Please read all instructions carefully before assembly, installation and/or use of this product.

Use for Parts: #59114 Rola™ 2-Bike Rack System

#59115 Rola™ 1-Bike Add-On

TOOLS REQUIRED

10mm or 13/32" Socket & Wrench

#59114 Rola™ 2-Bike Rack Carrier (Shown Assembled)

Tray Attachment Hardware:

(3) Plastic Hand Knob

(1) Plastic Hand Knob - Locking

(4) 5/16-18 Carriage Bolts

PART

59115

Cequent Consumer Products Inc

Solon, OH 44139 USA

Cequent Help Hotline: 1-800-234-6992

Product Name:

(A)

DESCRIPTION

Bottom Support Bracket

Bike Rack Kit

Adventure System Bike Rack

Product Code:

(C)

(B)

www.rolaproducts.com

Page 1

59114 & 59115

QTY.

59114N

3-24-05 Rev_A

Table of Contents

Need help?

Do you have a question about the 59114 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rola 59114

Page 1 Product Name: Product Code: 59114 & 59115 Please read all instructions carefully before assembly, installation and/or use of this product. Use for Parts: #59114 Rola™ 2-Bike Rack System #59115 Rola™ 1-Bike Add-On TOOLS REQUIRED 10mm or 13/32” Socket & Wrench #59114 Rola™...
Page 2 Flat Washer Plastic Hand Knob Bracket Hex Nut Tie Down Strap 59114 contains two (2) complete Bike Rack Kits 59115 contains one (1) complete Bike Rack Kit *59115 Installation Instructions start at STEP 4. www.rolaproducts.com Page 2 Cequent Consumer Products Inc...
Page 3 Adventure System Bike Rack Product Name: Product Code: 59114 & 59115 Please read all instructions carefully before assembly, installation and/or use of this product. • Place the Main Support Brackets on top of Cargo Tray with the mounting holes toward the center of the tray.
Page 4 Adventure System Bike Rack Product Name: Product Code: 59114 & 59115 Please read all instructions carefully before assembly, installation and/or use of this product. • Assemble the Bike Wheel Troughs together using (2) hex bolts, (2) flat washers, and (2) hex nuts. LEAVE LOOSE AT THIS STEP.
Page 5 Adventure System Bike Rack Product Name: Product Code: 59114 & 59115 Please read all instructions carefully before assembly, installation and/or use of this product. Grabber Plastic Protector Cushions • Place Plastic Protector Cushions into each side of Grabber and make sure cushion is fully seated.
Page 6 Adventure System Bike Rack Product Name: Product Code: 59114 & 59115 Please read all instructions carefully before assembly, installation and/or use of this product. Support Bracket Tube C-shaped Bracket Flat washer Hex nut U-bolt Plastic Hand Knob • Install U-bolt downward through Wheel Trough around the Support Bracket Tube. Place C-shaped Bracket onto U-bolt, legs facing down.
Page 7 Adventure System Bike Rack Product Name: Product Code: 59114 & 59115 Please read all instructions carefully before assembly, installation and/or use of this product. Vehicle Side Locking Knobs to the outside For (1) Bike Carrier Locate Wheel Trough Toward vehicle •...
Page 8 • Check load at stops during trip to ensure tightness and security. • This rack is designed for typical use and applications (on paved or smooth gravel roads). Do not use this ROLA™ Bike Rack on a vehicle that will be driven on rough roads or where the rack (and bikes) will be subjected to significant or constant jarring and/or shock.
