  • Page 1 G-Class Owner's Manual Nur für internen Gebrauch / For internal use only...
  • Page 2 Symbols In this Owner's Manual, you will find the fol- lowing symbols: WARNING Warning notices draw your attention to haz- ards that may endanger your health or life, or the health or life of others. Environmental note Environmental notes provide you with infor- mation on environmentally aware actions or disposal.
  • Page 3 Welcome to the world of Mercedes-Benz The technical documentation team at Daimler AG wishes you safe and pleasant Before you first drive off, read this Owner's motoring. Manual carefully and familiarise yourself with your vehicle. For your own safety and a longer vehicle life, follow the instructions and warn- ing notices in this manual.
  • Page 5: Contents

    Contents Index ............4 At a glance ........... 25 Introduction ......... 20 Safety ........... 37 Opening and closing ......67 Seats, steering wheel and mirrors ..89 Lights and windscreen wipers ..103 Climate control ......... 123 Driving and parking ......141 On-board computer and displays ..
  • Page 6: Table Of Contents

    Index Setting the centre air vents ... 139 1, 2, 3 ... Setting the side air vents ....139 12 V socket ........278 Alarm system 4ETS (Electronic Traction System) see ATA (Anti-Theft Alarm system) Function/notes ........ 62 All-wheel drive 4MATIC (permanent four-wheel Transfer case .........
  • Page 7 Index Neutral (ECO start/stop function) . 150 Belt tensioner Overview ........149 Activation ......... 39 Problem (fault) ....... 156 Function ........... 47 Program selector button ....152 Blind Spot Assist Pulling away ........144 Activating/deactivating ....220 Selector lever ........ 149 Display message ......
  • Page 8 Index Standing lamps ......116 Turn signals (front) ......117 Cabriolet Changing gears ........152 Draught stop ........84 Checklist Soft top ..........81 After driving off-road ...... 171 Tonneau cover ......... 85 Before driving off-road ....170 Cabriolet soft top Child-proof locks Cleaning .........
  • Page 9 Index Switching the ZONE function on/ Delayed switch-off off ..........131 Exterior lighting (on-board com- THERMATIC automatic climate puter) ..........222 control (2-zone) ......125 Interior lighting ......222 Cockpit Diagnostics connection ...... 22 Overview .......... 26 Diesel ..........339 see Instrument cluster Diesel particle filter ......
  • Page 10 Index Door Driving system Automatic locking (on-board com- Variable SPEEDTRONIC ....178 puter) ..........223 Driving systems Automatic locking (switch) ....74 Blind Spot Assist ......190 Central locking/unlocking (key) ..68 Cruise control ........ 173 Display message ......249 Display message ......
  • Page 11 Index EBD (electronic brake force distri- ® (Electronic Stability Pro- bution) gram) Display message ......231 AMG menu (on-board computer) . . . 226 Function/notes ........ 64 Deactivating/activating ....63 ECO start/stop function Display message ......229 Deactivating/activating ....146 Function/notes ........
  • Page 12 Premium-grade unleaded petrol ..338 Gearshift program Problem (malfunction) ....159 SETUP (on-board computer) ..226 Quality (diesel) ....... 339 Genuine Mercedes-Benz parts ..334 Refuelling ........156 Genuine wood trim and trim strips Tank content/reserve fuel ..... 338 (cleaning instructions) ...... 296 Fuel/water separator Glove compartment ......
  • Page 13 Index HOLD function Overview .......... 68 Function/notes ......196 Problem (malfunction) ..... 72 Starting the engine ......144 Key positions Key ..........143 Immobiliser .......... 64 Kickdown Indicator and warning lamps Manual drive program ....155 Coolant .......... 260 DISTRONIC PLUS ......262 Engine diagnostics ......
  • Page 14 Matt finish (cleaning instructions) . . 293 Important safety notes ....38 Memory card (audio) ......218 Odometer Memory function ....... 102 see Total distance recorder Mercedes-Benz Service Centre see Trip meter see Qualified specialist workshop Off-road Message memory (on-board com- Differential locks ......204 puter) ..........
  • Page 15 Index Off-road driving Parking ..........163 Checklist ........170 Engaging park position ....150 Driving on sand ......171 Important safety notes ....163 Important safety notes ....169 Position of exterior mirror, front- Travelling uphill ......172 passenger side ....... 101 Off-road fording .........
  • Page 16 Index Resetting the current lap ....227 Remote control Starting a new lap ......226 Auxiliary heating/ventilation ..135 Stopping ........226 Changing the batteries (auxiliary RACETIMER (on-board computer) ..226 heating) ......... 137 Radar sensors Programming (garage door Overview ........347 opener) ..........
  • Page 17 Index Seat Notes ..........337 Folding the front seat backrests Washer fluid ........343 forwards (EASY-ENTRY feature) ..94 Settings Seat backrest Calling up a stored setting ..... 102 Folding back ........269 Factory (on-board computer) ..225 Seat belt On-board computer .......
  • Page 18 Index In the Instrument cluster ....211 Surround lighting (on-board com- Segments ........212 puter) ..........222 Selecting the unit of measure- Suspension tuning ment ..........221 SETUP (on-board computer) ..226 see Instrument cluster Switching off the alarm (ATA) .... 64 SPEEDTRONIC Display message ......
  • Page 19 Index Timing (RACETIMER) ......226 Transmission Tonneau cover ........85 see Automatic transmission Top Tether ..........52 Transmission positions ....151 Transport (vehicle) ......313 Total distance recorder ....215 Travelling uphill Tow-away protection ......65 Towing Brow of hill ........173 Trip computer (on-board com- Important safety notes ....
  • Page 20 Index VIN ............336 Unladen weight ......... 344 Unlocking Warning and indicator lamps Emergency unlocking ....... 74 ABS ..........254 From inside the vehicle (central Brakes ........... 253 unlocking button) ......73 Distance warning signal ....262 ® ..........256 ®...
  • Page 21 Index Windscreen heating ......132 Windscreen washer fluid see Windscreen washer system Windscreen washer system Notes ..........343 Topping up ........290 Windscreen wipers Problem (malfunction) ....121 Rear window wiper ......120 Replacing the wiper blades .... 120 Switching on/off ......119 Winter Driving in winter ......
  • Page 22: Note

    Mercedes-Benz will take back your planet to be used sparingly and in a manner Mercedes-Benz to dispose of it in an environ- which takes the requirements of both nature mentally responsible manner, in accordance and humanity into account.
  • Page 23: Equipment

    Mercedes-Benz recommends that you use a underbody, tyres or wheels. This could cause Mercedes-Benz Service Centre for this pur- your vehicle to be damaged, which in turn pose.
  • Page 24: Diagnostics Connection

    There is a risk of an accident. work on electronic components Do not connect any equipment to a diagnos- Mercedes-Benz recommends that you use a tics connection. Mercedes-Benz Service Centre. WARNING Loose equipment or cables hanging from a...
  • Page 25: Correct Use

    ® tions (e.g. airbag deployment or ESP inter- Mercedes-Benz Service Centre. vention). Inform Mercedes-Benz as soon as possible This data is used exclusively to: about any change in address or vehicle own- assist in the rectification of faults and ership.
  • Page 26 Introduction © HOWEVER CAUSED AND ON ANY THEORY OF rights reserved. 1996-2000 by David LIABILITY, WHETHER IN CONTRACT, STRICT Turner, Robert Wilhelm, and Werner Lemberg. LIABILITY, OR TORT (INCLUDING NEGLI- GENCE OR OTHERWISE) ARISING IN ANY Gnu compiler WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF ©...
  • Page 27 Cockpit ..........26 Instrument cluster ......27 Multifunction steering wheel ..... 31 Centre console ........32 Overhead control panel ...... 34 Door control panel ......35...
  • Page 28 Cockpit Cockpit Function Page Combination switch Steering wheel gearshift paddles Instrument cluster Horn Overhead control panel PARKTRONIC warning display Climate control systems Ignition lock To adjust the steering wheel Cruise control lever Light switch To open the bonnet...
  • Page 29 Instrument cluster Instrument cluster Displays and controls Instrument cluster: kilometres Function Page Speedometer with segments Multifunction display Rev counter Coolant temperature gauge Fuel gauge Instrument cluster lighting control...
  • Page 30 Instrument cluster Instrument cluster: miles Function Page Speedometer with segments Multifunction display Rev counter Coolant temperature Fuel gauge Instrument cluster lighting control...
  • Page 31 Instrument cluster Warning and indicator lamps Function Page Function Page L Dipped-beam head- % Diesel engine: pre- lamps glow ? Coolant ® ÷ ESP R Rear foglamp K Main-beam headlamp O Front foglamps J Brakes (yellow) ; Engine diagnostics · Distance warning 8 Reserve fuel #! Turn signals ®...
  • Page 32 Instrument cluster Function Page Function Page L Dipped-beam head- % Diesel engine: pre- lamps glow ? Coolant ® ÷ ESP R Rear foglamp K Main-beam headlamp O Front foglamps J Brakes (yellow) ; Engine diagnostics · Distance warning 8 Reserve fuel #! Turn signals ®...
  • Page 33: Comand

    Multifunction steering wheel Multifunction steering wheel Function Page Function Page Multifunction display Selects a menu Audio/COMAND display Selects a submenu or Switches on LINGUA- scrolls through lists TRONIC; see the separate operating instructions Confirms selections and hides messages Rejects or ends a call Exits telephone book/ Back redial memory...
  • Page 34: Upper Section

    Centre console Centre console Centre console, upper section Function Page Function Page Audio system; see the sep- £ Hazard warning arate operating instruc- lamps tions 45 Indicator lamp COMAND Online ® å ESP Seat heating & Auxiliary heating s Seat ventilation c PARKTRONIC ¤...
  • Page 35: Comand

    Centre console Centre console, lower section Function Page Function Page Stowage compartment/ Cigarette lighter ashtray Audio controller, see the Automatic transmission separate operating instruc- selector lever tions COMAND controller To select park position To switch the windscreen + Selects/deselects heating on/off LOW RANGE off-road gear Ú...
  • Page 36: Overhead Control Panel

    Overhead control panel Overhead control panel Function Page Function Page p Switches the left- ¡ Opens/closes the hand reading lamp on/off sliding sunroof c Switches the front ë Deactivates tow- interior lighting on away protection u Switches the rear Rear-view mirror interior lighting on/off Buttons for the garage door | Switches the front...
  • Page 37 Door control panel Door control panel Function Page Function Page n Activates/deacti- r45= vates the override feature Stores settings for the seat, for the side windows in the exterior mirrors and steer- rear compartment ing wheel (memory func- tion) W Opens/closes the To adjust the seat side windows %&...
  • Page 39 Useful information ......38 Occupant safety ........38 Children in the vehicle ......48 Driving safety systems ....... 60 Anti-theft systems ......64...
  • Page 40: Useful Information

    Occupant safety Seat belts, together with the Supplemental Useful information Restraint System, SRS ( page 39), are complementary, co-ordinated restraint sys- This Owner's Manual describes all mod- tems. They reduce the risk of injury in spe- els, series and optional equipment for your cific, pre-defined types of accident situations vehicle that were available at the time of and thereby increase occupant safety.
  • Page 41: Triggering

    Occupant safety Triggering of belt tensioners, belt force SRS (Supplemental Restraint System) limiters and airbags Introduction During the first stage of a collision, the airbag SRS reduces the risk of occupants coming control unit evaluates important physical into contact with the vehicle's interior in the data relating to vehicle deceleration or accel- event of an accident.
  • Page 42 Occupant safety How the airbag system works is deter- Observe the following notes to reduce the risk mined by the severity of the collision detec- of serious or even fatal injury caused by airbag ted, especially the vehicle deceleration or deployment: acceleration, and the apparent type of acci- all vehicle occupants –...
  • Page 43: Front Airbags

    Occupant safety front-passenger seat, you must move the In order to prevent potential breathing diffi- front-passenger seat as far back as possi- culties, you should leave the vehicle as soon ble. as it is safe to do so. You can also open the window to allow fresh air to enter the vehicle make sure there are no heavy or sharp- interior.
  • Page 44: Windowbag

    Occupant safety Windowbags Driver's airbag : deploys in front of the steering wheel; front-passenger front air- G-Class off-road vehicles, long-wheelbase bag ; deploys in front of and above the glove version, are equipped with windowbags. compartment. Windowbags : enhance the level of protec-...
  • Page 45 Occupant safety Mercedes-Benz recommends that you have cannot provide the intended level of protec- the NECK-PRO head restraints checked at a tion. Do not use head restraint covers. qualified specialist workshop after a rear-end The NECK-PRO head restraints increase pro- collision.
  • Page 46: Fastening

    This may result in the child or mends that you only use seat belts which have other occupants being seriously or fatally been approved by Mercedes-Benz for your injured. vehicle. Persons under 1.50 m tall cannot wear the Seat belts are the most effective means of seat belts correctly.
  • Page 47 Occupant safety If necessary, adjust the seat belt to the appropriate height ( page 46). If necessary, pull upwards on the shoulder section of the seat belt to tighten the belt across your body. Further information on releasing the seat belts with release button ?( page 46).
  • Page 48: Releasing

    Occupant safety Adjust the height so that the upper part of the seat belt is routed across the centre of your shoulder. To raise: slide the belt sash guide upwards. The belt sash guide engages in various posi- tions. To lower: draw belt sash guide release : forwards and hold it.
  • Page 49: Function

    Rear seat belt status indicator Comply with safety regulations when dispos- The rear-compartment seat belt status indi- ing of belt tensioners. Any Mercedes-Benz cator tells you if the rear passengers have Service Centre can provide details of these their seat belts fastened.
  • Page 50: Children In The Vehicle

    Children in the vehicle Belt tensioners do not correct incorrect seat Children in the vehicle positions or incorrectly fastened seat belts. Child restraint systems Belt tensioners do not pull vehicle occupants back towards the backrest. Important safety notes If the seat belt is also fitted with a belt force WARNING limiter and this is triggered, the force exerted by the seat belt on the vehicle occupant is...
  • Page 51: On The Front-Passenger Seat

    Mercedes- Mercedes-Benz vehicles. Benz Service Centre. It is advisable to use Mercedes-Benz care WARNING products to clean child restraint systems. When leaving the vehicle, it can still roll away...
  • Page 52: Lamp

    Information about recommended child on a suitable rear seat. restraint systems is available at any Mercedes-Benz Service Centre. only use a forward-facing child restraint system on the front-passenger seat and move the front-passenger seat to the rear- most position.
  • Page 53: Isofix

    AIRBAG OFF indicator lamp does not light up system on the front-passenger seat detects briefly when you turn the key in the ignition whether a special Mercedes-Benz child seat lock to position 2. with automatic child seat recognition has been fitted there. In such cases, 4 PASSENGER AIRBAG OFF indicator lamp : lights up.
  • Page 54: Top Tether

    ISOFIX child Install the ISOFIX child restraint system. seat securing system, which are specially tes- Comply with the manufacturer's instruc- ted and approved for Mercedes-Benz vehi- tions when installing the ISOFIX child cles. restraint system.
  • Page 55 Children in the vehicle Tension Top Tether belt =. Comply with the manufacturer's installation instruc- tions when doing so. Move the head restraint back down again slightly if necessary ( page 92). Make sure that you do not interfere with the cor- rect routing of Top Tether belt =.
  • Page 56: Suitable Positions

    Problem Possible causes/consequences and M Solutions The 4 PASSENGER A special Mercedes-Benz child seat with a transponder for auto- matic child seat recognition has been fitted to the front-passenger AIRBAG OFF indicator seat. The front-passenger front airbag has therefore been disabled lamp on the centre con- as desired.
  • Page 57 Children in the vehicle Weight categories Front-passenger airbag is Front-passenger front air- not disabled: bag is disabled: Category II: 15 to 25 kg Group III: 22 to 36 kg Vehicles with automatic child seat recognition in the front-passenger seat: a "Universal" category child restraint system with a transponder for automatic child seat recognition must be fitted when the front-passenger airbag is disabled.
  • Page 58 Children in the vehicle Carry-cot weight category Size category Equipment Rear seat, left and right ISO/L1 ISO/L2 Weight category 0: up to 10 kg, up to approximately 6 months Size category Equipment Rear seat, left and right ISO/R1 Weight category 0+: up to 13 kg, up to approximately 15 months Size category Equipment Rear seat, left and right...
  • Page 59 Children in the vehicle Order number A 000 970 10 00 B6 6 86 8224 Automatic child seat rec- ognition The child restraint system may only be fit- ted to the left-hand or right-hand rear seat. Weight category 0+: up to 13 kg, up to approximately 18 months Manufacturer Britax Römer Britax Römer...
  • Page 60 Children in the vehicle Order number A 000 970 12 00 A 000 970 17 00 Automatic child seat rec- ognition For child restraint systems without a trans- ponder, move the front-passenger seat to the rearmost position. Suggested "Universal" category ISOFIX child restraint systems: Carry-cot weight category Size categories F, G...
  • Page 61: Child-Proof Locks Important Safety Notes

    Children in the vehicle Category I: 9 to 18 kg Size categories D, C, B, A Manufacturer – Type – Approval number (E1 ...) – Order number – Automatic child seat recognition – Size category Manufacturer Britax Römer Type DUO PLUS Approval number (E1 ...) 03 301133 04 301133...
  • Page 62: Driving Safety Systems

    Driving safety systems ABS (Anti-lock Braking System) page 60) BAS (Brake Assist System) ( page 61) Adaptive brake lamps ( page 61) ® (Electronic Stability Program) page 62) EBD (electronic brake force distribution) page 64) ADAPTIVE BRAKE ( page 64) Trailer stabilisation To activate: press the child-proof lock lever down in the direction of arrow ;.
  • Page 63: Adaptive Brake Lamps

    Driving safety systems Off-road ABS WARNING If ABS is faulty, the wheels could lock when If the LOW RANGE shift range is selected by braking. The steerability and braking charac- the transfer case, ( page 202), an ABS sys- teristics may be severely impaired. Addition- tem specifically suited to off-road terrain is ally, further driving safety systems are deac- automatically activated.
  • Page 64: Ets (Electronic Traction System)

    Driving safety systems light up continuously. The hazard warning ® If ESP detects that the vehicle is deviating lamps switch off automatically if you travel from the direction desired by the driver, one faster than 10 km/h. You can also switch off or more wheels are braked to stabilise the the hazard warning lamps using the hazard vehicle.
  • Page 65: Deactivating/Activating

    Driving safety systems Traction control brakes the drive wheels indi- ® It may be best to deactivate ESP in the fol- vidually if they spin. This enables you to pull lowing situations: away and accelerate on slippery surfaces, for when using snow chains example if the road surface is slippery on one in deep snow side.
  • Page 66: Anti-Theft Systems

    Anti-theft systems by braking and limiting the engine output until The immobiliser is always deactivated the vehicle/trailer combination has stabi- when you start the engine. lised. Trailer stabilisation is active above speeds of ATA (Anti-Theft Alarm system) about 60 km/h. EBD (electronic brake force distribu- tion) Observe the "Important safety notes"...
  • Page 67: Interior Motion Sensor

    Anti-theft systems Remove the key from the ignition lock. Tow-away protection Press button :. Function Indicator lamp ; lights up briefly. An audible and visual alarm is triggered if your Lock the vehicle with the key. vehicle's angle of inclination is altered while Tow-away protection remains deactivated tow-away protection is primed.
  • Page 68 Anti-theft systems Deactivating Remove the key from the ignition lock. Press button :. Indicator lamp ; lights up briefly. Lock the vehicle with the key. The interior motion sensor remains deacti- vated until the vehicle is unlocked and locked again.
  • Page 69 Useful information ......68 Key ............68 Doors ............ 73 Rear door (G-Class long-wheelbase version) ..........75 Tailgate (G-Class Cabriolet) ....76 Side windows ........77 Sliding sunroof ........79 Soft top (G-Class Cabriolet) ....81...
  • Page 70: Useful Information

    Useful information Loads which are not secured or not stored properly increase the risk of children being This Owner's Manual describes all mod- injured in the following circumstances: els, series and optional equipment for your strong braking manoeuvres vehicle that were available at the time of sudden changes of direction going to press.
  • Page 71 If you do not open the vehicle within Do not attach any heavy or large objects to approximately 40 seconds of unlocking: the key. Remove any bulky keyrings before inserting the key into the ignition lock. the vehicle is locked again. the anti-theft system is primed again.
  • Page 72: General Notes

    neously for approximately six seconds until To unlock the fuel filler flap: insert the battery check lamp : flashes twice. key into the ignition lock. The key now functions as follows: Removing the emergency key element To unlock the driver's door and fuel filler flap: press the % button once.
  • Page 73: Checking The Battery

    Mercedes-Benz recommends that you have the batteries replaced at a qualified specialist workshop. Checking the battery Battery compartment cover Emergency key element Press emergency key element ; into the opening in the key in the direction of the arrow until battery tray cover : opens.
  • Page 74: Loss

    Problems with the key Problem Possible causes/consequences and M Solutions You cannot lock or The key battery is discharged or nearly discharged. unlock the vehicle Point the tip of the key at the driver's door handle from a dis- using the key. tance of approximately 50 cm and try to unlock or lock the vehicle again.
  • Page 75: Doors

    Doors Doors Important safety notes WARNING If children are left unsupervised in the vehicle, they could: open the doors, thus endangering other people or road users. get out and disrupt traffic. operate the vehicle's equipment. Pull door handle ;. Additionally, children could set the vehicle in If the door is locked, locking knob : pops motion if, for example, they: up.
  • Page 76 Doors The central locking button does not lock or The vehicle is locked automatically when the unlock the fuel filler flap. ignition is switched on and the wheels are turning. You could therefore be locked out if: the vehicle is being pushed. the vehicle is being towed.
  • Page 77: Rear Door (G-Class Long-Wheelbase Version)

    Turn the emergency key element back and Press release button : and pull door han- remove it. dle ;. Check if the doors, including the rear door Open the rear door. or tailgate (G-Class Cabriolet), are locked. Insert the emergency key element into the key.
  • Page 78: Tailgate (G-Class Cabriolet)

    Tailgate (G-Class Cabriolet) Closing Push the rear door closed from outside the vehicle. If necessary, lock the vehicle with the & button on the key. Tailgate (G-Class Cabriolet) Important safety notes Raise safety catch : and pull lever = in WARNING the direction of the arrow.
  • Page 79: Side Windows

    Side windows Pull handle B upwards and push down the Activate the override feature for the rear side tailgate. windows. When leaving the vehicle, always take the key with you and lock the vehicle. Never leave children unattended in the vehi- Closing cle.
  • Page 80: Convenience Opening Feature

    Press and hold the % button until the Front left side windows and the sliding sunroof are in Front right the desired position. Rear right (G-Class long-wheelbase ver- To interrupt convenience opening: sion only) release the % button. Rear left (G-Class long-wheelbase version...
  • Page 81: Sliding Sunroof

    Sliding sunroof If a side window is obstructed again during Change the position of the sliding sunroof closing and reopens again slightly: or open a side window slightly to reduce or eliminate these noises. Immediately after the window blocks, pull the corresponding switch again until the side window has closed.
  • Page 82 Sliding sunroof Open the rear door. Pull off edge protection : from the door pillar in the direction of arrow ;. Pull away rear panel trim = as far as nec- essary in the direction of arrow ? until the electrical connections can be accessed.
  • Page 83: Soft Top (G-Class Cabriolet)

    Soft top (G-Class Cabriolet) If the sliding sunroof is obstructed during the outside temperature must be over closing and reopens again slightly: −15 †. the fabric must not be dirty, wet or fro- Immediately after the sliding sunroof zen. blocks, pull the ¡ switch in the over-...
  • Page 84 Soft top (G-Class Cabriolet) To close the soft top To close the soft top To open the soft top To open the soft top Pull the soft-top switch in the direction of Press the soft-top switch in the direction of...
  • Page 85 Soft top (G-Class Cabriolet) WARNING If anywhere other than the indicated gripping points is gripped, you or others can become trapped or stuck. There is a risk of injury. Take off jewellery and watches. Only hold the indicated gripping points. Do not reach between the cover halves and into the hinges.
  • Page 86: Draught Stop

    Soft top (G-Class Cabriolet) Draught stop General notes WARNING If the draught stop is incorrectly fitted, it could detach itself during a journey and endanger other road users. There is a risk of an accident and injury. Fit the draught stop as described. Do not place any objects on top of the fitted draught stop.
  • Page 87: Tonneau Cover

    Soft top (G-Class Cabriolet) Store draught stop ; in bag with zip :. ® Pull Tenax safety catches = apart to release them. ® Press Tenax safety catches = onto the Tonneau cover corresponding pegs on the vehicle. Press safety buttons ? onto the corre- General notes sponding pegs on the vehicle.
  • Page 88 Soft top (G-Class Cabriolet) Detach securing hooks ;. Fold up the tonneau cover and stow it in the bag in the luggage compartment.
  • Page 89 Soft top (G-Class Cabriolet) Problems with the soft top Problem Possible causes/consequences and M Solutions The soft top cannot be The soft top closing procedure has been interrupted. opened or closed. Wait approximately five seconds, then repeat the procedure. The fuse is faulty.
  • Page 91 Useful information ......90 Correct driver's seat position .... 90 Seats ............ 91 Steering wheel ........97 Mirrors ..........99 Memory functions ......102...
  • Page 92: Useful Information

    Correct driver's seat position you have moved the backrest to an almost Useful information vertical position. you have set the seat angle so that your This Owner's Manual describes all mod- thighs are gently supported. els, series and optional equipment for your vehicle that were available at the time of you can depress the pedals properly.
  • Page 93: Seats

    Seats Seats accident. Never drive if the head restraints are not engaged and set correctly. Important safety notes WARNING WARNING Occupants should only travel sitting on seats The seats can still be adjusted when there is which have the head restraints fitted. On a no key in the ignition lock.
  • Page 94: Luxury

    Seats the seat back. There is a risk that the seats Seat fore-and-aft adjustment and/or the objects could be damaged. Backrest angle When the rear bench seat is folded for- You can store the seat settings using the wards, the front seats cannot be moved to memory function ( page 102).
  • Page 95: Battery

    Seats your head or neck in the event of an accident or a similar situation. Adjusting the rear seat head restraint height To adjust the side bolsters of the head restraint: push or pull right and/or left- hand side bolster : into the desired posi- tion.
  • Page 96: Adjusting The 4-Way Lumbar Sup Port

    Seats Adjusting the multicontour seat Folding the front seats forward (EASY- ENTRY, G-Class Cabriolet) General notes WARNING Make sure that nobody can become trapped when moving the seat. If there is a risk of someone becoming trapped, press the seat adjustment switch on the door.
  • Page 97: Battery

    Seats Interrupting the EASY-ENTRY feature The following adjustments are made: the seat cushion and head restraint move To interrupt the EASY-ENTRY feature you can down. do the following: the seat moves forwards or backwards, Press one of the seat adjustment buttons depending on the starting position.
  • Page 98: Switching The Seat Ventilation On Off

    Seats Problems with the seat heating To switch on: press button : repeatedly until the desired heating level is set. If the on-board voltage is too low, the seat To switch off: press button : repeatedly heating is switched off automatically. until all the indicator lamps go out.
  • Page 99: Steering Wheel

    Steering wheel If the battery voltage is too low, the seat Adjusting the steering wheel ventilation may switch off. Problems with the seat ventilation If one or all of the indicator lamps in the seat ventilation button are flashing, the seat ven- tilation has switched off automatically.
  • Page 100: Battery

    Steering wheel To activate: make sure that the key is in Steering wheel EASY-ENTRY/EXIT fea- position 1 or 2 in the ignition lock. ture Turn the catch in the direction of Important safety notes arrow :. Indicator lamp = lights up. WARNING To deactivate: make sure that the key is Make sure that nobody can become trapped...
  • Page 101: Mirrors

    Mirrors Position of the steering wheel when the EASY-ENTRY/EXIT feature is active The steering wheel moves upwards and towards the dashboard if: you remove the key from the ignition lock you open the driver's door with the key in position 0 or 1 in the ignition lock. The steering wheel only moves upwards and towards the dashboard if it has not Make sure that the key is in position 1 or...
  • Page 102: Battery

    Mirrors Exterior mirror pushed out of position Make sure that the key is in position 1 or page 143) in the ignition lock. Press button : repeatedly until you hear Briefly press button :. the mirror engage in position. Both exterior mirrors fold in or out. The mirror housing is engaged again and Make sure that the exterior mirrors are you can adjust the exterior mirrors as usual...
  • Page 103: Parking Position

    Mirrors Using the memory button Parking position for the exterior mir- ror on the front-passenger side Setting/storing the parking position Using reverse gear Left-hand exterior mirror Right-hand exterior mirror Adjustment button Memory button Left-hand exterior mirror You can set the front-passenger side exterior Right-hand exterior mirror mirror so that you can see the rear wheel on Adjustment button...
  • Page 104: Memory Functions

    Memory functions Calling up a stored parking position set- WARNING ting The memory function can still be used when the key has been removed. For this reason, children should never be left unsupervised in the vehicle. They could otherwise become trapped when adjusting the seat or the steer- ing wheel.
  • Page 105 Useful information ......104 Exterior lighting ........ 104 Interior lighting ......... 110 Replacing bulbs ......... 114 Windscreen wipers ......119...
  • Page 106: Useful Information

    Important safety notes to legal standards. Avoid the continuous use of the T side lamps for several For reasons of safety, Mercedes-Benz recom- hours. If possible, switch on the X right mends that you drive with the lights switched or the W left parking lamp.
  • Page 107: Automatic Headlamp Mode

    Exterior lighting Daytime driving lights The exterior lighting (except the side lamps/ parking lamps) switches off automatically if you: remove the key from the ignition lock open the driver's door with the key in posi- tion 0 Dipped-beam headlamps Left-hand parking lamps Right-hand parking lamps Side lamps, licence plate and instru- ment cluster lighting...
  • Page 108: Foglamps

    Exterior lighting The automatic headlamp feature is only an wise not be visible and you could endanger aid. The driver is responsible for the vehicle's yourself and others. lighting at all times. Left-hand parking lamps Right-hand parking lamps Side lamps, licence plate and instru- ment cluster lighting Automatic headlamp mode/daytime 4Ã...
  • Page 109: Rear Foglamp

    Exterior lighting Press the N button. To switch on the rear foglamp: turn the key in the ignition lock to position 2 or start The green N indicator lamp in the instru- the engine. ment cluster lights up. Turn the light switch to L or Ã. To switch off the front foglamps: press the N button.
  • Page 110: Combination Switch

    Exterior lighting To switch on the parking lamps: the key Foglamps (except AMG vehicles) is not inserted in the ignition lock or it is in Rear foglamp position 0( page 143). To switch on: turn the light switch to Turn the light switch to W (left-hand side of the vehicle) or X (right-hand side of the vehicle).
  • Page 111: Hazard Warning Lamps

    Exterior lighting Main-beam headlamps Headlamp flasher Main-beam headlamps Main-beam headlamps Turn signal, right Turn signal, right Headlamp flasher Headlamp flasher Turn signal, left Turn signal, left To switch on the main-beam head- To switch on: turn the key in the ignition lamps: turn the key in the ignition lock to lock to position 1 or 2, or start the engine.
  • Page 112: Interior Lighting

    Interior lighting The hazard warning lamps automatically The cornering lamp may remain lit for a short switch on if: time, but is automatically switched off after no more than three minutes. an airbag is deployed the seat belt tensioners are triggered, or the vehicle decelerates rapidly from a Headlamps and turn signals misted speed of more than 70 km/h and comes to...
  • Page 113 Front overhead control panel p Switches the left-hand front reading lamp on/off Example: rear-compartment overhead control c Switches the front interior lighting panel, long-wheelbase G-Class p Switches the right-hand reading t Switches the luggage compartment lamp on/off lighting/rear interior lighting on/off...
  • Page 114: Luggage Compartment Lighting

    Interior lighting When a front door is opened, the front interior To switch on: press the c symbol on lighting comes on. When a rear door is rocker switch B. opened, the rear interior lighting comes on. To switch off: set rocker switch B to the In addition, the courtesy lights come on.
  • Page 115: Rear Interior Lighting

    Interior lighting Open the rear door. To switch off with the rear door open: press lock : down in the direction of the arrow until it engages. The luggage compartment lighting is switched off. To switch on with the rear door open: press lock cylinder ;...
  • Page 116: Replacing Bulbs

    Replacing bulbs Other bulbs Courtesy lighting in the front doors The courtesy light is switched on to help you WARNING see better when it is dark. Bulbs and lamps can be very hot. You should To switch on: activate the interior lighting therefore allow them to cool down before you change them.
  • Page 117 (rear) tail lamp/parking lamp reversing lamp rear foglamp Overview of bulb replacement – bulbs Example: G-Class, long-wheelbase version Front lamps Tail lamp/parking lamp: R 5 W Brake lamp/tail lamp: P 21/5 W You can replace the following bulbs. The...
  • Page 118 Replacing bulbs Replacing the front bulbs Side lamps/parking lamps Remove headlamp A. Lightly press bulb holder B; at the same time, turn it anti-clockwise and pull it out. Switch off the lights. Loosen screws : but do not remove. Remove panel ; upwards in the direction of the arrow.
  • Page 119: Foglamps

    Replacing bulbs Front foglamps/cornering lamps with foglamp function Hold lamp A. Lightly press bulb holder B, turn it anti- clockwise to the stop and pull it out. Switch off the lights. Unscrew screws :. Remove cover ;. Take bulb C out of bulb holder B. Insert the new bulb into bulb holder B.
  • Page 120: Rear Foglamp

    Replacing bulbs Switch off the lights. Switch off the lights. Unscrew screws :. Unscrew screws :. Remove lens ;. Remove lens ;. Turn signals Turn bulb = anti-clockwise, applying slight Brake/tail lamp pressure, and remove it from the bulb holder. Tail lamp/parking lamp Insert the new bulb into the bulb holder and Turn the corresponding bulb anti-clock-...
  • Page 121: Windscreen Wipers

    Windscreen wipers the wiper blades twice a year, ideally in spring and autumn. Do not operate the windscreen wipers when the windscreen/rear window is dry, as this could damage the wiper blades. Moreover, dust that has collected on the windscreen/rear window can scratch the glass if wiping takes place when the wind- screen/rear window is dry.
  • Page 122: Rear Window Wiper

    Combination switch Mercedes-Benz recommends that you have è Switch the wiper blades changed at a qualified b To wipe with washer fluid specialist workshop.
  • Page 123 Windscreen wipers Removing the wiper blades Slide new wiper blade ; with the recess onto wiper arm :. Engage locking spring = into the end of the wiper arm. Make sure that wiper blade ; is seated correctly. Fold wiper arm : back onto the wind- screen.
  • Page 125: Climate Control

    Useful information ......124 Overview of climate control sys- tems ........... 124 Operating the climate control sys- tem ............. 126 Adjusting the air vents ..... 139...
  • Page 126: Useful Information

    Overview of climate control systems Ventilate the vehicle for a brief period Useful information during warm weather, e.g. using the con- venience opening feature ( page 78). This This Owner's Manual describes all mod- will speed up the cooling process and the els, series and optional equipment for your desired vehicle interior temperature will be vehicle that were available at the time of...
  • Page 127: Matic Climate Control

    Overview of climate control systems Control panel for THERMATIC automatic climate control (2-zone) To set the temperature, left ( page 131) To demist the windscreen ( page 131) To switch the ZONE function on/off ( page 131) To activate/deactivate cooling with air dehumidification ( page 128) To switch the rear window heating on/off ( page 133)
  • Page 128: Operating The Climate Control System

    Operating the climate control system Operating the climate control system Switching climate control on/off Points to observe before use If climate control is switched off, the air supply and air circulation are also switched off. Only select this setting briefly. Otherwise, the windows may mist up. Switching the air conditioning on To set the temperature, left ( page 131)
  • Page 129 Operating the climate control system Turn the key to position 2( page 143) in the ignition lock. Press the à button. The indicator lamp in the à button lights up. Airflow and air distribution are set to auto- matic mode. Press the ^ button.
  • Page 130: Cooling With Air Dehumidification

    Operating the climate control system Activating/deactivating the cooling with air dehumidification function Points to observe before use WARNING If the "cooling with air dehumidification" function is deactivated, the air inside the vehicle will not be cooled (during warm weather) or dehumidified. The windows could mist up more quickly. This may prevent you from observing the traffic conditions, thereby causing an accident.
  • Page 131 Operating the climate control system To switch climate control on/off ( page 126) To set climate control to automatic mode ( page 130) Press the Á button. The indicator lamp in the Á button lights up. Deactivating the cooling with air dehumidification function To set the temperature, left ( page 131) To demist the windscreen (...
  • Page 132: Indicator Lamp

    Operating the climate control system Problems with the cooling with air dehumidification function To set the temperature, left ( page 131) To demist the windscreen ( page 131) To switch the ZONE function on/off ( page 131) To activate/deactivate cooling with air dehumidification ( page 128) To switch the rear window heating on/off ( page 133)
  • Page 133: Demisting The Windscreen

    Operating the climate control system Turn the key to position 2( page 143) in Setting the airflow the ignition lock. Turn the key to position 2( page 143) in Set the desired temperature. the ignition lock. To switch on: press the à button. To increase: press the K button.
  • Page 134: Demisting The Windows

    Operating the climate control system Windows misted up on the outside The climate control system switches to the following functions: Switch on the windscreen wipers cooling with air dehumidification (only page 119). with engine running) Press the _ button repeatedly until the high airflow (depending on the outside P or O symbol appears in the dis- temperature)
  • Page 135: Culation Mode

    Operating the climate control system back on as soon as there is sufficient volt- Activating/deactivating air-recircula- age. tion mode WARNING Switching the rear window heating Only switch over to air-recirculation mode on/off briefly at low outside temperatures. Other- wise, the windows could mist up, thus impair- Switching on/off ing visibility and endangering yourself and others.
  • Page 136: Important Safety Notes

    Operating the climate control system ary vehicle for up to 30 minutes after the the vehicle alight. Choose your parking spot engine has been switched off. The heating accordingly. time depends on the coolant temperature and Operating the auxiliary heating is thus pro- on the interior temperature that has been set.
  • Page 137: Remote Control

    Operating the climate control system The on-board computer can be used to spec- Press button :. ify up to three departure times, one of which The red or blue indicator lamp in but- may be preselected ( page 223). ton : lights up. Switching off the auxiliary heating/venti- Switching the auxiliary heating/venti- lation...
  • Page 138: Setting The Departure Time

    Operating the climate control system u To switch on the auxiliary heating/ The auxiliary ventilation ventilation is switched on. The num- , To check the status/set the depar- ber in the display shows the remaining time (in ture time minutes) for the auxiliary Your vehicle comes with one remote control.
  • Page 139 Operating the climate control system Press the u and ^ buttons simulta- cialist workshop or to a col- neously. lection point for used batter- The new departure time is stored. ies. Activating the set departure time Press the , or . button repeatedly until the desired departure time appears in the display.
  • Page 140 Operating the climate control system Problems with the auxiliary heating/ventilation Display messages Possible causes/consequences and M Solutions The signal transmission between the transmitter and the vehicle is faulty. FAIL Change your position in relation to the vehicle, moving closer if necessary.
  • Page 141: Adjusting The Air Vents

    Adjusting the air vents Display messages Possible causes/consequences and M Solutions If the auxiliary heating is faulty: Have the auxiliary heating checked at a qualified specialist workshop. Adjusting the air vents Setting the centre air vents Important safety notes WARNING Very hot or very cold air can flow from the air vents.
  • Page 142: Rear

    Adjusting the air vents To open/close: turn thumbwheel = to the left or right. Setting the rear-compartment air vents To open/close: turn thumbwheel : up or down. To set the air direction: move slider ; for the corresponding rear-compartment air vent to the left, right, up or down.
  • Page 143 Useful information ......142 Running-in notes ....... 142 Driving ..........142 Automatic transmission ....149 Refuelling ........... 156 Parking ..........163 Driving tips ........164 Driving systems ........ 173 Off-road driving systems ....201 Towing a trailer ......... 206...
  • Page 144: Useful Information

    Driving After 1,500 km, you may gradually bring the Useful information vehicle up to full road and engine speeds. Additional running-in notes for AMG vehicles: This Owner's Manual describes all mod- els, series and optional equipment for your Do not drive at speeds above 140 km/h for vehicle that were available at the time of the first 1,500 km.
  • Page 145: Key Positions

    Driving AMG vehicles: at low engine oil temper- WARNING atures (below +20 †), the maximum Unsuitable footwear can hinder correct usage engine speed is restricted in order to pro- of the pedals, e.g.: tect the engine. To protect the engine and shoes with thick soles maintain smooth engine operation, avoid shoes with high heels...
  • Page 146: Pulling Away

    Driving You can also use the touch-start function. Starting the engine To do this, turn the key to position 3 Important safety notes page 143) and release it immediately. The engine then starts automatically. WARNING Combustion engines emit poisonous exhaust gases such as carbon monoxide.
  • Page 147: Eco Start/Stop Function

    Driving You can open the doors from the inside at ECO start/stop function (AMG vehi- any time. cles) You can also deactivate the automatic lock- Important safety notes ing feature ( page 223). WARNING Upshifts take place at higher engine speeds after a cold start.
  • Page 148 Driving If the ECO start/stop function has been man- ¤ symbol is not shown. If this is the ually deactivated ( page 146) or if a mal- case, the ECO start/stop function is not function has caused the system to be deac- Stop/Start available.
  • Page 149 Driving Stop/Start inactive Automatic engine start In addition, the mes- sage is shown in the AMG menu in the multi- The engine is started automatically if: function display. In general: If you shift the transmission from R to D, you switch off the ECO start/stop func- the ECO start/stop function is available tion by pressing the ECO button.
  • Page 150 Driving Problems with the engine Problem Possible causes/consequences and M Solutions The engine does not There is a malfunction in the engine electronics. start. The starter motor There is a malfunction in the fuel supply. can be heard. Turn the key back to position 0 in the ignition lock before attempting to start the engine again.
  • Page 151: Automatic Transmission

    Automatic transmission Problem Possible causes/consequences and M Solutions The coolant tempera- The coolant level is too low. The coolant is too hot and the engine ture display is showing is no longer being cooled sufficiently. more than 120 †. A Stop as soon as possible and allow the engine and the coolant display message may to cool down.
  • Page 152: Engaging Reverse Gear

    Automatic transmission The current transmission position P, R, N or Park position P is automatically engaged: D appears in the transmission position dis- if you remove the key from the ignition lock play in the multifunction display. if you open the driver's door while travelling at low speed in transmission position D or Transmission position and drive pro- gram display...
  • Page 153: Transmission Positions

    Automatic transmission Staying in neutral (N) Transmission positions WARNING Park position If children are left unsupervised in the vehicle, This prevents the vehicle from roll- they could: ing away when stopped. Do not shift the transmission into position open the doors, thus endangering other page 149) unless the vehicle is people or road users.
  • Page 154: Driving Tips

    Automatic transmission Changing gear Program selector button The automatic transmission shifts to the indi- General notes vidual gears automatically when it is in trans- The program selector button allows you to mission position D. Gearshifting is deter- choose between drive programs with differ- mined by: ent driving characteristics.
  • Page 155: Automatic Drive Program

    Automatic transmission Drive program S is characterised by the fol- Steering wheel gearshift paddles lowing: sporty engine and transmission settings the vehicle pulling away in first gear the automatic transmission shifting up later as a result of the later automatic transmis- sion shift points, the fuel consumption pos- sibly being higher Shift ranges...
  • Page 156: Manual Drive Program

    Automatic transmission matic transmission protects against engine engaged is shown in the multifunction dis- damage by not shifting down. play. Manual drive program M differs from drive If the maximum engine speed for the shift programs E and S with regard to spontaneity, range is reached and you continue to accel- responsiveness and smoothness of gear erate, the automatic transmission shifts up...
  • Page 157: Manual Drive Program

    Automatic transmission If you slow down or stop without shifting down, the automatic transmission auto- matically shifts down. Selecting the optimal gear for maxi- mum acceleration Pull the left-hand steering wheel gearshift paddle until the transmission selects the optimum gear for the current speed. Kickdown You can also use kickdown for maximum acceleration in manual drive program M.
  • Page 158: Refuelling

    Refuelling Problems with the automatic transmission Problem Possible causes/consequences and M Solutions The transmission has The transmission is losing oil. problems shifting gear. Have the transmission checked at a qualified specialist work- shop immediately. The acceleration ability The transmission is in emergency mode. is deteriorating.
  • Page 159 Refuelling would result in damage to the fuel system and engine, which could lead to a vehicle fire. Do not use petrol to refuel vehicles with a diesel engine. Do not use diesel to refuel vehicles with a petrol engine. Even small amounts of the wrong fuel result in damage to the fuel system and the engine.
  • Page 160: Fuel Filler Flap Emergency Release

    Open the fuel filler flap. wise. The fuel filler cap audibly engages. Press the fuel filler flap closed until it G-Class Cabriolet: the emergency release is engages. located in the luggage compartment on the right-hand side, when viewed in the direction of travel.
  • Page 161 Refuelling Problems with the fuel and fuel tank Problem Possible causes/consequences and M Solutions Fuel is leaking from the Risk of explosion or fire vehicle. The fuel line or the fuel tank is defective. Turn the key to position 0( page 143) in the ignition lock immediately and remove it.
  • Page 162: Topping Up

    Further information about BlueTEC exhaust amounts of ammonia vapour may be ® gas aftertreatment and about AdBlue released. be obtained from any Mercedes-Benz Service Ammonia vapours have a pungent odour and Centre. are particularly irritating to: ® Topping up AdBlue...
  • Page 163 For further information on AdBlue , see page 341). ® AdBlue refill canisters can be obtained at many filling stations or at a Mercedes-Benz ® Service Centre. AdBlue refill canisters are often sold with a filler hose. A filler hose that ®...
  • Page 164 :. Place disposable hose ; on the opening ® AdBlue refill bottles can be obtained at many filling stations or at a Mercedes-Benz Service ® of AdBlue refill canister : and screw it Centre. Refill bottles without a threaded seal on clockwise until hand-tight.
  • Page 165: Parking

    Have the AdBlue supply topped up fully the parking brake must be applied. if necessary. Mercedes-Benz recommends the transmission must be in position P and that you use a qualified specialist workshop the key must be removed from the ignition for this purpose.
  • Page 166: Driving Tips

    Driving tips If the key is in position 1 or 2 in the ignition boosting effect. You will require considerably lock, the ! indicator lamp in the instru- more effort to steer and brake. There is a risk ment cluster is lit. of an accident.
  • Page 167: Driving Tips

    Driving tips drive short distances, you should take a 20 If the brakes have been subjected to a heavy minute trip on a motorway or rural road at load, do not stop the vehicle immediately, but least every 500km. drive on for a short while. This allows the air- flow to cool the brakes more quickly.
  • Page 168: High-Performance Brake System

    Brake pads/linings which have not observe the following: been approved for Mercedes-Benz vehicles or which are not of an equivalent quality could pull the parking brake upwards with the affect your vehicle's operating safety.
  • Page 169: Aquaplaning

    Driving tips Driving on wet roads Aquaplaning If water has accumulated to a certain depth on the road surface, there is a danger of aqua- planing occurring, even if: you are driving at low speeds the tyres have adequate tread depth. For this reason, do not drive in tyre ruts, and brake carefully.
  • Page 170: Slippery Road Surfaces

    Driving tips Clean any mud from the tyre tread after ensure an adequate supply of fresh air, open fording. a window on the side of the vehicle that is not Apply the brakes to dry them after fording. facing into the wind. Water offers a high degree of resistance, WARNING the ground is slippery and, in some cases,...
  • Page 171: Off-Road Driving

    Driving tips Observe the following when on hilly roads: Off-road driving Do not shift the transmission to position Important safety notes WARNING If the gradient is too steep for your vehicle, back up in reverse gear. If you drive up a steep incline at an angle or turn on a steep incline, the vehicle could slip Do not continuously depress the brake sideways, tip and overturn.
  • Page 172: Before Driving Off-Road

    Engine oil level: check the engine oil and Always keep the doors, the rear door or top it up if necessary. tailgate (G-Class Cabriolet), the side win- Only then does the engine receive enough dows and the sliding sunroof closed while oil when the vehicle is standing on a steep the vehicle is in motion.
  • Page 173: After Driving Off-Road

    Driving tips Checklist after driving off-road Driving on sand Driving over rough terrain places greater Observe the following rules when driving on demands on your vehicle than driving on nor- sand: mal roads. After driving off-road, check the Shift the transfer case to LOW vehicle.
  • Page 174: Approach/Departure Angle

    Observe the safety notes ( page 169) and the general notes ( page 169) on off-road G-Class 36° 27° driving. long-wheel- Shift the transfer case to LOW base ver- RANGE( page 202).
  • Page 175: Driving Systems

    Driving systems Accelerate gently and make sure that the This way you use the engine's braking wheels are gripping. effect to reduce the speed. If this is not sufficient, brake gently. When doing so, Avoid high engine speeds, except when make sure that the vehicle is facing in the driving on sandy and muddy routes with direction of the line of fall.
  • Page 176: Activation Conditions

    Driving systems Do not use cruise control: You can operate cruise control and variable SPEEDTRONIC with the cruise control lever. in traffic conditions that do not allow you When you activate cruise control, the stored to drive at a constant speed, e.g. heavy speed is shown in the multifunction display traffic, on winding roads or off-road for five seconds.
  • Page 177: Selecting

    Driving systems Selecting cruise control To activate at the current speed/last stored speed To activate or reduce speed To switch between cruise control and var- iable SPEEDTRONIC To deactivate cruise control You can store the current speed if you are driving faster than 30 km/h.
  • Page 178 Driving systems To activate at the current speed/last stored speed To activate or reduce speed To switch between cruise control and var- iable SPEEDTRONIC To deactivate cruise control You can store the current speed if you are driving faster than 30 km/h. Accelerate the vehicle to the desired speed.
  • Page 179 Driving systems To activate at the current speed/last stored speed To activate or reduce speed To switch between cruise control and var- iable SPEEDTRONIC To deactivate cruise control Keep in mind that it may take a brief moment until the vehicle accelerates or decelerates to the set speed.
  • Page 180: Variable Speedtronic

    Driving systems Making adjustments in 10 km/h incre- To switch between cruise control and var- ments iable SPEEDTRONIC To deactivate cruise control There are several ways to deactivate cruise control: Briefly press the cruise control lever for- wards B. Brake. Briefly press the cruise control lever in the direction of arrow A.
  • Page 181: Variable Speedtronic

    Driving systems If you fail to adapt your driving style, SPEED- To store the current speed or a lower TRONIC can neither reduce the risk of acci- speed dent nor override the laws of physics. SPEED- To switch between cruise control and var- TRONIC cannot take account of road, weather iable SPEEDTRONIC and traffic conditions.
  • Page 182 Driving systems to the vehicle in front, for vehicle speed, for If this is the case, you will hear a warning Limit exceeded Limit braking in good time and for staying in lane. tone and the Only engage SPEEDTRONIC when the current for the G 350 BlueTEC) message appears road, weather and traffic conditions permit it in the multifunction display.
  • Page 183 Driving systems Limit in the G 350 CDI) message will Making adjustments in 10 km/h incre- ments appear in the multifunction display. If no speed is stored, variable SPEED- TRONIC stores the current speed and main- tains it. Making adjustments in 1 km/h incre- ments To activate or increase speed LIM indicator lamp...
  • Page 184: Important Safety Notes

    Driving systems There are several ways to deactivate variable As a result, DISTRONIC PLUS may neither give SPEEDTRONIC: warnings nor intervene in such situations. There is a risk of an accident. Briefly press the cruise control lever for- wards B. Always pay careful attention to the traffic sit- uation and be ready to brake.
  • Page 185: Cruise Control Lever

    Driving systems be warned visually and acoustically. DIS- If there is no vehicle in front, DISTRONIC TRONIC PLUS cannot prevent a collision with- PLUS operates in the same way as cruise out your intervention. An intermittent warn- control in the speed range between ing tone will then sound and the distance 30 km/h and 200 km/h.
  • Page 186: Activation Conditions

    Driving systems cruise control lever in the direction of arrow Activating while driving LIM indicator lamp = on the cruise control lever indicates which function you have selec- ted: LIM indicator lamp = off: DISTRONIC PLUS is selected. LIM indicator lamp = on: variable SPEEDTRONIC is selected.
  • Page 187 Driving systems Switching on while stationary stored. Otherwise, it sets the vehicle cruise speed to the previously stored value. This function may be useful if you want to keep up with the traffic flow, e.g. at the end of a tailback. Driving with DISTRONIC PLUS You can only activate DISTRONIC PLUS if: Pulling away and driving...
  • Page 188 Driving systems you switch on the respective turn signals. On steep uphill or downhill gradients or if there is a malfunction, the transmission may DISTRONIC PLUS does not detect a danger also be automatically shifted into position P. of collision. If these conditions are met, your vehicle is Displays in the instrument cluster accelerated.
  • Page 189: Distronic Plus

    Driving systems Display when DISTRONIC PLUS is deacti- Specified minimum distance to the vehi- vated cle in front; adjustable Vehicle in front, if detected In the Assistance menu ( page 220) of the on-board computer, you can select the dis- tance display.
  • Page 190: Deactivating

    Driving systems Deactivating DISTRONIC PLUS briefly up : or down ; beyond the pres- sure point. The last stored speed increases or decrea- ses in 10 km/h increments. DISTRONIC PLUS is not deactivated if you depress the accelerator pedal. If you accel- erate to overtake, DISTRONIC PLUS adjusts the vehicle's speed to the last speed stored after you have finished over-...
  • Page 191: Distronic Plus

    Driving systems passenger door or one of the rear doors is Vehicles that are not driving in the middle of their lane open. the vehicle has skidded. If DISTRONIC PLUS is deactivated, you will DIS‐ hear a warning tone. You will see the TRONIC PLUS off message in the multifunc- tion display for approximately five seconds.
  • Page 192: Blind Spot Assist

    Driving systems DISTRONIC PLUS has not yet detected the Blind Spot Assist vehicle in front on the edge of the carriage- Important safety notes way, because of its narrow width. The dis- tance to the vehicle in front will be too short. WARNING Obstructions and stationary vehicles Blind Spot Assist does not react to:...
  • Page 193 Driving systems Monitoring range of the sensors Indicator and warning display WARNING Blind Spot Assist does not react to: vehicles overtaken too closely on the side, placing them in the blind spot area vehicles approaching and driving by with a speed difference of more than approx- imately 11 km/h As a result, Blind Spot Assist may not give...
  • Page 194: Active Blind Spot Assist

    Driving systems The brightness of the indicator/warning MAP PILOT is connected; see the separate lamps is adjusted automatically according to operating instructions for Audio 20. the ambient light. Make sure that Blind Spot Assist is activa- ted in the on-board computer Collision warning page 220).
  • Page 195: Active Blind Spot Assist

    Driving systems In such situations, Active Blind Spot Assist Vehicles that approach and drive past at high cannot warn you or intervene. There is a risk speeds are not detected. No visual nor audi- of an accident. ble warnings are emitted and the system does not brake the vehicle to correct your course.
  • Page 196: Active Blind Spot Assist

    Driving systems Due to the nature of the system: up yellow at speeds of up to 30 km/h. At speeds above 30 km/h, the indicator lamp warnings may be issued in error when driv- goes out and Active Blind Spot Assist is ing close to crash barriers or similar solid operational.
  • Page 197: Active Blind Spot Assist

    Driving systems Course-correcting brake application If a course-correcting brake application occurs, red warning lamp : flashes in the WARNING exterior mirror and a dual warning tone Active Blind Spot Assist is only an aid sounds. In addition, display ; appears in the designed to assist driving.
  • Page 198: Towing A Trailer

    Driving systems Activation conditions Make sure that active Blind Spot Assist page 220) is activated in the on-board You can activate the HOLD function if: computer. the vehicle is stationary. Turn the key to position 2 in the ignition the engine is running or it has been lock.
  • Page 199: Parktronic

    This may damage the transfer case. chains if necessary. Damage of this sort is not covered by the For information about driving off-road, see Mercedes-Benz implied warranty. All page 169). wheels must remain either on the ground or be fully raised. Observe the instructions...
  • Page 200 Driving systems PARKTRONIC is an electronic parking aid with ultrasonic sensors. It indicates visually and audibly the distance between your vehicle and an object. PARKTRONIC is only an aid. It is not a replace- ment for your attention to your immediate surroundings.
  • Page 201: Deactivating/Activating

    Driving systems Warning displays One or more segments light up as the vehicle approaches an obstacle, depending on the vehicle's distance from the obstacle. From the: sixth segment onwards, you will hear an intermittent warning tone for approx- imately two seconds. seventh segment onwards, you will hear a warning tone for approximately two sec- onds.
  • Page 202: Reversing Camera

    When manoeuvring or parking, make sure workshop. Mercedes-Benz recommends that there are no persons, animals or objects that you use a Mercedes-Benz Service in the area in which you are manoeuvring. Centre for this purpose. Under the following circumstances, the...
  • Page 203: Off-Road Driving Systems

    Off-road driving systems Activating/deactivating the reversing To deactivate: the reversing camera is deac- camera tivated if you: shift the transmission to position P drive forward ten metres shift the transmission from R to another position (after 15 seconds) drive forwards at a speed of over 10 km/h Off-road driving systems Transfer case...
  • Page 204: Shifting

    Off-road driving systems General notes HIGH Position for all normal on- RANGE road driving conditions Low-range position for driv- RANGE ing off-road Also for use on steep uphill or downhill gradients, espe- cially when towing a trailer Current shift range The vehicle travels around half the speed of on-road driving range HIGH RANGE.
  • Page 205: Shifting To Neutral

    Off-road driving systems Press LOW RANGE button ;. Repeat the gear change process. When the shift procedure is complete, the Make sure to meet all conditions for chang- LOW RANGE transfer case position appears ing gears. in the multifunction display. TC Malfunction Visit workshop Indicator lamp : lights up.
  • Page 206: Differential Locks

    Off-road driving systems Differential lock to you losing control of the vehicle. There is a risk of an accident. General notes Disengage the differential locks immediately on firm, high-grip surfaces. WARNING When differential locks are engaged on a firm, WARNING high-grip surface, the vehicle's steerability is ®...
  • Page 207 Off-road driving systems Differential lock for the rear axle For further information on driving off-road, see ( page 169). To engage: press switch ?. You can only engage the differential locks Yellow activation indicator lamp A lights if the transfer case is in the LOW RANGE up first, followed by red function indicator off-road driving position ( page 201).
  • Page 208: Towing A Trailer

    Towing a trailer Couple and uncouple the trailer carefully. If Towing a trailer you do not couple the trailer to the towing Notes on towing a trailer vehicle correctly, the trailer could become detached. Important safety notes Make sure that the following values are not WARNING exceeded: The braking system can overheat if you leave...
  • Page 209 The maximum permissible trailer drawbar prescribed maximum speed in the relevant noseweight on the ball coupling is: country. 140 kg (G-Class long-wheelbase version) For certain Mercedes-Benz vehicles, the max- 115 kg (G-Class Cabriolet) imum permissible rear axle load is increased when towing a trailer.
  • Page 210: Pin Connector

    Towing a trailer Let the cover engage. Trailer power supply If you are using an adapter cable, secure You can connect accessories with a max- the cable to the trailer with cable ties. imum power consumption of 180 W to the permanent power supply.
  • Page 211 Useful information ......210 Important safety notes ....210 Displays and operation ....211 Menus and submenus ...... 214 Display messages ......228 Warning and indicator lamps in the instrument cluster ......251...
  • Page 212: Useful Information

    Important safety notes Useful information WARNING The operating safety of your vehicle could be This Owner's Manual describes all mod- impaired if maintenance work is carried out els, series and optional equipment for your incorrectly. This could cause you to lose con- vehicle that were available at the time of trol of your vehicle and cause an accident.
  • Page 213: Displays And Operation

    Displays and operation Displays and operation Instrument cluster Instrument cluster: kilometres Speedometer with segments ( page 212) Multifunction display ( page 214) Rev counter ( page 212) Coolant temperature ( page 212) Fuel gauge Instrument cluster lighting ( page 212) Instrument cluster: miles Speedometer with segments ( page 212)
  • Page 214: Temperature Gauge

    Displays and operation Rev counter ( page 212) Coolant temperature ( page 212) Fuel gauge Instrument cluster lighting ( page 212) The fuel supply is interrupted to protect the Instrument cluster lighting engine when the red band is reached. The lighting in the instrument cluster, in the displays and the controls in the vehicle inte- rior can be adjusted using the brightness con- Outside temperature display...
  • Page 215: Operating The On-Board Computer

    Displays and operation Left control panel Operating the on-board computer Overview Calls up the menu and menu bar Press briefly: Scrolls through lists Selects a submenu or function Audio In the menu: selects a stored station, an audio track or a video scene In the (telephone) menu:...
  • Page 216: Menus And Submenus

    Menus and submenus Outside temperature or speed Adjusts the volume page 221) Time Mute Transfer case position ( page 201) To show menu bar ?: press the = Back button or ; button on the steering wheel. Press briefly: Menu bar ? disappears after a few seconds. Back Text field = shows the selected menu or Switches off LINGUATRONIC,...
  • Page 217: Displaying The Range

    Menus and submenus Service From start menu ( page 220) The values in the submenu are calculated from the start of a journey whilst Settings menu ( page 221) From reset the values in the submenu are menu in AMG vehicles ( page 225) calculated from the last time the submenu The Audio,...
  • Page 218: Digital Speedometer

    Menus and submenus Digital speedometer For further information, see the separate operating instructions. ® Switch on the audio system with Becker MAP PILOT or COMAND Online, see the separate operating instructions. Press the = or ; button on the steer- Navi ing wheel to select the menu.
  • Page 219: Audio Menu

    Menus and submenus Change of direction announced without a Lane recommendations are only displayed if lane recommendation the relevant data is available on the digital map. Other status indicators of the naviga- tion system O: you have reached the destination or an intermediate destination.
  • Page 220: Operating

    Menus and submenus To select a station from the station audio devices or media support this func- list: press and briefly hold the 9 tion. or : button. If track information is stored on the audio If no station list is received: device or medium, the multifunction display will show the number and title of the track.
  • Page 221: Number From The Phone Book

    Rapid scrolling stops when you release the on the Internet at http:// button or reach the end of the list. www.mercedes-benz.com/connect If only one telephone number is stored for a name: press the 6 or a button to start dialling.
  • Page 222: Assistance Menu

    Menus and submenus Showing the distance display Press the 9 or : button to select the number you want to dial. Press = or ; on the steering wheel Press the 6 or a button to start dial- Assist. to select the menu.
  • Page 223: Permanent Display

    Menus and submenus Press the : or 9 button to select the Settings menu Display unit Speed-/odometer func- Introduction tion. You will see the selected setting: miles. Press the a button to save the setting. The selected unit of measurement for dis- tance applies to: Vehicles with instrument cluster in kil- Trip...
  • Page 224: Interior Lighting

    Menus and submenus Lights Surround light‐ If you have activated the function and the light switch is set to Setting the daytime driving lights Ã, the following functions are activated Day lights function can only be when it is dark: switched on with the engine turned off.
  • Page 225: Setting

    Menus and submenus Vehicle Activating/deactivating the acoustic locking confirmation Setting permanent SPEEDTRONIC Acoustic Lock If you switch on the function, Press the = or ; button on the steer- an acoustic signal sounds when you lock the Settings ing wheel to select the menu.
  • Page 226: Activating/Deactivating

    Menus and submenus maximum of two times, drive for a longer Press a to confirm. distance. Press the : or 9 button to select Change or C. This function is only available on vehicles with auxiliary heating ( page 126). Press a to confirm.
  • Page 227: Daytime Driving Lights

    Menus and submenus Switching the fold-in mirrors when lock- Press a to confirm. ing function on/off Reset all settings? message appears. Auto. fold in mir‐ When you activate the rors function, the exterior mirrors are folded Press the : or 9 button to select in when the vehicle is locked.
  • Page 228: Racetimer

    Menus and submenus using the full output of the engine during this Press = or ; on the steering wheel time. to select the menu. Press the 9 button repeatedly until the SETUP RACETIMER is shown. To start: press the a button to start the RACETIMER.
  • Page 229: Resetting The Current Lap

    Menus and submenus Overall evaluation Press the % button on the steering wheel. Press a to confirm Yes. The RACETIMER is interrupted if you stop the vehicle and turn the key to position page 143) in the ignition lock. If you turn the key to position 2 or 3( page 143) and then press a to confirm Start, timing is...
  • Page 230: Display Messages

    Display messages This function is only available if you have causes for the messages have been rem- stored at least two laps and have stopped the edied. RACETIMER. Message memory menu Press = or ; on the steering wheel to select the menu.
  • Page 231: Display Message

    Display messages Safety systems Display messages Possible causes/consequences and M Solutions !÷ ® ABS (Anti-lock Braking System), ESP (Electronic Stability Pro- gram), BAS (Brake Assist), the HOLD function, hill start assist and currently unavail‐ ® trailer stabilisation are temporarily unavailable. able See Owner's BAS and the adaptive brake lights may also have failed.
  • Page 232 Display messages Display messages Possible causes/consequences and M Solutions ® ® If ESP is not operational, ESP is unable to stabilise the vehicle. The danger of skidding and having an accident increases. Drive on carefully. Visit a qualified specialist workshop immediately. ÷...
  • Page 233: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions ÷ ® ® , BAS, the HOLD function, hill start assist and ESP trailer stabilisation are unavailable due to a malfunction. inoperative See BAS and the adaptive brake lights may also have failed. Owner's Manual In addition, the ÷...
  • Page 234: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions There is insufficient brake fluid in the brake fluid reservoir. In addi- tion, the J warning lamp in the instrument cluster lights up and Check brake fluid a warning tone sounds. level WARNING The braking efficiency may be impaired.
  • Page 235: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions There is a malfunction in the SRS (Supplemental Restraint Sys- tem). The 6 warning lamp also lights up in the instrument clus- Restraint syst. ter. malfunction Con‐ WARNING sult workshop The airbags or belt tensioners may either be triggered uninten- tionally or, in the event of an accident, may not be triggered.
  • Page 236: Lights

    Display messages Display messages Possible causes/consequences and M Solutions SRS has malfunctioned at the rear centre. The 6 warning lamp also lights up in the instrument cluster. Rear centre mal‐ WARNING function Consult workshop The airbags or belt tensioners may either be triggered uninten- tionally or, in the event of an accident, may not be triggered.
  • Page 237: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions The trailer brake lamp is faulty. Check whether you are permitted to replace the bulb yourself. Trailer brake lamp Visit a qualified specialist workshop. The rear left-hand or rear right-hand turn signal is faulty. Check whether you are permitted to replace the bulb yourself Rear left indica‐...
  • Page 238: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions The left-hand or right-hand front foglamp is faulty. Replace the bulb ( page 114). Front foglamp, leftorFront fog‐ lamp, right The rear foglamp is faulty. Check whether you are permitted to replace the bulb yourself Rear fog lamp page 115).
  • Page 239: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions You have left the key in the ignition lock. Remove the key from the ignition lock. Remove key The lights are still switched on when you leave the vehicle. A warning tone also sounds. Switch off lights Turn the light switch to Ã.
  • Page 240 Display messages Display messages Possible causes/consequences and M Solutions The coolant is too hot. A warning tone also sounds. Coolant Stop vehi‐ cle Switch engine WARNING Never drive with an overheated engine. Driving when your engine is overheated can cause some fluids which may have leaked into the engine compartment to catch fire.
  • Page 241: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions The battery is not being charged. A warning tone also sounds. Possible causes: faulty alternator torn poly-V-belt a malfunction in the electronics Stop the vehicle immediately, paying attention to road and traf- fic conditions, and switch off the engine.
  • Page 242 Display messages Display messages Possible causes/consequences and M Solutions The fuel level has dropped into the reserve range. Operation of the auxiliary heating is deactivated when the fuel level Reserve fuel level drops into the reserve range. Refuel at the nearest filling station. There is only a very small amount of fuel in the fuel tank.
  • Page 243: Driving Systems

    Display messages Display messages Possible causes/consequences and M Solutions Ø ® The AdBlue system is malfunctioning. A warning tone also sounds. Eng. start not pos‐ Visit a qualified specialist workshop immediately. sible in ... km Ø ® The AdBlue system is malfunctioning. A warning tone also sounds.
  • Page 244 Display messages Display messages Possible causes/consequences and M Solutions TC shift condition You have not met one or more shift conditions. not fulfilled Shift the automatic transmission to neutral position N. Engage NEUTRAL gear Repeat the gearshift process. TC shift condition You have exceeded the maximum speed for the gearshift process.
  • Page 245: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions Blind Spot Assist Blind Spot Assist or Active Blind Spot Assist is temporarily inop- currently unavail‐ erative. Possible causes: able See Owner's you have established the electrical connection between the Manualor trailer and your vehicle.
  • Page 246 Display messages Display messages Possible causes/consequences and M Solutions DISTRONIC PLUS DISTRONIC is deactivated and temporarily inoperative. Possible causes: currently unavail‐ able See Owner's the DISTRONIC PLUS cover in the radiator grille is dirty. Manual the function is impaired due to heavy rain or snow. the sensors in the bumpers are dirty.
  • Page 247: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions Cr. control and SPEEDTRONIC and cruise control are malfunctioning. SPEEDTRONIC inop‐ Visit a qualified specialist workshop. erative Limit While depressing the accelerator pedal beyond the pressure point (kickdown), SPEEDTRONIC cannot be activated. --- km/h Cruise control A condition for activating cruise control has not been met.
  • Page 248 Display messages Display messages Possible causes/consequences and M Solutions Check tyres The tyre pressure in one or more tyres has dropped significantly. The wheel position is displayed in the multifunction display. A warning tone also sounds. WARNING With tyre pressures which are too low, there is a risk of the fol- lowing hazards: the tyres may burst, especially as the load and vehicle speed increase.
  • Page 249 Display messages Display messages Possible causes/consequences and M Solutions Please correct The tyre pressure is too low in at least one of the tyres, or the tyre tyre pressure pressure difference between the wheels is too great. Check the tyre pressures at the next opportunity page 323).
  • Page 250: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions The tyre pressure in one or more tyres has dropped significantly. WARNING Tyre pressure Check tyre(s) With tyre pressures which are too low, there is a risk of the fol- lowing hazards: the tyres may burst, especially as the load and vehicle speed increase.
  • Page 251: Display Message

    G-Class Cabriolet: the tailgate is open. WARNING When the engine is running, exhaust gases can enter the vehicle interior if the tailgate (G-Class long-wheelbase version and G-Class Cabriolet) is open. There is a risk of poisoning. Close the tailgate (G-Class long-wheelbase version or G-Class Cabriolet).
  • Page 252: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions The power steering assistance is faulty. A warning tone also sounds. Power steering mal‐ function See Own‐ WARNING er's Manual You will need to use more force to steer. There is a risk of an accident. Check whether you are able to apply the extra force required.
  • Page 253: Warning And Indicator Lamps In The Instrument Cluster

    Warning and indicator lamps in the instrument cluster Display messages Possible causes/consequences and M Solutions Telephone No Your vehicle is outside the network provider's transmitter/ service receiver range. Wait until the mobile phone operational readiness symbol appears in the multifunction display. ¥...
  • Page 254: Warning Lamp

    Warning and indicator lamps in the instrument cluster Safety Seat belts Problem Possible causes/consequences and M Solutions The seat belt warning lamp reminds the driver and front passenger ü to fasten their seat belts. Only for certain coun- tries: the red seat belt Fasten your seat belt ( page 44).
  • Page 255: Warning Lamp

    Warning and indicator lamps in the instrument cluster Safety systems Problem Possible causes/consequences and M Solutions WARNING The red brake system The brake system is malfunctioning and the braking characteris- warning lamp comes on tics may be affected. while the engine is run- There is a risk of an accident.
  • Page 256: Warning Lamp

    Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ABS (Anti-lock Brake System) has been deactivated due to a fault. ® BAS (Brake Assist), ESP (Electronic Stability Program), the HOLD The red ABS warning ® function, hill start assist, the adaptive brake lights and ESP trailer lamp is lit while the...
  • Page 257 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® ABS is temporarily unavailable. BAS, ESP , EBD (electronic brake ® force distribution), the HOLD function, hill start assist, ESP trailer The red ABS warning stabilisation and the adaptive brake lights, for example, are there- lamp is lit while the fore also deactivated.
  • Page 258: Warning Lamp

    Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® EBD is faulty. Therefore, ABS, BAS, ESP , the HOLD function, hill ® start assist, the adaptive brake lights and ESP trailer stabilisation The red ABS warning are also not available, for example.
  • Page 259 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® ÷ or traction control has intervened because there is a risk of skidding or at least one wheel has started to spin. ® The yellow ESP warn- ing lamp flashes while Cruise control or DISTRONIC PLUS is deactivated.
  • Page 260 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® ® ÷å , BAS, the HOLD function, hill start assist and ESP trailer stabilisation are temporarily unavailable. ® The yellow ESP ® BAS and the adaptive brake lights may also have failed. OFF warning lamps are lit while the Self-diagnosis is not yet complete.
  • Page 261: Engine Diagnostics

    Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions You are driving with the parking brake applied. The yellow parking Release the parking brake. brake warning lamp The warning lamp goes out and the warning tone ceases. comes on while the vehicle is moving.
  • Page 262: Warning Lamp

    Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions The fuel level has dropped into the reserve range. The yellow reserve fuel Operation of the auxiliary heating is deactivated when the fuel level warning lamp lights up drops into the reserve range.
  • Page 263 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions The coolant level is too low. The red coolant warn- If the coolant level is correct, the airflow to the engine radiator ing lamp comes on may be blocked or the electric engine radiator fan may be mal- while the engine is run- functioning.
  • Page 264: Warning Lamp

    Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions Leave the vehicle and keep a safe distance from the vehicle until the engine has cooled down. Check the coolant level and top up the coolant, observing the warning notes ( page 289).
  • Page 265: Warning Lamp

    Warning and indicator lamps in the instrument cluster Tyres Problem Possible causes/consequences and M Solutions The tyre pressure monitor has detected a loss of pressure in at least one of the tyres. The yellow tyre pres- sure monitor warning WARNING lamp is on.
  • Page 267 Useful information ......266 Loading guidelines ......266 Stowage areas ........267 Features ..........275...
  • Page 268: Useful Information

    Loading guidelines Useful information This Owner's Manual describes all mod- els, series and optional equipment for your vehicle that were available at the time of going to press. Country-specific differen- ces are possible. Note that your vehicle may not be fitted with all features descri- bed.
  • Page 269: Stowage Areas

    Stowage areas Front stowage compartments If the rear bench seat is not occupied: insert the belt tongue on the outer seat Glove compartment belts into the buckle of opposite seat belt :. secure the load with sufficiently strong and wear-resistant lashing material. pad sharp edges for protection.
  • Page 270: Important Safety Notes

    Make sure that you remove any contain- ers from the rear-compartment cup holders before folding forward the backrests and seat cushions of the rear bench seat. G-Class Cabriolet: the rear bench seat is Map pockets split symmetrically. G-Class long-wheelbase version: the rear...
  • Page 271 The corresponding rear seat backrest is not engaged. Fold the backrest forwards. The rear seat backrest engages audibly. Seat backrest release lever Long lever Short lever G-Class long-wheelbase version: open the rear doors. This allows you better access to Backrest folded forward the release lever.
  • Page 272: Securing A Load

    Stowage areas Remove the head restraints ( page 93). If the seat backrests or rear bench seat are Pull short lever ; in the direction of the not fully engaged and the following occurs: arrow and hold it. sharp braking Pull long lever : in the direction of the a sudden change of direction arrow and fold the seat backrest forwards.
  • Page 273: Lashing Eyelets

    Lashing eyelets in the load compart- ment G-Class Cabriolet with the rear bench seat folded forwards Luggage compartment cover Important safety notes WARNING The luggage compartment cover is not a restraint system.
  • Page 274: Opening And Closing

    Stowage areas Opening and closing the luggage com- To fit: slide catches : towards the centre partment cover of the vehicle. Insert luggage compartment cover ; into the recesses in the side trim. Push down the right-hand and left-hand sides of luggage compartment cover ; until it engages.
  • Page 275: With Luggage Compartment Enlargement

    Stowage areas Open the rear door. Fold the rear bench seat forward into an This allows you to hook in the safety net upright position ( page 270). more easily. The safety net is tensioned by the rear bench seat. Fold the rear bench seat forward, without folding the seat backrest forward before- After driving a short distance, check the...
  • Page 276: Releasing

    Stowage areas Releasing the safety net Tensioning buckle Tensioning strap Tensioning buckle Hook Tensioning strap Lashing eyelet Hook Tensioning straps ? can be set to the Lashing eyelet length for lashing eyelets B using tension- Lift tensioning buckles = into the horizon- ing buckles =.
  • Page 277: Features

    Mercedes-Benz recommends that you only use roof carriers that have been tested and approved for Mercedes-Benz vehicles. This helps to prevent damage to the vehi- cle. To open: fold down the glove compartment Position the load on the roof carrier in such cover.
  • Page 278: Sun Visor

    Features Vanity mirror in the sun visor before folding forward the backrests and seat cushions of the rear bench seat. Sun visor Cup holders Bracket Mirror cover Mirror light Sun visors Mirror lights ? will only function if sun Sun visor overview visor : is clipped into bracket ;.
  • Page 279: Ashtray

    Features Ashtray in the rear compartment (G- Stowage compartment/ashtray Class long-wheelbase version) Stowage compartment/ashtray in the centre console WARNING Make sure that the engine has been switched off and that the parking brake is applied so that the vehicle cannot pull away unintention- ally.
  • Page 280: V Socket

    Features Socket in the rear compartment You can use the cigarette lighter socket for accessories up to 180 W page 278). 12 V sockets General notes If you are simultaneously using all three sockets in the vehicle, make sure that you do not exceed the maximum current draw of 45 A.
  • Page 281 To fold the bracket down: press the electromagnetic fields. bracket down and until it audibly engages. Mercedes-Benz recommends the use of an Depending on the vehicle's equipment, a approved exterior aerial. This ensures: USB connection, an AUX-IN connection or...
  • Page 282: Important Safety Notes

    HomeLink and/or compatible products is gramming it for the first time. available from: Turn the key to position 2( page 143) in any Mercedes-Benz Service Centre the ignition lock. ® the HomeLink hotline Press and hold transmitter button ;, = (0) 08000 466 354 65 (free of charge) or or ?.
  • Page 283 Features Point transmitter button B of garage door Synchronising the rolling code remote control A towards the transmitter buttons on the rear-view mirror at a dis- tance of 5to 30 cm. The distance between garage door remote control A and the integrated garage door opener depends on the system of the garage door drive.
  • Page 284 Features Problems when programming steps, make sure that new batteries have been fitted in the garage door remote con- trol. Align the aerial cable of the garage door opener unit. This can improve signal recep- tion/transmission. Opening or closing the garage door Remote control in the rear-view mirror Indicator lamp Transmitter buttons...
  • Page 285: Floormat

    Features cator lamp : will flash. Press the trans- Do not place floormats on top of one another. mitter button again if necessary. Clearing the remote control memory Slide the seat backwards. To fit: lay the floormat in the footwell. Press studs : onto retainers ;.
  • Page 287 Useful information ......286 Engine compartment ......286 Service ..........290 Care ............ 291...
  • Page 288: Useful Information

    Engine compartment Useful information Vehicles with a petrol engine: The elec- tronic ignition system uses high voltage. For This Owner's Manual describes all mod- this reason, you must never touch ignition els, series and optional equipment for your system components (ignition coil, ignition vehicle that were available at the time of cables, spark plug connectors or test socket) going to press.
  • Page 289: Bonnet Closing

    Engine compartment Opens the bonnet Lift the bonnet slightly. Petrol engine: push the handle of bonnet catch ; in the direction of the arrow and lift the bonnet. Diesel engine: pull the handle of bonnet catch ; in the direction of the arrow and lift the bonnet.
  • Page 290: Oil Level

    Engine compartment Checking the oil level using the oil dip- On all other models, the dipstick must be stick used to check the engine oil level. When checking the oil level: park the vehicle on a level surface. the engine should be switched off for approximately five minutes if the engine is at normal operating temperature.
  • Page 291: Topping Up

    Engine compartment If the engine is at normal operating tem- Turn cap : anti-clockwise and remove it. perature: repeat the measurement after Top up with the amount of oil required. about five minutes. Observe the specifications in the on-board If the engine is not at normal operating computer when doing so or fill carefully to the temperature: (e.g.
  • Page 292: Service

    (see separate Service Booklet). been tested and approved by Mercedes- You can obtain further information from a Benz. Mercedes-Benz Service Centre. Replace cap : and turn it clockwise as far The ASSYST service interval display informs as it will go.
  • Page 293: Care

    Arduous operating conditions or increased Use care products and cleaning agents rec- loads on the vehicle will require some service ommended and approved by Mercedes-Benz. work to be performed more often than for a vehicle in normal use. Such arduous condi-...
  • Page 294: Automatic Car Wash

    Care after having cleaned the wheels with wheel position 0/the à and Á buttons cleaner. Wheel cleaners could cause are switched off). increased corrosion of the brake discs and the windscreen wiper switch is at posi- brake pads/linings. For this reason, you tion 0.
  • Page 295: Cabriolet Soft Top

    Care Cleaning the G-Class Cabriolet soft top should drive for a few minutes after clean- ing. Braking heats the brake discs and the Never use any of the following to clean the brake pads/linings, thus drying them. The soft top: vehicle can then be parked up.
  • Page 296: Headlamps

    Clean the headlamp lenses with a damp windscreen and the rear window at regular sponge and a mild cleaning agent, e.g. intervals. Deposits such as leaves, petals Mercedes-Benz car shampoo or cleaning and pollen may under certain circumstan- cloths. ces prevent water from draining away. This...
  • Page 297: Chrome Parts

    Care Cleaning chrome parts Do not clean the exhaust pipe with acid- based cleaning agents such as sanitary cleansers or wheel cleaners. Impurities combined with the effects of road grit and corrosive environmental factors may cause flash rust to form on the surface. You can restore the original shine to the chrome parts by cleaning them regularly, especially in winter and after washing.
  • Page 298: Display

    Only use leather care agents Do not affix the following to plastic surfa- that have been tested and approved by ces: Mercedes-Benz. You can obtain these stickers from a qualified specialist workshop. films clean artificial leather covers with a cloth...
  • Page 299: Seat Belt

    Care detergent (e.g. washing-up liquid). Rub carefully and always wipe entire seat sec- tions to avoid leaving visible lines. Leave the seat to dry afterwards. Cleaning results depend on the type of dirt and how long it has been there. Note that regular care is essential to make sure that the appearance and com- fort of the covers are retained over time.
  • Page 301 Useful information ......300 Where will I find...? ......300 Flat tyre ..........305 Battery (vehicle) ........ 305 Jump-starting ........309 Towing and tow-starting ....311 Electrical fuses ......... 314...
  • Page 302: Useful Information

    Removing the warning triangle Turn handle : clockwise and fold up cover ; in the direction of the arrow. G-Class long-wheelbase version Remove warning triangle =. Warning triangle : is attached to the under- side of the rear bench seat.
  • Page 303: Fire Extinguisher

    Where will I find...? Setting up the warning triangle G-Class Cabriolet: the first-aid kit is located in the tailgate behind a cover. Press-stud Open the tailgate ( page 76) Reflectors Open the tailgate cover ( page 300). Feet Remove first-aid kit :.
  • Page 304: Vehicle Tool Kit

    Vehicle tool kit G-Class long-wheelbase version Fire extinguisher = is located in the stowage compartment under the driver's seat. Pull handle : upwards. Pull the catch of cover ; forwards in the direction of the arrow.
  • Page 305 Open the tailgate cover ( page 300). Remove vehicle tool kit :. Jack G-Class long-wheelbase version Make sure that, while fitting the vehicle The jack is located behind a cover in front of jack, there are no cables on the holder, in the front-passenger seat.
  • Page 306: Stainless-Steel Spare Wheel Cover

    Where will I find...? Removing the cover Pull cover ring : apart and remove it. Pull off cover panel ?. Protective tyre cover When refitting cover panel ?, make sure Pull rubber ring : of protective tyre that retainer A engages in recess B. cover ;...
  • Page 307: Flat Tyre

    Work on the battery, e.g. removing or instal- G-Class Cabriolet ling, requires specialist knowledge and the Secure the spare wheel of the G-Class use of special tools. Therefore, always have Cabriolet on spare wheel bracket ;, so work on the battery carried out at a qualified that valve : is accessible for checking the specialist workshop.
  • Page 308 Battery (vehicle) Always have work on the battery carried WARNING out at a qualified specialist workshop. During the charging process, a battery produ- Should it, in exceptional circumstances, be ces hydrogen gas. If a short circuit occurs or absolutely necessary to disconnect the bat- sparks are created, the hydrogen gas can tery yourself, please observe the following: ignite.
  • Page 309: Charging The Battery

    Explosive gases are created during charging and jump-starting. WARNING For safety reasons, Mercedes-Benz recom- Battery acid is caustic. There is a risk of injury. mends that you only use batteries which have been tested and approved for your vehicle by Avoid contact with the skin, eyes or clothing.
  • Page 310 Mercedes-Benz is being used. A battery charger unit specially adapted for Mercedes-Benz vehicles and tested and approved by Mercedes-Benz is available as an accessory. It permits the charging of the bat- tery in its installed position. Contact a Mercedes-Benz Service Centre for informa- tion and availability.
  • Page 311: Jump-Starting

    Jump-starting Jump-starting WARNING Battery acid is caustic. There is a risk of injury. Avoid contact with the skin, eyes or clothing. Do not inhale any battery gases. Do not lean over the battery. Keep children away from batteries. Wash battery acid immediately with water and seek medical attention.
  • Page 312 Jump-starting Do not use a rapid charging device to start the vehicle. Make sure the jump leads are not damaged. Make sure the jump leads are not touching any other metal objects when they are connected to the battery. If the indicator/warning lamps do not light up at temperatures around or below freezing point, the discharged battery is likely to be frozen (a commonplace scenario).
  • Page 313: Towing And Tow-Starting

    Towing and tow-starting Position number B identifies the charged battery of the other vehicle or an equivalent jump- starting device. The jump-start terminal point consists of terminals ; and ?. Lift up cover : of positive terminal ; in the direction of the arrow. Connect positive terminal ;...
  • Page 314: Towing Eye Front

    Towing and tow-starting For towing distances over 50 km, the entire The battery must be connected and charged. vehicle must be lifted up and transported. Otherwise, you: cannot turn the key in the ignition lock to Only secure the tow cable or towing bar position 2( page 143) to the towing eyes.
  • Page 315: In The Event Of Malfunctions

    Towing and tow-starting Move the selector lever to N. Towing the vehicle with both axles on the ground Shift the transfer case to neu- tral( page 203). It is important that you observe the safety Secure the towing cable to the towing eyes instructions when towing away your vehicle page 312).
  • Page 316: Electrical Fuses

    The fuse allocation chart and the spare fuses Only use fuses that have been approved for are in the main fuse box on the dashboard Mercedes-Benz vehicles and which have the page 315). correct fuse rating for the systems con- You will find the fuse removal device in the cerned.
  • Page 317: Dashboard

    Electrical fuses Dashboard fuse box Do not use a pointed object such as a screwdriver to open the cover in the dash- board. You could damage the dashboard or the cover. Make sure that no moisture can enter the fuse box when the cover is open. When closing the cover, make sure that it is lying correctly on the fuse box.
  • Page 318: In The Battery Case

    Electrical fuses Fold down the cup holder on the centre console ( page 275). Adjust the front-passenger seat to its fore- most position ( page 92). To open: remove screws :. Remove cover ; in the direction of the arrow. To close: clip in cover ;.
  • Page 319: Wheels And Tyres

    Useful information ......318 Important safety notes ....318 Operation ........... 318 Winter operation ....... 319 Tyre pressure ........321 Changing a wheel ......325 Wheel and tyre combinations ..329...
  • Page 320: Useful Information

    If you find no signs of damage, have the tyres Accessories that are not approved for your and wheels checked at a specialist workshop. vehicle by Mercedes-Benz or are not being When parking your vehicle, make sure that used correctly can impair the operating the tyres do not get deformed by the kerb or safety.
  • Page 321: Winter Operation

    100 km. They only standard valve cap or a valve cap approved reach their full performance after this dis- by Mercedes-Benz for your vehicle. tance. Do not fit anything onto the valve, such as Do not drive with tyres which have too little tyre pressure monitoring systems.
  • Page 322: Snow Chains

    M+S marking. have been specially approved for your vehicle Only winter tyres bearing the i snowflake by Mercedes-Benz, or that are of a corre- symbol in addition to the M+S marking pro- sponding standard of quality. vide the best possible grip in wintry road con- only use snow chains when the road sur- ditions.
  • Page 323: Tyre Pressure

    This can also result in tyre pressure loss. There is a risk of accident. Only screw standard valve caps or valve caps specifically provided by Mercedes-Benz for your vehicle onto the tyre valve.
  • Page 324 Tyre pressure Tyre pressure table Rim diameter : is part of the tyre size and can be found on the tyre sidewall. If a tyre size precedes a tyre pressure, the tyre Use a suitable pressure gauge to check the pressure information following is only valid tyre pressure.
  • Page 325: Tyre Pressure Monitor

    Tyre pressure Screw the valve cap onto the valve. The tyre pressure values given for low loads are minimum values which offer you Repeat these steps for the other tyres. good ride comfort characteristics. However, you can also use the values given for higher loads.
  • Page 326: Restarting

    Tyre pressure Warning messages of the tyre pressure ured at a filling station with a pressure gauge. monitor The tyre pressures shown by the on-board computer refer to those measured at sea If the tyre pressure monitor detects a signifi- level.
  • Page 327: Changing A Wheel

    130 Nm. After you have driven for a few minutes, the For safety reasons, Mercedes-Benz recom- system checks whether the current tyre mends that you only use wheel bolts of the pressures are within the specified range.
  • Page 328: Raising The Vehicle

    Mercedes-Benz. If the jack is used incorrectly, it could tip over while the vehicle is raised. the jack is designed only to raise and hold...
  • Page 329: Pump Lever

    Changing a wheel is being changed. It is not suited for per- full turn. Do not unscrew the wheel bolts forming maintenance work under the vehi- completely. cle. avoid changing the wheel on uphill and downhill slopes. before raising the vehicle, secure it from rolling away by applying the parking brake and inserting wheel chocks.
  • Page 330: Lowering

    130 Nm. only use wheel bolts which have been Push the jack piston back in and close the approved for Mercedes-Benz vehicles and the drain plug. respective wheel. Other wheel bolts could Use the bolts to secure the faulty wheel to work loose or damage the brake system.
  • Page 331: Wheel And Tyre Combinations

    ABS or ESP G 65 AMG Only use tyres, wheels or accessories tes- ted and approved by Mercedes-Benz. Cer- Not all wheel/tyre combinations can be tain characteristics, e.g. handling, vehicle mounted at the factory in all countries.
  • Page 332 265/60 R18 110 V 7.5J x 18 H2 ET 63 You can obtain information about tyres Tyre manufacturer and tyre dimensions that are not listed here recommended by at any Mercedes-Benz Service Centre. Mercedes-Benz: Yoko- All-weather tyres hama. Tyres Light-alloy...
  • Page 333 You can obtain information about tyres Tyres Light-alloy and tyre dimensions that are not listed here wheels at any Mercedes-Benz Service Centre. 265/60 R18 110 V 7.5J x 18 H2 ET 63 Spare wheel The spare wheel must be inflated to the...
  • Page 334 Mercedes-Benz: Dun- lop. You can obtain information about tyres and tyre dimensions that are not listed here at any Mercedes-Benz Service Centre. Spare wheel The spare wheel must be inflated to the maximum tyre pressure given in the table on the inside of the fuel filler flap.
  • Page 335: Technical Data

    Useful information ......334 Information on technical data ..334 Genuine Mercedes-Benz parts ..334 Vehicle electronics ......335 Identification plates ......336 Service products and capacities ..337 Vehicle data ........344 Trailer tow hitch ........ 346 24 GHz radar sensor system ... 347...
  • Page 336: Useful Information

    For this reason, Mercedes-Benz recommends approved. that you use genuine Mercedes-Benz parts or parts of equal quality. Only use tyres, wheels In Germany, certain parts are only officially and accessories that have been specifically approved for installation or modification if approved for your vehicle.
  • Page 337: Vehicle Electronics

    336) and the engine num- The operating permit may be invalidated ber ( page 337) when ordering genuine if the instructions for installation and use of Mercedes-Benz parts. RF transmitters are not observed. In particular, the following conditions must be complied with: Vehicle electronics only approved wavebands may be used.
  • Page 338: Identification Plates

    Be sure to observe the manufacturer's additional instructions when installing. Deviations with respect to wavebands, maxi- mum transmission outputs or aerial positions must be approved by Mercedes-Benz. The maximum transmission output (PEAK) at the base of the aerial must not exceed the following values:...
  • Page 339: Service Products And Capacities

    Components and service products must be matched. Mercedes-Benz recommends that you use products tested and approved by Mercedes-Benz. They are listed in this In addition to the information on the vehicle Mercedes-Benz Owner's Manual in the appro- identification plate, the vehicle identification priate section.
  • Page 340: Petrol

    If fuel is swallowed, seek immediate medi- cleaning additives recommended by cal attention. Do not induce vomiting. Mercedes-Benz should be added to petrol, Change any clothing that has come into see "Additives". You can obtain further contact with fuel immediately.
  • Page 341: Diesel

    As much as possible, build up. In this case, Mercedes-Benz recom- avoid driving at full throttle. mends the use of additives that have been Regular unleaded petrol with an octane approved for Mercedes-Benz vehicles;...
  • Page 342 Do not mix such fuels with diesel fuel and Only use flow improvers tested and approved do not use any special additives. This can by Mercedes-Benz. During use, please otherwise lead to engine damage. This observe the information on operation.
  • Page 343: Notes

    -11 †. The vehicle is equipped with Therefore, only Mercedes-Benz approved ® an AdBlue preheating system at the factory. engine oils may be used in Mercedes-Benz Winter operation can therefore be guaran- engines. teed even at temperatures below -11 †. Further information on tested and approved...
  • Page 344: Viscosity

    Service products and capacities Petrol engines MB Approval Vehicle model Capacity including oil filter G 500 229.3, 229.5 G 63 AMG G 63 AMG 229.5 G 65 AMG G 65 AMG 229.5 Additives Diesel engines MB Approval Do not use any additives with the engine G 350 BlueTEC 228.51, oil.
  • Page 345: Notes

    When the vehicle is first delivered, it is fil- Further information on coolants can be led with a coolant mixture that ensures found in the Mercedes-Benz Specifications adequate antifreeze and corrosion protec- for Service Products, MB Specifications for tion.
  • Page 346: Vehicle Data

    Adapt the mixing ratio to the outside temper- ature. Dimensions and weights Down to Ò10 †: mix 1 part MB WinterFit to G-Class long-wheelbase version 2 parts water. Down to Ò20 †: mix 1 part MB WinterFit to 1 part water.
  • Page 347 Vehicle data G-Class Cabriolet The missing values for the following models were not available at the time of going to print: G 63 AMG G 65 AMG All mod- AMG vehi- cles (except AMG vehi- cles) 1905 mm – :Upper-...
  • Page 348: Trailer Tow Hitch

    Trailer tow hitch Trailer tow hitch Trailer loads Mounting dimensions G-Class long-wheelbase version (all models) WARNING Permissible trailer load, 750 kg Only have a trailer tow hitch retrofitted at a unbraked qualified specialist workshop. Permissible trailer load, 3500 kg If you have a trailer tow hitch retrofitted,...
  • Page 349: 24 Ghz Radar Sensor System

    24 GHz radar sensor system The 24 GHz radar sensor system requires separate approval for each country. Maintain the minimum distance from radio telescope facilities. The current country overview can be obtained from a Mercedes-Benz Service Centre or on the Internet at: http://www.mercedes-benz.de/betriebsanleitung.
  • Page 351 Internet Further information about Mercedes-Benz vehicles and about Daimler AG can be found on the following websites: http://www.mercedes-benz.com http://www.daimler.com Editorial office You are welcome to forward any queries or suggestions you may have regarding this Owner's Manual to the technical documenta-...
  • Page 352 ÉHLI0000000722{ËÍ HLI0000000722 Order no. 6515 4141 02 Part no. HLI 000 00 00 722 Edition ÄJ 2012-Ma Nur für internen Gebrauch / For internal use only...

Table of Contents

Save PDF
