Summary of Contents for RRD WH-FLIGHT ALU 85
- Page 1 RRD WH-FLIGHT ALU 85 HYDROFOIL & WINDFOIL BOARD OWNERS’ MANUAL AND ASSEMBLING INSTRUCTION - ENGLISH MANUAL - French, German, Spanish, Italian version online on:...
- Page 2 READ THIS MANUAL CAREFULLY BEFORE USING YOUR ‘’RRD WH-FLIGHT ALU 85 HYDROFOIL” AND KEEP IT STORED FOR FUTURE READING RRD strongly recommends to follow windsurfing lessons in a specialized school before using a hydrofoil for the first time. The use of a hydrofoil involves inherent risks and can cause severe injuries or, sometimes fatal, accidents if misused.
- Page 3 • Rule N°1: YOUR PERSONAL SAFETY It is strongly recommended to practice in the company of other users who could eventually call for assistance or help in case of emergency. You should never ride alone. • Rule N°2: PERSONAL SAFETY EQUIPMENT Helmet: It is strongly recommended to wear a helmet to protect you in case of a fall or any other unexpected situations.
- Page 4 •The warnings and practices set forth above represent some common risks encountered by users. •This list does not purport to cover all instances of risk or danger. Please use common sense and good judgment. •GET TO KNOW THE RRD WIND-HYDROFOIL (WH-FLIGHT HYDROFOIL)
- Page 5 The front and rear wings of the hydrofoil work as lifting devices. The wings create a lifting force from the flow of water that travels across them at speed. This is the reason why they are built with a specific sectional profile: The shape of the wings’...
- Page 6 USING THE RRD WH-FLIGHT HYDROFOIL On shore Handling : The RRD windfoil should always be laid on its side when left on the ground, Never leave the windfoil (assembled with the board) standing up or upside down. It can easily fall on its side and get damaged.
-
Page 7: Important Note
Stalling the foil can unsettle the rider and result in abrupt falls. IMPORTANT NOTE Our WH-flight ALU 85 hydrofoil is composed of Aluminium parts (Mast, Fuselage, Plate) and Hybrid Carbon parts (Front and Rear Wings) assembled together by stainless steel screws. The mast is assembled to the board using a dedicated plate with Tuttlebox inserts. - Page 8 WINDFOIL SCREW SET PROVIDED...
- Page 10 HYDROFOIL ASSEMBLING INSTRUCTIONS In order to assemble your new WH-Flight Hydrofoil correctly please follow this instructions: 1) Join the mast to the plate. Then tighten the 3 X 60mm screws to secure the TuttleBox head to the plate and make sure that the screws are tightened properly.
- Page 11 Hydrofoil head into the finbox slot. Make sure the finbox is clean from sand or any other debris that might cause friction in inserting the mast head inside the box. Please use extra care when inserting or removing the mast from the foilboard. This is the moment when you can really damage your board.
- Page 12 RRD Windfoil boards program RRD firmly believe in the development of foilwindsurfing at all levels. We have developed a specific program to allow everyone to have access to foilwindsurfing without having to necessarily buy a dedicated board. You can finally go in the water with 7/8 knots and make the most of all light wind days in locations with marginal conditions.
- Page 13 The H-fire 91 is our first dedicated windsurf foil board in collection. The board is 236 x 91 cms of width, with a very wide tail and the deck shape for an easy and comfortable ride while in the air or in the water. Once the board is up and going it is so simple to go fast and keep the whole system in control.
- Page 15 TUTTLE HEAD BASE PLATE MAST REAR WING FUSELAGE FRONT WING...
- Page 16 DISTRIBUTED BY: Ricci International S.r.l. Via Rubino, 15/19 58100 Grosseto · Italy Ph. +39. 0564.452304 / 455786 Fax +39.0564.452691 FOLLOW US ON: • facebook.com/RRDinternational • vimeo.com/robertoriccidesigns • issuu.com/robertoriccidesigns • @rrd_international #robertoriccidesigns #rrd #rrdwindsurf www.robertoriccidesigns.com info@robertoriccidesigns.com...
