Installation Instructions for
Gia Mirror Kit
B
ATH
G
ENERAL RODUCT NFORMATION
P
I
Suitable for damp locations.
CAUTION - RISK OF FIRE
This product must be installed in accordance with the
applicable installation code by a person familiar with the
construction and operation of the product and the
hazards involved.
Use minimum 90°c supply conductors.
CAUTION: It is important to determine the location of
the electrical box/driver and fixture layout before
beginning the following installation.
Install the Fixtures
1A
CARDBOARD TEMPLATE
2
1
ELECTRICAL
BOX
1
Ensure that the electrical box is located behind the mirror location.
-For multiple mirror installations, an electrical box must be present behind the mirror which is the center of the group.
-For multiple mirror installations with 600 lms/ft, two electrical boxes must be present behind each outer mirror to support
the additional driver.
2
2
Using the provided cardboard mirror template and a fixture; level, measure, and mark the location of mirror(s) and fixtures.
C
OLLECTION
:
3
36.5"
5
24"
MULTIPLE MIRROR INSTALLATION
MULTIPLE MIRROR WITH 600 LMS/F INSTALLATION
3
1
5
1
700BCGIAMR_
2
3
1
5
2 2
3
1
5
920BCGIADM
1.2
