Lindsay LBLE100A Installation Manual

High Output two-way Broadband Line Extender
Model
LBLE100A
Lindsay's LBLE100A is a TOUGH outdoor hardened distribution amplifier offering two outputs, multiple diplex filter
options and the latest GaAs hybrid technology to provide superior performance up to 1 GHz.
The LBLE100A fills out the selection of 1 GHz Distribution Amplifiers and Line Extenders giving you extra reach and
higher output.
Designed with flat operational gain of 34 dB in the forward band and 20 dB in the reverse band. The LBLE100A has
sockets for JXP style plug-in controls. Input and midstage attenuators & equalizers, for forward bandwidth equalization &
balancing. And input attenuator plus output attenuator & equalizer for reverse path balancing. Universal JXP style pads
applicable for both attenuator and equalizer functions.
The amplifiers are powered via HFC power (40-90 VAC) or by seperate AC input. (220 VAC) (optional).
FEATURES
•
1 GHz high performance
GaAs-FET Technology for
high output levels with low
distortions
•
15 PSI tested aluminum
die cast housing
•
Two High Output ports
•
Bi-directional split
frequency 42/54 MHz or
65/87 MHz
•
Input stage and Inter-
stage level slope are
adjustable in both
Upstream & Downstream
path
•
Balanced alternative
technology, adopt
attenuation plug-in form to
balance adjustment
•
JXP style pad controls
applicable for both
attenuator and equalizer
functions
•
High-efficiency switching
power, multi-stage surge
suppression circuitry
Bandwidth
5-42 MHz / 54-1000 MHz
5-65 MHz / 87-1000 MHz
SPECIFICATIONS (Typical)
Typical, for T = 20degC, Zin = Zout = 75 ohms
Parameter
Up to 860 MHz also
Bandwidth available instead of
Full Gain (Min)
Flatness
Return Loss, IN/OUT
RF Output Signal Level
Gain Adjustment Range JXP plug-in pad
Slope Adjustment Range JXP plug-in pad
Noise Figure
At dynamic range
NPR
Hum Modulation
CTB
CSO
Forward: CH-2
Group Delay
Reverse: 41-42 MHz
Dimension
Powering
Power Consumption
Operating Temperature
Weight
1
Installation Manual
40-90 VAC or
220 VAC External Powering
Notes Forward
54-1000
or
1000 MHz 87-1000
≥ 34
± 0.75
≥ 16 (54 – 550 MHz)
≥ 14 (550 – 1000 MHz)
≥ 48
0 – 20
0 – 20
≤ 7.0
-
≥ 35 dB
≥ 65
≥ 71
≥ 66
≤ 35.0
(W x H x L) 300 x 220 x 128
40-90 VAC 50/60 Hz;
25 VA
40
-25 to +55
4
LBLE100A
Powering
Reverse Units
5-42
or MHz
5-65
≥ 20 dB
± 0.75 dB
-16 dB
≥ 44 dBmV
0 – 20 dB
0 – 20 dB
≤ 7.0 dB
≥ 40 dB
≥ 60 dBc
≥ 65 dBc
≥ 63 dBc
≤ 20.0 ns
mm
Watts
°C
kg
LBLE100A_August 2015_ver 1
