FIM-7901E Interface Module Guide

Advertisement

Table of Contents
loading

Related Manuals for Fortinet FIM-7901E

Summary of Contents for Fortinet FIM-7901E

  • Page 1 7000 FIM-7901E Interface Module Guide...
  • Page 2 FORTINET DOCUMENT LIBRARY http://docs.fortinet.com FORTINET VIDEO GUIDE http://video.fortinet.com FORTINET BLOG https://blog.fortinet.com CUSTOMER SERVICE & SUPPORT https://support.fortinet.com  http://cookbook.fortinet.com/how-to-work-with-fortinet-support/ FORTIGATE COOKBOOK http://cookbook.fortinet.com FORTINET TRAINING SERVICES http://www.fortinet.com/training FORTIGUARD CENTER http://www.fortiguard.com FORTICAST http://forticast.fortinet.com END USER LICENSE AGREEMENT http://www.fortinet.com/doc/legal/EULA.pdf FEEDBACK Email: techdocs@fortinet.com Friday, June 23, 2017 FIM-7901E Interface Module Guide 01-540-374567-20170623...

  • Page 3: Table Of Contents

    Installing SFP+ and SFP transceivers To install transceivers FIM-7901E mounting components Inserting a FIM-7901E module into a chassis Shutting down and removing a FIM-7901E board from a chassis Troubleshooting FIM-7901E does not startup FIM-7901E status LED is flashing during system operation...

  • Page 4: Fim-7901E Interface Module

    FPM processor modules. The FIM-7901E can be installed in any FortiGate-7000 series chassis. Normally you would install two FIM-7901E modules in chassis hub/switch slots 1 and 2. Two FIM-7901Es provide a total of 32 10GigE small form-factor pluggable plus (SPF+) interfaces for a FortiGate-7000 chassis.

  • Page 5: Physical Description

    -31 to 158°F (-35 to 70°C) Relative Humidity 10% to 90% (Non-condensing) Front panel LEDs From the FIM-7901E font panel you can view the status of the module LEDs to verify that the module is functioning normally. State Description The FIM-7901E is powered off.

  • Page 6: Front Panel Connectors

    Connection at 10Mbps. Front panel connectors You connect the FIM-7901E to your 100Gbps networks using the C1 to C4 front panel CFP2 interfaces. The front panel also includes M1 and M2 SFP+ interfaces for the base channel, four Ethernet management interfaces (MGMT1 to MGMT4), and a USB port.

  • Page 7: Supported Transceivers

    NMI switch When working with Fortinet Support to troubleshoot problems with the FIM-7901E you can use the front panel non-maskable interrupt (NMI) switch to assist with troubleshooting. Pressing this switch causes the software to dump registers/backtraces to the console. After the data is dumped the board reboots. While the board is rebooting, traffic is temporarily blocked.

  • Page 8: Fim-7901E Hardware Architecture

    FIM-7901E interface module FIM-7901E hardware architecture The FIM-7901E includes an integrated switch fabric (ISF) that connects the front panel interfaces to the DP2 session-aware load balancers and to the chassis backplanes. The ISF also allows the DP2 processors to distribute sessions amoung all NP6 processors on the FPM modules in the same chassis.

  • Page 9: Hardware Installation

    This chapter describes installing a FIM-7901E interface module into a FortiGate-7000 chassis. Installing SFP+ and SFP transceivers You must install SPF+ transceivers into the FIM-7901E front panel A1 to A32 interfaces before connecting them to 10Gbps networks. The FIM-7901E ships with two 10GBASE-SR SFP+ transceivers. See...

  • Page 10: Fim-7901E Mounting Components

    (when open the latch slides up about 2 mm) The FIM-7901E handles align the module in the chassis slot and are used to insert and eject the module from the slot. The latches activate micro switches that turn on or turn off power to the module. When both latches are FIM-7901E Interface Module Guide Fortinet Technologies Inc.

  • Page 11: Inserting A Fim-7901E Module Into A Chassis

    If the module is not receiving power all LEDs remain off. FIM-7901Es are hot swappable. The procedure for inserting a FIM-7901E into a chassis slot is the same whether or not the chassis is powered on.
  • Page 12 In the photograph an example FIM-7901E is being installed into chassis slot 1 of a FortiGate-7040E chassis. 2. Unlock the left and right handles by pushing the handle latches up about 2 mm until the handles pop open.
  • Page 13 Hardware installation Inserting a FIM-7901E module into a chassis 3. Carefully slide the module into the slot until the handles engage with the sides of the chassis slot, partially closing them. Insert the module by applying moderate force to the front faceplate (not the handles) to slide the module into the slot.
  • Page 14 Inserting a FIM-7901E module into a chassis Hardware installation 5. Tighten both retention screws to secure the module in the chassis. You can tighten the retention screws by hand with a Phillips screwdriver. If you use a power screwdriver the tightening torque needs to be adjusted between 3 In-lb to 4 In-lb (0.4 N-m to 0.48 N-m).
  • Page 15 Hardware installation Inserting a FIM-7901E module into a chassis As the latches are locked, power is supplied to the module. If the chassis is powered on during insertion the status LED flashes green as the module starts up. Once the module has started up and is operating correctly, the front panel LEDs are lit for normal operation.

  • Page 16: Shutting Down And Removing A Fim-7901E Board From A Chassis

    Disconnect all cables from the FIM-7901E module, including all network cables and USB cables or keys. FIM-7901Es are hot swappable. The procedure for removing a FIM-7901E from a chassis slot is the same whether or not the chassis is powered on.
  • Page 17 Hardware installation Shutting down and removing a FIM-7901E board from a chassis 1. Fully loosen the retention screws. You must fully loosen the screws or the handles may be damaged when used to eject the board from the chassis slot.
  • Page 18 Shutting down and removing a FIM-7901E board from a chassis Hardware installation 3. Fully open the handles to eject the module from the chassis. You need to open the handles with moderate force to eject the module from the chassis.

  • Page 19: Troubleshooting

    Latches and handles not fully closed If the latches or handles are damaged or positioned incorrectly the FIM-7901E may not start up. Make sure the latches are fully closed and the handles are correctly aligned, fully inserted and locked and the retention screws are tightened.

  • Page 20: Quick Fim-7901E Configuration

    CLI. You can connect to the GUI using HTTP or HTTPS, You can connect to the CLI using SSH or Telent or by a direct console connection to the FIM-7901E Console port. Use a terminal emulator with the following settings to connect to the console port: bits per second: 9600, data bits: 8, parity: none, stop bits: 1, flow control: none.
  • Page 21 Quick FIM-7901E configuration Changing network settings At any time during the configuration process, if you run into problems, you can reset the FIM-7901E to the factory defaults and start over. From the CLI enter execute factoryreset. Connect to the GUI by connecting MGMT1 of the module in slot 1 to your network and browsing to https://192.168.1.99.

  • Page 22: Cautions And Warnings

    Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips). FIM-7901E Interface Module Guide Fortinet Technologies Inc.

  • Page 23: Safety

    Attention: Débranchez les cordons de la source d’alimentation avant tout entretien. Grounding — To prevent damage to your equipment, connections that enter from outside the building should pass through a lightning / surge protector, and be properly grounded. Use an electrostatic discharge workstation FIM-7901E Interface Module Guide Fortinet Technologies Inc.
  • Page 24 Fiber optic transceiver must be rated 3.3V, 22mA max, Laser Class 1, UL certified component. Le transceiver optique doit avoir les valeurs nominales de 3.3 V, maximum 22 mA, Laser Class 1, homologué UL FIM-7901E Interface Module Guide Fortinet Technologies Inc.

  • Page 25: Regulatory Notices

    European Conformity (CE) - EU This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FIM-7901E Interface Module Guide Fortinet Technologies Inc.

  • Page 26: Voluntary Control Council For Interference (Vcci) - Japan

    此 为 A级 产 品 ， 在 生 活 环 境 中 ， 该 产 品 可 能 会 造 成 无 线 电 干 扰 。 这 种 情 况 下 ， 可 能 需 要 用 户 对 其 采 取 切 实 可 行 的 措 施 。 FIM-7901E Interface Module Guide Fortinet Technologies Inc.
  • Page 27 Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests. In no event does Fortinet make any commitment related to future deliverables, features, or development, and circumstances may change such that any forward-looking statements herein are not accurate.
