EMG TB-HZ Installation Information

INSTALLATION INFORMATION
EMG MODELS: TB-HZ PICKUP
SPECIFICATIONS:
Logo Color
Magnet Type *
Inductance (Henries) (1)
DC Resistrance (kOhm)
Resonant Frequency (KHz) (2)
Resonant Frequency (KHz) (3)
Impedance at Resonance (kOhm) (2)
*Note: Magnet Type: A (Alnico) A/S (Alnico/Steel)
(1) Wired in Series
(2) Loaded with 500K Volume and Tone with a 20' (6M) Cable
(3) Loaded with 1 MegOhm / 47pf
Included with THE PICKUP:
1 VOLUME CONTROL (250K)
.235
SOLID
.390
(10)
MONO OUTPUT
JACK
BRIDGE GROUND
CONNECTOR
Installation notes:
The connector system allows an easy method of interchanging pickups. The SRO 5-Wire Cable and wire legend are compatible with all other
EMG-HZ Pickups, so any EMG-HZ Passive Pickup can be installed with any other EMG-HZ Pickup. The 5-Wire cable allows Series/Parallel switching
or simple single/dual-coil combinations can be used. For more information go to http://www.emgpickups.com.
SPECIAL NOTE: The Red Wire of the HZ Pickup is NOT for battery power, it is a coil wire.
Warranty
All EMG Pickups and accessories are warranted for a period of two years. This warranty does not cover failure due to improper installation, abuse or damage. If
upon examination the pickup is determined to be defective, a replacement will be made. Warranty replacement products are covered by this same warranty. This
warranty covers only those pickups and accessories sold by authorized EMG Dealers. This warranty is not transferable.
© 2014 Copyright EMG INC. All Rights Reserved.
MODEL:
TB-HZ
Silver
A/S
2.65
8.0
2.85
4.90
47.50
1 TONE CONTROL (250K)
(6) SOLID
ADJUSTMENT SCREWS (8)
MAXIMUM RECOMMENDED STRING WIDTH 2.50"
3.712
(94.28)
2.900
(73.65)
1.650
(41.91)
3.250
(82.55)
.125"(3.17) DIA. MOUNTING HOLES
EMG-HZ WIRING
COIL 1
+
BLACK
COIL 2
+
WHITE
12345
Pin 1 Green (GRN)
Pin 2 White (WHT)
Pin 3 Braid (GND)
Pin 4 Red (RED)
Pin 5 Black (BLK)
PICKUP CABLE 15" (38cm)
2 CONNECT CABLES 5.5" (14cm)
OUTPUT CABLE 6" (15cm)
BRIDGE GROUND WIRE 6" (15cm)
R .375 TYP
(9.52)
.90
(22.85)
_
RED
_
GREEN
