The EZW1204 Z-Wave Leak Sensor requires 3 x AA batteries. Depending on controller and leak configuration, a standard set of alkaline
batteries should last 3+ years. We recommend lithium batteries for a longer battery life.
•
The EZW1204 can be wall mounted using the snap-in base with wired leak sensor or it can be placed on the floor in sensitive areas.
Sensitive Leak Locations:
•
Laundry Room Floor
•
Floor by hot water tank
•
Below Dishwasher
•
Bathroom/s behind toilet (wall mount configuration)
•
Floor behind fridge with ice maker/water
•
Under kitchen sink (wall mount configuration)
•
Sump pump (wall mount configuration
Caution: If you do not have experience installing
and configuring EZW1204 type of devices, please
consult a professional installer.
Specifications:
•
Model: EZW1204 (U.S.)
•
3 x AAA Batteries required
•
Z-Wave Plus, 908MHz
•
Wireless Range: 30M (line of sight)
•
Leak Sensor with 3 x gold spring probes
•
Snap-In base for wall mounting
•
Wired Plug In Leak Sensor
•
3 x LED Status Indicators
•
Lever switch for inclusion/exclusion
Floor Mounting:
Select a clean area that is likely to pool water in the case of a leak. Place the EZW1204 (without wall mount base) on the floor or surface in this leak
sensitive area. The surface should be flat so that EZW1204 is resting with all three spring loaded pins touching the floor or flat surface. The wall
mount kit should be use for the installation in areas where the sensor might be disturbed or move by a pet or person.
EZW1204 Quick Start Guide
Advertisement
Table of Contents
Summary of Contents for EcoNet EZW1204
- Page 1 Floor Mounting: Select a clean area that is likely to pool water in the case of a leak. Place the EZW1204 (without wall mount base) on the floor or surface in this leak sensitive area. The surface should be flat so that EZW1204 is resting with all three spring loaded pins touching the floor or flat surface. The wall...
- Page 2 (wired plug at 180 degrees pointing down). Mount the sensor disc using double-sided tape so that it is in an ideal position to sense water. Snap the EZW1204 into the wall bracket and test by wetting the sensor disc with a wet cloth. The EZW1204 must be positioned in the wall bracket properly for the disc sensor to work.
- Page 3 EZW1204 Leak Senor into your Smart Home automation for notification and activation of other devices such as the EcoNet Valve Robot to shut off the water. Once in position, when the leak sensor probes, either on the bottom or on the wired disc probe, get wet, it will send a “leak message”...
- Page 4 Z-Wave Network inclusion Press the Power button 3 or more times rapidly (within 0.5 seconds). It is recommended to keep the EZW1204 within 1M/3ft of the controller. (Set controller to inclusion mode first) Z-Wave Network exclusion Power the button 3 or more times rapidly (within 0.5 seconds). It is recommended to keep the EZW1204 within 1M/3ft of the controller.
