Jung eNet FM HS 1 T Operating Instructions Manual

eNet
Remote control, 1-channel Toggle
Remote control, 1-channel Toggle
Art. No. : FM HS 1 T
Operating instructions

1 Safety instructions

Keep button cells out of reach of children! If button cells are swallowed, get medical help
immediately.
Risk of explosion! Do not throw batteries into fire.
Risk of explosion! Do not recharge batteries.
The radio communication takes place via a non-exclusively available transmission path,
and is therefore not suitable for safety-related applications, such as emergency stop and
emergency call.
These instructions are an integral part of the product, and must remain with the end
customer.

2 Device components

(1) Status LED
(2) Button

3 Function

System information
This device is a part of the eNet system.
High transmission reliability at a radio frequency of 868 MHz is achieved by the transmission
behaviour and bidirectional data transfer.
The range of a radio system depends on various external circumstances. The range can be
optimised by the choice of installation location.
This device complies with the requirements of the R&TTE Directive 1999/5/EC. Declaration of
Conformity and further information on the eNet system can be found on our website.
The device may be operated in all EU and EFTA countries.
82582503
J:0082582503
Figure 1: Radio hand transmitter 1-gang
1/6 13.03.2014
