GENERAL SAFETY INFORMATION

To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts,
   
cuts/abrasions, and other hazards read all warnings and instructions included with and on the fixture box and
all fixture labels.
Before installing, servicing, or performing routine maintenance upon this equipment, follow these general
   
precautions.
Commercial installation, service and maintenance of luminaires should be performed by a qualified licensed
   
electrician.
To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
   
Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.
   
DO NOT INSTALL DAMAGED PRODUCT!
   
This fixture is intended to be connected to a properly installed and grounded UL listed junction box.
   
Suitable for Dry or Damp locations
   
WARNING: RISK OF ELECTRICAL SHOCK
Turn off electrical power at fuse or circuit breaker box before wiring fixture to the power supply.
   
Turn off the power when you perform any maintenance.
   
Verify that supply voltage is correct by comparing it with the luminaire label information.
   
Make all electrical and grounded connections in accordance with the National Electrical Code and any
   
applicable local code requirements.
All wiring connections should be capped with UL approved wire connectors.
   
CAUTION: RISK OF INJURY
Wear gloves and safety glasses at all times when removing luminaire from carton, installing, servicing or
   
performing maintenance.
Avoid direct eye exposure to the light source while it is on.
   
Account for small parts and destroy packing material, as these may be hazardous to children.
   
CAUTION: RISK OF FIRE
Keep combustible and other materials that can burn away from luminaire and lamp/lens.
   
MIN 90°C SUPPLY CONDUCTORS.
   
SAVE THESE INSTRUCTIONS
Use only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer. Each luminaire
is to be used with inside driver kit. Wiring to be performed by qualified electrician only.
U.L. Lighting Fixtures Corp.
Specifications and data subject to change without notice. Consult factory when critical.
Consult factory for additional configurations and options not listed or shown.
LA618 SUSPENDED
INSTALLATION INSTRUCTIONS
APPLIES TO MODELS:
LA618-2, LA618-4, LA618-5
www.ullighting.net | 718.726.7500
Visit our website for the most current data
Rev. 05/2017
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LA618 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for UL LA618 Series

  • Page 1 Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.     DO NOT INSTALL DAMAGED PRODUCT!     This fixture is intended to be connected to a properly installed and grounded UL listed junction box.     Suitable for Dry or Damp locations    ...
  • Page 2 LA618 SUSPENDED INSTALLATION INSTRUCTIONS APPLIES TO MODELS SUSPENDED INSTALLATION LA618-2, LA618-4, LA618-5 Step 1: Accessories Step 2: Drill hole in the ceiling, push the rubber plug into the ceiling, fix the fixing head 2 in the ceiling with 4X30PA screw. Step 3: A.
  • Page 3 LA618 CEILING SURFACE MONT INSTALLATION INSTRUCTIONS APPLIES TO MODELS CEILING SURFACE MOUNT INSTALLATION LA618-2, LA618-4, LA618-5 Step 1: Accessories Step 2: Plan hole distance, and drill 4 holes of 3.0mm φ and 1 hole of 10.0mm φ. Step 3: Fasten clip and elevated parts of clip with screws. Step 4: Fasten assembled clip kits in plastic rubber of ceiling with screws.
  • Page 4 LA618 CONTINUOUS RUN INSTALLATION INSTRUCTIONS APPLIES TO MODELS CONTINUOUS RUN INSTALLATION LA618-2, LA618-4, LA618-5 Step 1: Accessories Step 2: Snap AC input wire of lamp into U-Shape notch of connected section, then align fixing hole of connected section to fixing hole on lamp, finally fasten connected section and lamp with screws. Step 3: Align fixing hole of other side to fixing hole of lamp tail, then fasten connection section and lamp.
