Summary of Contents for DTS INSIGHT MegaNETIMPRESS
- Page 1 Startup Manual DTS INSIGHT CORPORATION...
- Page 2 (2) The contents of this manual are subject to change without prior notice due to improvement of the functionality. (3) If any question about the contents of this manual arises, contact DTS INSIGHT CORPORATION. (4) DTS INSIGHT CORPORATION shall not be held responsible for direct or indirect adverse effects resulting from operation of this system irrespective of the above item (3).
-
Page 3: Table Of Contents
Contents Overview & Features ..................1 Notes & Points ....................2 Checking Hardware and Software (Standard Package) ......3 Hardware ........................3 Software ........................4 Installing the Software .................. 5 Setting up IP Address to Programmer Main Unit ........6 Connecting with a PC (AZ490 Setting Remote Controller) ...... -
Page 4: Overview & Features
Overview & Features The MegaNETIMPRESS/C”arNETIMPRESS/NETIMPRESS next (hereafter called as “NETIMPRESS”) is the in-circuit programmer that can perform high-speed on-board programming of an microcomputer with built-in flash ROM or flash ROM connected to external bus of a microcomputer. AAA.YLC: License for Device A BBB.YLC: License for Device B... -
Page 5: Notes & Points
Notes & Points The Control Module is specifically designed and built for the NETIMPRESS programmer and cannot be used for any other purposes. (A CF card commercially available cannot be used as the Control Module.) About this manual This Startup Manual describes only the initial setup procedures required to perform programming. -
Page 6: Checking Hardware And Software (Standard Package)
Checking Hardware and Software (Standard Package) This chapter explains the standard package of hardware and software that will be provided for the NETIMPRESS programmer. (The hardware and software to be provided may differ depending on your environments.) Hardware The following items are included in the hardware package of the NETIMPRESS. NETIMPRESS main unit (AF320/AF420/AF520/AF620/AF430) AC adapter specially built for the NETIMPRESS... -
Page 7: Software
Software The following items are included in the software package of the NETIMPRESS. AZ490 (Remote Controller to download the various files, execute the device functions and set up various parameters) AZ482 (F/DF Sheet Generator to create a file to set up an IP address to the programmer main unit and download the files) AZ481 (Key File Generator to create an ID code Key to communicate with a PC, and a... -
Page 8: Installing The Software
Since they are the self-expanding files, decompress them on a PC and install them. Note: When you complete installing them and if you choose the default setting, they will be registered in [DTS INSIGHT Tools], which you can open by selecting [Start] → [Program]. -
Page 9: Setting Up Ip Address To Programmer Main Unit
Setting up IP Address to Programmer Main Unit To set up an IP address to the programmer main unit so as to control it via Ethernet from a PC, follow the below steps. * As a stand-alone, you can set IP address by using FUNC E2 to E4. For how to operate NETIMPRESS as a stand-alone, refer to a chapter “Setting Ethernet”... - Page 10 (3) Enter IP address, port information, etc. to set up in the programmer main unit, and select [File] → [Save As] and enter a file name with extension “.ycm” to save. (This file name can be changed.) Note: [Default Gateway] does not have to be set up in most cases, just enter “0.0.0.0”. When using the NETIMPRESS via a router, enter an address of the router.
- Page 11 The IP address information is set up in the NETIMPRESS and displayed on the LCD. Then, the NETIMPRESS main unit is started.
-
Page 12: Connecting With A Pc (Az490 Setting Remote Controller)
Connecting with a PC (AZ490 Setting Remote Controller) To set up environments to control the NETIMPRESS from the Remote Controller AZ490, follow the steps below. (1) Start the AZ490. (2) Enter IP address and port number of the NETIMPRESS main unit and press Communication Check . -
Page 14: Adding A License To The Control Module
Adding a Licence to the Control Module To add a licence to the Control Module, follow the steps below. (1) Click … button in the Add Licence field located in the center of the CF Card Information tab. (2) File selection window is shown. Select the licence file (xxx.YLC) that is provided in the form of CD-ROM, and then click OK button. -
Page 15: Creating Impress Module Folder (Yim)
Creating Impress Module Folder (YIM) With the Control Module, you can save and maintain a programming object and programming environments data in a folder called Impress Module folder (YIM). When you finish adding a license, create the YIM folder and set up programming environments. How to create YIM folder (1) Click Create YIM folder in the IMPRESS Folder... - Page 16 (2) The name of YIM folder you have created is displayed in the Folder/File List window. Then, right-click on the YIM folder you have created and select [Select] → [OK]. * You can select the folder by double-clicking the folder on the tree view of Folder/File List window, or clicking Select YIM Folder...
-
Page 17: Downloading Files And Setting Programming Environments
Downloading Files and Setting Programming Environments This chapter explains the steps to download the various files to set up programming environments to the current YIM folder. It also explains how to download the definition program (extension: CM), parameter (extension: PRM), and bundle files. (1) Downloading the Definition Program Click the Load Definition Program... - Page 18 (3) Downloading the bundle files Download the bundle files that are required for programming by pressing Copy File(Load) in the Bundle File field. The KEY file, BTP file and AMK file are the major bundle files. * Since the bundle files to be provided differ depending on each device, check with the manual of the Control Module you use.
- Page 19 (4) Setting up parameters The parameters you have downloaded in Step 2 are the default values and you need to modify them according to your environments. Open the Parameter Table 1 tab and make the settings. For details, see the Manuals for Control Module and Micom-Pack.
- Page 20 (5) Downloading a programming object As you finish Step 1 to Step 4, most of programming environments are now set up. Then, the next step is to download a programming object by clicking Load Object Data on the Object Data field.
-
Page 21: Using The Remote Controller Az490
Using the Remote Controller AZ490 By using the Remote Controller AZ490, you can download the various files, set up programming environments and execute the device functions. The screen of the AZ490 consists of the following six tabs. Host Interface Configuration tab to connect with the programmer ... -
Page 22: Basic Operation Tab
10.1 Basic Operation tab The Basic Operation tab is mainly used to execute the device functions. (1) Current IMPRESS Module The name of YIM folder currently selected is displayed. (“SH7058RED.YIM” is displayed in the above example.) Device Function With this Device Function field, you can execute the various device functions. Current File File name loaded by clicking Load Object Data... -
Page 23: Parameter Table 1 Tab
10.2 Parameter Table 1 tab The Parameter Table 1 tab is used to make the programming settings according to your environments. (5) MCU Type The default device name is displayed, which can be changed. The name set up here will be displayed in the LCD of the NETIMPRESS main unit. (“FH809” is displayed in the above example.) (6) TVcc Threshold This is used to check whether the power of a target is turned on when the device functions... -
Page 24: File Transfer Tab
10.3 File Transfer tab The File Transfer tab is used to add a license, transfer a file required to set up programming and a programming object, and work with a YIM folder (create/select/copy/delete). (10) (11) (9) Folder/File List Window This field is used to display YIM folder and other files to create, select, copy or delete them. YIM folders you have created are listed. -
Page 25: Impress Module Folder (Yim)
Impress Module Folder (YIM) 11.1 Folder Management With the Control Module, you can save and maintain a programming object and programming environments data in a folder called Impress Module folder (YIM). The YIM folder created in the Control Module can be saved in a PC using the card reader, for example. -
Page 26: Folder Configuration
11.2 Folder Configuration (1) You can create more than one YIM folder in the compact flash and switch them with the function key. For details, see Chapter 8 “Creating Impress Module Folder (YIM)”, Step (2). (2) BTP(* .BTP) file and a user OJB such as .KEY, .YSM, etc. are saved in the DOS area. (3) The buffer file (BUF.SYS) and the definition file (CM.SYS) of each one type are saved for YIM folder you have created. -
Page 27: Key File
Key File The security function is built in the firmware of a flash microcomputer to prevent a third person from reading and writing ROM illegally. As the mechanism of the security function, a specific area of flash memory is set as an area to store an ID code, and whenever access is tried from a serial programmer, the same data with ID data written to the microcomputer is sent to the microcomputer as an ID code, and if they are found not matching, the access is not allowed. - Page 28 (2) Enter address where ID is stored, ID size and ID data value. In the above example, 0000608B is entered as security address, 8byte as ID size and IEC213971A15B443 as data value respectively. (3) Save KEY file Select [File] → [File Save].
-
Page 29: Sum Check Function Of Ysm File
SUM Check Function of YSM file This function is used to check a SUM value of data whenever executing the device functions so as to prevent programming illegal object data. This function is very useful in case data of an object to program is garbled all of a sudden. By saving a SUM value of an object in YSM file, data is automatically checked by the NETIMPRESS. - Page 30 No.2: flag (Fixed) Address = 00000000 (Fixed) Size = 1 Enter Data = “ 01 “ or “ 00 ” (Check SUM = 01, Do not check SUM=00) NO.1 NO.2 * For SUM check of YSM file, there is also a function to check the data in the certain area of buffer memory.
-
Page 31: Csb File
CSB File A CSB file is used to execute command sequence. Execution sequence of a CSB file is assigned to the two EXE keys on the upper part of the NETIMPRESS main unit. Set up a command with CSB file. LK1,01,DF;EPR EXE1 (Pressing EXE1 executes ERP.) - Page 32 About CSB file (1) Sample 1 (the standard sample: Test.csb) The standard CSB file named “Test.csb” is provided, which contains the following. Sequence to be executed: EXE1= Execute ERP EXE2= Execute PR * To execute the above command sequence, a YIM folder has to be selected in advance. LK1,01,DF;EPR LK2,01,DD;Program (2) Sample 2...
- Page 33 When “EXE1“ is pressed: SH7750R01.YIM (the first half external flash memory) is loaded as the current IMPRESS Module. EPR is executed on contents of SH7750R01.YIM to a target. SH7750R02.YIM (the second half external flash memory) is loaded as the current IMPRESSS Module.
