Summary of Contents for Sun Kingdom LS-1A
- Page 1 Handheld Slit Lamp Microscope Handheld slit lamp LS-1 Operation Instruction Manual...
-
Page 2: Table Of Contents
Chongqing Sunkingdom Medical Instrument Co., Ltd. Content Preface............................1 1 Summary............................ 2 1.1Machinery description.....................2 1.2Product features.......................2 1.3Product structure......................3 1.4Models difference......................4 1.5Produc label ........................4 2 Technical parameter.......................5 2.1Basic parameter....................... 5 3 Installation and debugging....................6 3.1Un-packing checking.......................6 3.2Installation..........................6 3.3Debugging......................... 7 3.4 Installation Instruction of the Battery...............9 3.5 The charging indicator..................11 4 Usage and requirements................ -
Page 3: Preface
Preface Dear User： Thank you very much for choosing LS-1A/LS-1B hand-held slit lamp Microscope manufactured by Chongqing Sunkingdom Medical Instruments Co.(hereinafter called Sunkingdom). For your security and benefit, please read the operation instruction as well as the datum of the instruments carefully before using it. -
Page 4: Summary
Chongqing Sunkingdom Medical Instrument Co., Ltd. 1.Summary 1.1 Summary This instruction apply to ：LS-1A\LA-1B Contraindication：No Products structure and components：The optical body, movement mechanism, illumination system, hand-held handle, power supply. Products application：Anterior segment and internal eye lesion examination. 1.2Product features 1.High brightness white LED cold-light lamp,maximum brightness not lower than 50,000lux，work life can be 50,000 hours。... -
Page 5: Product Structure
Chongqing Sunkingdom Medical Instrument Co., Ltd. 1.3Product structure The hardware structure diagram 1、Eyepiece 2、Diopter adjustment：Adjust the diopter to get the clear image. 3、Adjust the pupil distance 4、Objective magnification changer ：10×,16×（For LS-1B only） 5、Brightness adjusting knob：From left to right, the brightness brighten up. 6、Handle 7、Charging power supply socket... -
Page 6: Models Difference
14、Filters adjusting knob 15、Slit angle adjusting track 1.4 Models difference Visual field Model Hardware structures magnification diameter Optical body, movement mechanism, LS-1A illumination system, hand-held handle, power supply. 10X：11 mm optical body, movement mechanism 16X：7 mm LS-1B ,illumination system, hand-held handle, 10X、16X power supply. -
Page 7: Technical Parameter
Chongqing Sunkingdom Medical Instrument Co., Ltd. 2.Technical parameter 2.1Basic parameter model LS-1A LS-1B item Slit type Rotating slit wheel selection slit lamp type Binocular hand held Biomicroscope slit lamp eyepiece Converging binocular at 13° Magnification 10 X、16X lever change Work distance... -
Page 8: Installation And Debugging
Chongqing Sunkingdom Medical Instrument Co., Ltd. 3.Installation and debugging 3.1 Un-packing checking Open the package , take the slit lamp and other accessories out . Figure1 Accessories list ：figure 1， （16X objective for LS-1B only） 1.Portable slit lamp 2.Chargeable power adapter 3.Power line 4.Forehead-rest bracket ：... -
Page 9: Debugging
Chongqing Sunkingdom Medical Instrument Co., Ltd. Figure 2 When the indicator on power adapter become to green , indicating charge complete, the portable slit lamp can use alone. 3.2.2 Forehead-rest bracket . Take out the forehead-rest bracket ，align the mounting hole on the optical body, and tighten the fixed screw. - Page 10 Chongqing Sunkingdom Medical Instrument Co., Ltd. Aperture slit Adjust PD width adjusting knob Filters adjusting knob Adjust diopter Slit angle adjusting Figure 4 Figure 5 track 3.3.2 Adjusting aperture , slit width , filter Adjusting aperture and slit width knob to get the largest spot .Adjust the filter to the white position.（figure 5）...
-
Page 11: Installation Instruction Of The Battery
Chongqing Sunkingdom Medical Instrument Co., Ltd. 3.4 Installation Instruction of the Battery 1.Put the handle slit lamp flat on a table(Fig. 1), and prepare a phillips screwdriver. 2. Remove the screw in picture 2(Fig. 2), then take the lid off( Fig. 3) . - Page 12 Chongqing Sunkingdom Medical Instrument Co., Ltd. 3.Prepare the battery and plug into the power outlet on the equipment with force after aiming the plug at the outlet, and be careful the direction of the plug. (Fig.4, 5, 6) 4.Put the power lines and battery into the slit lamp and insert the lid back, do not get the lid stuck.(Fig.7, 8)
-
Page 13: The Charging Indicator
Chongqing Sunkingdom Medical Instrument Co., Ltd. 5.Close the lid and reinstall the set screw.(Fig.9, 10) 3.5 The charging indicator When the slit lamp is charging,the indicator lamp on AC adapter is red ,once it finished indicator lamp will become green. -
Page 14: Usage And Requirements
Chongqing Sunkingdom Medical Instrument Co., Ltd. 4.Usage and requirements 4.1 Requirements 1）Use in darkroom. 2）Working environment conditions ： Temperature： 5℃～40℃； Relative humidity ： ≤80%； Atmosphere pressure： 760hPa～1060hPa。 3）Running mode： intermittent service. 4）This instrument is internal power unit ,B-type application part. 4.2 Usage 1）Rotating the slit width adjusting knob and filter adjusting knob to right place , and rotate the illumination arm to right place. -
Page 15: Maintenance And Preventive Inspection
Chongqing Sunkingdom Medical Instrument Co., Ltd. 5.Maintenance and preventive inspection 5.1 Maintenance 1 Conduct a full charge process for the portable slit lamp battery at least once a month. 2 Disinfect the whole instruments with 75% alcohol wipes at least once a month. 5.2 Preserve 1 After finishing the examination , please put the portable slit lamp in where is flat and not easy to reach.（avoid drop and break.）. -
Page 16: Transportation And Storage
Chongqing Sunkingdom Medical Instrument Co., Ltd. 6.Transportation and storage The instrument which was prepackaged can transport by usual vehicle. Please avoid heavy load , shaking, free from exposure to the sun and rain. The well-packaged portable slit lamp should be stored in dry, well-ventilated ,no corrosive gas indoor where environment temperature at -5℃～55℃, relative humidity lower than 80% , and the atmosphere pressure between 500 hPa～1060 hPa . -
Page 17: Graphic Symbol Interpretation
Chongqing Sunkingdom Medical Instrument Co., Ltd. 7.Graphic symbol interpretation 7.1 Graphic symbol on instrument interpretation B Type application part Caution！Consult accompanying documents Direct current Fuse protector Brightness adjusting Change magnification Size of light spot 1.6 0.8 0.5 0.15 □ Filter O B.F N.D R.F Manufacturer Date of Manufacture... -
Page 18: Common Faults
Chongqing Sunkingdom Medical Instrument Co., Ltd. 8.Common faults Solutions Fault Phenomenon Check whether the power switch on(By press the button) Check whether the slit width adjust to largest . No light Check whether the filter is on right position. Check the chargeable battery Adjust the diopter ring to compensate the diopter Unsharp images Enhanced brightness... -
Page 19: Precautions
Chongqing Sunkingdom Medical Instrument Co., Ltd. 9.Precautions 1、 Disinfect the forehead rest bracket which directly contact with patient with 75% alcohol wipes after and before every examination to avoid cross infection. 2、the instrument can be used by hand held and put it on the flat as well . 3、the instrument is precise instrument , please handle gently. - Page 20 Chongqing Sunkingdom Medical Instrument Co., Ltd. 17. Waterproof grade IPX0.Durable life of 6 years. 18. Without the permission of us or our authorized distributor, do not open the box of the instrument or we will not take the consequences. 19. Do not touch the surface of lens with hand or hard objects. 20.
-
Page 21: Warranty Statement
Chongqing Sunkingdom Medical Instrument Co., Ltd. 10.Warranty Statement The factory can provide the material of repairable parts 1.Sunkingdom will provide lifelong maintenance and free consultation. 2..Since the date of purchase, Sunkingdom provide free warranty for one year on the condition one follow the instructions. 3.The followings are not listed in the free warranty：...
