Summary of Contents for GEZE SECULOGIC T 320 Series
- Page 1 GEZE EN Installation And Commissioning Instructions With Connection Diagram SECULOGIC T 320 Emergency Exit System Terminal...
-
Page 2: Table Of Contents
SECULOGIC T 320 Content In this document ..............................3 Product description ......................................3 Other documents ......................................3 Symbols and signs ......................................3 Safety and liability ..............................4 Basic safety instructions .....................................4 Product liability ......................................4 Installation and assembly ...........................5 Requirements ........................................5 Install the terminal ......................................5 Commissioning ..............................5 Requirement ........................................5 Service mode ........................................5 Settings ..........................................6... -
Page 3: In This Document
This instruction describes the installation, commissioning and connection of the GEZE Terminal T 320. Product description The GEZE terminal is part of the SecuLogic escape route system and secures and monitors electrically locked doors in bidirectional emergency routes. Doors along emergency routes are reliably safeguarded against unauthorised access in both emergency directions by the GEZE door control unit with Terminal T 320. -
Page 4: Safety And Liability
The GEZE door control unit is designed to control and monitor electrically locked emergency routes. External products may only be integrated after consulting GEZE. Contrary to intended use The connection of products which were not expressly approved for use by GEZE is contrary to the intended purpose. 2.2 Product liability à... -
Page 5: Installation And Assembly
Installation and assembly Installation and assembly WARNING! Danger of electric shock. Installation may only be carried out by an expert authorised by GEZE. Check that the cables are disconnected before installation. Requirements à Cable routing is in accordance with GEZE cable diagram à... -
Page 6: Settings
Commissioning SECULOGIC T 320 4.2.3 Connect the service terminal ST 220 with the door control unit The service terminal is connected with the door control unit via an infrared interface. Service terminal ST 220 Infrared interface to TZ 320 ESC button Before covering the control unit, hold the service terminal and press the ON button for approximately one second. -
Page 7: Description Of Basic Functions
SECULOGIC T 320 Commissioning 4.5 Description of basic functions 4.5. 1 Short-term unlock Short -term unlock is the authorised, time-limited release of the emergency route locking device. During the short -term unlock time the door can be passed through without triggering an alarm. It is triggered via the inter- nal key-operated push button or an external control device connected to the 'short-term unlock' input. -
Page 8: Operation
Operation SECULOGIC T 320 Operation 'Locking' LED 'Door state' LED 'Alarm' LED Emergency button Display Colour Meaning Locked Red flashing (every second) Sluice allocated Red flashing (every 2 seconds) Locked via burglar alarm system Red flashing (3 seconds on, 1 second off) Locked level Green Unlocked Green flashing (every second) Short-term unlock... -
Page 9: Open The Doors And Trigger The Alarm In An Emergency
SECULOGIC T 320 Operation 5.2 Open the doors and trigger the alarm in an emergency By actuating the emergency button, the interlocking elements on the corresponding door are switched off (indirect release via TZ 320). Press emergency button. à LED 1 lights up green and LED 3 lights up yellow. The door is unlocked. à... -
Page 10: Read Out Fault Report (Via Tz 320)
T 320 / TZ 320, all LEDs and the emergency button lighting go out All LEDs are off despite F1 locking device of the TZ 320 is defective Change the F1 fuse power supply (GEZE Id-No. 138362, VE 10) -
Page 11: Connection Diagram
24 V DC supply unit Indirect release + 24 V DC Indirect release - GND R5485-B, communication with door control unit TZ 320 R5485-A, communication with door control unit TZ 320 X103 Ribbon cable plug connector for GEZE key-operated push button... -
Page 12: Terminal T 320
The mains fuse is implemented on-site. GEZE power supply unit with TZ 320N UP = NET220. 500 mA max. 350 mA for periphery GEZE power supply unit with TZ 320N AP = NT19.2-24. 750 mA max. 650 mA for periphery Spatially separate the primary and secondary sides. -
Page 13: Connection Of External Key-Operated Push Button To T 320
SECULOGIC T 320 Connection diagram Simplified diagram of connection between the TZ 320 and T 320 Sequence of terminals modified T 320 Door terminal TZ 320 Door control unit X104 (red terminal strip) X107 (green terminal strip) GND supply 24 V DC 24 V DC supply Indirect release Indirect release +... -
Page 14: Technical Data
Technical Data SECULOGIC T 320 Technical Data Terminal T 320 UP Terminal T 320 UP Function Monitoring and control of a door in bidirectional emergency routes (with a door control unit TZ 320) Dimensions 55 x 55 x 37 mm (W x H x D) W x H: Helmet T: Distance of top edge of bearing ring to rear edge of terminal Installation... -
Page 15: Terminal T 320 Ap
SECULOGIC T 320 Technical Data Terminal T 320 AP Terminal T 320 AP Variants T 320 green T 320 white-aluminium Function Monitoring and control of a door in bidirectional emergency routes (with a door control unit TZ 320) Dimensions 77 x 197 x 88 mm (W x H x D) Installation Wall mounting Operating voltage... - Page 16 GEZE India Private Ltd. 2630 Taastrup Niederlassung West China MF2 & 3, Guindy Industrial Estate Tel. +45(0)46-323324 Nordsternstraße 65 GEZE Industries (Tianjin) Co., Ltd. Ekkattuthangal Fax +45(0)46-323326 45329 Essen Shuangchenzhong Road Chennai - 600 097 E-Mail: danmark.se@geze.com Tel. +49 (0) 201-83082-0...
