HeiTel CamLine Device Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CamLine
(Englisch)
Devic e M anual
Version 2.06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CamLine and is the answer not in the manual?

Questions and answers

Summary of Contents for HeiTel CamLine

  • Page 1 CamLine (Englisch) Devic e M anual Version 2.06...
  • Page 2 CamLine (English) Ha rdwa re Manual Version 2.06...
  • Page 4 HeiTel GmbH CamLine Hardware Manual CamLine...
  • Page 5 Furthermore, HeiTel is not liable for any loss or misuse of information resulting from the use of this manual. In particular, HeiTel is not liable for any damages such as financial losses or delayed or terminated business resulting from the use or misuse of this manual, even if HeiTel or a representative of HeiTel was made aware of the possibility of such damage.

  • Page 6: Table Of Contents

    ............19 Suitable Transmission Networks ..............19 Interface Settings ..................19 Modem Settings ..................19 Modem configuration through CamLine ............ 21 4.2 Configuration of ext. modem/ISDN-TA via Hyperterminal ..21 Example initialisations for modems/TAs ............. 22 Operation with a Dedicated Line ............... 22 Technical Data ................
  • Page 7 CamLine...

  • Page 8: Introduction

    HeiTel's years of experience as a pioneer in the field of digital video has en- abled the development of a carefully designed, reliable product with a high quality to cost ratio for a wide range of applications.
  • Page 9 1 Introduction CamLine...

  • Page 10: Advice On Reading This Manual

    2 Advice on Reading this Manual 2 Advice on Reading this Manual This manual informs you of all CamLine functions and provides all the neces- sary operating instructions. Using the CamLine device while connected direct- ® ly to a PC or laptop with the CamTel Windows Software will allow you to quickly become familiar with the transmission and recording functions.
  • Page 11 2 Advice on Reading this Manual CamLine...

  • Page 12: System Description

    3 System Description The system description provides you with an overview of the CamLine system and the requirements for the correct operation of CamLine. Here you will find information on the operating conditions, safety and security information for operation, a description of the device, its interfaces and equipment connec- tions.

  • Page 13: Hardware Description

    3 System Description 3.2 Hardware Description The CamLine unit is delivered with an interface for connection to external da- ta transmission devices. Front view CamLine Modem RS-232 The pin assignment of the modem communications interface is compatible Interface with the IBM PC standard. It is equipped with all required control lines through a 9 pin SUB-D plug and is reserved for the connection of a modem, ISDN-TA, GSM interface or a TCP/IP Alarm Adapter.
  • Page 14 Auto-baud recognition allows a connection at 115200 Baud, even when CamLine is set to 230400 baud. Ensure the null mode cable is connected to both PC and CamLine before ap- ® plying power to the CamLine or starting the CamTel Windowssoftware.

  • Page 15: Rear View

    Called party not available Rear View Control Interface All control inputs and outputs on the CamLine devices are realised in the form of easily accessible screw/clamp connections. The inputs are decoupled by means of capacitors to protect against faults and are connected to ground (pin 3).
  • Page 16 (the relay breaks in the event of a power failure). Switch on In order to signal that CamLine is currently online, the relay switches on for connection the duration of the connection and switches off at the end of the connection.
  • Page 17 The impedance of the video input is set 75 Ohm (on). Adjusting the video The picture quality should be checked at the receiver. The settings for bright- signal ness and contrast can be adjusted at the receiver for each camera. CamLine...

  • Page 18: Installation And Setup Instructions

    General Safety and Security Instructions Do not subject the device to strong vibrations or shocks. Avoid humid or dusty environments, extreme cold or heat and strong mag- netic fields. CamLine can be operated between 0°C and 55°C ambient temperature. Ensure adequate ventilation.
  • Page 19 3 System Description CamLine...

  • Page 20: Connection Of External Devices And Components

    Local Baud Rates The local baud rate refers to the interface speeds of the serial interface be- tween the modem/TA and CamLine (not to the transmission rate on the trans- mission medium). In most cases, e.g. for the transmission over ISDN lines or for null modem con- nections directly to the PC, the setting 115200 baud is correct.
  • Page 21 The ISDN terminal adapter must be set to the X.75 protocol. Echo must be off (ATEO). Using an MSN If your CamLine transmitter shares an ISDN line together with other data transmission equipment, a separate calling number (multiple subscriber num- ber) must be obtained and entered for each device.

  • Page 22: Modem Configuration Through Camline

    If the modem cannot be pre-configured on a PC, the initialisation can also be entered in the transmitter settings of CamLine. CamLine sends this string to the modem every time the unit is switched on and every time the transmitter settings are changed.

  • Page 23: Example Initialisations For Modems/Tas

    ISDN. ISDN dedicated lines are available in various configura- tions, with or without D channel (data control channel) and with one or two B channels (data bearer channels). The terminal adapter ELSA Microlink TL pro can be adapted to any of these dedicated lines. CamLine...

  • Page 24: Technical Data

    9 pin SUB-D plug with RS-232 interface, pin assignment as for IBM PC Housing Dimensions: 116 x 30 x 180 (W x H x D in mm) Operating Tempera- +0°C...+55°C ture: Weight: aprrox. 0.32 kg CamLine ® Configuration: with CamTel Windows Software included ® Operation:...
  • Page 25 5 Technical Data CamLine...

  • Page 26: Troubleshooting

    The individual sections are organised systematically according to various top- ics. Text passages should only be skipped based on references to additional information. 6.1 Null Modem Connection Not Possible ........26 6.2 Remote Transmission Not Possible...........26 6.3 Image Display Errors..............27 Please consult the section concerning the appropriate topic. CamLine...

  • Page 27: Null Modem Connection Not Possible

    6.1 Null Modem Connection Not Possible A null modem connection between the transmitter and receiver systems is only possible with the original HeiTel null modem cable (indicated by orange- red sticker on cable). Standard commercial null modem cables cannot be used.

  • Page 28: Image Display Errors

    3. Check the settings of the transmitting device, the transmitting device particularly with regard to the video inputs, are too strong or too ensure correct 75 Ohm. weak. 3. The brightness and con- trast settings in the Cam- Line transmitting device are incorrect. CamLine...
  • Page 29 6 Troubleshooting CamLine...

  • Page 30: Supplement

    7 Supplement 7 Supplement Supplements to this manual which could not be included at the time of print- ing can be found on the following pages. CamLine...
  • Page 31 7 Supplement CamLine...
