Summary of Contents for HFT PurgEye 200 IP65
- Page 1 PurgEye 200 IP65 ® WELD PURGE MONITOR ® with PurgeNet™ USER INSTRUCTIONS PurgEye a ‘Family’ Series of Weld Purge Monitors ® ®...
- Page 2 Copyright © HFT . All rights reserved. ® This publication may not be reproduced by any means without the written permission of Huntingdon Fusion Techniques HFT ®. All logos, names, trademarks are the property and ownership of HFT ® E&OE...
-
Page 3: Table Of Contents
INDEX PAGE 3 Index ..............Getting started ............ 4 - 5 Connections ............Controls .............. 7 - 8 Status icons ............PurgeNet™ interface ..........Care and maintenance ......... Warning .............. Other languages ..........Customer support and worldwide care ....Warranty ............. Address and contact details ........ -
Page 4: Getting Started
gETTINg STarTED PAGE 4 Your PurgEye 200 IP65 Weld Purge Monitor is a hand held ® ® IP65 rated instrument to read from 0.1% (1000 ppm) down to 0.0001% (1 ppm) oxygen. Your PurgEye 200 IP65 Weld Purge Monitor delivery and ®... - Page 5 Exhaust filter Display Status icons Function button PPM / % STANDBY + 10 - 10 Display button © HFT ® Adjust + Adjust - button button The monitor will display dashes until it picks up a reading of 1000 ppm.
-
Page 6: Connections
coNNEcTIoNS PAGE 6 PurgeNet™ The PurgEye 200 IP65 Weld Purge Monitor is fitted with a 3-pin ® ® PurgNet™ connector on the top right of this hand held model. This connector is used to connect smart accessories, is also used for powering and/or charging your PurgEye 200 IP65 and connecting ®... -
Page 7: Controls
coNTrolS PAGE 7 Function The function button is used to operate the sample pump and activate the mute and power on/off functions. Holding the function button for more than 1 second will turn your PurgEye 200 IP65 on or off. ®... -
Page 8: Controls
coNTrolS continued... PAGE 8 Data logging NoTE: Is deactivated from new. Data logging NoTE: Automatic mode records data when the pump is running. (Our recommendation is to keep it in automatic mode when the pump is running) Data logging NoTE: Manual mode allows data logging from third party accessory. -
Page 9: Status Icons
STaTUS IcoNS PAGE 9 When necessary, the following four status icons will be displayed on the right hand side of the display. Display units This will be either ‘PPM’ or ‘%’ for oxygen concentration values. Press and hold ‘display’ button to change the display units. Battery status When the PurgEye 200 IP65 is running on batteries a filled... -
Page 10: Purgenet™ Interface
PUrgENET™ INTErfacE PAGE 10 Smart accessories: When supported, PurgeNet™ accessories are connected to the PurgeNet™ interface connection, they will be automatically detected by your PurgEye 200 IP65 and extra menu options may appear, ® as required. Language Support current support: The PurgEye 200 IP65 product range currently ®... -
Page 11: Care And Maintenance
carE and MaINTENaNcE PAGE 11 Zirconium Oxide Sensor Care As a general guideline, the gases to be measured should be free from dust, organic vapours, condensation and products capable of condensing. Such components can block the gas conduits in the sensor and cause permanent damage. -
Page 12: Warning
MUST ALWAYS be used, or your PurgEye may read incorrectly ® and/ or be permanently damaged. Spare filters available from your HFT Distributor. ® Internal Pump The internal pump should not be force fed with any pressure as it may be damaged. -
Page 13: Other Languages
Other laNgUagES in ProgrESS PAGE 13 Les autres langues sont actuellement dans le progrès. Pour le moment, s’il vous plaît contacter votre Distributeur local. Andere Sprachen sind momentan im Gange. Kontaktieren Sie vorläufig, bitte Ihren örtlichen Verteiler. Otros idiomas son actualmente en progreso. Para ahora, contacta por favor su Distribuidor local. -
Page 14: Customer Support And Worldwide Care
+49 (0) 2423 954 051 Veuillez contacter notre partenaire en France et en Afrique France Inertage ® Email: clemenceretel@huntingdonfusion.com Tel: +33 6 52 84 28 39 HFT France ® Para la información adicional en Español, contacta por favor Internet: www.codesol.com Email: codesol@codesol.com... -
Page 15: Warranty
Should you encounter a problem with your product, please notify us immediately upon receipt. Huntingdon Fusion Techniques HFT warrants this product to be ® free of defects in workmanship and material, with exceptions stated below. - Page 16 Tel +44 (0) 1554 836 836 Fax +44 (0) 1554 836 837 www.huntingdonfusion.com Email hft@huntingdonfusion.com E&OE Copyright © HFT . All rights reserved. ® This publication may not be reproduced by any means without the written permission of Huntingdon Fusion Techniques HFT ®...
