Summary of Contents for AGFEO HS-Module 30
- Page 1 Installation Instructions HS-Module 30 Headset module for retrofitting ST 30 system telephones...
-
Page 2: Safety Instructions
Safety Instructions - Do not remove or plug in the ST 30 connection cable during a storm. - Lay the ST 30 cable so that it cannot be stepped on or tripped over. - Make sure no liquid is allowed to enter the system telephone. This may lead to short- circuits. -
Page 3: Table Of Contents
Installation ............................. 9 Operation with System Firmware 6.0 and Above .................. 9 Operation with System Firmware prior to V. 6.0 ................. 10 Updating your ST30 ..........................10 Headsets Tested by AGFEO ......................... 10 Copyright ............................. 11 Technical Changes ..........................11... -
Page 4: Included In Supply Package
'ST 30 Digital Ver. 3.1'. The telephone has to be updated before slotting in the module. The system firmware does not have to be updated! The HS 30 functions on all AGFEO PBEs which support the ST 30 system telephone. To update the telephone's software, press *,0 and # simultaneously. This procedure is... -
Page 5: Installing The Module
HS-Module 30 Installing the Module You need to remove the western plug attached to the ISDN connection cable from the ISDN socket first before opening the system telephone ST 30 module slot! To remove the ISDN connection cable, use your finger nail (or a small screwdriver) to press the clip on the western plug towards the body of the plug and pull on the cable at the same time to remove it. -
Page 6: The Headset Module Jumper
HS-Module 30 The Headset Module Jumper You need to set the operating mode on both jumperblocks before installing the HS Module 30. Setting the jumper to DHSG operating mode: Jumperblock 1 Jumperblock 2 Jumperblock 2 Jumperblock 1 Setting the jumper to AUX operating mode:... -
Page 7: Operating Mode: Dhsg
HS-Module 30 Operating mode: DHSG The DHSG (Wireless Headset) interface is a newly designed industry standard which various headset and end device manufacturers have joined up with. This bidirectional interface ensures that all telephones and headsets function together irrespective of the manufacturer, and provides a wide range of features. The telephone can signalise On-hook, Off-hook and Ring to the headset and the headset can signalise On-hook and Off-hook to the telephone the other way around. -
Page 8: Operation With System Firmware 6.0 And Above
HS-Module 30 Operation with System Firmware 6.0 and Above Allocate a headset button on the ST 30 or a dedicated STE 30 with the help of the TK-Suite Configurator or via the menu with the help of !31. The headset is now ready for operation. -
Page 9: Operating Mode: Aux
HS-Module 30 Operating Mode: AUX This mode of operation is only presently authorised for headsets from GN-Netcom with an AUX jack. Further authorisation can be proofed on request. In this mode of operation, the telephone can signalise an incoming call to the headset, and the headset can signalise 'On-hook' and 'Off-hook' to the telephone. -
Page 10: Operation With System Firmware Prior To V. 6.0
Headsets Tested by AGFEO The following headsets have been tested by AGFEO for functionality with the HS Module 30: Manufacturer Model... -
Page 11: Copyright
Gaswerkstr. 8 D-33647 Bielefeld (Germany) All rights to this documentation are reserved by AGFEO GmbH & Co. KG. This applies in particular to the issue of patents or the entry of registered designs. Neither the complete documentation nor any parts of it are allowed to be changed or translated into any language or any form of computer language by any means without our express written permission. - Page 12 Ident. no. 1100290 Subject to change without notice. No liability can be accepted for AGFEO GmbH & Co. KG errors contained in this Gaswerkstr. 8 document. D-33647 Bielefeld Printed in Germany Internet: http://www.agfeo.de 0047...
