Stand 06/2014
a brand of Hugo Lahme GmbH
POWER LED 2.0
15
VitaLight
®
15 POWER LED 2.0
underwater floodlight
VitaLight
®
15 POWER LED 2.0
projecteur de piscine
1
a brand of Hugo Lahme GmbH
Diese Anleitung ist sorgfältig
zu lesen und aufzubewahren.
This manual is to be read
carefully and archived.
Cet instruction doit être
exactement lu et archivé.
User manual
Instruction
Art.-Nr.: 578163
Art.-Nr.: 578163
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VitaLight 15 Power LED 2.0
Summary of Contents for VitaLight 15 Power LED 2.0
-
Page 1: User Manual
This manual is to be read carefully and archived. Cet instruction doit être exactement lu et archivé. POWER LED 2.0 User manual VitaLight ® 15 POWER LED 2.0 underwater floodlight Instruction VitaLight ® 15 POWER LED 2.0 projecteur de piscine Stand 06/2014 Art.-Nr.: 578163... - Page 2 Underwater floodlight made of high quality corrosion resistant gun metal or bronze and stainless steel, security glass with stepped edge 10 mm and 5 m VitaLight® special underwater cable 2 x 1.5 mm². Safety class III IP 68. Le projecteur de piscine est en bronze et inox de haute qualité résistant à la corrosion, verre de sécurité épaulé 10 mm et 5 m de câble subaquatique spécial VitaLight®...
- Page 3 a brand of Hugo Lahme GmbH VDE 0100 702! Installation instruction Put the underwater floodlight on the pool border. Pull the cable through the cable gland of the built-in-niche into the junction box. Then fix the cable gland in the built-in niche carefully. Leave about 1 m of the connection cable rolled inside the built-in niche.
- Page 4 / Neutral / Neutre PE = / Grounding / Terre Table page 5 Tableau page 5 15er / 15 POWER LED 2.0 24 x 3 Watt Monochrom / Cable configuration / Branchement des câbles 24V DC + / Brown / Brun...
- Page 5 a brand of Hugo Lahme GmbH ATTENTION: For underwater floodlights with 5 cable pre-assembled IP 65. Cable length / cable cross section You get the underwater floodlight ex works with a cable length of 5 m. If a cable needs to be extended, it will be selected according to the length required from the junction box to the supply unit.
- Page 6 a brand of Hugo Lahme GmbH / Maintenance instruction / Guide de soins Use only solvent- and acid-free cleaners for cleaning of the visible parts. Please do not use a high pressure cleaner. Effectuer le nettoyage des pièces visibles à l’aide de produits ne contenant pas de solvant. Ne pas utiliser des appareils à haute pression.
- Page 7 Power supply unit 100-240V AC / 24V DC, 200 W, 50/60Hz, IP 54 40600050 monochrome for 4 underwater floodlights 15 POWER LED 2.0 Appareil d'alimentation 100-240V AC / 24V DC, 200 W, 50/60Hz, IP 54 pour 4 monochrome projecteurs 15 POWER LED 2.0 100-240V AC / 24V DC, 200 W, 50/60Hz, IP 54 POWER LED 2.0...
- Page 8 a brand of Hugo Lahme GmbH brands of Hugo Lahme GmbH ALLPOOLS 121500, , 60- ”, “ .: +7 (495) 787 01 07, +7 (495) 787 01 08, 295053, . .: +380 95 719 47 47 info@allpools.ru, allpools.ru Hugo Lahme Perfektion in jedem Element.
