19" 2HU Splicing, Patching and Storage shelf

1 Introduction

2 General

2.1 Kit contents

2.2 Tools

2.3 Optional extras

3 Installation of the shelf

3.1 Mounting of shelf in the rack

3.2 Preparation of the shelf

3.3 Preparation of the trays

4 Cable termination

4.1 Cable termination in the rack

Loose tube cable

Loose tube ribbon cable

Central core cable

IFC cable

4.2 Side cable termination directly on

the shelf

Loose tube cable

IFC cable

4.3 Back cable termination directly on

the shelf

Loose tube cable

IFC cable

1 Introduction

Product function

This shelf is a 19" mechanical enclosure for a physical fiber management system.

It is used for splicing and patching: splicing primary coated fiber from loose tube cable or pigtails to fiber pigtails

on a single element base and connector patching to patchcords with a capacity of 48 splices and connections.

It is a high density multifunctional unit designed for particular applications and environments.

This unit uses Patching/Splicing Trays with 12 connector positions.

The GPST-12 trays house the splices, slack fiber, connectors, pigtails and patchcords.

It can be installed in Tyco Electronics's FIST rack and other 19" or metric (ETSI) racks.

Follow local safety regulations related to optical fiber plant elements.

FIST-GPS2-J

I N S T A L L A T I O N

5 Fiber routing

5.1 Installation of loose tube on the tray

5.2 Installation of break-out cable on the tray

5.3 Installation of IFC cable on the tray

5.4 Installation of ribbon cable on the tray

6 Storage

7 Patching

8 Closing the shelf

9 Important steps

I N S T R U C T I O N

Table of Contents

Need help?

Do you have a question about the FIST-GPS2-J and is the answer not in the manual?

Questions and answers

Summary of Contents for Tyco Electronics FIST-GPS2-J

Page 1 This unit uses Patching/Splicing Trays with 12 connector positions. The GPST-12 trays house the splices, slack fiber, connectors, pigtails and patchcords. It can be installed in Tyco Electronics’s FIST rack and other 19” or metric (ETSI) racks. Follow local safety regulations related to optical fiber plant elements.
Page 2: General
General Kit contents 2.1.3 Loose Tube/preconnectorized IFC IN- patchcord OUT (example: FIST-GPS2-J-AIA-4) 1 unit, incorporating 2.1.1 Patch cord IN - patch cord OUT (example: FIST-GPS2-J-AAA-4) • metal chassis with drawer • hingable metal front cover 1 unit, incorporating • hinge and Velcro strap for installation of GPST-12 trays •...
Page 3: Fist-Gps2-J
2.1.5 Non-preconnectorized break-out cable IN-patchcord 2.1.7 Shelf with storage OUT (example: FIST-GPS2-J-AKA-4) (example: FIST-GPS2-J-AAN-T) 1 unit, incorporating 1 unit, incorporating • metal chassis with drawer • metal chassis with drawer • hingable metal front cover • hingable metal front cover •...
Page 4: Installation
Tools required for installation • FACC-ALLEN-KEY-5-350 To mount the shelf in the rack • FACC-CAGE-NUT-TOOL For easy installation of cage nuts in the rack • FACC-TUBE-STRIPPER-02 Loose tube stripper • FISTV-E7170-0003-S5027 Marker pen Optional extras* FIST-UST-... * Side cable termination unit (max. 2 cables) FIST-CT-2HU-B-2 Back cable termination unit (max.
Page 5: Preparation Of The Shelf
3.1.3 Space requirements Preparation of the shelf minimum 60 mm at left/right for horn and IFC or pigtails. minimum 60 mm at left /right in case of cable side termination. minimum 45 mm at back in case of cable back termination. Spacing between adjacent units may vary depending on frame upright pitch and cable management products! 3.2.1...
Page 6: Cable Termination
Cable termination Cable termination in the rack Cable is already terminated in the rack or in the side duct of the rack on the cable termination plate. For the loose tube cable the tubes are protected from the cable termination plate with the flex tube. For central core cable, fibers are guided into guiding tubes (5 mm) who go "CLICK"...
Page 7 Loose tube ribbon cable 4.1.6 In case of loose tube cable: position the strength member at the bottom. Bundle the loose tubes with tape. Secure the strength 4.1.3 Kit content FIST-GR-CTB100 (loose tube ribbon) member with the screws. Continue with installation from paragraph •...
Page 8 4.1.9 Central core ribbon cable. 4.1.12 Secure with the cable clamp. Don’t squeeze the cable. Prepare the cable. Make sure you have 1,5 m of ribbon fiber on the tray. Respect dimensions shown on the drawings. Clean the fibers very well to make easy feeding possible.
Page 9 4.1.16 Slide the tool over the ribbons. Bundle at the end using Teflon tape (bundle in groups as you want to feed them through the tubes). Remove the unraveling device. 4.1.14 The tube divider FIST-GR-TD-5mm can be mounted in the rack. Install as shown.
Page 10: Side Cable Termination Directly On
Side cable termination directly on the shelf 4.2.1 The cable can be terminated on the shelf: cable terminations are suited for max. 2 cables, cable retention with tie-wraps, the loose tubes are fed through a flexible tube to the shelf, the strength member is attached to the plate.
Page 11 4.2.4 Install the flex tube holder on the bracket. 4.2.7 Fasten the flex tube (before trays are inserted) at the back of the metal hinge plate using 2 small tie-wraps and fix the flex tube with a third tie-wrap to the platform. Assure that tie-wraps are well tensioned to avoid slippage of the tube and cut the excess length of the tie-wraps.
Page 12 4.2,12 For cable coming from top use a reverse assembly. IFC cable 4.2.10 First fasten the flex tube at the bottom tube holder and afterwards at the top tube holder. 4.2.13 Kit contents • 1 metal plate • 2 strength member connectors + screws •...
Page 13: Back Cable Termination Directly On
4.2.15 Install the edge protection at the bottom of the opening. Mount the drum on the side panel. Cut the strength member to 60 mm 4.3.4 Apply 1 layer of foam tape around the flex tube at maximum. Attach the strength member and install as shown. approximately 10 mm from the end.
Page 14: Fiber Routing
4.3.7 Guide the identified loose tubes into the flex tube. This can be facilitated by keeping the end of the loose tubes bundled together with a piece of tape. Make a loop with the flexible tube behind the shelf and fix the flex tube into the clip of the termination plate.
Page 15 5.1.3 Cut a rubber foam to length and tape it around the loose tube. 5.1.6 If necessary, tubes can be bundled with 1 foam. If loose tubes are added at a later date, use other positions. 5.1.4 Push the loose tubes in the tray and mark them again 15 mm beyond the second tie wrap.
Page 16 5.1.13 Secure all the tubes with the two tie-wraps as shown. 5.1.10 Place the splice protector in the holder, start at outside of the In case not all fibers will be installed at day 1 tray, (hold the splice holder with finger to prevent bending) and coil the fibers in the tray.
Page 17: Installation Of Break-Out Cable On The Tray
5.1.18 Splicing and storage. Installation of break-out cable on the tray 5.2.1 Use the GTU kit for the termination of a group of 4 pigtails. 5.2.2 Identify the 4 pigtails. Bundle them with PVC tape. Route them up to the tray, mark the 4 pigtails on the GTU position. Make sure there is 1,5 m pigtail available from this point.
Page 18 5.2.3 Strip the pigtail jacket at the marks. Cut the Kevlar to ± 10 cm. 5.2.7 Take the GTU at the metal clip and pull at the Kevlar until it locks completely. 5.2.8 Cut excess Kevlar. Identify the pigtails. Remove the secondary coating 10-20 mm from the GTU (only possible in case of semi-tight pigtail).
Page 19: Installation Of Ifc Cable On The Tray
Installation of IFC cable on the tray 12 splice module 5.2.10 Mount the GTU. Start at outside of the tray. 5.3.1 For ease of installation start with the bottom tray. If possible apply 1 wrap of foam tape around the IFC, just before the jacket end (This foam prevents from easy pull-out and provides protection to the 5.2.11 Strip the pre-mounted pigtails (see 5.1.7-5.1.8).
Page 20: Installation Of Ribbon Cable On The Tray
5.3.5 Splicing repair connectors is possible : one can use the splice holder which is premounted in the tray. 5.3.6 Check wether all fibers are properly routed before placing the cover on the IFC module. All fibers should be underneath the containment lips.
Page 21: Storage
5.4.2 Make the splices and store the overlength without twists in the PATCH-PATCH: storage of a patch cord entering the shelf at storage area. the right side is shown. Check the position of the small bendcontrol. Installation of ribbon pigtail on the tray PATCH-SPLICE: storage of a patch cord entering the shelf at the right side is shown.
Page 22: Patching
Patching Repeat this procedure with the other pigtails. Respect routing of jumpers as shown on the picture. Provide sufficient slack for patching to all other positions in the shelve. Routing of incoming pigtails and outgoing patchcords. Route the jumper through the horn up to the tray. Remove the connector adaptor out of the tray and mount the connector into it as described.
Page 23: Important Steps
Closing Identification of the shelf and the trays. Place the labels and write down information. Write down information on the ID-cards. 9 Important steps • In case of loose tube termination side or back: don't modify the predefined flex tube length; apply foam tape to the flex tube;...
Page 24 Tel.: 32-16-351 011 of Sale for this product and in no case will Tyco Electronics be liable for any incidental, indirect or consequential damages arising out of the sale, resale, use or misuse of the product. Users of Tyco Electronics products should make their own evaluation to determine Fax: 32-16-351 697 the suitability of each such product for the specific application.
