Summary of Contents for Alfda AEF2000
- Page 1 Dehumidifier AEF2000...
-
Page 2: Table Of Contents
Notes for disposal Dear customer! Thank you very much for purchasing our alfda® Luftentfeuchters AEF2000. Please read the operating instructions carefully before using it for the first time. This manual contains important notes for the ideal use and handling of the device. -
Page 3: Warnings
In case of technical problems, please be sure that the dehumidifier is turned off, take out the power plug and get in contact with the seller of your device or with our alfda- service-hotline. Only turning off the device won´t switch off all consumers. Running the device while there are technical problems can cause a breakdown off the device, electric shocks,fire or similar problems. -
Page 4: Preauction
Thats why persons only should use is it after explicit instrucions and oversight of another person, which is respondable for the safety. This person also should make sure that children are not playing with the device. Preauction The dehumidfier must be used on a flat and stable underground. Only use the device upright (standing), in order to avoid malfunctions or unusual noises After the transport let the device stand up straight for at least 24 hours. - Page 5 Informations about how to deal with refrigerants: Do not damage any components of the refrigerant circuit. Outflowing refrigerant might not be noticed, because its odorless. Devices with flammable refrigerants Please take care of the statutory gas regulations Work on a refrigerant circuit may only be carried out by persons who have a currently valid certificate from an accredited assessment body to ensure safe handling of refrigerants in accordance with an assessment specification recognised throughout the industry.
-
Page 6: Components & Installation Instructions
Components Placement For a efficient use of the dehumidifier take note of the minimum distances like in the picture: IMPORTANT: If reception signals from television sets, radios etc. are disturbed, please ensure a minimum distance of 70 cm between the affected device and the dehumidifier! Seite | 6... -
Page 7: Display-Indication & Control Panel
Display (Touch-Panel) Water tank full: When the water tank is full, the control lamp lights up. Colour-indicator-display: Using a humidity sensor, your dehumidifier measures the relative humidity in the room, shows it on the display and in the form of a three-colour indicator display (see picture): BLUE relativ humidity in the room: 30% - 50% GREEN relativ humidity in the room: 50% - 70%... -
Page 8: Operation & Function
Operations and functions of the dehumidifier: DEHUMIDIFY MODE (choice of different modes) By pressing the button "DEHUMIDIFY MODE" you can select different operating modes according to your needs. The unit starts in automatic dehumidification mode the first time it is switched on. By repeatedly pressing the "MODE"... - Page 9 TIMER (set operating time) - You can activate the timer function in any operating mode by pressing the "TIMER" button. After pressing the "TIMER" key, the display shows "Hr" for hours and "00" for the number of hours. The display "Hr" lights up during the complete timer operation. Before programming, make sure that the timer function is not already activated (the display must not show "Hr").
- Page 10 HUMIDITY SETTINGS You can set the desired humidity in the range of 30% - 80%. Press repeatedly to increase the setting value at 5% intervals. Once the maximum value of 80% has been reached, pressing the key again will restore the minimum value of 30%.
-
Page 11: Insert Additional Fliterfleece (Opt.)
159712 in the online shop of the manufacturer: https://www.allergiker-shop-alfda.de This is a coarse dust filter of filter class G3 with a separation of 80% - 90% for particles >10 µm (e.g. construction site dust). In addition to air cleaning, this fleece also provides additional protection against soiling for your dehumidifier during normal dehumidification operation. -
Page 12: Water Tank / Drainage-Tube
HEPA filter, which filters fine dust and the smallest particles. Water tank / Drainage-tube Your dehumidifier will stop operation if the water tank is full or has not been properly inserted into the appliance. - Page 13 PLEASE NOTE: During the dehumidification process, water collects in the water tank. If the water tank is full, the dehumidifier switches off automatically and a signal tone sounds. This is also indicated by a signal light on the display. In this case, the other symbols (e.g. operating modes) are hidden, as operation can only be resumed after the water tank has been emptied.
-
Page 14: Notes For Use
Note: When using the drainage hose, the water tank must be inserted in the unit. If the permanent drainage by means of a drainage hose is not used, please remove the hose from the condensate drain. The condensation water is then returned to the water tank. Signal tone Each keystroke is confirmed with a signal tone. -
Page 15: Cleaning Of The Dehumidifier
Cleaning the dehumidifier Turn off the power and unplug the unit before start cleaning or other routine maintenance. Cleaning the housing Only wipe the dehumidifier with a dry and soft cloth. To remove heavy dirt, clean the unit with a damp cloth. -
Page 16: Technical Dates
Technical data Model alfda® AEF2000 Recommended room size 20–30 m² Dehumidifaction perfomance 20 Liter / Day 30°C / 80 %) Water tank capacity 5,5 Liter Power supply 220-240 V ~ (50 Hz) Power consumption 420 W Net-weight 14,5 kg dimensions... - Page 17 Is the device installed Only use the device on a flat Loud operating noise during correctly and according to and stable surface. operation the instructions? Problem Points to check Problem solving measure Is the water tank full? Empty the water tank. Operation stops during the Is the room temperature Dehumidification continues...
-
Page 18: Notes
ATTENTION: Refrigerant may only be filled in by the manufacturer!!! Notes ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ Seite | 18... -
Page 19: Warranty Condtions
The following steps are necessary to assert the guarantee: Please contact customer service by e-mail (verkauf@alfda.de) and describe the problem. Please include your name and invoice number on the proof of purchase. If a return is agreed, return the unit securely packaged at your expense to Customer Service. -
Page 20: Notes For Disposal
Hg = Battery contains more than 0.0005 mass percent mercury. Please follow the instructions above. adress: contact: +49 (0) 851 – 85 16 38 -88 alfda Artikel für Allergiker Handels GmbH phone: +49 (0) 851 – 85 16 38 -30 Wörth 19 fax:...
