MidMono Amplifier:
4 ohm
Ground
8 ohm
The following diagram is on the bottom of each amplifier:
INPUT
CONNECTOR
100K
SPEAKER
TERMINALS
12AX7
6922
Quicksilver Audio Mid Mono Amplifier
Bottom View
INPUT TUBE
DRIVER TUBE
12AX7
6922
OUTPUT
TRANSFORMER
Red
Red
Black
BIAS PIN JACKS
POWER SUPPLY
CAPACITOR
OUTPUT TUBES
POWER
TRANSFORMER
Fuse
2 amp
slo-blo
POWER
CORD
2
AMP
FUSE
POWER
SWITCH
Push in at
top to
turn on.
