Tyco Electronics 00007-1856 Manual

7.2V R/C
7.2V R/C
CONTENTS

Vehicle

Transmitter

7.2V Battery Pack

7.2V Charger

9V Battery

q
VEHICLE OPERATION
FORWARD

CHASSIS

Refer to label on transmitter and vehicle
for frequency. Do not race vehicles with
the same frequency.
e
w
REVERSE
CAUTION-ELECTRIC TOY:
8 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS,PRECAUTIONS SHOULD BE
OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK.
INPUT: 120VAC, 60Hz, 12VA. OUTPUT: 8.5VDC, 420mA, 3.6W.
Keep these instructions for future reference: they contain important information.
IMPORTANT: Please read all "Consumer Information" (last page) before operating your vehicle.
CAUTION:
Surfaces may become hot and cause burns if
electronics get wet. Do not operate vehicle through water or snow.
q Steering Adjuster
w Battery Door
e Battery Latch
r ON/OFF/SOUND Switch
*
Switch Positions:
= OFF
= ON (no engine sounds)
= ON (engine sounds)
r
LEFT
00007-1856
NOT RECOMMENDED
FOR CHILDREN UNDER
RIGHT
