Pace ThermoTweez Handpiece TT-65 Operation & Maintenance Instructions Manual

Hide thumbs Also See for ThermoTweez Handpiece TT-65:
Table of Contents

Advertisement

Quick Links

®
TT-65
TT-65 ThermoTweez Handpiece
Operation & Maintenance Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThermoTweez Handpiece TT-65 and is the answer not in the manual?

Questions and answers

Related Manuals for Pace ThermoTweez Handpiece TT-65

Summary of Contents for Pace ThermoTweez Handpiece TT-65

  • Page 1 ® TT-65 TT-65 ThermoTweez Handpiece Operation & Maintenance Instructions...
  • Page 2 TT-65 TT-65 ThermoTweez Handpiece Part Number 7025-0001 Manual Number 5050-0336 Rev. C...
  • Page 3 PACE SensaTemp power source. CAUTION Always use this handpiece in a well ventilated area. A fume extraction system such as the PACE Arm-Evac is highly recommended to help protect personnel from solder flux fumes. NOTE Remember that the ThermoTweez is primarily a component removal tool.
  • Page 4 2 Mounting Screws supplied. 3. Install the Drip Tray and secure with Mounting Screw. 4. The SX-80 Tip & Tool Stand can be attached to some PACE power sources. Refer to the power source Operation & Maintenance manual for the applicable instructions.

  • Page 5: Handpiece Setup

    TT-65 HANDPIECE SETUP HANDPIECE ALIGNMENT Check the handpiece heaters for proper alignment with each other. Proper handpiece (and tip) alignment is essential for effective operation. 1. Remove any installed tip halves. 2. With the handpiece at room temperature, adjust the Heaters parallel to each other (see ) using the Tip Gap Á...

  • Page 6: Power Source Connection

    288 - 343°C (550 - 650°F) range. Tip temperature and removal times will vary with each application. PACE recommends the use of a 316°C (600°F) tip temperature setting for initial use in any particular application.

  • Page 7: Tip Installation

    Temperature Selection System booklet. NOTE Selection of the proper tips is essential for successful repair. If you do not have the proper tip, call PACE or your local authorized PACE distributor for assistance. Ask for a copy of the PACE Tip & Applications Catalog for the latest listing of available tips.
  • Page 8 TT-65 a) Small PLCC Tips (no slots) and Chip Component Tips: 1. Position the tip ends as shown. 2. Squeeze the handpiece closed to press the tip ends together. 3. Holding the handpiece closed, adjust the tip ends as necessary so that they meet precisely together.
  • Page 9 2. Using the tip gap adjustment thumb screw at the rear of the ThermoTweez handpiece, increase the space between the tip halves to allow insertion of the Sponge Tool or Fiber Tool from the Tip Maintenance Station (PACE P/N 6993-0138). NOTE The Tip Tool may also be used for this purpose.
  • Page 10 Proper preparation will insure optimum results and increase tip life. NOTE The use of a PACE Tip Maintenance Station (P/N 6993-0138) is recommended for the proper preparation and maintenance of all ThermoTweez tips. If this item has not been purchased, contact your local authorized PACE distributor for assistance.

  • Page 11: Special Applications

    TT-65 SPECIAL APPLICATIONS If you require assistance in the use of this handpiece or require assistance with a special application, contact PACE Applications Support at: Telephone: 1-888-(535)-7223 (toll-free) or (301) 490-9860 Fax: (301) 604-8782 CORRECTIVE MAINTENANCE Use Table 1 and the illustrations to determine the cause of malfunctions to your ThermoTweez handpiece.

  • Page 12: Wiring Diagram

    TT-65 SY MP TO M SY MP TO M CHECKOUT CHECKOUT PROCEDURE PROCEDURE CAUSE CAUSE S O LU T I O N S O LU T I O N SY MP TO M SY MP TO M CHECKOUT CHECKOUT PROCEDURE PROCEDURE CAUSE CAUSE...

  • Page 13: Replacement Parts

    TT-65 REPLACEMENT PARTS Table 2 lists the parts needed to maintain your ThermoTweez handpiece. Description Part Number 6010-0082-P Heater Assembly "A" (with sensor) 6010-0083-P Heater Assembly "B" (without sensor) 1348-0547 Heater Set Screw 1100-0206 Tip Tool 1100-0234 Tip Alignment Tool Cushion Grip Kit 6993-0155 Replacement Pads For Cushion Grips...
  • Page 14 Contact your local authorized PACE Distributor or PACE Incorporated to obtain the latest specifications. The following are registered trademarks and/or servicemarks of PACE Incorporated, Laurel Maryland U.S.A. and may only be used to identify genuine PACE products or services: Arm-Evac, Cir-Kit, ConducTweez, CRAFT, Flo-D-Sodr, Heat Wave,...
