Summary of Contents for WS 5501 Series
- Page 1 5501 Series If parts are missing or damaged, DO NOT return to the store. For immediate assistance with assembly or to order replacement parts, please call: 1-317-804-9160 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 For Questions or Customer Service Contact Customer Service (317)804-9160 www.wildsports.com Wild Sales LLC Office Chair 1 Year Limited Warranty Wild Sales LLC warrants its products to be free from defects in material and workmanship as described below. Wild Sales LLC will, at its option, repair or replace without charge (excluding freight charges), defective products or parts during the following warranty periods.
-
Page 3: Parts Identification
PARTS IDENTIFICATION CASTERS 5-STAR - x 5 BASE - x 1 TELESCOPING COVER LIFT - x 1 - x 1 SEAT LEFT PLATE - x 1 - x 1 RIGHT SEAT CUSHION - x 1 - x 1 BACK CUSHION - x 1 -20 x 1 ”... - Page 4 Place the 5-star base (B) upside down on a firm surface. Insert one caster (A) into the socket of each of the five points on the base. When inserting the caster into the 5-star base apply a little pressure to the caster to pop it into position. Turn the 5-star base right side up so the casters are on the floor.
- Page 5 Hardware used in Step 2 NOTE: Before attaching, make sure the label marked “FRONT” on the seat cushion (H) and the engraving on the seat plate (E) are facing the same direction. Place the seat (H) on a firm surface with the padded side down exposing the underside of the seat. Align the holes in the seat plate (E) with the threaded inserts in the bottom of the seat (H).
- Page 6 Hardware used in Step 3 Lay the seat cushion (H) upside down on a firm surface. NOTE: for proper assembly of the chair it is important to NOT fully tighten any of the machine screws installed in this step until all machine screws are installed. Align the holes in the support plate attached to the back cushion (I) over the matching threaded inserts in the seat cushion (H).
- Page 7 Hardware used in Step 4 Align the holes in the left arm (F) with the threaded insert in the back cushion (I) and the threaded insert in the seat cushion (H). Insert a ” x 2” machine screw (2) through the arm and into the threaded insert in the back cushion (I). Insert a ”...
- Page 8 CAUTION: Arms and base can be damaged by hitting sharp edges on a desk. STEP 1 STEP 2 STEP 3 Operating Instructions STEP 1: To Adjust Seat Height: While sitting in chair, reach under the right side of the chair to find the flat surface handle. Lift the handle and raise your body off the chair to allow the chair to lift to your desired height.
