Read this manual before using this product. Failure to follow the
instructions and safety precautions in this manual can result in serious injury,
damage to the product, or incorrect readings. Keep this manual in a safe
location for future reference.
Copyright © 2011 by SKF Reliability Systems
All rights reserved.
5271 Viewridge Court San Diego, CA 92123-1841 USA
Telephone: (858) 496-3400,
Fax: (858) 496-3531
Customer Service: 1-800-523-7514
Wireless Infrared Thermometer
User Manual Part No. 32107300-EN
CMAC 4230
Revision B
User Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SKF CMAC 4230
Summary of Contents for SKF CMAC 4230
- Page 1 Keep this manual in a safe location for future reference. Copyright © 2011 by SKF Reliability Systems All rights reserved. 5271 Viewridge Court San Diego, CA 92123-1841 USA...
- Page 2 Tell us how we’re doing! It’s important that you’re satisfied with the quality of our product user manuals. We appreciate your feedback; if you have comments or suggestions for improvement, please tell us how we’re doing! (SKF CM User Manual Feedback@skf.com)
- Page 3 SKF shall not be liable Products warranted for two (2) years by SKF for any claim for which notice is received by SKF are as follows: all standard Eddy Probes, Eddy Probe Drivers, and Eddy Probe Extension...
- Page 4 SKF-supplied or writing by SKF, Buyer shall forward to SKF any Product claimed by Buyer as being defective. SKF-approved devices and/or components. The...
- Page 5 SERVICES, IF ANY, PROVIDED BY SKF, AND warranty shall not be deemed to have failed of THIS DISCLAIMER SHALL EXTEND AS WELL their essential purpose so long as SKF is willing TO ANY LIABILITY FOR NONPERFORMANCE and able to perform to the extent and in the manner prescribed in this limited warranty.
-
Page 7: Table Of Contents
Table of Contents Introduction to the CMAC 4230 Wireless Infrared Thermometer Application..............1-1 Safety Instructions ..........1-1 Laser Safety ............1-3 Technical specifications ..........1-3 Bluetooth configuration........1-5 Functional description and operating instructions Operation..............2-1 Measuring marking...........2-1 Measurement ............2-2 Operating and display elements......2-2 Display screen............2-3 Settings...............2-4 Setup................2-5... - Page 8 Physical and Environmental Specifications Physical characteristics ..........A-1 Power supply............. A-1 Environment.............. A-1 Accuracy at 25 °C (77 °F) ........A-1 Regulatory approvals..........A-2 TOC - 2 Wireless Infrared Thermometer CMAC 4230 User Manual...
-
Page 9: Introduction To The Cmac 4230 Wireless Infrared Thermometer
Introduction to the CMAC 4230 Wireless Infrared Thermometer Application The CMAC 4230 is a contactless temperature measuring device with an integrated Bluetooth™ and is designed for industrial use in hazardous areas. Safety Instructions WARNING! Your safety is extremely important. Read and follow all warnings in this document before handling and operating the equipment. - Page 10 Introduction to the CMAC 4230 Wireless Infrared Thermometer Safety Instructions Device service must be performed only by qualified SKF repair personnel. Use only accessories recommended or provided by SKF Reliability Systems. Energized equipment Never work on energized equipment unless authorized by a responsible authority.
-
Page 11: Laser Safety
Introduction to the CMAC 4230 Wireless Infrared Thermometer Laser Safety Errors and load restrictions If there is a possibility of the safety of the device being hampered, the device must be taken out of operation and removed from the hazardous area immediately. - Page 12 Introduction to the CMAC 4230 Wireless Infrared Thermometer Technical specifications Optical resolution 60:1 (19 mm measuring spot for (standard optics): 1.15 m) Accuracy (+25 °C): ± 0.75% of the measured value or ± 0.75 K, whichever is greater (± 2 K for measurement objects below –5...
-
Page 13: Bluetoothtm Configuration
Introduction to the CMAC 4230 Wireless Infrared Thermometer BluetoothTM configuration Manufacturer: Model (LR6): Varta Alkaline No. 4806 LR6 Varta Alkaline Extra Longlife No. 4006 Varta Alkaline Maxi Tech No. 4706 Varta Alkaline Electric Power No. 8006 Varta No. 4706 Alkaline LR6 Varta LR6 High Energy No. -
Page 15: Functional Description And Operating Instructions
The majority of applications are measured with an emissivity of 0.95. The CMAC 4230 is therefore preset to 0.95 and can be adjusted in steps of 0.01 depending on the application. Emissivity range over 1.00 is intended for applications, where adjacent measurement objects having different temperatures are to be measured. -
Page 16: Measurement
Switch on the device by pressing the measurement button (F). Press the appropriate function key (H). To change the functions, either press ENTER or press the current function key first and then the desired one. 2 - 2 Wireless Infrared Thermometer CMAC 4230 User Manual... -
Page 17: Display Screen
(1) Status and warning icon (2) Time (3) Measured value (4) Graphical display of the measured value (5) Emissivity (6) Status line (7) Mode display (8) Battery status (9) MAX, MIN, DIFF Icon Wireless Infrared Thermometer CMAC 4230 2 - 3 User Manual... -
Page 18: Settings
Toggles between the date and time display. TC-K: Thermocouple type Temperature range for the K type: -30 to +400 °C The thermocouple must be used only outside the Hazardous area! Factory defaults DIL switch 2 - 4 Wireless Infrared Thermometer CMAC 4230 User Manual... -
Page 19: Setup
(Microlog Inspector only) On the Settings display, select the Temperature Gun icon to display the Temperature Gun Setup screen. (MARLIN only) Press the Wireless Connection icon in the MARLIN’s taskbar. The WIRG Setup screen displays. Wireless Infrared Thermometer CMAC 4230 2 - 5 User Manual... - Page 20 Temperature Gun setup display without saving your changes. (MARLIN only) Press the Select WMCD button to connect to the highlighted WIRG, or press the Close button to exit the WIRG Setup display without saving your changes. 2 - 6 Wireless Infrared Thermometer CMAC 4230 User Manual...
- Page 21 Low alarm (lower limit) The setting of a temperature value, which when drops below this value should initiate an optical (blinking green LED (A) and blinking laser) and an acoustic warning Wireless Infrared Thermometer CMAC 4230 2 - 7 User Manual...
- Page 22 Press SETUP (N) until “Offset” appears in the display. Select the value using arrow keys (C) and confirm by pressing ENTER (D). The icon (1) appears in the display. 2 - 8 Wireless Infrared Thermometer CMAC 4230 User Manual...
-
Page 23: Setting The Mode
The lowest measured value (3) is always displayed as long as the measurement button is kept pressed. The currently measured value appears in the status line (7). Min-Max range Wireless Infrared Thermometer CMAC 4230 2 - 9 User Manual... - Page 24 Sensor port This function must be executed only outside the hazardous area. To determine an unknown emissivity: Connect the sensor to the port at the end of the handle. 2 - 10 Wireless Infrared Thermometer CMAC 4230 User Manual...
-
Page 25: Data
For reading the stored values, press ENTER (D) without pressing the measurement button. Then press the DATA key (M) until RCL appears in the display. A memory location is displayed (6). Use arrow keys (C) to select another memory location. Wireless Infrared Thermometer CMAC 4230 2 - 11 User Manual... - Page 26 Press DISPLAY (L) once. Use arrow keys (C) to choose between Auto Range (temperature range includes measured minimum and maximum values) and Manual Range (refer to the Begin (Manual Range) section). 2 - 12 Wireless Infrared Thermometer CMAC 4230 User Manual...
- Page 27 Manual setting of the upper limit of the temperature range to be shown graphically. Press DISPLAY (L) until “End” appears in the status line. Change the value (6) using arrow keys (C). Cycle Wireless Infrared Thermometer CMAC 4230 2 - 13 User Manual...
-
Page 28: Changing Batteries
Open the handle. You need 2 Type LR6 (AA / type approved) batteries for operating the measuring device. Important: Always replace all batteries together. Make sure of proper polarity of the inserted batteries. Properly dispose all batteries in an environmentally safe manner. 2 - 14 Wireless Infrared Thermometer CMAC 4230 User Manual... -
Page 29: Emissivity
Most organic materials as well as lacquered and oxidized surfaces have an emissivity of 0.95. The emissivity is preset to 0.95 in the CMAC 4230 for this reason, but can be changed using the rocker switch. The determination of the temperatures of shiny or highly polished metal surfaces results in inaccurate measured values. -
Page 30: Selecting The Material
Use arrow keys to change the value until the displayed temperature matches that of the contact sensor. Reference the Sensor Port section in Chapter 4 for details on connecting the sensor. 3 - 2 Wireless Infrared Thermometer CMAC 4230 User Manual... -
Page 31: Taking Care Of Your Device
Repairs Repair work is subject to the different nationally valid regulations and directives. Work should be performed by the manufacturer, as all repairs must be examined to ensure functional safety. Wireless Infrared Thermometer CMAC 4230 4 - 1 User Manual... -
Page 32: Cleaning, Maintenance And Storage
Remove the batteries from the device if it is to be stored for long periods. The storage temperature should be within the permitted range between -20 to +50 °C (without batteries). 4 - 2 Wireless Infrared Thermometer CMAC 4230 User Manual... -
Page 33: Physical Characteristics
10 to 95% relative humidity Accuracy at 25 °C (77 °F) ±0.75% of the measured value or ±0.75 K, whichever is greater ±2 K for measurement objects below –5°C (23°F) Response time: 250 ms Wireless Infrared Thermometer CMAC 4230 A - 1 User Manual... -
Page 34: Regulatory Approvals
NI/I/2/ABCD/T6 Ta = 50 °C I/2/IIC/T6 Ta = 50 °C WARNING! The CMAC 4230 Wireless infrared thermometer must not be opened in the hazardous area and must be operated only when in its leather pouch. The batteries must be changed only outside of the hazardous area.
