About this documentation:
This documentation was originally produced in Dutch by:
Wagenbouw HAPERT
Version name :
Fifth edition
:
© Copyright
:
No part of this documentation may be reproduced in any form whatsoever without the
permission of Wagenbouw HAPERT, except for those chapters that are intended to be
reproduced for use with this documentation, such as summarised instructions and
markings placed on trailers.
About the trailer:
This user documentation is intended for all HAPERT trailers.
For further information, see the type plate on the trailer.
About the manufacturer:
The trailer was manufactured by:
Wagenbouw HAPERT BV (in short: HAPERT)
Handelsweg 13
5527 AL Hapert
The Netherlands
Tel: +31 (0) 497 38 68 68
Fax: +31 (0) 497 38 68 82
Internet:
www.hapert.com
E-mail:
info@hapert.com
User documentation/CE/warranty conditions
January 2019
Wagenbouw HAPERT BV, Hapert, 1998
