Summary of Contents for Qtx PAR FADER
- Page 1 PAR FADER Item ref: 154.098UK 32 Channel DMX Controller User Manual Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Top panel Start address + LED numerical display Start address - Page indicator LEDs Channel faders Page select button Master fader Rear panel Power on/off switch 9Vdc power adaptor input DMX out XLRF 9V battery compartment Setting up Connect the DMX output (10) to the first DMX lighting fixture or effects unit in line using a DMX cable with 3-pin XLR connection.
- Page 3 The PAR FADER also has a DMX start address which is the DMX address of Fader 1 on page 1, usually set to “001”. To set a different start address, use the Start Address Up and Down buttons (1, 3) to set the start address, which will be shown in the display (2).
-
Page 4: Specifications
Specifications Power supply 9Vdc, 1000mA power adaptor (supplied) Battery Optional 9V PP3 battery (not supplied) Controls On/off switch, 8 faders, 1 master fader, page select, start address +/- DMX channels 32 (4 pages of 8) DMX connection XLRF output Dimensions 230 x 135 x 53mm Weight 910g...
