SILLIA 60P Series Installation Notes

For solar panels with the solrif frame

Hide thumbs

French manufacturer of solar panels

March

Installation note for solar panels with the Solrif frame

1. Introduction

2. Safety

3. Installation and electrical connection

4. Maintenance and servicing

5. Electrical characteristics

Document subject to technical changes. The latest version can be downloaded from our website:

www.sillia.com. These instructions deal only with the installation of photovoltaic modules. To install

Solrif framed modules with the SILLIA Confort integration structure please revert to the specific

installation note also available from our website: www.sillia.com.

Page 1 sur 8

Document NI0003_V04 : Installation note for solar panels with the Solrif frame

SILLIA Energie – 4 Avenue Pierre Marzin 22303 LANNION Cedex – France

Tel : +33 (0)2 96 05 80 50

Table of Contents

Need help?

Do you have a question about the 60P Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SILLIA 60P Series

Page 1 Document subject to technical changes. The latest version can be downloaded from our website: www.sillia.com. These instructions deal only with the installation of photovoltaic modules. To install Solrif framed modules with the SILLIA Confort integration structure please revert to the specific installation note also available from our website: www.sillia.com.
Page 2 48MXXX, 60QcellsXXX and 50QcellsXXX. 1.2 Service manual : This manual describes the mounting and electrical connection of SILLIA Energie’s modules in a photovoltaic field. Any installation must follow the rules described in this document. Those instructions are intended for fitters, developers and people designated by the developer. All the staff performing the installation of the photovoltaic modules must have the qualifications required for solar panels roof installation.
Page 3 Solrif frame of the SILLIA Energie modules.  Use an installation solution which allows the passage of air in sufficient quantity (SILLIA Energie recommends an air gap of 20 mm underneath the modules with SOLRIF frame). 3.2 Fixation of the SILLIA Energie modules ...
Page 4 3.2.1 Installation of SILLIA Energie modules : The SILLIA Energie photovoltaic modules fitted with a Solrif frame can be installed only in a landscape mode. Solar panels can be installed according to the sequences of installation presented below, it is a guarantee of safety, practicability and quality.
Page 5 SILLIA Energie recommends a minimal number of hooks to be installed, depending on the size of the solar panel : 60 cells 50 cells 48 cells (1705 x 1023) (1682 x 864) (1377 x 1023) "Side” hooks "Glass” hooks Total fixing points /panel...
Page 6 Electrical connections must not be located on the flow of the water  SILLIA Energie recommends avoiding that the parts assuring the pressure on the cables of the junction box may be facing upward in the direction of the water flow.
Page 7 During module serial connection, make sure that the polarity of the connection is correct. Exemple : 3.2.4 Earthing The SILLIA Energie solar panels with a Solrif frame must be connected to the earth according to the prescriptions and current standards. To ensure that the grounding connections are properly made, proceed as follows : -to fix the cable on the upper frame holes, use self-tapping stainless steel screws with a 4.2 diameter...
Page 8 Wipe the module surface with water and a soft and appropriate cloth. 5 Electrical Characteristics The technical characteristics of the modules are available on our website: www.sillia.com. The maximal number of modules (60PXXXX / 60MXXX / 60QcellsXXX) that could be installed in series is 22.
