- Page 1 Quick Start Guide: DataBand ISU...
-
Page 2: Trademarks
No part of this work may be reproduced or used in any form or by any means (graphic, electronic or mechanical) without written permission from Net2Edge. The information contained herein is confidential property of Net2Edge Limited. The use, copying, transfer or disclosure of such information is prohibited except by express written agreement with Net2Edge Limited. -
Page 3: Table Of Contents
Making Connections .................... 6 Installing DbManager ................... 7 Initial Configuration / Setup .............. 8 Connecting to DataBand ISU ................8 Notes on configuring DataBand ISU ..............9 Device Settings ....................10 PRI Ports ......................10 ISDN Numbers ....................10 BRI Ports ......................11 Imux Ports ...................... -
Page 4: Introduction
QSG | Quick Start Guide: DB-ISU Introduction This document is a basic guide for configuring a new Net2Edge DataBand ISU. A full User Manual for configuring all settings on the unit is supplied on the DbManager Installation Disk. Applications Net2Edge DataBand CSI and ISU devices are central-site and remote-site ISDN inverse multiplexers, I-MUXes, Terminal Adaptors or ISDN aggregators. -
Page 5: Getting Started
Remove the four short screws near the front or rear panel on the left and right hand sides of the DataBand ISU. The unit can be mounted with the front panel facing forward or with the ports facing forward as required. -
Page 6: Standard Accessories
Enables the DataBand ISU to be mounted in a standard 19" rack 3.4 Making Connections First, connect the ISDN cables to DataBand ISU followed by the Terminal Port management cable (if required). If the unit has a DC power supply connection, use the screw terminals to connect the DC power source. -
Page 7: Installing Dbmanager
3.5 Installing DbManager DbManager is required in order to monitor and manage the DataBand ISU. Management can be made using the Terminal (serial) port, or using TCP/IP over a LAN or WAN. DbManager is installed using the CD provided with product or can be downloaded from the Net2Edge Website: www.net2edge.com... -
Page 8: Initial Configuration / Setup
QSG | Quick Start Guide: DB-ISU Initial Configuration / Setup Follow these steps to connect to DataBand ISU with DbManager and configure the unit for use. Configuration of DataBand ISU is carried out by setting up DbManager to make a... -
Page 9: Notes On Configuring Databand Isu
Once connected to a unit, an existing configuration file can be loaded to the device. Go to File Open File and navigate to the saved file. Click Open. Now the file must be uploaded to DataBand ISU: Go to File Upload and wait until the progress bar completes. -
Page 10: Device Settings
The ISDN Numbers window can be used to define the Bonding Numbers which DataBand ISU sends back to calling devices in order to set up conferences at speeds of up to 1024kbps. The Bonding Numbers should be the DDI or MSN numbers of the local ISDN line supplied by the carrier. -
Page 11: Bri Ports
(*#+) 4.7 Imux Ports DataBand ISU can be fitted with single or dual Imux Ports. Each Imux port can have numbers and ISDN ports assigned to it, so that incoming conferences are directed to specific ports as they arrive. Click on an Imux Port to access the configuration options. -
Page 12: Front Panel
Phone Book option. 4.8 Front Panel The front panel of DataBand ISU can be used to initiate a conference with a remote site whose number and data rate settings have been pre-configured in the Phone Book, or to instantly start a conference with another site using a new number and target data rate. -
Page 13: Additional Resources
QSG | Quick Start Guide: DB-ISU 4.10 Additional Resources All Net2Edge products and the DbManager application have their own User Manuals which can be found in the 'Documents & Manuals' folder on the DbManager installation disk or by registering at the Net2Edge website: www.net2edge.com... -
Page 14: Contacts
QSG | Quick Start Guide: DB-ISU Contacts Corporate Headquarters Net2Edge Limited Kulite House BASINGSTOKE Hampshire RG24 8UG United Kingdom Tel: +44 345 013 0030 Support: support@net2edge.com Sales: sales@net2edge.com General: info@net2edge.com.com www.net2edge.com www.net2edge.com...
