Dishwasher
Installation Instructions
(To be used in conjunction with User Instructions)
l Please read these Installation Instructions to ensure safe,
correct fitting of this appliance.
l T he dishwasher should be fitted by a suitably competent,
qualified person.
l P lease keep these instructions in a safe place for future reference.
l D anger of suffocation keep packaging material away from children.
Throughout this manual the
following symbols are used.
Warning for hazardous
situations with regard to
life and property.
Warning for
electric shock.
Warning for
risk of fire.
LAM8606
Advertisement
Table of Contents
Related Manuals for Howdens Lamona LAM8606
Summary of Contents for Howdens Lamona LAM8606
-
Page 1: Installation Instructions
LAM8606 Dishwasher Installation Instructions (To be used in conjunction with User Instructions) l Please read these Installation Instructions to ensure safe, correct fitting of this appliance. l T he dishwasher should be fitted by a suitably competent, qualified person. l P lease keep these instructions in a safe place for future reference. l D anger of suffocation keep packaging material away from children. Throughout this manual the following symbols are used. Warning for hazardous situations with regard to life and property. Warning for electric shock. -
Page 2: Table Of Contents
2. Dishwasher connections........p.4 9. Standard decor door preparation ......p.9 3. Fit feet and raise 10mm below 10. Decor drawer frontals preparation ....p.9 worktop height .............p.6 11. Fit decor door / decor drawer frontals ....p.10 4. Locate securing brackets ........p.6 12. Final adjustment and secure dishwasher ..p.11 5. Protection strip for timber worktops ....p.7 13. Fit plinth ..............p.12 6. Positioning the dishwasher .........p.7 14. Connect water/plumbing/electric ......p.12 7. Adjust feet and raise dishwasher to underside of worktop (level) .......p.8 www.howdens.com... -
Page 3: Tools Required
Tools required DO NOT use high speed impact 24mm open power tools. ended spanner T20, flat and cross head screw drivers Parts supplied +50mm A (3.5x14) B (4x43mm) C (4x36mm) www.howdens.com Copyright © 2018 Howden Joinery Ltd. All rights reserved. -
Page 4: Dimensions
1 - Dimensions Position the dishwasher relative to service connections. 820-920mm 550mm 598mm 570mm 600mm (+1) 818mm (+100) Ensure the floor is level and strong enough to support a fully loaded dishwasher. 15mm 2 - Dishwasher connections max. 1000mm 100mm 1000mm 500mm 500mm 300mm 300mm All dimensions are to the floor. DO NOT insert the hose too deep into the waste pipe, (Maximum hose length, 3.5 metres). www.howdens.com... - Page 5 (Always use the new hose supplied with the dish er). Cold water supply 10-80 lpm. Ensure water is turned on and WARNING! This appliance WARNING! Do not use extension the isolator valve is accessible must be earthed. cables / adapters. (Socket must be accessible after fitting. Hose connection - 3/4”. after fitting). Cold water pressure - 0.1 – 1Mpa (0.3 - 1.0 Bar) Incorrect waste pipe configuration. Correct waste pipe configuration. www.howdens.com...
-
Page 6: Fit Feet And Raise 10Mm Below Worktop Height
For standard installation extension feet need to be fitted. 10-15mm Do not position Foot, max in cabinet run at 50mm this stage. Plus foot addition +50mm Front feet Rear feet DO NOT use high speed impact power tools. DO NOT damage the Flat head plastic screw heads. screw driver 4 - Locate securing brackets Insert brackets and fold. www.howdens.com... -
Page 7: Protection Strip For Timber Worktops
5 - Protection strip for timber worktops to avoid condensation damage NOTE: This strip must be fitted to timber worktops to avoid damage. Ensure protection strip is set to edge of square edged worktops. Ensure a clean and dust free surface. Cut to fit. 6 - Positioning the dishwasher NOTE: If necessary loosen and rotate the water hose towards the water supply and re-tighten. Always use the new NOTE: Ensure hoses are not kinked or trapped hose supplied with the behind the dishwasher. dishwasher. www.howdens.com... -
Page 8: Adjust Feet And Raise Dishwasher To Underside Of Worktop (Level)
7 - Adjust feet and raise dishwasher to underside of worktop (level). LEVEL Front feet Rear feet DO NOT use high speed impact power tools. DO NOT damage the plastic screw heads. Flat head screw driver 8 - Remove ‘H’ frame Unscrew the two screws and remove the plastic ‘H’ bracket. Retain the screws for stage 9/10. Cross head A (3.5x14) x2 www.howdens.com... -
Page 9: Standard Decor Door Preparation
Centre line Fit handle (if applicable) at this A (3.5x14) x4 stage and COUNTER-BORE SCREWS. 10 - Decor drawer frontals preparation 517mm 130mm 267mm 60mm 267mm 130mm 267mm Secure with the screws retained from stage 8 2 x 356mm drawer fronts = 712mm Centre plus two additional screws Normal door height = 716mm from the accessory bag. Therefore space between drawer fronts = 3-4mm Remove centre rail. A (3.5x14) x4 www.howdens.com... -
Page 10: Fit Decor Door / Decor Drawer Frontals
Fixing for standard decor door. Remove the existing fixings and using the 43mm screws supplied, secure at positions 2 and 5. Ensure correct alignment with the top of the door, (2mm overlap at top). Fixing for decor drawer frontals. Remove the existing fixings and using the 43mm screws supplied, secure at positions 2, 3 and 5. Ensure correct alignment with the top of the door, (2mm overlap at top). DO NOT fully tighten the screws. If necessary make final alignment and fully tighten the screws. Make sure screws are fastened flush but DO NOT over-tighten. B (4x43mm) x4 (x6) www.howdens.com... -
Page 11: Final Adjustment And Secure Dishwasher
Securing screws A (3.5x14) x4 A (3.5x14) x4 Maximum 600mm (+1) 600mm (+1) 601mm (+<1) Side fixing screws to cabinets. (Do not overtighten - Ensure gap is no larger than 601mm to avoid door sealing and leakage issues). If necessary re-align decor door / decor drawer frontals before finally securing. C (4x36mm) x2 www.howdens.com... -
Page 12: Fit Plinth
13 - Fit plinth Once decor door / decor drawer frontals are fitted correctly, fit the plinth. 14 - Switch on water and electric Cold water supply 10-80 lpm. REMOVE CAP/END Run a programme cycle to confirm successful installation and that there are no leaks. MAKING SPACE MORE VALUABLE Product information correct at the time of publication in June 2018. The company has a policy of continuous product development and reserves the right to change any products and specifications given in this manual. Subject to the Terms and Conditions of Trading, a copy of the Howdens Joinery Terms and Conditions is available upon request. Howden Joinery Ltd, First Floor, 40 Portman Square, London, W1H 6LT. Registered in England 526923 812110AA...
