- Page 1 Slimdrive GB Installation instructions SL NT SL NT-FR...
-
Page 2: Table Of Contents
Slimdrive SL NT/SL NT-FR Table of contents Symbols and illustrations ............................3 Product liability ................................3 Safety ...................................4 Intended use........................................4 Safety instructions ......................................4 Safety conscious working ....................................5 Inspection of the installed system ................................5 Environmentally conscious working .................................5 Overview..................................6 Diagrams ..........................................6 Tool ............................................6 Torques ..........................................6... -
Page 3: Symbols And Illustrations
Slimdrive SL NT/SL NT-FR Symbols and illustrations Symbols and illustrations Warnings In these instructions, warnings are used to warn against material damage and injuries. Always read and observe these warnings. Observe all the measures that are marked with the warning symbol and warning word. -
Page 4: Safety
à in entrances and interior areas of pedestrian traffic, in commercial plants and public areas The Slimdrive SL NT and the Slimdrive SL NT-FR must not be used as fire or smoke control door drives. The Slimdrive SL NT-FR is approved for use in emergency exits. -
Page 5: Safety Conscious Working
Slimdrive SL NT/SL NT-FR Safety 3.3 Safety conscious working à Secure workplace against unauthorised entry. à Watch pivoting range of long parts. à Never carry out work with a high safety risk (e.g. installing the drive, cover or door leaf) while alone. -
Page 6: Overview
Pin punch 4 mm Side-cutting pliers Crimping pliers for cables Wire stripper Multimeter Display programme switch DCU1 (mat. no. 103940)/Service terminal ST220/GEZEconnects Key-operated switch (only for Slimdrive SL NT-FR) (mat. no. 074437) 4.3 Torques see module bearer drawing and drive drawing... -
Page 7: Pre-Installation
Slimdrive SL NT/SL NT-FR Pre-installation Pre-installation The most up-to-date diagram is applicable for performing the pre-installation work. All components must be identified and installed in accordance with the drive diagram. 5. 1 Cutting the running rail and cover to size Cut the running rail and cover to the required length. -
Page 8: Fitting The Left-Hand Module Bearer
Pre-installation Slimdrive SL NT/SL NT-FR 5.4 Fitting the left-hand module bearer Fit the left-hand module bearer in compliance with the drawing. 5.5 Connecting the alarm contact to the locking device (optional) Only screw the red locking pin (1) in again after the cover has been placed on. Remove screws M2.3 x 10 on the feedback switch (4) of the locking mechanism. -
Page 9: Fitting The Right-Hand Module Bearer
Slimdrive SL NT/SL NT-FR Pre-installation Fit the three-core transformer cable (4) to terminal (5) of the transformer. 5.7 Fitting the right-hand module bearer Fit the right-hand module bearer as shown in the drawing. 5.8 Connecting the cable to the right-hand module bearer Slimdrive SL NT Slimdrive SL NT-FR SlimdriveXSLXNT Lay rotary transducer cable (1) and motor connection cable (2) to the control unit. -
Page 10: Pre-Positioning The Pre-Mounted Module Bearer, Left And Right
Apply the stickers, see the drive drawing: à Information plate (enter the date of manufacture, supplement digits of Classes 5 and 7) à TÜV sticker à Ü symbol (for Slimdrive SL NT-FR) 5. 1 0 Pre-mounting the roller carriage on the door leaf ForX1-leafXsystems Slide the clamping plate (1) into the connect- ing profile. - Page 11 Slimdrive SL NT/SL NT-FR Pre-installation Mount the short driver (6) to the clamping plate (1) using 2 screws. ForX2-leafXsystems Slide the roller carriage (2, 4) into the connecting profile (3). Secure the roller carriage (towards the secondary closing edge) using setscrews (5).
-
Page 12: Installation
Installation Slimdrive SL NT/SL NT-FR Installation Secure workplace against unauthorised entry. Always perform work with a second technician. Use a stepladder or stepstool. Keep inside area of running rail clean. 6. 1 Preparations on site Check the on-site preparations to ensure proper installation: à... - Page 13 Slimdrive SL NT/SL NT-FR Installation MountingXaXrunningXrail Protect the running surface from damage. Prepare cable routing in accordance with local conditions. Mount the running rail (2) on the base construction. Install light barrier profiles/draught sealing profiles according to local conditions (see installation diagram).
- Page 14 Installation Slimdrive SL NT/SL NT-FR FittingXtheXrollerXcarriageXintoXtheXrunningXrail Insert roller carriage (2) into the running rail (1) as shown below. Insert the mounting aid (3) as shown below to secure the roller carriage in the running rail.
- Page 15 Slimdrive SL NT/SL NT-FR Installation Push the track-supporting rollers (4) upwards and tighten using screws (5). 6.2.3 Suspending the door leaf and screwing it in place. Move the roller carriage (1) into the door opening (4). Suspend the door leaf (3) on the height adjustment screws (6). Screw the door leaf in place using screws (7).
- Page 16 Installation Slimdrive SL NT/SL NT-FR 6.2.4 Adjusting door leaves Observe the applicable standards and guidelines on crushing, shearing and drawing-in spots. AdjustXtheXparallelXpositionXandXheightXofXtheXdoorXleaves Place wedge under the door leaf. Use the hanger bolts (3) to align the door leaf flush. Ensure the same height and parallel closing edges when doing so.
- Page 17 Slimdrive SL NT/SL NT-FR Installation 6.2.5 Fitting the pre-assembled module bearer on the left and right WARNING! Unsecured components may fall when under load. When mounting the module bearer, make sure that its entire length is suspended in the running rail (2). Position the right module bearer (3) in such a way that it does not collide with the motor.
- Page 18 Installation Slimdrive SL NT/SL NT-FR 6.2.7 Tensioning the toothed belt The toothed belt must be pre-tensioned with 300 N ±35 N (see drive drawing). Loosen 2 screws (2). Push the motor (3) to the right by hand. Loosen the screw (1) and move the sliding...
- Page 19 Slimdrive SL NT/SL NT-FR Installation Fix the cable holder (2) to the running rail. Fix the cable holder (3) to the control unit. Route the transformer cable (1) through the cable holder to the control unit. 6.2. 1 0 Connecting the toothed belt locking (optional) and control unit When fitting the cover (3) make sure that no cables become jammed.
- Page 20 Installation Slimdrive SL NT/SL NT-FR 6.2. 1 4 Mounting the earthing Screw the earthing (1) onto the running rail. Depending on the drive position, attach 1 or 2 of the following earthing points: à next to the module bearer on the left (see figure) à...
-
Page 21: Commissioning
Slimdrive SL NT/SL NT-FR Installation 6.3 Commissioning 6.3. 1 Connecting the drive WARNING! Danger of fatal injury due to electric shock! The electrical system (230 V) may only be connected and disconnected by a professional electrician. Perform the power connection and equipment earth conductor test in accordance with VDE 0100 Part 610. - Page 22 Installation Slimdrive SL NT/SL NT-FR 6.3.2 Mounting the cover MountingXtheXcoverXsuspensionXpieceXinXtheXcover Slide 1 cover suspension piece (1) each into the upper and lower screw duct of the cover (2). Use 2 screws to secure the cover suspension piece (1) in the end section of the cover.
- Page 23 Slimdrive SL NT/SL NT-FR Installation MountingXtheXcoverXsecuringXdevice CAUTION! Danger of injury! Persons can be injured when the cover is pivoted. Always make sure two persons handle the cover. CAUTION! Danger of injury from falling cover! Make sure that the cover has latched in securely at the side elements.
-
Page 24: Dismantling
Installation Slimdrive SL NT/SL NT-FR 6.3.3 Commissioning the door system Information on the connection and parameter assignment of the safety sensors as well as the inputs and outputs and on commissioning can be found in the wiring diagram. 6.3.4 Creating test log Perform safety analysis. -
Page 25: Service And Maintenance
See chapter 6.2.5. 7.2 Maintenance check The mandatory maintenance work on the Slimdrive SL NT and Slimdrive SL NT-FR is to be carried out by properly trained personnel: à at least once a year à when the service indicator on the programme switch lights up (see wiring diagram) Provide test documents and keep them up-to-date. -
Page 26: Troubleshooting
Troubleshooting Slimdrive SL NT/SL NT-FR Troubleshooting 8. 1 Mechanical faults Cause Remedy Running rail deformed Replace the running rail Check the installation surface Door leaf does not move smoothly Check the door leaf (see below) Roller carriage jammed or defective, high wear at the... -
Page 27: Replacing Fuse In Transformer
Slimdrive SL NT/SL NT-FR Troubleshooting 8.5 Replacing fuse in transformer ATTENTION! Danger of fatal injury due to electric shock! Disconnect the system from the 230 V mains network on site before removing the PCB cover. - Page 28 Germany BalticXStates Hungary ScandinaviaX–XFinland GEZE Hungary Kft. GEZE Sonderkonstruktionen GmbH GEZE GmbH Baltic States office Branch office of GEZE Scandinavia AB Bartók Béla út 105-113. Planken 1 Dzelzavas iela 120 S Herralantie 824 Budapest 97944 Boxberg-Schweigern 1021 Riga Postbox 20 H-1115 Tel.
