Operating Instructions
REOTRON SMP

Power Supply

REO (UK) LTD
Units 2-4 Callow Hill Road, Craven Arms Business Park,
Craven Arms, Shropshire SY7 8NT
Tel. 01588 673411
Fax 01588 672718
www.reo.co.uk
eMail: sales@reo.co.uk
ELEKTRONIK
SMP_24_100_200_ANL_EN_
10/06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REOTRON SMP and is the answer not in the manual?

Questions and answers

Summary of Contents for Reo Elektronik REOTRON SMP

  • Page 1: Power Supply

    ELEKTRONIK Operating Instructions REOTRON SMP Power Supply REO (UK) LTD Units 2-4 Callow Hill Road, Craven Arms Business Park, Craven Arms, Shropshire SY7 8NT Tel. 01588 673411 Fax 01588 672718 www.reo.co.uk eMail: sales@reo.co.uk SMP_24_100_200_ANL_EN_ 10/06...
  • Page 2: Technical Safety Information For The User

    REOTRON SMP Operating Instructions ELEKTRONIK Technical safety information for the user This description contains the necessary information for the correct application of the product described below. It is intended for use by technically qualified personal. Qualified personnel are persons who, because of their training, experience and position as well as their...
  • Page 3: Table Of Contents

    REOTRON SMP Operating Instructions ELEKTRONIK Contents Technical safety information for the user ..................1 Contents ............................... 2 1.0 General ..............................3 2.0 Functions ..............................3 3.0 Fault conditions ........................... 4 4.0 Combining several units ......................... 4 5.0 Technical Data............................4 6.0 Controls ..............................
  • Page 4: General

    REOTRON SMP Operating Instructions ELEKTRONIK 1.0 General Primary switching circuit with DC output. Internal regulator for voltage, current or power control. Controlled from two setpoints (setpoint 1 = voltage, setpoint 2 = current) using either a 0...10 V, 0(4)...20 mA analogue signal or a Potentiometer. Setpoint 1 is used in the power regulation mode. The touch panel is used for making settings and keys “I“...
  • Page 5: Fault Conditions

    REOTRON SMP Operating Instructions ELEKTRONIK 3.0 Fault conditions Faults conditions are displayed for: Over temperature Error Low mains voltage Lo.Po. High mains voltage Error When a fault condition occurs the unit switches itself off and an error message is displayed. The error message must be cancelled in menu “C 009“.
  • Page 6: Controls

    REOTRON SMP Operating Instructions ELEKTRONIK 6.0 Controls 6.1 Description of controls The unit is operated and set up by using six buttons that are used in conjunction with a LED DISPLAY display, in the front touch panel. All configuration and parameter settings can be made through this panel.
  • Page 7: Displays

    REOTRON SMP Operating Instructions ELEKTRONIK 6.4 Displays During normal operation “run“ is displayed on the LED panel. In the programming mode a shortened description of the function is displayed. New settings are upon when leaving the programming mode or if no keys are pressed for 30 seconds delay, then the settings will be saved.
  • Page 8: Parameter Settings And Ranges

    REOTRON SMP Operating Instructions ELEKTRONIK 6.5 Parameter settings and ranges Parameter Code Factory settings Access code: • 0 / I E.S.O. Disable external set point • 0 / I 4.20 4...20 mA • 0 / I E.F.P. Power regulation •...
  • Page 9: Settings

    REOTRON SMP Operating Instructions ELEKTRONIK 7.0 Settings Code 002 Set point 1, Voltage [%] Set point 2, Current [%] Set point 3, Power [%] Run mode 7.1 Configure Code 003 E.S.O. = 0 = External Set piont E.S.O. = I = Internal Set point (Keys) 4.20 = 0 = External Set point 0...20 mA / 0...10V...
  • Page 10: Reset Error Messages

    REOTRON SMP Operating Instructions ELEKTRONIK 7.4 Reset error messages Code 009 Error reset Error and all set points reset Check set point "P" 7.5 Save user settings Code 143 Save new parameters Run mode 7.6 Recall saved settings Code 210...
  • Page 11: Connections

    REOTRON SMP Operating Instructions ELEKTRONIK 8.0 Connections Control terminals Internal relais Enable +10V Set point current +10V Set point voltage Power terminals...
  • Page 12: Dimensions

    REOTRON SMP Operating Instructions ELEKTRONIK 9.0 Dimensions REOTRON 1 2 3 4 5 6 7 8 9 10 SMP 24-200 Dims. INPUT SMP 100 405 365 3x 400V 50/60Hz SMO 200 505 465...
  • Page 13: Connection Example

    REOTRON SMP Operating Instructions ELEKTRONIK 10.0 Connection example Parallel connection Output terminals Load Output terminals Common terminals Load...
