BEFORE UNPACKING

READ THIS GUIDE!

This Quick Start Guide will show you how to safely

and properly install, test and register the

SCAN~LINK Armour System™

SLAU-UV-NB-XXX-XX-04

SLAU-UV-NB-XXX-XX-04 KIT

This guide contains directions on the legally mandated

requirements for a proper installation.

Improper installation and/or modifications to the device not expressly

approved by SCAN~LINK Technologies Inc. may expose the operator to

harmful radiation and may void the user's authority to operate the

equipment.

The SCAN~LINK Armour System™ is to be used only as a tool to assist a

vehicle operator and does not replace any safety procedures in place, nor

does it remove any responsibility for the safe operation of the vehicle from

the driver.

CAUTION:

Changes or modifications not expressly approved by SCAN~LINK

Technologies Inc. could void the user's authority to operate the equipment.

The SCAN~LINK Armour System™ is intended for use on mobile equipment in

construction and industrial applications. It is not intended for use by the general

public.

ENGLISH

Table of Contents

Need help?

Do you have a question about the ARMOUR SLAU-UV-NB Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SCAN-LINK ARMOUR SLAU-UV-NB Series

Page 1 BEFORE UNPACKING READ THIS GUIDE! This Quick Start Guide will show you how to safely and properly install, test and register the SCAN~LINK Armour System™ SLAU-UV-NB-XXX-XX-04 SLAU-UV-NB-XXX-XX-04 KIT This guide contains directions on the legally mandated requirements for a proper installation. Improper installation and/or modifications to the device not expressly approved by SCAN~LINK Technologies Inc.
Page 2 DISCLAIMER The SCAN~LINK Armour System™ is not ‘safety rated’ and thus cannot be relied on as front-line defense against equipment-to- pedestrian or equipment-to-object strikes. It is intended as a supplementary safety system only, to improve operator and pedestrian awareness and to help ‘fill in’ blind spots. There is no replacement for proper training and operation of equipment.
Page 3 CONTENTS/ REQUIREMENTS STEP ONE: MOUNT PAGE 7 STEP TWO: WIRE PAGE 10 STEP THREE: TEST PAGE 13 STEP FOUR: REGISTER PAGE 15 SPECIFICATIONS PAGE 16 HOOK-UP DIAGRAMS PAGE 18 LIMITED WARRANTY PAGE 20 Armour System Quick Start Guide 1_4...
Page 4: Agency Certifications
AGENCY CERTIFICATIONS This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 5 20cm (8 inches) from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. For further information on RF exposure and compliance, please visit the following links: https://support.scan-link.com https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm https://sms-sgs.ic.gc.ca/search/radioEquipmentPortal Armour System Quick Start Guide 1_4...
Page 6: Package Contents
PACKAGE CONTENTS: SLAU-UV-NB-XXX-XX-04 DISPLAY UNIT POWER HARNESS ANTENNA UNIT Additions included in SLAU-UV-NB-XX-XX-04-KIT EXTERNAL ALARM MOUNTING BRACKET SERIAL NUMBERS (MACs) Write these down now before installing: Antenna 00 : 1C : 2C : XX : XX : XX : XX : XX Display 00 : 1C : 2C : XX : XX : XX : XX : XX...
Page 7: Antenna Mounting
MOUNTING Antenna Mounting The ideal mounting height for the Armour Antenna is between 5 and 6 feet (150-180cm), but can be installed up to a maximum of 15 feet (4.5 meters) above grade. Installing above this level will negatively affect the range of detection. Choose a mounting location on your machine with 15”...
Page 8: Display Mounting
The Antenna must have a clear view of the ground and be free of obstructions to all sides! With the fasteners of your choice, securely attach the mounting bracket face to your machine in the chosen area, with the pivot bolts on the bottom. The holes in the mounting bracket are 1/4”...
Page 9 OPTION: Exterior Alarm - Mount and Connect The SCAN~LINK Armour™ package may have come with an external alarm so workers outside the cab know when they are in proximity to a piece of active equipment. The alarm can be mounted in the Antenna Mounting Bracket. The bracket has mounting holes on either side for the alarm.
Page 10: Display Wiring
WIRING Display Wiring While still in the cab, route and connect the wire leads to the appropriate terminals. These wires may be extended with 18AWG (1.02mm) or larger wire: Red Wire Always VCC (+12-28VDC ) Power Supply Black Wire Always VDD (-) Equipment Ground Power Supply Orange Wire...
Page 11: Antenna Wiring
It is advised to power the in-cab display from a fused circuit (a 1A fuse is sufficient) to avoid a short circuit if for whatever reason the wire is pinched. Antenna Wiring Your Armour unit may have come with several cables. For now, we are only interested in one of them: the Power Harness.
Page 12 will be active at all times, regardless of whether the vehicle is in reverse or not! Route the wire, being careful to avoid pinch points, and connect to a fused 12-24V power source. The Antenna is fused internally, however, this will not protect the wire or vehicle if the wire were to short against the frame of the vehicle, and so fusing at 1A is strongly recommended.
Page 13 TESTING Side View Top View 20' (6m) Range Procedure Turn the vehicle on to ignition power (you don't need to start the engine unless it's required to put the vehicle in reverse). If you have the ORANGE wire of the antenna connected to a Reverse Signal, you'll need to put the vehicle in reverse.
Page 14 light up one to four and back down to one. The more lights lit, the louder the volume. When you step back outside of the detection area, the alarm(s) will remain activated for an additional three seconds. Test one more time. If you have to stand closer than 16.4 feet (5 meters) to the vehicle, it's possible that you need to adjust your aim either up or down.
Page 15 It only takes a couple of minutes, and is done online. Head over to http://www.scan-link.com, and under the 'Resources' menu, click 'Warranty Registration'. Use the following credentials:...
Page 16: Specifications
902.3 – 927.7 MHz North American unlicensed band Frequency Wireless Link 2.405 – 2.475 GHz North American unlicensed band Frequency Industry Canada Registered under SCAN-LINK 9283A-SLAU270NB Technologies Inc. Registered under SCAN-LINK FCC ID YUU-SLAU270NB Technologies Inc. Registered under Skyetek/Synapse IFT ID 201801C03800 Wireless Inc.
Page 17 IFT ID 201801A01279 Inc. Audible 99dB(A) Max @ 20cm (8 inches) typical Warning 88dB(A) Min @ 20cm (8 inches) typical Intensity Ingress Indoor use only Protection RoHS Compliant Yes For other specifications, please e-mail support@scan-link.com. Armour System Quick Start Guide 1_4...
Page 18 Armour System Quick Start Guide 1_4...
Page 19 Armour System Quick Start Guide 1_4...
Page 20: Limited Warranty
LIMITED WARRANTY Manufacturer Limited Warranty and Limitation of Liability Warranty Coverage SCAN~LINK Technologies Inc. (“SCAN~LINK”) warrants to the original end-user purchaser (“Purchaser”) of this SCAN~LINK device (“Device”) that the Device will be free from defects in materials and workmanship and will operate without mechanical failures under normal use, as defined in this Limited Warranty, for a period that commences on the date that the Device was delivered to the vendor who sold the Device (“Dealer”) or delivered to the...
Page 21 10. After receiving the Device, if SCAN~LINK determines that the Device is defective and covered under this Limited Warranty, SCAN~LINK may at its absolute and sole discretion: Repair the defective portion of the Device without charge to the Purchaser with new or reconditioned parts; Replace the defective Device without charge to the Purchaser with a comparable new or refurbished device;...
Page 22 Limited Warranty will not be affected. This document is copyright SCAN~LINK Technologies Inc., 2016. Current as of September, 2018. SCAN~LINK may have updated documentation which can be located on our website, www.scan-link.com. Armour System Quick Start Guide 1_4...
