Related Manuals for Waterflow NZ Naturalflow Series
Summary of Contents for Waterflow NZ Naturalflow Series
- Page 1 NaturalFlow Series NF1500 Treatment System System Specifications & Installation Instructions...
- Page 2 The Wormorator® and associated dose tank has a 2000ltr reserve capacity where pump loading is necessary to allow for 24 hrs emergency storage should a pump fail. The operating capacity of the NaturalFlow Series NF1500 Treatment System is 800ltrs per day of combined Black and Grey water.
- Page 3 NATURALFLOW SERIES NF1500 System Specification & Installation Instructions New Zealand’s Leaders in Eco-Sustainable, Odourless Wastewater and Sewage Systems Wormorator® & Dose Chamber Specifications Tanks are made of Cotene 9050 which is a linear medium density polyethylene, designed specifically for rotational molding of large tanks and products that require a high level of rigidity. It contains a fully formulated long term UV stabilization package (with a minimum UV8 rating) and is suitable material for wastewater treatment containment meeting all the requirements of Section 4.3.3 of AS/NZS 1547:2012 which cross...
- Page 4 2. Filter media 15yrs 3. Dosing float/and or pumps 2yrs 4. WATERFLOW NZ LTD will at its discretion replace or repair such components that prove to be faulty with the same or equivalent part at no charge. 5. Warranty of operation covers the performance of the NaturalFlow systems as connected to the effluent inflow for which they are designed, and also installed to the criteria as set out in the relative installation instructions and procedures.
- Page 5 NATURALFLOW SERIES NF1500 System Specification & Installation Instructions NaturalFlow Series NF1500 Dose Installation Instructions The NaturalFlow system is to be installed or signed off by a registered Drain layer to the design specified by Waterflow NZ Ltd. The following installation instructions and procedures followed correctly will ensure System performance is not compromised in any way.
- Page 6 NATURALFLOW SERIES NF1500 System Specification & Installation Instructions NaturalFlow Series NF1500 Pump Installation Instructions The NaturalFlow system is to be installed or signed off by a registered Drain layer to the design specified by Waterflow NZ Ltd. The following installation instructions and procedures followed correctly will ensure System performance is not compromised in any way.
- Page 7 NATURALFLOW SERIES NF1500 System Specification & Installation Instructions Appendix A and B Appendix A High Water Table: For installation in high water table areas, make sure you have a pump to pump away ground water whilst installing. Excavate a pump cavity to one side of the platform and pump ground water away during entire installation process .Half fill dose tank with water, this will flow back into Wormorator as well and will...
- Page 8 NATURALFLOW SERIES NF1500 System Specification & Installation Instructions NaturalFlow Series NF1500 Flow Charts NaturalFlow Series NF1500 Treatment System Dose 750mm Dia Lid Grey Black Water Water from from House House Matrix Filter Advanced Primary 1260 To Disposal Field as per...
- Page 9 Call us today to discuss your needs 0800 628 356 Or for more information www.naturalflow.co.nz Head Office South Island Office Waterflow NZ Ltd NaturalFlow South Ltd, PO Box 24, 1160 State Highway 12, 82 Johns Road, Maungaturoto 0547, New Zealand Belfast, Christchurch 8051 P.
- Page 10 Waterflow NZ Ltd “We do it simpler” Home Owner Care Guide...
-
Page 11: Table Of Contents
HOME OWNERS MANAGEMENT PLAN HOME OWNERS CARE GUIDE • Contents …3 To The Home Owner …4 Waterflow NZ Ltd Warranty …5 Caring For Your Wastewater And Sewage System …8 In A ‘Nutshell’… …9 Household Cleaning Chemicals …10 Cleaning Substitutes …11... -
Page 12: To The Home Owner
HOME OWNERS MANAGEMENT PLAN HOME OWNERS CARE GUIDE • To The Home Owner Thank you for choosing a NaturalFlow System to treat and care for your on-site sewage and wastewater. NaturalFlow is a truly natural living system that uses well-established, sustainable processes to treat both solid and liquid waste. -
Page 13: Waterflow Nz Ltd Warranty
• Waterflow NZ Ltd Warranty WATERFLOW NZ LTD warrants that the NaturalFlow System will be free from defects in material and workmanship for the following periods of time from the date of installation as set out in the following conditions: 1. -
Page 14: Caring For Your Wastewater And
1. Industry recommendation is to have a maintenance contract in place at all times 2. Visual check of treatment system 3. Visual check of land application system 4. Notify Waterflow NZ of any issues Inspection Checklist: When checking the system operation, take particular note of;... - Page 15 HOME OWNERS MANAGEMENT PLAN HOME OWNERS CARE GUIDE • Caring For Your Wastewater And Sewage System Components of Your Complete Wastewater Septic System A typical wastewater septic system has two main components: a Wastewater and Sewage Treatment System and a Land Application System (or disposal field) The NaturalFlow System treats and reduces the solid content of the wastewater by up to 95%.
- Page 16 HOME OWNERS MANAGEMENT PLAN HOME OWNERS CARE GUIDE • Caring For Your Wastewater And Sewage System Washing machines By selecting the proper load size, you’ll reduce wastewater. Washing small loads of laundry on the large-load cycle wastes precious water and energy. If you can’t select load size, run only full loads of laundry.
-
Page 17: In A 'Nutshell
• Discard any drugs down the sink or toilet • Empty rubbish bags into Wormorator • Alter or add any part of your system without Waterflow NZ LTD’s approval 0800 628 356 www.naturalflow.co.nz 0800 628 356 www.naturalflow.co.nz... -
Page 18: Household Cleaning Chemicals
HOME OWNERS MANAGEMENT PLAN HOME OWNERS CARE GUIDE • Household Cleaning Chemicals Effects on Wastewater and Disposal System Receiving Environments Use of many cleaning chemicals in facilities served by on-site disposal systems, can result in high concentrations of the constituents in those cleaning agents being discharged into the receiving soils. -
Page 19: Cleaning Substitutes
HOME OWNERS MANAGEMENT PLAN HOME OWNERS CARE GUIDE • Cleaning Substitutes Substitutes For Household Cleaning Chemicals (Ref TP58) Use of the following readily biodegradable substitutes for common potentially harmful household cleaning chemicals will reduce the stress on any wastewater system, significantly enhance the performance of the whole system and increase the life of the land application system, while reducing the potential effects of the receiving soils. -
Page 20: Water Tolerant Plants Suitable For On-Site Wastewater Disposal Systems
HOME OWNERS MANAGEMENT PLAN HOME OWNERS CARE GUIDE • Water Tolerant Plants Suitable For On-Site Wastewater Disposal Systems Plantings that will soon have your field looking magnificent! Below are the most common of native and other plant species that are tolerant or fond of moist conditions, such as those associated with wastewater disposal fields. - Page 21 Waterflow NZ Ltd “We do it simpler” Call us today to discuss your needs 0800 628 356 Or for more information www.naturalflow.co.nz Head Office South Island Office Waterflow NZ Ltd NaturalFlow South Ltd, PO Box 24, 1160 State Highway 12,...
