Summary of Contents for Mobility Designed M+D Crutch
- Page 1 Instructions For Use L10003 Rev 4 (01/07/19)
- Page 2 INDEX Thank you for your purchase of the M+D Crutch™! Setup: 4. Height and weight range At Mobility Designed, we believe mobility should 5. Intended Use be as painless as possible. The M+D Crutch™ was 6. Product Structures and features born out of personal inspiration to make life better 7.
- Page 3 M+D Crutches Models English- Intended Use MD10013 M+D Crutch Pair - White The M+D Crutch™ is to be used as a walking aid for MD10014 M+D Crutch Pair - Black patients who are non-weight bearing on a single lower MD10015 M+D Crutch Left - White...
- Page 4 *Tip- Recommendations from the manufacturer. Caution- User should take particular care to review. *Tip: feet are designed for easy removal and are snug to reduce noise. If you find removing foot is tight, push snap button and apply pressure on the top of the foot to hold in place while pulling on leg tube until released.
- Page 5 Audible “click” to secure leg. 1. Insert leg: Depress snap-button in leg to insert leg tube into body of M+D Crutch™. height. *Caution: If snap-button pushes too far inside leg: stop use of crutch, use flat-head screw- driver to pop back out.
- Page 6 Attention: When fitting handles for your arm length, note the one with a blue button should be adjusted for your right arm. Finding the right handle length: B) Place arm in cradle and hold handle. Elbow should rest Insert handle into crutch body: against back of cradle.
- Page 7 Attention: Hole in handle tube must line up with hole on crutch body. Remember handles angle inward slightly, so tilt the handle until the holes align. Secure Handle tube to crutch body: After determining appropriate handle length, place Use coin or screwdriver to tighten the screw. screw (previously removed from tube) in corresponding screw hole.
- Page 8 Caution: Unlocking cradle allows freedom of motion. Become comfortable using crutch before attempting Default arm band position Tip: To easily feel which side of button is used to lock cra- dle, note there is a braille dot on only the locking side.
- Page 9 Pull here to remove from cradle Step 1. To change the arm band placement remove Step 2. Pull up on bottom hard plastic arm band clip screw using a screwdriver. to pop off side rail.
- Page 10 Hook top tabs first Align hole on arm band clip to hole on cradle rail. Push on bottom till “clicks” into place Make sure both top and bottom tabs of arm band To place arm bands back on cradle align top of clip are securely snapped to rail, then place washer arm band clip to lip of cradle rail.
- Page 11 The ABC’s of the M+D Crutch are the key to maintaining (Bicep curl) (Core engaged) good stability. (A-Frame) Elbows tight to your sides Crutch feet wider than shoulder width Make an A-FRAME with your crutches by keeping your Keeping your elbows tight to your sides move crutch feet ELBOWS IN tight to your sides and placing your crutch forward doing a small BICEP CURL.
- Page 12 Tip: Handles are hand specific and angle inward toward body. *Caution: When Only the right reaching up, user can handle button is become unbalanced blue and has a if crutch leaves braille dot on ground. Crutch can the button move in unexpected ways, take caution, it could inadvertently hit something or trip...
- Page 13 M+D Crutch™. 5. How do i clean my M+D Crutch™? Use water and a paper towel or rag for cleaning. Caution: Using unlocked cradle with hands free...
- Page 14 M+D Crutch™ Warranty Manufacturer info: The M+D Limited Warranty covers your M+D Crutch™ and M+D branded accessories against manufacturing defects Mobility Designed, Inc. for one year from the date you received your product. Our warranty is in addition to rights provided by consumer law.
