Atención:
Este purificador puede ser usado por niños a partir de 8 años y personas
capacidades físicas, sensoriales
o mentales reducidas
conocimiento, si se les han dado instrucciones sobre el uso del purificador de manera
segura, entienden los peligros derivados de su uso y están bajo supervisión. Los niños
no deben jugar con el purificador. Los trabajos de limpieza y mantenimiento no deben
ser realizados por niños sin supervisión
Si el cable de alimentación estuviese dañado, deberá ser sustituido por el fabricante o un
servicio técnico autorizado para evitar cualquier peligro / daño.
con
o faltas de experiencia y
Existen funciones opcionales, por favor verifique con el vendedor si su máquina tiene estas funciones.
RUBY PURE 75
Gracias por elegir este producto.
Por favor, lea atentamente el manual de instrucciones
antes de usarlo y consérvelo para futuras consultas.
Advertisement
Table of Contents
Related Manuals for Lineaplus RUBY PURE75
Summary of Contents for Lineaplus RUBY PURE75
- Page 1 RUBY PURE 75 Atención: Gracias por elegir este producto. Por favor, lea atentamente el manual de instrucciones antes de usarlo y consérvelo para futuras consultas. Este purificador puede ser usado por niños a partir de 8 años y personas capacidades físicas, sensoriales o mentales reducidas o faltas de experiencia y conocimiento, si se les han dado instrucciones sobre el uso del purificador de manera...
- Page 2 Purificador de aire ÍNDICE inteligente PRECAUCIONES INSTRUCCIONES DE FUNCIONAMIENTO Encendido ADVERTENCIA Crea un ambiente sano para evitar virus PRECAUCIÓN Bloqueo infantil Selección de velocidades Modo noche RENDIMIENTO Y CARACTERÍSTICAS Temporizador TÉCNICAS Rendimiento Selección de funciones Características técnicas Aviso para cambio de filtro COMPONENTES MANTENIMIENTO Y LIMPIEZA Anti bacterias...
- Page 3 CAUTIONS ATTENTION In order to prevent harm or damage happened to users or others, be sure to comply with the requirement as below: WARNING Please supervise your Do not connect or No disassembly,repair and Do not use the over run socket or Do plug the power into the socket Warning/Attention disconnect the power...
-
Page 4: Product Performance
ATTENTION PRODUCT PERFORMANCE AND TECHNICAL FEATURES Product performance ATTENTION Filtro antimicrobiano: Elimina el moho, alergénos y bacterias. ● Do not use in the room with Do not blow in any combustible Do not use in the watery or high Do not power the unit on when using HEPA: fabricado con una nueva generación de materiales, elimina eficazmente partículas dañinas insecticide in the room lampblack such as kitchen. -
Page 5: Component Introduction
COMPONENT INTRODUCTION COMPONENTES Exterior Operating parts Diagram of operating button ● Trasera Panel de control Entrada de aire 2H 4H 8H Ions Frontal Frontal Frontal Lateral derecho Lateral izquierdo Interior Encendio/apagado Velocidad Temporizador Funciones Antimicrobiano+HEPA Cubierta izquierda Cuerpo Carbón activado+foto catalizador Cubierta derecha Intelligent air purifier User manual... - Page 6 CAUTIONS BEFORE OPERATING CAUTIONS BEFORE OPERATING How to touch the control panel? Installation of the filters Please touch the button with whole finger ● Take off right side cover. ● ,activated carbon+photo catalyst filter,and tear off its PE bag,please install filters sequentially. Take out ●...
-
Page 7: Power Setting
OPERATING INSTRUCTION OPERATING INSTRUCTION Power setting Fan speed setting Pressing SPEED icon to select Low、Med、High speed, The diagram as following: ● Pressing the power icon, the device start to work. ● 2H 4H 8H Ions 2H 4H 8H Ions Children lock setting Sleep mode ●... -
Page 8: Timer Setting
OPERATING INSTRUCTION OPERATING INSTRUCTION Timer setting Filter replacement reminder Pressing TIMER button to select 2H、4H、8H and no timing mode, The diagram as following: ● When speed indictor flashing, it means the filter's life comes to end, please replace new filter. When speed indictor still flashing after a new filter replaced, press time setting button and hold on for 5 seconds, after a sound like "D",speed indictor will stop flashing and the machine start to record the filter using time. - Page 9 MAINTENANCE AND CLEANING INSTRUCTION If the machine can't work properly,please kindly check as below before you send it out for repair. ● Maintenance and cleaning instruction Checking methods Abnormal occurrence Solution Maintenance and cleaning instruction Benzene Acohol ● Please check if the plug is disconnected from the socket. Please remove plug from the socket before Power plug should be plugged properly ●...
-
Page 10: Technical Parameters
TECHNICAL PARAMETERS TECHNICAL PARAMETERS Parameters of the unit Filter parameters Description Model No.: PURE 75 Size Life time 209 x 10 2 x 40 ( mm) Voltage Supply: Antimicrobial+HEPA About 6 months 220V-240V,50Hz Activated carbon 203 x 97 x15 (mm) About 6 months ≥70m Air flow volume(m... - Page 11 Attention: RUBY PURE 75 This appliance can be used by children aged from 8 years and above and persons with reduced Intelligent air purifier physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand Sedative Series ·...
- Page 12 Intelligent air purifier DIRECTORY INDEX Sedative Series · desktop CAUTIONS OPERATING INSTRUCTION 9-12 WARNING Power setting Children lock setting ATTENTION Fan speed setting Sleep mode PRODUCT PERFORMANCE Timer setting AND TECHNICAL FEATURES Product performance Function setting Technical features Filter replacement reminder Environment self cicatrization produces "air vitamin"...
- Page 13 CAUTIONS ATTENTION In order to prevent harm or damage happened to users or others, be sure to comply with the requirement as below: WARNING Please supervise your Do not connect or No disassembly,repair and Do not use the over run socket or Do plug the power into the socket Warning/Attention children and avoid...
- Page 14 ATTENTION PRODUCT PERFORMANCE AND TECHNICAL FEATURES Product performance ATTENTION Antimicrobial Filter: Eliminates mold,allergens and bacterial. ● Do not use in the room with Do not blow in any combustible Do not use in the watery or high Do not power the unit on when using HEPA: Using a new generation of composite materials, can effectively remove of particle.
- Page 15 COMPONENT INTRODUCTION COMPONENT INTRODUCTION Diagram of the outlook Operating parts Diagram of operating button ● Back cover Touch control panel Air in 4H 8H Ions Front cover Front cover Side cover Front view Left view Right view Diagram of unit Speed Power Timer...
- Page 16 CAUTIONS BEFORE OPERATING CAUTIONS BEFORE OPERATING How to touch the control panel? Installation of the filters Please touch the button with whole finger ● Take off right side cover. ● ,activated carbon+photo catalyst filter,and tear off its PE bag,please install filters sequentially. Take out Antimicrobial HEPA...
- Page 17 OPERATING INSTRUCTION OPERATING INSTRUCTION Power setting Fan speed setting Pressing SPEED icon to select Low、Med、High speed, The diagram as following: ● ● Pressing the power icon, the device start to work. 2H 4H Ions 2H 4H Ions Children lock setting Sleep mode pressing power icon and hold on for 5 seconds, after a sound like"D", then enter children lock mode.
- Page 18 OPERATING INSTRUCTION OPERATING INSTRUCTION Filter replacement reminder Timer setting Pressing TIMER button to select 2H、4H、8H and no timing mode, The diagram as following: ● When speed indictor flashing, it means the filter's life comes to end, please replace new filter. When speed indictor still flashing after a new filter replaced, press time setting button and hold on for 5 seconds, after a sound like "D",speed indictor will stop flashing and the machine start to record the filter using time.
- Page 19 MAINTENANCE AND CLEANING INSTRUCTION If the machine can't work properly,please kindly check as below before you send it out for repair. ● Maintenance and cleaning instruction Checking methods Abnormal occurrence Solution Maintenance and cleaning instruction Benzene Acohol ● Please check if the plug is disconnected from the socket. Power plug should be plugged properly Do not work Please remove plug from the socket before...
- Page 20 TECHNICAL PARAMETERS TECHNICAL PARAMETERS Parameters of the unit Filter parameters Description Model No.: PURE 75 Size Life time 209 x 102 x 40(mm) About 6 months Voltage Supply: Antimicrobial+HEPA 220V-240V,50Hz Activated carbon 203 x 97 x15(mm) About 6 months Air flow volume(m /h): ≥70m and photo catalyst...
