set and display settings in any unit based on a specified conversion expression Setting items Frequency (Hz), cycle (sec), amplitude (Vp-p, Vpk), DC offset (V), phase (deg) and duty (%) Conversion expression [(internal setting)+n]×m, [log (internal setting)+n]×m Specify a conversion expression and values of n and m.
Page 317: Options
17.17 Options Remote control GPIB IEEE-488.1, SCPI-1999/IEEE-488.2 USB USBTMC, USB 1.1 Full-speed LAN(Option) 17.17 Options PA-001-1318 multi-I/O cable Cable with connector on one end, for connection to multi-I/O connector on rear panel. 2 m length. Cut off at one end. PA-001-2342 LAN I/F 10BASE-T/100BASE-TX,RJ-45 connector 17.18 General Characteristics...
Page 318 17.18 General Characteristics Ambient temperature/humidity range conditions (see next image) Guaranteed operation range 0°C to +40°C, 5 to 85%RH (Where absolute humidity is 1 to 25g/m , non-condensing) The temperature range is limited for some specifications Altitude: 2000m or lower Storage requirements: -10 to +50°C, 5 to 95%RH (Where absolute humidity is 1 to 29g/m...
Page 319 17.18 General Characteristics ■Outline dimensional drawing (WF1967) WF1967/WF1968 17-29...
Page 320 17.18 General Characteristics ■Outline dimensional drawing (WF1968) WF1967/WF1968 17-30...
Page 321 17.18 General Characteristics ■Rack mount dimensional drawing (EIA, for 1 unit) WF1967/WF1968 17-31...
Page 322 17.18 General Characteristics ■Rack mount dimensional drawing (EIA, for 2 units) WF1967/WF1968 17-32...
Page 323 17.18 General Characteristics ■Rack mount dimensional drawing (JIS, for 1 unit) WF1967/WF1968 17-33...
Page 324 17.18 General Characteristics ■Rack mount dimensional drawing (JIS, for 2 units) WF1967/WF1968 17-34...
Page 325 For repair service under warranty, the product must be returned to either NF or an agent designated by NF. Purchaser shall prepay all shipping cost, duties, and taxes for the product to NF from another country, and NF shall pay shipping charge to return the product to purchaser.
Page 327 However, we assume no responsibility for any damage regarding the contents of this manual. • We assume no responsibility for influences resulting from the operations in this manual. WF1967/WF1968 Instruction Manual (Operation) NF Corporation 6-3-20 Tsunashima Higashi, Kohoku-ku, Yokohama 223-8508, JAPAN Phone: +81-45-545-8111 Fax: +81-45-545-8187 http://www.nfcorp.co.jp/ ◯ C Copyright 2015 NF Corporation...
Page 329 空白...
Page 330 NF Corporation 6-3-20, Tsunashima Higashi, Kohoku-ku, Yokohama 223-8508 JAPAN Aufgrund laufender Weiterentwicklungen sind Änderungen der Spezifikationen vorbehalten. Alle Angaben vorbehaltlich Satz- und Druckfehler. nbn Austria GmbH Riesstraße 146, 8010 Graz Tel. +43 316 40 28 05 | Fax +43 316 40 25 06...

This manual is also suitable for:

Wave factory wf1967

NF WAVE FACTORY WF1968 Instruction Manual (Operations

1 Overview

2 Preparations before Use

3 Panels and I/O Terminals

4 Basic Operations

5 Saving and Recalling Settings

6 Variable Parameter Waveforms

7 Creating Arbitrary Waveforms

8 Convenient Use of 2-Channel Equipment

9 Synchronizing Multiple Units

10 Using External Frequency Reference

11 Using the Sequence Oscillation

12 Using User-Defined Units

13 Other Utility Settings

14 Troubleshooting

15 Maintenance

16 List of Initial Settings

17 Specifications

Quick Links

Need help?

Questions and answers

Related Manuals for NF WAVE FACTORY WF1968

Summary of Contents for NF WAVE FACTORY WF1968
