Summary of Contents for Domino GAS HOME
- Page 1 GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 GAS HOME INSTALLATION AND OPERATING MANUAL Domino consulting sagl info@dominoconsulting.ch Via Bosia 13 · Paradiso CH 6902 Technology division www.dominoconsulting.ch CHE 240 435888...
-
Page 2: General Introduction
Harmful gas detector + Carbon Monoxide CIVIL AUTOMATION GENERAL INTRODUCTION The GAS HOME board is the most advanced gas detector currently on the market. It is able to detect: Butane, Propane, Methane and Carbon Monoxide. Alarm: visual, acoustic, radio transmission. - Page 3 GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 The sophisticated system detects the presence of explosive gases in the environment, considerably before the threshold of L.I.E., that is, before the quantity of dispersed gas can be dangerous or harmful.
- Page 4 GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 INDEX Introduction and Application Pag. 1 Index Pag. 4 Technical Data Pag. 5 Legal connection and Test function Pag. 6 Active Safety, Installation, Maintenance and Cleaning Pag. 7 Limitation and Warranty Pag.
- Page 5 GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 TECHNICAL DATA GAS HOME TYPE DESCRIPTION Supply Till 220V 50Hz MAX Consumption 200 mA Sound Power 80 Db a 1m 1 green led for the normal functioning 1 yellow led for active preheating or anomaly...
-
Page 6: Data Sheet
GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 DATA SHEET ELECTRICAL CONNECTION Insert the appropriate plug into a 220V socket. Take care to ensure that the sensor has legibly oriented lettering. This favors a correct aeration of the sensor, since the passage of air takes place naturally, from the bottom to the top. -
Page 7: Sleep Mode
GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 FUNCTIONALITY OF ONBOARD BUTTON The button on the device is used to perform a function test of the outputs and to switch the device on or off. Pressing the button for about 1 second, upon release, a LED and buzzer test will be performed. -
Page 8: Sensor Calibration
GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 SENSOR CALIBRATION The sensor is calibrated at the factory and self-regulates according to the environmental measurements. Important: It is possible to carry out a calibration operation by closing the appropriate jumper on the printed circuit board and keeping the button pressed for 10 seconds. The red LED lights up, which indicates the procedure in progress. - Page 9 GAS HOME INSTALLATION AND OPERATION MANUAL Rel.0 Nov. 2018 The device is covered by a 1-year legal guarantee. The warranty is void if there are any signs of damage, tampering or use that does not comply with the specifications on the device.
