Summary of Contents for Urbaco Luxor CC6U200PR
- Page 1 Luxor Luxor Technical Centre Technical Centre Installation, Use & Maintenance Installation, Use & Maintenance English...
-
Page 2: Table Of Contents
Contents Contents 1- Legend of symbols............................Pag.3 2-Conditions of use..............................Pag.3 2.1-Intended use............................Pag.3 2.2-Limits to use.............................Pag.3 3-Reference Standards............................Pag.3 4-Descriptions............................Pag.3 4.1-Technical centre - technical features.....................Pag.3 4.2-Technical centre: components and dimensions ................Pag.4 4.3-(Technical centre) Pneumatic performances.................Pag.5 5-Control panel..............................Pag.6 5.1-Summary table of accessories’ power demands................Pag.7 5.2-Electrical connections........................Pag.8 5.3-Release/discharge the system from/inside the centre..............Pag.8 6-Technical centre installation...........................Pag.10... -
Page 3: 1- Legend Of Symbols
The use of this product for purposes other than those described above and installation executed in a manner other than as in- structed in this technical manual are prohibited. Urbaco has no responsibility for any improper use of the system 2.2 Limits to use Do not allow children to play or loiter within the movement area of the bollard. -
Page 4: Technical Centre: Components And Dimensions
4.2 (Technical centre) Description: Components and dimensions Compressor group/unit Control panel Magnetic loops (optional) Hot/Cold thermostats (optional) Cooling fans (optional) Heating unit (optional) Automatic purge (optional with timer) Floor mounting basement (optional) Air joints for bollards (Ø 10) Air circuit discharge Pressure regulator (manometer) -
Page 5: Technical Centre) Pneumatic Performances
4.3 (Technical centre) Pneumatic performances The following performances have been recorded with a 50 m long conduit of 10 mm diameter Max no. of Luxor bollards operated simultaneously by a single technical centre Max no. Ø 200 Ø 270 Ø 320 of bollards h 600 h 800... - Page 6 5 Card 5 Card Trimmer for the automatic closing time adjustment 1 2 3 4 Fuses 1 2 3 4 Buttons for radio programming Compressor 1 2 3 4 Connector for radio cards Table of fuses Additional control boards for Fuse for accessories managing up to 3 access ways Fuse for main line...
-
Page 7: Control Panel
5.1 Summary table of 24 V accessories’ power demand, expressed in W U200 control panel to control 1 access way Max no. of Single Total power (W), if connectable Total power (W), if with Type of accessory accessory with monostable accessories and bistable solenoid valve power (W) -
Page 8: Electrical Connections
5.2 Electrical connections Compressor Line voltage 230V - 50/60Hz Compressor Magnetic sensor/photocells max power supply (see tab. in chap. 5.1) Flashing light output voltage 24V 25W Red traffic light and illuminated ring (see tab. in chap. 5.1) Yellow traffic light (see tab. in chap. 5.1) Solenoid valve for the upward movement max voltage 24V AC (see tab. -
Page 9: Release/Discharge The System From/Inside The Centre
Closing button N.C. STOP button Step by step Endstop - opening Endstop - closing SMA N.C. contact Compressor surveillance 5.3 Release/discharge the system from/inside the centre To discharge air from the system and consequently move down the bollards, you can open the tap nearby the pressure switch (we recommend you to do it when the compressor is shut down, in order to avoid that it starts automatically to compensate the pres- sure fall).To put the system into operation again, close the air discharge as shown in fig. -
Page 10: 6-Technical Centre Installation
6 Technical centre installation 6 Technical centre installation 6.1 Preliminary checks -Check that no conduits or other obstacles shall prevent from excavating and installating operations. -Check the soil consistence and its loading capacity. -On the power supply line provide an omnipolar disconnecting device with an opening distance between contacts equal to or larger than 3 mm. - Page 11 6.2 Technical centre fastening with reinforcement (optional – COREH02-LUX code) Dimensions and holes spans Provided with: • M8 cage nuts – 4 pieces • washers – 4 pieces D8x24 • securing screws – 4 pieces M8x16 UNI 5739 • securing screws for inspection flange 4 square holes for the M8 locked nuts...
- Page 12 7 Connection of additional devices 7 Connection of additional devices 7.1 Cooling fans (optional – COVF-LUX code) 1) Take off the grids that shall support the fans. 2) On the grids mount the motors (please check to put one for intake and another in discharge), by using the supplied cables.
- Page 13 7.3 Assembling the timed condensate drain (optional code COPURA-LUX) The timed condensate drain must be secured to the compressor support base using the threaded holes provided. Disconnect mains power. Disconnect the cable between the pressure switch and the motor and insert the timed drain cable. Pass the standard drain pipe behind the compressor and cut to size to connect it at the condensate drain inlet.
-
Page 14: Cooling Fans (Optional)
8 Safety instructions Important safety instructions This product must only be employed for its originally intended use. Any other use is wrong and potentially dangerous. The manufacturer cannot be held liable for any damages resulting from wrongful, erroneous or negligent uses. Avoid working close to the hinges or other moving mechanical parts. - Page 15 9.3 Records of intervention Check point Check and maintenance Other actions Cover fastening ________________________________________ ________________________________________ Slide ring ____________________________________________________________________ Endstop sensors ____________________________________________________________________ Solenoid valve ____________________________________________________________________ No air leak ____________________________________________________________________ Air discharge efficiency ____________________________________________________________________ Cover positioning ____________________________________________________________________ ____________________________________________________________________ Illuminated ring ____________________________________________________________________ Magnetic loops Installer stamp Date of intervention Operator’s full name...
- Page 16 Check point Check and maintenance Other actions Cover fastening ________________________________________ ________________________________________ Slide ring ____________________________________________________________________ Endstop sensors ____________________________________________________________________ Solenoid valve ____________________________________________________________________ No air leak ____________________________________________________________________ Air discharge efficiency ____________________________________________________________________ Cover positioning ____________________________________________________________________ ____________________________________________________________________ Illuminated ring ____________________________________________________________________ Magnetic loops Installer stamp Date of intervention Operator’s full name Technician signature Client signature...
-
Page 17: 10-Phasing Out And Disposal
10 Phasing out and disposal We kindly ask you to also safeguard the envirnoment, because we at URBACO considere it to be one of the fundamental elements of development of its market and operational strategies. You can do this by simply following simple disposing... - Page 18 URBACO SA ZA du Couquiou 84320 ENTRAIGUES -FRANCE www.urbaco.com...
