QuickStart

(More detailed instructions follow):
1. Connect the Antennae to the router finger-tight.
2. Connect your computer's Ethernet port to one of the Router's LAn Ethernet ports with
an Ethernet Cable.
3. Plug the power supply in to the router and plug it into the wall.
4. Start a browser on the computer, go to http://10.0.0.1.
5. Log in with username ayrmesh, Password ayrmesh.
6. Click on Click HERE to set up your router.
7. Follow the directions on the screen to set up your router.
8. After it has rebooted, connect the router to your Internet connection.
9. Make sure your computer can access the Internet.
Quick tour – back of the router:
AnTEnnA COnnECTORS
LAn PORTS (4)
WAn PORT (1)
POWER InPuT
Quick tour – LightS on front of the router:
LAn COnnECTIOnS
WIFI On
WAn COnnECTIOn
POWER
