Summary of Contents for Bay Alarm VISTA-20BAY

  • Page 1 9,67$ %$< 6HFXULW\6\VWHP ,QVWDOODWLRQDQG6HWXS*XLGH ARMED AWAY STAY TEST BYPASS INSTANT CODE CHIME I I I I I I READY SINCE 1946 Liberty System PANIC HEAT COOL BYPASS ACTIVE SINCE 1946 N7526-4V1 5/00 File No: S1632...
  • Page 3: Recommendations For Proper Protection

    RECOMMENDATIONS FOR PROPER PROTECTION The Following Recommendations For The Location Of Fire And Burglary Detection Devices Help Provide Proper Coverage For The Protected Premises. Recommendations for Smoke and Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.
  • Page 4: Table Of Contents

    Table of Contents • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Conventions Used in This Manual .......................
  • Page 5 Table of Contents (cont’d) Section 9 - External Sounders ........................9–1 Compatible Sounders............................9–1 Sounder Connections............................9–2 Sounder Supervision ............................9–2 Testing the Sounder ............................9–2 Section 10 - Long Range Radio.........................10–1 About Long Range Radio..........................10–1 Connection..............................10–1 Dynamic Signaling Feature ..........................10–2 Section 11 - Remote Keyswitch.........................11–1 Introduction ..............................11–1 Installing the Keyswitch ..........................11–1 Programming for the Remote Keyswitch .....................11–3...
  • Page 6 Table of Contents (cont’d) Section 21 - Remote Programming and Control (Downloading)............21–1 About Remote Programming.........................21–1 Equipment Required .............................21–1 Initial Download ............................21–2 Remote Programming Commands........................21–2 Remote Programming Advisory Notes ......................21–2 Section 22 - System Communication .......................22–1 Panel Communication with Central Station....................22–1 Report Code Formats.............................22–1 Section 23 - System Operation........................23–1...
  • Page 7 Figure 21. Connection of AAV Unit When not Using a 4285/4286 VIP Module ..........12–2 Figure 22. Connection of AAV Unit When also Using a 4285 or 4286 VIP Module ........12–2 Figure 23. VISTA-20BAY Summary of Connections ..............Inside Back Cover...
  • Page 8: Conventions Used In This Manual

    Conventions Used in This Manual • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Before you begin using this manual, it is important that you understand the meaning of the following symbols: A UL note includes specific information that must be followed if you are installing this system for a...
  • Page 9: Introduction

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Description The VISTA-20BAY is a security system control that supports up to 38 zones, including eight basic hardwired zones (1 through 8) and a maximum of 30 expansion zones. These expansion zones may include up to eight hardwired zones, or up to 30 wireless zones if hardwired zones are not used.
  • Page 10 VISTA-20BAY Installation & Setup Guide Remote Keypads Up to 4 of either of the following keypads may be used in the installation: • Fixed-Word Keypad: 6128 • Alpha Keypad: SK6139A-BAY (2-line alphanumeric displays). To program from a keypad, you must connect a SK6139A-BAY 2-line alpha keypad, but it need not stay in the system.
  • Page 11: Section 1 - Introduction

    Section 1 - Introduction Powerline Carrier devices require the use of the optional 4300 Transformer Module instead of the supplied 1321 AC Transformer. Optional Phone Module • Supports the ADEMCO 4285/4286 VIP Module (refer to Section 8: 4285/4286 VIP Module for further information) •...
  • Page 12 To program from a keypad, you must connect a SK6139A-BAY 2-line alpha keypad, but it need not stay in the system. Communication Formats Supported The VISTA-20BAY supports the following communication formats: • ADEMCO Low Speed (Standard or Expanded) • Sescoa/Radionics (Standard or Expanded) •...
  • Page 13: Installing The Control

    S E C T I O N Installing the Control • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section General Information Mounting the Control and RF Receiver Circuit...
  • Page 14: Mounting The Control's Circuit Board Alone In The Cabinet

    VISTA-20BAY Installation & Setup Guide 1. Remove the cabinet door. It is easily RETAINER CLIP removable for servicing and is easily re- (NOTE POSITION) installed. 2. Remove the lock knockout from the control cabinet door. Insert the key into LOCKED RETAINER the lock.
  • Page 15: Mounting Control And Rf Receiver Circuit Boards Together In The Cabinet

    Section 2 - Installing The Control Mounting Control and RF Receiver Circuit Boards Together in the Cabinet 1. Hang two long mounting clips (provided with receiver) on the raised cabinet tabs, as shown in Detail B in Figure 3. 2. Insert the top of the receiver board (removed from its own case as described in its instructions) into the slots at the top of the cabinet, as shown in Detail A in Figure 3.
  • Page 16: Standard Phone Line Connections

    VISTA-20BAY Installation & Setup Guide Standard Phone Line Connections The wiring connections shown here are not applicable if the 4285/4286 VIP Module is used. Refer to Section 8: 4285/4286 VIP Module for information regarding phone line connections, which are different than those shown here.
  • Page 17: Wiring The Ac Transformer

    Section 2 - Installing The Control Wiring the AC Transformer 1321 Transformer Wire the 1321 Transformer to terminals 1 and 2 on the control board. See wiring table below for wire gauge to use. Use caution when wiring the transformer to the control panel to avoid blowing the fuse inside the transformer (the fuse is nonreplaceable).
  • Page 18: Installing The Backup Battery

    VISTA-20BAY Installation & Setup Guide Installing the Backup Battery If necessary, refer to Section 13: Final Power-Up for information regarding battery size to use, etc. Do not attach the connector cable to the battery terminals until you are instructed to do so later in the manual.
  • Page 19: Installing Remote Keypads

    S E C T I O N Installing Remote Keypads • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section General Information Using a Supplementary Power Supply to Power...
  • Page 20: Mounting The Keypads

    Using a Supplementary Power Supply to Power Additional Keypads The VISTA-20BAY control provides 600mA max (500mA max for UL installations) for powering keypads (up to a maximum of 4) and other devices from the auxiliary power output.
  • Page 21: Preliminary Checkout Procedure

    1. Temporarily connect a 2000-ohm end-of-line resistor across each of the basic hardwire zones 1-8, as shown in Figure 23. VISTA-20BAY Summary of Connections diagram. Without actual zone wiring or EOL resistors connected, the keypads will not display the READY message.
  • Page 22 VISTA-20BAY Installation & Setup Guide 3–4...
  • Page 23: Basic Hardwired Zones 1-8

    Wiring Burglary and Panic Devices to Zones 1-8 1. Connect sensors/contacts to the hardwired zone terminals (8 through 20). See Figure 23. VISTA-20BAY Summary of Connections diagram. 2. Connect closed circuit devices in series in the high (+) side loop. The EOL resistor must be connected in series with the devices, following the last device.
  • Page 24: Figure 8. 2-Wire Smoke Detector Connected To Zone 1

    VISTA-20BAY Installation & Setup Guide Wiring 2-Wire Smoke Detectors to Zone 1 1. Connect 2-wire smoke detectors across zone 1 terminals 8 (+) and 9 (–). Observe proper polarity when connecting the detectors. 2. If an EOL resistor is presently connected across zone 1 terminals, remove it. The EOL resistor must be connected across the loop wires at the last detector.
  • Page 25: Figure 9. 4-Wire Smoke Detector Connections (Zones 2-7)

    Section 4 - Basic Hardwired Zones Wiring 4-Wire Smoke/Combustion Detectors on Zones 2-7 The system supports as many 4-wire detectors as can be powered from Auxiliary Power on the control on zones 2-7. Refer to the detector’s instructions for complete details regarding proper installation and operation.
  • Page 26: Figure 10. Glassbreak Detector Connections To Zone 8

    VISTA-20BAY Installation & Setup Guide Wiring 2-Wire Latching Glassbreak Detectors on Zone 8 Use zone 8 for connection of compatible 2-wire latching-type glassbreak detectors. Connect all detectors in parallel across zone 8 (terminals 19 and 20). After an alarm, the first code + OFF turns off the siren and disarms the system; the second code + OFF clears the memory of alarm and resets the glassbreak detector.
  • Page 27: Programming Hardwired Zones

    Section 4 - Basic Hardwired Zones Programming Hardwired Zones Each zone must be programmed into the system using the ∗56 Zone Programming mode, or ∗58 Expert Programming Mode, which assigns characteristics that define the way the system responds to faults on that zone. Refer to Section 15: Zone Response Type Definitions and Section 17: Zone Programming for specific instructions on programming hardwired zones.
  • Page 28 VISTA-20BAY Installation & Setup Guide 4–6...
  • Page 29: Wired Zone Expansion

    S E C T I O N Wired Zone Expansion • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Introduction Programming Wired Expansion Zones...
  • Page 30: Figure 11A. Wiring Connections, 4219 Expansion Module

    VISTA-20BAY Installation & Setup Guide 4219 DIP SWITCH FOR SETTING ADDRESS AND ZONE A RESPONSE REED (TAMPER) SWITCH TAMPER JUMPER POSITION 4-PIN CONSOLE PLUG 4219 IN CABINET CONNECTIONS SAME (NOT TAMPERED) GRN DATA OUT AS TB2 TO CONTROL 4219 REMOTE (TAMPER PROTECTED) (–) GROUND...
  • Page 31: Programming Wired Expansion Zones

    Section 5 - Wired Zone Expansion Programming Wired Expansion Zones ✱ ✱ Each zone must be programmed into the system using the 58 Zone Programming mode, which assigns characteristics that define the way the system responds to faults on that zone. Refer to Section 15: Zone Response Type Definitions and Section 17: Zone Programming for specific instructions on programming wired expansion zones.
  • Page 32 VISTA-20BAY Installation & Setup Guide 5–4...
  • Page 33: Wireless Expansion (5800 System)

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Wireless Expansion In addition to its basic wired zones, the VISTA-20BAY control supports up to 30 wireless zones using an appropriate 5881 type RF receiver. The actual number of zones supported depends on whether you are using a wired zone expander module.
  • Page 34: Installing The 5881/5882 Receiver

    VISTA-20BAY Installation & Setup Guide Installing the 5881/5882 Receiver RF System Installation Advisories Follow the guidelines below when installing the RF receiver. (Disregard if the receiver is mounted in the control cabinet.) • Place the RF receiver in a high, centrally located area for best reception.
  • Page 35: Installing The 5800Tm Module

    Terminal 6 YELLOW (Data from Control) Terminal 7 BLUE: Not Used Do not cut any of the jumpers on the 5800TM when using it with the VISTA-20BAY. For additional information, refer to the 5800TM’s instructions. Jam Detection and Reporting When field ✱...
  • Page 36 VISTA-20BAY Installation & Setup Guide For button transmitters (RF “keys”), such as the 5801, 5803, 5804, and 5804BD, you must assign a unique zone number to each individual button used on the transmitter. Each button on the transmitter also has a predesignated loop or input number, which is automatically displayed on the keypad.
  • Page 37 Section 6 - Wireless Expansion Transmitter Battery Life Do not install batteries in wireless transmitters until you are ready to enroll the transmitters during system programming. After enrolling, batteries need not be removed. Batteries in the wireless transmitters may last from 4 to 7 years, depending on the environment, usage, and the specific wireless device being used.
  • Page 38: Series Transmitters Table

    VISTA-20BAY Installation & Setup Guide 5800 Series Transmitters Table Also refer to Appendix A for transmitter input loops/button locations. Model Description Input Type and Special Notes 5801 Wireless Panic Enroll as “3” for RF (supervised), or “4” for UR (unsupervised).
  • Page 39: Installing 5800 Series Transmitters

    Section 6 - Wireless Expansion Installing 5800 Series Transmitters To be sure reception of the transmitter's signal at the proposed mounting location is adequate, perform a Go/No Go Test. Go/No Go Test Mode The Go/No Go Test verifies adequate RF signal strength from the proposed transmitter location, and allows you to reorient or relocate transmitters, if necessary, before mounting the transmitters permanently.
  • Page 40 VISTA-20BAY Installation & Setup Guide 6–8...
  • Page 41: Relay Outputs & Powerline Carrier Devices

    S E C T I O N Relay Outputs & Powerline Carrier Devices • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Relay/Powerline Carrier Device Basics Powerline Carrier Devices...
  • Page 42: Figure 13. 4204 Connections To Control

    VISTA-20BAY Installation & Setup Guide 2. Set the 4204/4229's DIP switch for a device address of “1” (switch 2 in the OFF position and switches 3, 4, and 5 in the ON position). Switch 1 determines the unit's cover tamper response (ON = disabled, OFF = enabled).
  • Page 43: Powerline Carrier Devices

    Section 7 - Relay Outputs & Powerline Carrier Devices 4229 ADDRESS SETTINGS SWITCH ("—" means "OFF") NUMBER — — — — — — — — — — — — — — — — — — — — — — — —...
  • Page 44: Programming Relay Outputs

    CONTROL BOARD Figure 15. 4300 Transformer Wiring Connections Programming Relay Outputs In the VISTA-20BAY, each device must be programmed as to how to act (ACTION), when to activate (START), and when to deactivate (STOP). Refer to the programming procedures for ✱...
  • Page 45: 4285 & 4286 Vip Module

    Installing the Phone Module General Information The 4285 or 4286 VIP Module is an add-on accessory for the VISTA-20BAY that permits access to the security system via a TouchTone phone (either on-premises or by a call-in when away). The 4286 VIP Module has the additional capability of controlling thermostat(s) and providing external speaker output.
  • Page 46 VISTA-20BAY Installation & Setup Guide Affix the phone module’s connections label (supplied separately) to the inside of the phone module's cover, if the cover is used. If you have installed the module within the cabinet, affix the label to the inside of the control cabinet's door.
  • Page 47: Figure 16. 4285/4286 Vip Module Wiring Connections

    Section 8 - 4285/4286 VIP Module 4285/4286 VIP MODULE WIRING NOTES: • Wire the phone module exactly as shown, using a direct-connect cord and RJ31X jack. • If you do not hear touch-tones when pressing keys after phoning the security system via an on- premises phone, try reversing the pair of wires connected to terminals 3 and 4 on either phone module and the pair of wires connected to terminals 21 and 22 on the control.
  • Page 48: Programming The 4285/4286 Vip Module

    VISTA-20BAY Installation & Setup Guide Programming the 4285/4286 VIP Module You must program the system for use with the 4285 or 4286 VIP Module. This includes assigning a phone code and selecting words from the Alpha Vocabulary List. Refer to the programming sections for specific programming details.
  • Page 49: External Sounders

    10.2-13.8 VDC voltage range, and must be mounted indoors. Example: Wheelock Signals Inc. siren model 34T-12 (provides 85dB[A] for NFPA 74 and Standard 985). The VISTA-20BAY complies with NFPA requirements for temporal pulse sounding of fire notification appliances.
  • Page 50: Sounder Connections

    VISTA-20BAY Installation & Setup Guide Sounder Connections The VISTA-20BAY provides a 12VDC output, which can power external alarm sounders (bells or sirens; see compatible sounders listed previously). This output will activate a sounder when an alarm occurs. Make connections to alarm output terminals 3 (+) and 4 (–). See Figure 17.
  • Page 51: Long Range Radio

    S E C T I O N Long Range Radio • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section About Long Range Radio Dynamic Signaling Feature...
  • Page 52: Dynamic Signaling Feature

    VISTA-20BAY Installation & Setup Guide Dynamic Signaling Feature This VISTA-20BAY control panel features Dynamic Signaling Delay (DSD) and Dynamic Signaling Priority (DSP) message reporting when Long Range Radio is used. These ✱ ✱ message outputs are accessed through data fields 54 and 55.
  • Page 53: Remote Keyswitch

    S E C T I O N Remote Keyswitch • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Introduction Programming for the Remote Keyswitch...
  • Page 54: Figure 20A. Keyswitch Wiring (4300 Interface Transformer Not Used)

    VISTA-20BAY Installation & Setup Guide 9-PIN 1 2 3 4 5 6 7 8 9 CONNECTOR ON CONTROL PANEL 4146 KEYSWITCH 4142TR CABLE (ARMED) YELLOW THESE WIRES NOT CONNECTED IF 4300 INTERFACE (READY) TRANSFORMER IS GREEN NOT BEING USED WHITE...
  • Page 55: Programming For The Remote Keyswitch

    Section 11 -Remote Keyswitch Programming for the Remote Keyswitch 1. With one 2-line alpha keypad (SK6139A-BAY), enter the programming mode by keying: Installer code + 8 + 0 + 0 If RF zones, wired expansion, or a keyswitch will be used, data fields ✱ 22 RF System, ✱ 25 Wired Zone Expansion, and ✱...
  • Page 56: Keyswitch Operation

    VISTA-20BAY Installation & Setup Guide Typical summary display A summary display appears, showing the data for zone 7 that Zn ZT was just programmed. If it is programmed satisfactorily, press 07 77 HW: 1 ✱ ] to continue. The next request is to enter an alpha descriptor for zone 7. As P r o g r a m A l p h a ? this is a keyswitch zone, no descriptor is required.
  • Page 57: Audio Alarm Verification (Aav) Unit

    S E C T I O N Audio Alarm Verification (AAV) Unit • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section General Information Wiring Connections...
  • Page 58: Figure 21. Connection Of Aav Unit When Not Using A 4285/4286 Vip Module

    VISTA-20BAY Installation & Setup Guide EARTH GROUND CONTROL EAGLE 23 24 25 SUPPLIED CABLE RED (R) RJ31X GREEN (T) (CA38A GREY (R) BROWN (T) in Canada) CONTROL/ DIALER HEADER 4204 RELAY 1 BROWN SHOWN TO PREMISES HANDSET DIP Switch INCOMING...
  • Page 59: Final Power-Up

    S E C T I O N Final Power-Up • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Earth Ground Connections Connecting the Backup Battery...
  • Page 60: Battery Tests

    • Red to the positive (+) battery tab on the control board • Black to the negative ( – ) battery tab on the control board. Refer to Figure 23. VISTA-20BAY Summary of Connections (SOC diagram) for location of the (+) and (–) battery tabs on the control board.
  • Page 61: Mechanics Of Programming

    S E C T I O N Mechanics of Programming • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section About Programming Interactive Mode Programming...
  • Page 62: Entering Program Mode

    VISTA-20BAY Installation & Setup Guide Entering Program Mode You may use one of the following methods: ✱ a) Press both [ ] and [#] at the same time within 50 seconds after power is applied to the control, or b) After power-up, enter Installer code (4 1 1 2) + 8 0 0.
  • Page 63: Loading Factory Defaults

    Section 14 - Mechanics Of Programming Loading Factory Defaults ✱ To load the factory defaults, enter the Programming mode, press 97, then exit the Programming mode. Do not press ✱ 97 to load defaults if any programming has been done previously—data already programmed into the system will be changed! ✱...
  • Page 64 VISTA-20BAY Installation & Setup Guide 14–4...
  • Page 65: Zone Response Type Definitions

    S E C T I O N Zone Response Type Definitions • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Zone Type Definitions •...
  • Page 66 VISTA-20BAY Installation & Setup Guide Type 04 This zone type gives a delayed alarm (using the programmed entry/exit time) if the entry/exit zone is faulted first. Otherwise this Interior Follower zone type gives an instant alarm. This zone type is active when the panel is armed in the AWAY or MAXIMUM mode.
  • Page 67: Section 15 - Zone Response Type Definitions

    Section 15 - Zone Response Type Definitions Type 10 This zone type gives Entry Delay (using the programmed entry time) if it is tripped when the panel is armed in the AWAY mode. Interior w/Delay Entry Delay begins whenever sensors in this zone are violated, regardless of whether or not an Entry/Exit Delay zone was tripped first.
  • Page 68 VISTA-20BAY Installation & Setup Guide 15–4...
  • Page 69: Data Field Descriptions

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Introduction The following pages list all data fields in the VISTA-20BAY in numerical order. If you have performed the programming instructions that were included with the installation of each of the peripheral devices covered in previous sections, this table will simply serve as a reference for all data fields in the system.
  • Page 70 VISTA-20BAY Installation & Setup Guide ✱ 25 WIRED ZONE EXPANSION 0 = no expander module connected 1 = 4219 connected 2 = 4229 connected 3 = 4204 connected ✱ 26 CHIME BY ZONE 0 = no (chimes on fault of any entry/exit or perimeter zone when chime mode...
  • Page 71 Section 16 - Data Field Descriptions ✱ 30 KEYSWITCH ENABLE (Zone 7) 0 = Disable 1 = Enable ✱ 31 SINGLE ALARM SOUNDING PER ZONE (per armed period) 0 = no limit on alarm sounding per zone 1 = limit alarm sounding to once per arming period for a given zone UL installations: Must be 0 (no limit) ✱...
  • Page 72 VISTA-20BAY Installation & Setup Guide ✱ CONFIRMATION OF ARMING DING 0 = no ding 1 = confirmation ding after arming system 2 = confirmation ding after arming from RF button or RF keypad only (ding occurs when the system receives the RF transmission) Confirmation of arming is -second external sounder “ding”...
  • Page 73 Section 16 - Data Field Descriptions ✱ ✱ For Fields ✱ PRIMARY SUBS ACCOUNT NO. 15 | 15 | 15 | 15 Enter digits 0-9; See box at left. # +11=B; # +12=C; ✱ SECONDARY SUBS ACCOUNT NO. # +13=D; # +14=E; or # +15=F.
  • Page 74 VISTA-20BAY Installation & Setup Guide Pager Report Format Entries 6 through 9 sends a report to a pager using the following format: The pager report is formatted as follows: AAAAAAAAAAAAAAAA – BBB – CCCC where: A = (Optional.) Up to 16 digits for account numbers, PIN numbers, or any additional data that will precede the 7-digit system status code BBB and CCCC (see B and C below).
  • Page 75 Section 16 - Data Field Descriptions ✱ SESCOA/RADIONICS SELECT 0 = Radionics (0-9, B-F reporting) 1 = SESCOA (0-9 only reporting) Select 0 for all other formats. DYNAMIC ✱ DYNAMIC SIGNALING DELAY (DSD) SIGNALING ✱ ✱ This field enables you to select the time the panel should wait for 54 - acknowledgment from the first reporting destination before it attempts to send a message to the second destination.
  • Page 76 VISTA-20BAY Installation & Setup Guide ✱ EXPERT PROGRAMMING MODE Interactive Menu mode used for enrolling transmitters, programming zone attributes, and report codes. Refer to Section 17: Zone Programming for procedure. TO PROGRAM ✱ Report codes can be programmed using the interactive...
  • Page 77 Section 16 - Data Field Descriptions If Contact ID format has been programmed, the message contains the zone number and error code 374 (Trouble-Exit Error) to define the alarm as an Exit Error (rather than E/E or Interior). If 4+2 format is used, the digit entered in this field is sent, followed by the second digit of the programmed alarm code for that zone.
  • Page 78 VISTA-20BAY Installation & Setup Guide ✱ TROUBLE RESTORE REPORT CODE 0 | 0 See box on previous page. This code is sent when a trouble in a zone is restored. ✱ BYPASS RESTORE REPORT CODE 0 | 0 See box. This code is sent when a zone that has been bypassed is unbypassed.
  • Page 79 #15. The default of 3 = Alarm/Alarm Restore (1) + Trouble/Trouble Restore (2). The VISTA-20BAY system has the ability to record various events in a history log (48-event capacity). The types of events to be logged can be selected as indicated.
  • Page 80 VISTA-20BAY Installation & Setup Guide ✱ PHONE LINE MONITOR ENABLE 0 = not used 1 = local keypad display only when phone line is faulted 2 = local keypad display plus keypad trouble sound when line is faulted. No automatic timeout.
  • Page 81 Section 16 - Data Field Descriptions ✱ INITIALIZE DOWNLOAD ID AND SUBSCRIBER ACCT. NO. FOR DOWNLOADING ✱ Pressing 96 initializes the system for downloading. ✱ SET ALL PROGRAM FIELDS TO DEFAULT VALUES ✱ Pressing 97 automatically loads all defaults and erases any information previously programmed.
  • Page 82 VISTA-20BAY Installation & Setup Guide 16–14...
  • Page 83: Zone Programming

    S E C T I O N Zone Programming 58 Menu Mode) ✱ ✱ • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section About Zone Programming To Remove a Zone...
  • Page 84 VISTA-20BAY Installation & Setup Guide È Zone Number Zone Type (ZT): Enter the Zone Type response (or change it, if necessary). 10 Zone Type Each zone must be assigned to a zone type, which defines the way Perimeter Ç in which the system responds to faults in that zone.
  • Page 85 Section 17 - Zone Programming Serial number Entry and Loop Number Entry: 10 INPUT S/N: Used only when enrolling wireless transmitters. Do one of the A 0 2 2 - 4 0 6 4 following: a. Transmit two open and close sequences. If you are using a NOTE: The [A] and [B] keys may be used to move the button-type transmitter, press and release the button twice.
  • Page 86: 58 Expert Programming Mode Procedures

    VISTA-20BAY Installation & Setup Guide If Serial or Loop If the serial/loop number combination transmitted does not match Numbers do not match the serial number entered, a display similar to the one below after activating the appears. If the loop number does not match, it is also transmitter displayed.
  • Page 87 Section 17 - Zone Programming A summary screen appears, showing zone 01’s current Zn ZT RC In: programming or default values. 01 09 10 HW: Enter the first digit of the zone number to be programmed. In ZT RC In: the example at the left, where zone 10 is to be programmed, the –...
  • Page 88: To Remove A Zone

    VISTA-20BAY Installation & Setup Guide The prompt to confirm appears. This prompt appears only if 10 XMIT TO CONFIRM you answered “Yes” to the SET TO CONFIRM? prompt at the ✱ PRESS TO SKIP bottom of page 17-4. To confirm, activate the loop input or button that corresponds to this zone.
  • Page 89: To Delete A Transmitter Serial Number

    Section 17 - Zone Programming 4. Enter 00. This sets the zone type to Zone Disabled. 0 1 Z o n e T y p e ✱ Z o n e D i s a b l e d Press [ ] to continue.
  • Page 90 VISTA-20BAY Installation & Setup Guide 3. Press [#] if you want to return to zone attributes screen. 4. When [ ✱ ] is pressed, the selected template will be displayed. 01 02 03 04 Top line of display represents loop numbers, bottom line 21 22 23 28 represents zone type assigned for each zone.
  • Page 91 Section 17 - Zone Programming Wireless Key Predefined Default Templates LOOP 3 GREEN/YELLOW LOOP 2 YOU MUST LOOP 2 PROGRAM THIS BUTTON LOOP 4 LOOP 1 RED/YELLOW LOOP 4 (YOU MUST PROGRAM THIS BUTTON) LOOP 3 LOOP 1 • • • •...
  • Page 92 VISTA-20BAY Installation & Setup Guide 17–10...
  • Page 93: Output Device Programming

    S E C T I O N Output Device Programming ✱ 80 Menu Mode) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Programming Options Defined Programming Output Relays and Powerline...
  • Page 94 VISTA-20BAY Installation & Setup Guide 2. Zone List (ZL) is a group of zones to which the event applies in order to activate a particular device. Note that there are 3 Output Device- ✱ Related zone lists that can be programmed in 81 Menu mode;...
  • Page 95: Programming Output Relays And Powerline Carrier Devices

    Section 18 - Output Device Programming Programming Output Relays and Powerline Carrier Devices ✱ While in Program mode, press 80 to enter Output Device Menu mode. This mode is used to program all Output Devices used in the system (4229 or 4204 Relay Modules, or ✱...
  • Page 96 VISTA-20BAY Installation & Setup Guide CHOICES FOR ZONE TYPES 00 = Not Used 04 = Interior Follower 08 = 24-Hr Aux 01 = Entry/Exit #1 05 = Trouble Day/Alarm Night 09 = Fire 02 = Entry/Exit #2 06 = 24-Hr Silent...
  • Page 97 Section 18 - Output Device Programming 2. The second condition for turning on the indicator is triggering a 24-hour aux. zone (Zone Type 08). Therefore, program (ZT) as ✱ ] to continue. 08. Press [ 3. To STOP the Device action and turn off the lamp, you do not want to use a restore of any zone, so enter a 0 for Stop: Zn Lst (ZL).
  • Page 98 VISTA-20BAY Installation & Setup Guide 18–6...
  • Page 99: Zone Lists

    S E C T I O N Zone Lists (*81 Menu Mode) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section About Zone List Menu Mode Zone List Displays...
  • Page 100 VISTA-20BAY Installation & Setup Guide 19–2...
  • Page 101: Alpha Descriptor Programming

    The Alpha Vocabulary List and Character Chart are on a following page. Zone Descriptors For the Alpha keypad used with the VISTA-20BAY, you can program into the system a user- friendly English language description/location of all protection zones, keypad panics, and RF receiver supervision faults.
  • Page 102 VISTA-20BAY Installation & Setup Guide ✱ 2. Press P r o g r a m A l p h a ? 0 = N o , 1 = Y e s The Program Alpha ? prompt appears. 3. Press 1 (Yes).
  • Page 103: Adding Custom Words

    Section 20 - Alpha Descriptor Programming 9. Press 6 to accept the selected word. ✳ Z N 0 1 B A C K If these are the only words you are using for the NOTE: D O O R descriptor, press 8 instead of 6 to save them in memory. Ç...
  • Page 104 ALPHA VOCABULARY LIST (For Entering Zone Descriptors) NOTE: The list below is a revised vocabulary list that differs from lists for earlier versions of the VISTA-20. Use only this list when programming VISTA-20BAY zone descriptors. (Word Space) • 064 DUCT •...
  • Page 105: Remote Programming And Control (Downloading)

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • About Remote Programming The VISTA-20BAY can be remotely programmed from an IBM-compatible personal computer (PC), an ADEMCO CIA modem, and ADEMCO's COMPASS software (as specified below).
  • Page 106: Initial Download

    Hayes Smartmodem 1200 External Modem Hayes Smartmodem 1200B Internal Modem (Rev. 1.2 or higher) Hayes external Optima 24 Plus FAX96 Modem Practical Peripherals PM14400FXSA • COMPASS® Downloader Software (at revision level supporting the VISTA-20BAY). • Appropriate interconnecting cables. Initial Download ✱...
  • Page 107: System Communication

    S E C T I O N System Communication • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Panel Communication with Central Station Report Code Formats...
  • Page 108 VISTA-20BAY Installation & Setup Guide The following describes each format in greater detail. 3+1 and 4+1 Standard Formats Comprise a 3- (or 4-) digit subscriber number and a single-digit report code (e.g. Alarm, Trouble, Restore, Open, Close, etc). 3+1 and 4+1 Expanded Formats Comprise a 3- (or 4-) digit subscriber number, and a two-digit report code.
  • Page 109 Section 22 - System Communication ADEMCO Contact ID Reporting takes the following format: CCCC Q EEE ZZZ where: CCCC = Customer (subscriber) ID Q = Event qualifier, where: E = new event, and R = restore EEE = Event code (3 hexadecimal digits) Note: For a complete list of event codes, refer to the Central Station office receiver manual.
  • Page 110 VISTA-20BAY Installation & Setup Guide 22–4...
  • Page 111: System Operation

    S E C T I O N System Operation • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Security Codes 4285/4286 VIP Module...
  • Page 112: Keypad Functions

    VISTA-20BAY Installation & Setup Guide • Duress code is User code No. 16. When this is used to perform any system operation, a special code is sent to the monitoring station. Instruct users to be careful not to use this code for normal usage.
  • Page 113: Relay/Powerline Carrier Devices

    Section 23 - System Operation SUMMARY OF ARMING MODES Features for Each Arming Mode Arming Perimeter Mode Exit Delay Entry Delay Interior Armed Armed AWAY STAY INSTANT MAXIMUM Panic Keys There are three panic key pairs or (on some keypads) lettered keys that, if programmed, can be used to initiate alarms manually and send a report to the Central Station.
  • Page 114: Trouble Conditions

    VISTA-20BAY Installation & Setup Guide • A display of EXIT ALARM or EA and a zone indication appears when the Exit Delay ends if an exit or interior zone contained a fault during closing. The alarm sounder and keypad sound continuously until the system is disarmed (or timeout occurs). An “Exit Alarm”...
  • Page 115 Section 23 - System Operation Power Failure Displays • If there is no keypad display at all and the POWER indicator (if present) is not lit, operating power for the system has been lost and the system is inoperative. • If the message AC LOSS (on alpha keypads) or NO AC (on fixed-word keypads) is displayed, and the POWER indicator (if present) is off, the keypad is operating on battery power only.
  • Page 116 VISTA-20BAY Installation & Setup Guide 23–6...
  • Page 117: Testing The System

    S E C T I O N Testing the System • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • In This Section Test Procedure •...
  • Page 118 VISTA-20BAY Installation & Setup Guide The keypads display all zone numbers of wireless units programmed into the system. As the system receives a signal from each of the transmitters, the zone number of that transmitter disappears from the display. The transmitter codes may be checked upon installation, or in an installed system.
  • Page 119: Troubleshooting Guide

    Transmitter signal not Check or change transmitter's battery. 1a. Transmitter or 5881/5882 is not properly received at 5881/5882. Check VISTA-20BAY's AC power. powered. 1b. If transmitter is 5827/5827BD: House 1b. Check code switches inside transmitter. Must match with RF House Code Code is not set in field *24, or transmitter programmed in VISTA-20BAY.
  • Page 120 2b. Telephone connection not secure. 2b. Check all connections. 2c. Digital communicator malfunctioning. 2c. Check with a different VISTA-20BAY. 2d. Telephone number in program needs 2d. Program prefix or access code into the prefix or access code.
  • Page 121 CONTACTING TECHNICAL SUPPORT PLEASE, before you call Technical Support, be sure you: • READ THE INSTRUCTIONS! • Check all wiring connections. • Determine that the power supply and/or backup battery are supplying proper voltages. • Verify your programming information where applicable. •...
  • Page 122 VISTA-20BAY Installation & Setup Guide NOTES 25–4...
  • Page 123: Specifications & Accessories

    • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Specifications VISTA-20BAY SECURITY CONTROL 12-1/2” W x 14-1/2” H x 3” D (318mm x 368mm x 76mm) 1.
  • Page 124 VISTA-20BAY Installation & Setup Guide 6128 REMOTE KEYPAD 1. Physical: 5-3/4” W x 4-3/4” H x 1” D (146mm x 121mm x 25mm) Voltage Input: 12VDC; Current Drain: 30mA 2. Electrical: 3. Interface Wiring: To control panel's keypad connection points.
  • Page 125: Accessories (Compatible Devices)

    Section 26 - Specifications & Accessories 4229 WIRED EXPANSION/RELAY MODULE 1. Physical: 6-1/2” W x 4-1/4” H x 1-1/4” D (169mm x 108mm x 32mm) 2. Electrical: Voltage Input: 12VDC; Current Drain: 35mA (Relays off) 180mA (Relays on) 3. Interface Wiring: To control panel's keypad connection points.
  • Page 126 VISTA-20BAY Installation & Setup Guide System Sensor Indoor piezo sounder (red or beige), rated at 90 dB @ 10 feet. PA400B (beige) PA400R (red) Compatible 2-Wire Smoke Detectors System Sensor 2300T Photoelectric w/heat sensor, direct wire 2400 Photoelectric, direct wire...
  • Page 127: Transmitter Input Loop Identification

    A P P E N D I X 5800 RF System Wireless Transmitters • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Transmitter Input Loop Identification All of the transmitters illustrated below have one or more unique factory-assigned input (loop) ID codes.
  • Page 128 VISTA-20BAY Installation & Setup Guide A–2...
  • Page 129: Appendix B - Regulatory Agency Statements

    A P P E N D I X Regulatory Agency Statements • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • UL NOTICE: This is a “Grade A”...
  • Page 130 VISTA-20BAY Installation & Setup Guide B–2...
  • Page 131: Appendix C - Warnings And Limited Warranty

    A P P E N D I X Warnings and Limited Warranty • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • WARNING! THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection...
  • Page 132 VISTA-20BAY Installation & Setup Guide Wireless transmitters (used in some systems) are designed to provide long battery life under normal operating conditions. Longevity of batteries may be as much as 4 to 7 years, depending on the environment, usage, and the specific wireless device being used. External factors such as humidity, high or low temperatures, as well as large swings in temperature, may all reduce the actual battery life in a given installation.
  • Page 133: Index

    Index • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 1011BE12M ..........
  • Page 134 VISTA-20BAY Installation & Setup Guide Cancel Report Code........... 16–9 Exit Error Alarm ..........23–3 Central Station..........16–8 Exit Error Report Code........16–8 Character (ASCII) Chart ........20–4 Expanded or 4+2 Format ........16–8 Character Chart ..........20–1 Expert Programming mode ......16–8 Character List ........... 20–3 External Sounders ..........9–1...
  • Page 135 Index Mechanics of Programming......14–1 Report Codes .............16–8 Model 112 ............11–1 Report Format ...........16–5 Modem ............... 14–1 Response Time (RT) ..........17–2 Momentary Switch..........11–1 Restore ...............16–9 Monitored Telephone Line ....... 23–4 RF.................6–4 No Alarm Response........... 15–3 RF House ID Code........6–4, 16–1 No.
  • Page 136 VISTA-20BAY Installation & Setup Guide Trouble by Day ..........15–2 Wiring 2-Wire Smoke Detectors......4–2 Trouble Condition ..........23–4 Wiring 4-Wire Smoke/Combustion Detectors..4–3 Trouble Report Code ......... 16–9 Wiring Length/Gauge Chart.......3–1 Trouble Restore Report Code ......16–9 Wiring Run Chart ..........3–2 Troubleshooting Guide ........
  • Page 137: Figure 23. Vista-20Bay Summary Of Connections

    Figure 23. VISTA-20BAY Summary of Connections...
  • Page 138 SINCE 1946 BAY ALARM 925 Ygnac io Valley Road Walnut Cr eek , CA 94596 ¬19 l N7526-4V1 5/00...

Table of Contents
