Center CenterStore Solar Series Servicing Installation And Servicing Instructions

UNVENTED MAINS PRESSURE SOLAR WATER HEATERS
190, 210, 250 and 300 LITRE CAPACITY INDIRECT MODELS
The CENTERSTORE Solar unvented solar cylinder water heater incorporating immersion heater(s) and thermal
controls Factory fi tted temperature/pressure relief valve l Cold water combination valve assembly l Expansion
vessel and mounting bracket l Tundish l Motorised valve l Compression nuts and olives l Immersion heater spanner
IMPORTANT: PLEASE READ AND UNDERSTAND ALL THESE INSTRUCTIONS
BEFORE COMMENCING INSTALLATION. PLEASE LEAVE THIS MANUAL WITH
Benchmark places responsibilities on both manufacturers and installers. The purpose is to ensure that customers
are provided with the correct equipment for their needs, that it is installed, commissioned and serviced in
accordance with the manufacturer's instructions by competent persons and that it meets the requirements of
the appropriate Building Regulations. The Benchmark Checklist can be used to demonstrate compliance with
Building Regulations and should be provided to the customer for future reference.
Installers are required to carry out installation, commissioning and servicing work in accordance with the Benchmark
Code of Practice which is available from the Heating and Hotwater Industry Council who manage and promote
the Scheme. Visit www.centralheating.co.uk for more information.
IMPORTANT NOTE TO USER: PLEASE REFER TO THE USER INSTRUCTIONS SECTION ON PAGES 14 AND 15 FOR
IMPORTANT INFORMATION WITH RESPECT TO THE BENCHMARK SCHEME

INTRODUCTION

The CENTERSTORE Solar cylinder is a purpose de-
signed unvented solar water heater. The unit has a
stainless steel inner vessel, which ensures an excellent
standard of corrosion resistance. The outer casing is a
combination of resilient thermoplastic mouldings and
corrosion proofed steel sheet. All products are insulat-
ed with CFC/HCFC free polyurethane foam to meet the
latest European heat loss requirements (see Table 6).
The unit is supplied complete with all the necessary
safety and control devices needed to allow connection
to the cold water mains. All these components are
preset and not adjustable.
For latest prices and delivery to your door visit MyTub Ltd - www.mytub.co.uk - info@mytub.co.uk 0844 556 1818
INSTALLATION AND SERVICING INSTRUCTIONS
PACK CONTENTS
l Installation instructions
THE CUSTOMER FOR FUTURE REFERENCE.
THE BENCHMARK SCHEME
Solar
This appliance complies with the requirements of the
CE marking directive and is Kiwa approved to show
compliance with Building Regulations (Section G3).
The following instructions are offered as a guide to
installation which must be carried out by a competent
plumbing and electrical installer in accordance with
Building Regulation G3, The Building Standards
(Scotland) Regulations 1990, or The Building Regula-
tions (Northern Ireland).
NOTE: Prior to installation the unit should be stored in
an upright position in an area free from excessive damp
or humidity.
