- Page 1 Mifare reader M1000 Art. No: 480060 (black), 480061 (white) User manual M1000_usermanual_ENGfeb19...
- Page 2 Table of Contents Introduction page 3 Installation page 3 Programming users page 4 3.1 Mastertransponder page 4 3.2 Programming user tags page 4 3.3 Deleting user tags page 4 Configuration page 5 4.1 Programming mode page 5 4.2 Backup/cloning page 5 4.3 Settings page 5 4.3.1 OC Split...
- Page 3 1. Introduction M1000 is a flexible Mifare reader for many applications. The reader has 3 LED’s (yel- low, green and red) for indication of approved/rejected tag and for navigation when configurating the readers settings. 80 users (possible in 2 blocks for individual out- put). In standby the yellow LED is lit (● ○ ○) By approved tag or card the yellow and green LED are lit (● ● ○) By rejected tag or card the red LED is lit (○ ○ ●) 2. Installation Mount the reader on a even surface. Connect the wires to power supply, locking device, assembly box etc. Note: Right after the voltage is applied lights all 3 LED’s and the buzzer sounds. Right after the yellow LED flashes and the buzzer is silent.
- Page 4 Show a Mifare tag 2 times etc. ● ● ○ ● ● → ● ● ○ ● ● → ● ● ○ The M1000 can also delete all users at once, delete a lost user and delete the master transponder. Use the enclosed configuration scheme as a guide.
- Page 5 4. Configuration 4.1 Programming mode To configure the M1000, the reader must be disconnected and reconnected (for about 2 seconds). Now the Master transponder can configure the M1000’s settings. Please see the configuration schema // markings. Remember to show the Master Transponder within 10 seconds to allow you to change the M1000’s configurations (timeout). The following configurations only work after power on / off as described. 4.2 Backup/cloning The M1000’s information can be stored and loaded with a Backup card (Art. No. 480080). Please see the enclosed configuration scheme for further information. 4.3 Settings These settings can split the outputs, invert the outputs, and set the timeout. Use the enclosed configuration scheme. 4.3.1 OC Split (1 flash on the yellow LED) From the factory, the loaded tags enable both outputs (user space 1 to 80). This set- ting divides the user locations. User 1 to 40 activates output 2 (yellow wire) and user space 41 to 80 activates output 1 (white wire).
- Page 6 4.3.3 Timeout (4 flashes on the yellow LED) This function sets the M1000’s timeout time. Show the master transponder to start, the buzzer gives a beep for every second, show the master transponder again to end the count. 4.3.4 Free locker (5 flashes on the yellow LED) The Free locker function can be used for access control, especially where the user often switches. Show the reader a card or tag, and if the cabinet is free, it will lock and can only be unlocked with the same card or tag. Free locker timeout Count for hours, so if you want it to be set to 4 hours, wait for 4 seconds. Save 0 for the reader not to open after x hours, but only when the card/tag is showed to the reader again. Default is set to 10 hours. User position 1 resets free locker.
- Page 8 Thank you for choosing Conlan’s products. For further assistance, please contact Our support service.
