Audio MusiKraft
Nitro
LOMC (low output moving coil) phono cartridges
Owner's Manual
* Read this manual before handing the cartridge *
This manual is for general information and applies to all Audio MusiKraft
Nitro
Cartridges.
- The World's First and Only "Tunable" and "Customizable" Phono Cartridge –
Audio MusiKraft, Quebec, Canada /
/
rev. 10/2019
audiomusikraft.com
info@audiomusikraft.com
Advertisement
Table of Contents
Summary of Contents for Musikraft Nitro Series
- Page 1 LOMC (low output moving coil) phono cartridges Owner’s Manual * Read this manual before handing the cartridge * This manual is for general information and applies to all Audio MusiKraft Nitro Cartridges. - The World’s First and Only “Tunable” and "Customizable" Phono Cartridge –...
- Page 2 Audio MusiKraft would like to thank you for purchasing this fine piece of audio equipment! We took a lot of pride in manufacturing it from start to finish. Get ready for the dramatic change and to - Take Control of your Sound -...
-
Page 3: General Warnings
In the event you need to clean the Audio MusiKraft shell, only clean with very soft damped cloth when the cartridge motor and the tone wood inserts are removed from its shell. Treat this piece of equipment as if it was jewelry and it will last you a lifetime. -
Page 4: Included In The Kit
Almost infinite sonic tuning capability. Included in the Kit: One (1) Audio MusiKraft phono cartridge One (1) 3D printed black plastic guard One (1) Torrefied pine wood insert set (Beeswax patina on external face) One (1) Maple wood insert set (3 coat lacquer on external face) -
Page 5: How To Use
How to Use: Mounting on tonearm a) The MusiKraft can be mounted on any commercially available universal tonearm or headshell built to ½” EIA standards. In order to obtain the best performance from the cartridge, it is important to select a well constructed medium to high mass (10g or more) tonearm, and a solid headshell which both offers good performance. - Page 6 The output voltages are 0.35 mV (Nitro1) and 0.30mV (Nitro2). Since these are low relative to an MM type cartridge, your system must have a MC phono input or you will either need a MC head amp or a step-up transformer (SUT). Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com...
- Page 7 (video supported help) a) Motor installation is the reversed procedure Tone wood inserts The modular Audio MusiKraft design renders the inserts interchangeable within all the Nitro cartridge models. Each insert set contains (3) three pieces; one (1) piece for the cover and two (2) for the sides.
- Page 8 Slip out the motor With the help of the wooden pushrod, apply pressure on the edge of the internal surface of the top insert so it comes out. g) Proceed with the sides. Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com info@audiomusikraft.com...
- Page 9 Be rigorous, this is fine-tuning at its best. You will notice that the fine cartridge generator is very sensitive to its surrounding Audio MusiKraft shell tuning combinations. During your A/B comparisons, do not change the volume position, find a comfortable level from start and leave it as is. Changing it will impact your perception.
- Page 10 4) Listen now to the cartridge with your preferred wood inserts (natural or with treatment / finish): a) Choose preferred wood set and dial-in your preferred screw setting b) Fine-tune screws to your sonic preference Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com...
-
Page 11: Specifications
40Ω ± 20 % 14Ω ± 20 % Recommended load resistance: 100Ω min. (40 Ω min. SUT) 100Ω min. (14Ω min. SUT) 100Ω min. (40 Ω min. SUT) 100Ω min. (14Ω min. SUT) Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com info@audiomusikraft.com... - Page 12 14Ω ± 20 % Electrical impedance (1 kHz): 100Ω min. (40 Ω min. 100Ω min. (14Ω min. 100Ω min. (40 Ω min. 100Ω min. (14Ω min. Recommended load resistance: SUT) SUT) SUT) SUT) Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com info@audiomusikraft.com...
- Page 13 5 x 10-6 cm/dyne Compliance (on disc): 40Ω ± 20 % 14Ω ± 20 % Electrical impedance (1 kHz): 100Ω min. (40 Ω min. SUT) 100Ω min. (14Ω min. SUT) Recommended load resistance: Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com info@audiomusikraft.com...
- Page 14 For best fitment, we suggest buying your extra wood sets at cartridge or shell's date of purchase. Downloads Common Wood Inserts List and Pictures (24 species) (PDF) Complete Wood Inserts Pricelist and Density Chart (100 species) (PDF) Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com info@audiomusikraft.com...
- Page 15 We hope these instructions will help you get the best out of your cartridge. We would greatly appreciate receiving your feedback and thanks in advance for sharing your experience with other enthusiasts. All the Best, Audio MusiKraft Audio MusiKraft, Quebec, Canada / rev. 10/2019 audiomusikraft.com info@audiomusikraft.com...
